Living Spaces DE-GCL-FUO-4824XL User manual

Rectangle Fire Table
ltem# 282562 FIRE OR EXPLOSION HAZARD
If you smell gas:
·Shut off gas to the appliance.
·Extinguish any open flame.
·If odor continues, leave the area immediately.
·After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance. An LP-cylinder not connected for
use shall not be stored in the vicinity of this or any
other appliance.
:
Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
MOD CONCRETE FIREPIT
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

If the information in this manual is not followed exactly, a fire or explosion may result causing property
damage, personal injury, or loss of life.
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

B
2boxes1pc 1pc 1pc
ABDE
A
D
C
1pc
E
C
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

Check that the control knob for the gas
OFF
Open the door panel.
.Place propane gas tank (not included) into the
tank seat. Make sure the gas tank sits on the tank
seat completely. Turn the preassembled wing
screw on the outer part of tank seat clockwise to
secure the propane gas tank tightly.
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

Close the door panel.
5. Turn the cylinder valve on the tank clockwise to
close the propane tank. Attach the preassembled
regulator from the table top to the cylinder valve by
turning the regulator coupling nut clockwise. Make
sure it is fastened securely and tighten connections
by hand only.
R
B
OFF
6. Remove the rubber cap on the electronic igniter
(R) by unscrewing and slide battery (B) into the battery
slot. Make sure the positive side of the battery faces
outwards. Screw the electronic igniter cap over the
battery tightly.
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

7. Pour the boxes of lava rocks into the firebowl, then
pave the lava rocks.
To ensure proper function, the guard on this burner
should be free of lava rocks at all times.
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

To Light
1. Make sure the control knob is in the "off" position.
2. Remove door and slowly open the valve on the propane gas tank by turning the knob
counterclockwise.
3. Replace the door on the body.
4. Push and hold in the electronic igniter to create sparks within the electrode, continue to
hold.
5. Push in the control knob and turn to the "low" position. Keep holding down the control knob
to allow gas to flow for 45 seconds.
6. If ignition doesn't occur within a few seconds release the control knob and rotate to the
"OFF" position. Wait for 5 minutes for gas to clear and then repeat the above lighting
instructions.
7. Once the fire product is lit, the flame intensity may be controlled by turning the control knob
between the "low" and "high" positions.
To Extinguish
1. Turn control knob clockwise to the "low" position; let the knob pop up and continue turning
the control knob to the "off" position.
2. Close the cylinder valve on the propane gas tank if you don't intend to use it for a long time.
Page 9
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

Page 10
MOD CONCRETE FIREPIT
LS SKU# 282562
MODEL # DE-GCL-FUO-4824XL

Grand Classic Limited
Contact Grand Classic Limited for
Page 11
