Livoo DOC279 User manual

DOC279
2
4 5
3
1 7 6
26
11 18 19
21
12 9
15 8
25
13
10
16 17 14
24 23
27
20
22
1 *1 2 *1 3 *3
4 *1 5 *1 6 *2
7 *2 8 *1 (RF) 9 *1 (RB)
10 *1 (LF)
11 *1 (LB)
12 *2
13 *2 14 *2 15 *2
16 *1 17 *2 18 *1
19 *1 20 *1 21 *1
22 *1
23 *2 24 *2
25 *2 26 *2 27 *4
A
M5
-
55*16
B
M5
-
12*34
C
M4
-
8*4
D *2 E *4 F M4-12*2
G *2
Assembly instructions

1. B M5*12 4PCS 2. B M5*12 4PCS
10 11 9 8
B B
15
15
3. A M5*55 4PCS 4. A M5*55 4PCS
20
A
A
Fix the left front leg and left back leg to the
left board
with 4pcs M5*12
Fix the right front leg and right back leg to the
right board with 4pcs M5*12
Connect the bottom board and the side trolley
parts
Connect the bottom board and the side trolley
parts

5. B M5*12 2PCS
A M5*55 4PCS
6. D 2PCS
E 2PCS
12 21
B
24 25
E D E
D
16
A
7. F M4*12 2PCS 8. C M4*8 4PCS
27
F
C
17
22
23 14
Install the wheel
Attach the door handle to the door
Attach the beams to the legs

9. 10. B M5*12 4PCS
A M5*55 4PCS
B
7
A
26
15
G
11. 12. B M5*12 20PCS
B
6
B
B
Install the door
Install the
firebox on trolley
Install the side tables
Fix the side tables

13. 14.
E
2
3
15. 16.
4
5
18
19
Place the flame tamers into the trolley.
Place the warming rack onto the trolley
make sure the warming rack is flat and
stable.
Place the cooking grills into the trolley. Attach the grease cup to the grease tray.
The grease cup needs to be under the
grease drip hole.

17. 18.

Instruction Manual
WWW.LIVOO.FR
Reference : DOC279
Version : 1.5
Language : nglish
Plancha gaz station 3
burners

Instruction Manual
1
You have purchased a product LIVOO brand and we thank you. We take great care in design, ergonomics
and ease of use of our products. We hope that this product will give you complete satisfaction.
This instruction manual is also available on our website www.livoo.fr
Model.
DOC27
9
CS Number
CS 117884
Description:
Plancha gaz station 3 burners
Max power
9kW
( 654g/h)
2575-21
Pin: 2575DM30340
Category of gaz : I
3+(28-30/37)
I
3B/P(30)
I
3B/P(50)
I
3B/P(37)
Types of gas : Butane
(654g/h)
Propane
(642g/h)
LPG GAS MIXTURES (654 g/h)
Gas pressure :
28
-
30 mbar
37 mbar
30 mbar
50mbar
37
mbar
Injector size :
0.
86
mm
0.
86
mm
0.
7
6 mm
0.
82
mm
Injector mark :
0.86
0.76
0.82
Number and code
20211125
Year
2021
To be used only outside the premises
This appliance must be installed in accordance with current regulations and used in a well-
ventilated area
Consult the instructions before use
Caution: accessible parts can be very hot, keep away from young children
This appliance must be kept away from flammable materials during use
Do not move the appliance during use
Close the gas container valve after use. Do not modify the appliance
D STINATION LAND
I
3+(28-30/37)
：
BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT, SK, SI.
I
3B/P(30)
：
BE, CY, DK, EE, FI,FR, HU, IT, LT, NL, NO, SE, SI, SK, RO, HR, TR, BG, IS, LU, MT.
I
3B/P(50)
：
AT, CH, DE, SK

Instruction Manual
2
General Safety Instructions
1. PL AS R AD TH FOLLOWING INSTRUCTIONS CAR FULLY
B FOR USING TH APPLIANC AND K P TH M FOR
FUTUR
2. C UTION: This appliance will become very hot. Do
not move it during use.
3. Do not move the unit while in use.
4. C UTION: Do not leave the appliance within the
reach of children and pets.
5. Never leave the appliance unattended during use.
6. Do not allow children to use or play with the appliance.
7. Use the appliance only for its intended purpose.
8. W RNING! Do not use in closed or confined spaces.
Make sure it is placed in a well ventilated area.
9. The appliance is intended for outdoor use only and in
accordance with local regulations.
10. Incorrect use or action and non-compliance with the safety
instructions in this manual can result in serious injury or
I
3B/P(37)
：
PL
DELTA - BP61071 - 67452 Mundolsheim - FRANCE

