Living Spaces Caden 53004612 User manual

SKU# IMAGE DESCRIPTION QUANTITY SKU# IMAGE DESCRIPTION QUANTITY
Z1
Z3
Z4
Bolt: Ø 8 x 60mm
Sping Washer: Ø 8 x 12 x 2mm
Washer: Ø 8 x 19 x 2mm
4
Z2
Z3
Z4
Bolt: Ø 8 x 50mm
Sping Washer: Ø 8 x 12 x 2mm
Washer: Ø 8 x 19 x 2mm
4
Z5
Z7
Screw: Ø 4 x 40mm
Washer: Ø 4 x 9 x 1mm
3
Z6
Z7
Screw: Ø 4 x 30mm
Washer: Ø 4 x 9 x 1mm
4
Z8 Screwdriver 1
Z9 Open Wrench
Ø13 1
Z10 Adjustable Bolt 4
Bench Top
1
Bench Leg
2
Top Support
1
ASSEMBLY INSTRUCTIONS
Caden 88" Bench
ITEM No.: 53004612
(BOX 1)
Box of Table Top / Leaf/ Top Support/ Stretcher
(BOX 1)
Table Top / Leaf/ Top Support/ Stretcher Hardware List
COMPLETED BENCH ASSEMBLY
53004612
Stretcher
1
Page 1 of 4

ASSEMBLY INSTRUCTIONS
Caden 88" Bench
ITEM No.: 53004612
STEP 1 STEP 2
Z8
Z6
Z7 x4
53004612
Z8
Z5
Z7
3X
53004612
Page 2 of 4

ASSEMBLY INSTRUCTIONS
Caden 88" Bench
ITEM No.: 53004612
STEP 3
X4
x4
Z1
Z3
Z9
Z4
Z9
Z3
Z4
Z2
53004612
Page 3 of 4

ASSEMBLY INSTRUCTIONS
Caden 88" Bench
ITEM No.: 53004612
STEP 4 STEP 6
CLEANING INSTRUCTIONS
THE HARDWARE IS LOCATED IN THE PACKING ITEMS
NOTE: MUST TIGHTEN SCREWS PERIODICALLY. WITH USE SCREW MAY BE COME LOOSE CHECK TIGHTNESS OF ALL SCREWS EVERY 6-8
WEEKS.
After assembly, clean & polish the completed parts if necessary with soft cloth and industrial recognized furniture polish.
x4
Page 4 of 4
