2028$MAJORCA$POWER$RECLINER$W/$AIR$MASSAGE$$
USER$MANUAL

Components:
•Hand wand –placed in the side pocket (outside LAF arm/RAF arm), controls all motors and functions (reclining,
power headrest, lifting, etc.) via a direct connection with motors. .
•AC wall plug – connects the power transformer to the power outlet.
•DC cord – connects the power transformer to the DC socket (mounted on the rear bottom of LAF arm/RAF arm
stump).
•DC socket – receives power from DC cord then transfer to motors.
•Power Transformer –A box-shaped unit to transfer 110V AC power to 25V DC power to supply for the furniture.
•Junction Box –splitter/extension cord connecting the power transformer to multiple motors/air baddders/heat padding/
hand wand.
•Seat / Headrest Motor –motors mounted on mechanism to drive movement on seat/headrest via hand wand control.
•Air Bladders- mounted inside lower section of back, inflate the air bladders via hand wand control. Turns off
automatically after 30 minutes of use as safety feature.
•Heating pad – mounted inside lower section of back, produces heat via hand wand control. Turns off
automatically after 30 minutes of use as safety feature.

Quick Trouble-Shoot for Motors Malfunctioning:
Below are some possible reasons to cause motors to stop working:
1. Loose connection or wires not securely plugged in.
2. Broken side switch
3. Broken DC socket
4. Broken power transformer (especially when ALL motors stops working on one unit)
5. Power cords damaged
6. Motors failure
NOTE: In some cases a button on the switch might be stuck after being pushed, thus continuously
activating the motor. This can cause overheating or even damages on the power transformer.

Instruction$for$hand$wand$

Air Massage Standard Functions
HEAT
Description
Standard Function
The heat function is activated by pressing the HEAT button.
When active, the heat pad will provide up to 65 ⁰C of heat.
The heat function will be active while the HEAT button is illuminated.
To de -ac ti va te hea t, pres s t he HEAT bu tto n agai n. Th e HEAT b utton will not be
illuminated when the heat function is off.
The heat function has a 30-minute timer. After 30 minutes, the heat pad will turn off
automatically, and the HEAT button will not be illuminated.
Error:
HEAT Button
illuminated but
no
heat is produced.
If the HEAT button is illuminated, but the heat pad is not producing heat, the heat
pad could have become disconnected.
1) Unplug the piece of furniture from the wall outlet
2) Wait at least 30 seconds
3) Lift the back panel to reveal zipper pouch.
4) Unzip pouch to reveal the Junction.
5) Locate the Heat Cord (shown below)
6) Ensure that the heat pad is securely connected.
7) Zip the pouch and reset the back panel.
8) If the heat pad still does not produce heat, please contact your
furniture provide so that they may repair or replace the faulty part.
Heat Cord
Note: Heat will be disabled if any Headrest/Recline/Lumbar button is pressed. This is to ensure safety for
the user and to improve system longevity.
5

HEADREST/
RECLI
NE/
LUM
BAR/
HOM
E
Description
Standard Function
Headrest/Recline/Lumbar are sets of two buttons that control the motion
features of the piece of furniture. Headrest buttons will open and close the
headrest cushion. Recline will open and close the seat back and footrest if
applicable. Lumbar will open and close the lumbar air cushion. All open buttons
are located on the right side of the Hand Control, and all close buttons are located
on the left side of the Hand Control.
Home is a single button that controls the headrest and recline motion features.
Pressing the Home button will cause the headrest and recline cushions to return to
the closed position for as long as the Home button is pressed.
6

Note Using the Lumbar function will stop all other massage features. If the massage
feature is running and either Lumbar button is pressed, the massage will stop.
The Headrest/Recline/Lumbar buttons only allow one operation at a time. This is to
ensure safety for the user and longevity of the system.
If the Hand Control is disconnected from the system and then reconnected, the Hand
Control will take several seconds to connect to the system. The Hand Control will
flash three times to indicate that it has successfully connected.
Error:
Button is pressed but
the system does not
show movement.
If a Headrest/Recline/Lumbar button is pressed and no motion occurs, the Hand
Control could be in the lock out state.
1) Wait for at least 10 seconds and press the button again.
2) If motion does not occur ensure the Hand Control is connected.
3) Unplug the piece of furniture from the wall outlet.
4) Wait at least 30 seconds.
5) Lift the back panel and locate the zipper pouch.
6) Unzip the pouch and locate the Hand Control cord
7) Ensure that there are no frayed, pinched, exposed, or otherwise damaged
wires. Do not connect the Hand Control if the cord is damaged in any way.
8) Ensure that the Hand Control is securely connected to the Junction with
the white connectors (shown below).
9) Zip the pouch and reset the back panel.
Hand Control Connector
Error:
Headrest or Recline
motor does not
function.
If a Headrest or Recline motor does not function, a motor connection could
have become disconnected.
If the Headrest motor does not function:
1) Unplug the piece of furniture from the wall outlet
2) Wait at least 30 seconds
3) Lift the back panel to reveal zipper pouch.
4) Unzip pouch to reveal the Junction.
5) Locate the Headrest motor cord (shown below).
6) Ensure that there are no frayed, exposed, or otherwise damaged wires. Do
not connect the motor if the cord is damaged in any way.
7) Ensure that there is nothing blocking the path of the motor or
connected frame.
8) Zip the pouch and reset the back panel.
9) If the motor still does not function, contact your furniture provider so
they may replace or repair the faulty part.
7