Instruction Manual
3
death.
11. Incorrect use or action and failure to observe the safety
instructions in this manual may result in fire or explosion,
causing serious material damage.
12. Carry out a leak test every year and whenever the gas
cylinder is changed or disconnected. Check that the gas
hose connections are tight and in good condition.
13. The appliance must be installed on a flat, level, stable and
heat-resistant surface or floor before and during use.
14. Do not obstruct the ventilation openings of the
barbecue/plancha.
15. Do not use near flammable materials or substances. Do not
store unplugged gas cylinders or aerosol cans near this
appliance. Do not use within 1.5 metres of combustible
material.
16. No ignition products should be used with this appliance.
17. Do not lean over the appliance during lighting or cooking.
18. This appliance is for private use only. Do not use at events
or in public places.
19. Do not modify the appliance. This gas grill must be
assembled according to the assembly instructions provided.
If the appliance has been assembled in a shop, make sure
that the assembly has been carried out correctly and carry
out a leak test before using the grill. Incorrect assembly of
the appliance can be dangerous.
20. Do not use the barbecue/plancha in strong winds.
21. Do not use the barbecue/plancha if all parts are not in place.

Instruction Manual
4
Be sure to follow the assembly instructions to properly
assemble this barbecue/plancha. Incorrect assembly can
be dangerous.
22. Use appropriate heat-resistant barbecue utensils to handle
cooking food. Wear protective gloves when using the
barbecue/plancha to avoid burns. Some accessible parts
can be very hot.
23. Do not cover the cooking grate with foil, dish or container
to avoid heat build-up. Do not cook in foil.
24. If your appliance has a lid, be careful when opening it. Hot
steam may be released from the inside.
25. DO NOT cook with the lid (if fitted) down when the valves
are on high heat, otherwise your appliance may be
damaged.
26. Allow the barbecue/plancha the ashes and its accessories
or parts to cool down completely before cleaning and
storing it. It is recommended to empty the ashes 24 hours
after using the barbecue/plancha.
27. Always allow to cool before storing or cleaning.
28. Clean the appliance and its accessories after each use to
avoid the accumulation of grease (risk of fire).
29. Please store the appliance in a dry and sheltered place.
30. For details on how to clean food contact surfaces, refer to
the following paragraph of the manual.
31. If you detect a smell of gas:
- Turn off the gas supply to the appliance
- Open the lid if the model has one

Instruction Manual
5
- xtinguish any open flame
- If the smell persists, stop using the appliance, move away
from the appliance and contact your dealer or the fire
brigade immediately.
gas leak may cause a fire or explosion which could result
in serious injury or death or damage to property.
32. Always close the gas cylinder when you are not using your
barbecue/plancha.
33. Please purchase gas connection accessories (hose,
regulator and gasket) that comply with the national
regulations in force in the country of destination. These
components must be replaced periodically, according to
the date indicated on the body of each of them, or
according to the national regulations in force in the country
of destination.
34. The gas supply pipe (not supplied) must be installed so that
it does not come into contact with the hot surfaces of the
grill during operation or during storage and travel.
35. Never attempt to disconnect the pressure regulator or any
gas connection while using the barbecue/plancha.
36. Follow the instructions for connecting the regulator for
your gas barbecue/plancha.
37. Inspect the gas supply hose before each use. If it is
excessively cracked, worn or cut, it must be replaced with
a pressure regulator and hose assembly specified by the
manufacturer before using the grill hose with a
replacement assembly specified by the manufacturer

Instruction Manual
6
before using the grill.
38. Do not overtighten connections. Do not use Teflon tape or
sealing fluids on connections.
39. Warning. Never connect your appliance to town gas
(natural gas). The gas circuit is designed exclusively for
butane/propane gas (G30/G31).
40. nsure that the gas cylinder is placed outside the appliance
during use.
41. Gas cylinders must never be used or stored lying down
42. After each use, ensure that all control levers are in the off
position (STOP)and that the gas cylinder supply is closed.
Although this appliance has been manufactured to avoid sharp edges, care should be taken when handling all
parts to avoid the risk of injury.
Remove all protective packaging and keep it away from children. Read the safety instructions carefully before you
start using your barbecue/plancha.
Refer to the parts list and assembly diagrams to assemble your barbecue/plancha. Make sure that no parts or
pieces are missing or damaged/broken, which could impair the proper functioning of the appliance. The
guarantee for this appliance cannot be applied for abnormal conditions of use, incorrect storage conditions, lack
of maintenance, modification of the product, use for professional purposes, etc.
IGNITION
Make sure that the appliance is positioned on a stable, flat surface.
Wear protective gloves and open the vents wide (if the model has them) so that the air can flow in and
accelerate the combustion.
C UTION: This barbecue/plancha will become very hot. Do not move it during use.
This product is intended for use with bottled gas only.
A regulator in accordance with N16129 of 28 mbar must be used for butane gas or 37 mbar for

