Living Spaces SEDONA 4144 User manual

MAS90: 5043-43416
4144 HARDWARE LIST:
QTY: DESCRIPTION:
32 1/4 X 4 HEX LAG BLK
32 3/16 USS FL WASHER BLK
20 6 X 1 1/4 PHIL FLAT PARTICLE BOARD SCREW
41/2 X 3 FLUTED DOWEL
7030-00395 KIT

4144/4145
SEDONA FULL/FULL BUNK BED
w/ 2 DRW UNDERDRESSER 00395
PARTS LIST:
A) 32-4 1/4" Lag Bolts
B) 32-Black Steel Washers
C) 2 -Bottom End Assemblies
D) 2 -Top End Assemblies
E) 4 –5 ¼" x 75" Mattress Rails w/Support Cleats
F) 4 –3 ¼" x 75" Guard Rails
G) 4 -1/2" x 3" Wooden Dowels
H) 6 -3 1/2" x 53 3/4" Mattress Supports
I) 20-1 1/4" Wood Screws
J) 4 - Metal knobs
K) 4 - 1 1/2" Pan head screws
TOOLS REQUIRED:
1) 7/16" Wrench or Socket Wrench
2) Phillips Head Screwdriver
Recommended: Electric driver with 7/16” socket
Make sure you have all parts before beginning assembly. If you need a part, contact Living Spaces.
1) Attach two mattress rails(E) to two bottom end assemblies(C) with 8 lag bolts and 8washers, and tighten.
Be sure that the holes in the legs of the bottom ends are pointed UP for this step!
2) Attach two mattress rails(E) and four guard rails(F) to top end assembly(D) with 24 lag bolts and 24
washers, and tighten. Be sure that the holes in the legs of the top ends are pointed DOWN for this step!
3) Roll out Full Slat Kit on mattress rail cleats, making sure to stretch it from end panel to end panel. Secure
with 4 wood screws at the ends of the two outermost slats. One in each corner of the bed. Center 3
individual Full slats in the 3 gaps built into the Slat kit, and secure with wood screws, one in each end of
the individual slats. Install one Slat Kit in each bed surface, top and bottom.
4) Place four wooden dowels in the four holes at the top of each bottom bed post (leg).
5) Lift the top bunk assembly up onto the bottom bunk assembly, ensuring that all 4dowels are inserted into
the holes in the bottom of the top bed posts (legs)
6) Attach 4 metal knobs to drawer fronts, and slide 2 Drw Underdresser under front mattress rail.
7) Add Mattresses no thicker than 10" and sleep well!
A FOUNDATION IS REQUIRED WITH 3 SLAT CONFIGURATION

00500
SAFETY WARNING
Our Bunk Beds have been tested by an Independent Laboratoryand are certified to be in compliance with: ASTM F-1427,
“Standard Consumer Safety Specification for Bunk Beds” and U.S. Government specifications 16 Code of Federal
Regulations, parts 1213 and 1513.
SAFETY WARNINGS
1. Follow the information on the warnings attached to the upper bunk end structure and on the carton. Do not remove
this label.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood of entrapment or
falls.
3. Surface of mattress must be at least five inches(127mm) below the upper edge of guardrails.
4. Do not allow children less than six years of age to use the upper bunk.
5. Periodically, check and ensure that the guardrail, ladder and other components are in their proper position, free from
damage and that all connectors are tight.
6. Do not allow horseplay on or under the bed and prohibit jumping on the bed.
7. Prohibit more than one person on upper bunk.
8. Always use the ladder or bed end for entering and leaving the upper bunk.
9. Do not use substitute parts. Contact manufacturer or dealer for replacement parts.
10. Use of a night-light may provide added safety precautions for a child using the upper bunk.
11. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed should be placed against
the wall to prevent entrapment between the bed and the wall. (This applies only to bunk beds without two full-length
guardrails.)
12. Always use guardrails on both long sides of the upper bunk.
13. The use of water or sleep flotation mattress is prohibited.
14. Keep these instructions for future reference.
STRANGULATION HAZARD
15. Never attach or hang items to any part of the bunk bed that are not designed for use with the bed for example, but not
limited to hooks, belts and jump ropes.
SIZE OF MATTRESS AND FOUNDATION
Your Twin bed is designed to use a mattress 37 ½”-38 ½” in width and 74” - 75” in length.
Your Full bed is designed to use a mattress 52”- 54” in width and 74” - 75” in length.
The total thickness of mattress and foundation (slat kit, bunk board, etc.) combined must not exceed 10”.
Note: There must be at least 5” from mattress sleeping surface to top edge of guardrail.
REPLACEMENT PARTS
Replacement parts, including additional guardrails, maybe obtained from your Furniture dealer.
A FOUNDATION IS REQUIRED WITH 3 SLAT CONFIGURATION

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
