Living Spaces Sedona 7030-01270 KIT User manual

Sedona Collection: Twin Contempo Bed
PARTS LIST
BOX 1: 4400 Contempo Twin Ends
Part # Description Quantity
S0076END Contempo Twin Headboard
1
BOX 2: 4717 Contempo Twin Frame
Part # Description Quantity
S1001SRL 5/4x6 Mattress Rail 2
149383/40 Twin Individual Slat 3
5040-43181 Hex Lag Bolt/Washer 8
5040-35410 #6 x 1 1/4 Phil Flat Slat Screw 10
7030-01270 KIT
For: 4717 Frame Rails/4400 Bed Ends
S0077END Contempo Full Footboard 1
COMPLETED ASSEMBLY

1) Attach two mattress rails(S1001SRL) to headboard assembly(S0076END) and footboard
assembly(S0077END) with 8 lag bolts and 8 washers(5040-43181), and tighten.
2) Place slat kit (sold separately) and individual slats(140383/40) in accordance with the diagram
on the last page of this instruction sheet. Attach the 5 designated slats to the mattress rail cleats
using the #6x1 ¼” slat screws(5040-35410).
5040-43181
S1001SRL
S0076END
S0077END

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
Diagram 1 Diagram 2
Scan Code for Instructional video

Sedona Collection: Trundle
PARTS LIST
BOX 1: 4466 Sedona Trundle
Part # Description Quantity
4466 Sedona Trundle Assembly
1
5048-00000 Bunkie Mattress 1
5045-65303 Caster Wheel 4
5045-65301 Caster Wheel Insert 4
5043-00205 Sedona Knob 4
5040-35643 1 1/2" Combo Truss Screw 4
7030-01285 KIT
4466 Trundle
COMPLETED ASSEMBLY

TOOLS REQUIRED:
NONE
ASSEMBLY INSTRUCTIONS:
1) Push the 4 caster inserts into the pre-drilled holes on the bottom of the bed. Make sure the inserts sit flush with the holes
and do not protrude. **Do no attempt to complete step 1 with the caster stems attached to the caster inserts**
4466
5045-65301
2) Once all 4 caster inserts are in place, install the caster wheels by pushing the stems of the caster wheels into the inserts
and locking them into place. Assembly is complete once all 4 caster wheels have been installed.
5045-65303
3) Attach the 4 Sedona knobs (5043-00415) to the front of your trundle assembly using the pre-drilled holes and the 1 1/2"
combo truss screws (5040-35643). Refer to the last page of these instructions for assistance.
4) Add bunkie mattress (5048-00000) and push completed trundle bed underneath the bottom bunk for storage, as shown
in completed assembly drawing on the front page of these instructions.

Mateo/Sedona/Summit Collections: Knob and Pull Installation
7030-01195 KIT
1. Locate the box containing your knobs and/or pulls in the bottom drawer of your case
good.
2. Identify which of the screw sizes is correct for your drawers/doors. The screw should
protrude no more than 1/4" when pushed through the pre-drilled holes on your
drawers/doors.
3. Push the screw through the back of the pre-drilled hole on the drawer/door and line it
up with the thread on the back of the knob/pull.
4. Tighten the screw into the back of the knob/pull until the knob/pull is tight against the
front of your drawer/door.
**You can tighten your screws with either a phillips screwrdiver,
a drill with a phillips bit, or your hand**
(Scan code for
instructional
video)
