Living Spaces Mateo 7030-01100 User manual

Mateo Collection: Twin/Twin Bunk Bed
PARTS LIST
BOX 1: 4241 Mateo Twin/Twin Bunk Ends
Part # Description Quantity
S0072END
MateoTwin Bottom Bunk End
2
S0073END
Mateo Twin Top Bunk End
2
BOX 2: 4240 Mateo Twin/Twin Bunk Frame
Part # Description Quantity
S1001SRL 5/4 x 6 x 75 Mattress Rail 2
S1010SRL 5/4 x 4 x 75 Mattress Rail 2
541750001 5/4 x 4 x 75 Guard Rail 4
149383/40 Twin Individual Slat
6
5040-43183 7MM x 100MM Decorative Lag Bolt 32
5040-35410 #6 x 1 1/4 Phil Flat Slat Scew 20
ALNWR 4MM Allen Wrench 1
PWRDD 4MM Power Drill Driver 1
FLDWL 3" Fluted Dowel 4
COMPLETED ASSEMBLY
7030-01100 KIT
4240 Frame Rails/4241 Bunk Ends

ASSEMBLY INSTRUCTIONS
S0072END
S0073END
S1010SRL
S1001SRL
541750001
5040-43183
FLDWL

00500
SAFETY WARNING
Our Bunk Beds have been tested by an Independent Laboratory and are certified to be in compliance with:
ASTM F-1427, “Standard Consumer Safety Specification for Bunk Beds” and U.S. Government
specifications 16 Code of Federal Regulations, parts 1213 and 1513.
SAFETY WARNINGS
1. Follow the information on the warnings attached to the upper bunk end structure and on the carton. Do
not remove this label.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood
of entrapment or falls.
3. Top surface of mattress must be at least five inches (127mm) below the upper edge of top guard rails.
4. Do not allow children less than six years of age to use the upper bunk.
5. Periodically, check and ensure that the guardrail, ladder and other components are in their proper
position, free from damage and that all connectors are tight.
6. Do not allow horseplay on or under the bed and prohibit jumping on the bed and ladder.
7. Prohibit more than one person on upper bunk.
8. Always use the ladder or bed end for entering and leaving the upper bunk.
9. Do not use substitute parts. Contact Living Spaces for replacement parts.
10. Use of a night-light may provide added safety precautions for a child using the upper bunk.
11. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed should be
placed against the wall to prevent entrapment between the bed and the wall. (This applies only to bunk
beds without two full-length guardrails.)
12. Always use guardrails on both long sides of the upper bunk.
13. The use of water or sleep flotation mattress is expressly prohibited.
14. Keep these instructions for future reference.
STRANGULATION HAZARD
15. Never attach or hang items to any part of the bunk bed that are not designed for use with the bed for
example, but not limited to hooks, belts and jump ropes.
SIZE OF MATTRESS AND FOUNDATION
Your Twin bed is designed to use a mattress 37”-39” in width and 74” - 75” in length.
Your Full bed is designed to use a mattress 52”- 54” in width and 74” - 75” in length.
The total thickness of mattress and foundation (slat kit, bunk board, etc.) combined must not exceed 10”.
Note: There must be at least 5” from mattress sleeping surface to top edge of guardrail.
REPLACEMENT PARTS
Replacement parts, including additional guardrails, may be requested from Living Spaces, usually at a cost.

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
Diagram 1 Diagram 2
Scan Code for Instructional video

Summit/Mateo Collection: Ladder
PARTS LIST
BOX 1: 4684 Summit/Mateo Ladder
Part # Description Quantity
S0050FFR Summit/Mateo Ladder Assembly
1
5045-65306 Ladder Hook
2
5040-35408 #8 x 1 1/4" Phil Flat Zinc Screw 8
7030-01205KIT
4684Ladder
(Scan code for
instructional
video)
COMPLETED ASSEMBLY

TOOL REQUIRED:
1. Phillips Head Screwdriver
TOOL RECOMMENDED:
1. Electric drill with phillips bit
ASSEMBLY INSTRUCTIONS:
1) Locate the pre-drilled holes in the back of the ladder.
2) Attach the ladder hooks hook-side-out with 4 screws, 2 on each hook.
3) Determine the best placement for your ladder on the top bunk, being mindful of
your child’s accessibility and safety. For Mateo bunks, the middle guard rail will
need to be used. For Summit bunks, the top guard rail can be used.
4) Secure ladder brackets to the guard rail using the remaining 4 screws, 2 on
each hook, and tighten.
STEP 1
S0050FFR
5045-65306
5040-35408
STEP 2
5040-35408