Headrest
Motor Cord
Error:
Headrest or
Recline motor
does not
function.
If the Recline motor does not function:
1) Unplug the piece of furniture from the wall outlet
2) Wait at least 30 seconds
3) Lift the back panel to reveal zipper pouch.
4) Unzip pouch to reveal the Junction.
5) Locate the Headrest motor cord (shown below).
6) Ensure that there are no frayed, exposed, or otherwise damaged wires.
Do not connect the motor if the cord is damaged in any way.
7) Ensure that there is nothing blocking the path of the
motor or connected frame.
8) Zip the pouch and reset the back panel.
9) If the motor still does not function, contact your furniture provider so
they may replace or repair the faulty part.
Recline M
otor Cord
Error:
Lumbar Air
cushion does not
inflate.
If the Lumbar air cushion does not inflate, the air hose may be disconnected,
pinched, or damaged.
1) 1) Unplug the piece of furniture from the wall outlet
2) Wait at least 30 seconds
3) Lift the back panel to reveal zipper pouch.
4) Unzip pouch to reveal the Junction.
5) Locate the air hose connectors (shown below).
6) Ensure that the connector is fully mated.
7) Ensure that the air hoses are not pinched or otherwise blocked.
8) Ensure that the air hoses are not damaged in anyway.
9) Zip the pouch and reset the back panel.
10) If the Lumbar air cushion still does not inflate, control your
furniture provider so they may replace or repair the faulty part.
Air Hose Connector
8

AIR MASSAGE
Description
Standard Function
The Air Massage has two massage modes with four zones. The Air Massage is
started by pressing the AIR button. The AIR Button will be lit red or green when the Air
Massage is active. The AIR button will be lit blue when the Air Massage is not active.
While the Air Massage is active, it can be turned off by pressing the AIR button
until it is lit blue.
The Air Massage mode can be changed by pressing the AIR button. There are two
massage modes: Alternate and Pulse. The Air Massage will always start in the
Alternate mode.
Each massage mode is indicated by the MODE button color. Alternate is Red and
Pulse is Green.
The Air Massage has a built in 30-minute timer. After 30 minutes the Air Massage
will turn off and the AIR button will be lit blue. Pressing a numerical button or the
MODE button will reset the 30-minute timer.
Note
Using the Lumbar function will stop all other massage features. If the massage
feature is running and either Lumbar button is pressed, the massage will stop.
Massage can be re-enabled when Lumbar buttons are not pressed.
Error:
Massage Zones
do not inflate.
If the Massage Zones do not inflate while Air Massage is active, the air hose could
be disconnected, pinched or damaged.
1) 1) Unplug the piece of furniture from the wall outlet
2) Wait at least 30 seconds
3) Lift the back panel to reveal zipper pouch.
4) Unzip pouch to reveal the Junction.
5) Locate the air hose connectors (shown below).
6) Ensure that the connector is fully mated.
7) Ensure that the air hoses are not pinched or otherwise blocked.
8) Ensure that the air hoses are not damaged in anyway.
9) Zip the pouch and reset the back panel.
10) If the Lumbar air cushion still does not inflate, control your
furniture provider so they may replace or repair the faulty part.
9

Air Hose Connector
10

POWER RECLINER PARTS

Check if the green
light on power
transformer is on
Check connection
security and
components integrity
on DC socket and
power cable.
Check connection
security and integrity
of motor’s 2-pin
cable
1. Check power
cords integrity and
connection to
transformer.
2. If power cords
undamaged, and
connection
secured, replace
power transformer.
Yes
No
Power Recliner Trouble Shooting
For dual-power recliners, please check connection and integrity of Y-Cable
splitter.