Instruction Manual
7
propane gas.
Never use an adjustable regulator with the product.
Make sure that the regulator is correctly set so that the supply pipe and valves are filled with gas.
Otherwise, the burners will not have enough power and will not light or will cut out regularly.
If you need to replace the gas cylinder, make sure that the appliance is switched off and that there is no
source of ignition nearby (spark, cigarette, open flame, etc.).
Make sure that the gas hose is not twisted, stretched, bent or kinked to allow free flow of gas.
ASS MBLY INSTRUCTION
CHECK JOINED DOCUMENT WITH SSEMBLY INSTRUCTIONS
INSTRUCTIONS FOR US
Never grill your food in the flames.
Flames can be caused by residues of grease and juice dripping onto the burners. To imitate the flames, clean the
burners regularly, when not in use and when the appliance is completely cool.
The burners should ALWAYS be in the low position during cooking.
Protect your hands when cooking with protective gloves.
Do not use in strong winds. Do not use wood or lava stone.
1. ssembly steps
Make sure your grill is assembled correctly. The detailed assembly instructions below provide specific
assembly procedures for each model. Follow these instructions carefully to ensure proper assembly of
your grill.
Caution: While we strive to make the assembly process as easy as possible, machined steel parts may
have sharp corners and edges that can cause cuts if handled improperly during assembly procedures.
Use caution when handling parts during assembly. It is strongly recommended that you protect your
hands with a pair of work gloves.
This equipment must be installed with sufficient ventilation to prevent unacceptable concentrations of
substances harmful to health from developing in the area where it is installed.
2. Preparation
You will need a gas cylinder and a regulator appropriate for the gas pressure to operate this gas
barbecue. The regulators must comply with the NF standard for France, and BS N 16129:2013 for other
countries.
Note: For other countries, the cylinder and regulator are dependent on the national situations of the
recipient countries.
Consejos para ahorrar energía:
a) Réduire le temps nécessaire à l'ouverture du couvercle.

Instruction Manual
8
b) Éteignez le gril dès que la cuisson est terminée.
c) Ne préchauffez le gril à gaz que pendant 10 à 15 minutes. (Sauf pour la première utilisation)
d) Ne pas préchauffer plus longtemps que recommandé.
e) N'utilisez pas un réglage plus élevé que nécessaire.
f) Raccordez le tuyau et le régulateur au réservoir de gaz situé sur le côté gauche du gril à gaz, en tenant
compte du fait que le réservoir de gaz doit être maintenu à l'écart de la chaleur et dans une position
sûre. La longueur recommandée du tuyau ne doit pas dépasser 1,5 m.
3. Installation
After purchasing your gas cylinder, you are ready to install it with your gas grill.
a) Changing the gas cylinder should be done away from any source of ignition. Place the gas cylinder on
the left side or inside of your barbecue, keeping in mind that the cylinder must be kept away from heat
and in a safe position.
b) When you are ready to use your gas barbecue insert the regulator into the gas bottle valve and
tighten it firmly.
Caution: Before attempting to light your gas barbecue, you must refer to the lighting
instructions and the safety and warning points.
Check the hose before each use for cracks, cuts or scratches. If the hose is found to be defective, do not
attempt to use your gas barbecue under any circumstances.
When changing your gas cylinder, make sure there are no sources of ignition nearby (fire, cigarettes,
open flames, etc.).
Make sure the hose is not twisted in any way that would affect the flow of gas when installing your gas
grill. The hose should not have excessive tension and should not touch any part of the gas grill that may
be hot.
Please choose a flexible hose that is resistant to heat over 80 ℃
The flexible hose should be changed when the expiration date indicated on the hose is reached. It is
necessary to change the flexible tube when national conditions require it and if it is found to be
defective.
How to change your cylinder
•Note: turn off the gas cylinder (no key is needed)
•If you place the gas bottle outside the barbecue the height of the gas bottle must be less than
47 cm, and the width less than 31 cm. The net weight of the gas bottle should not exceed 5
kg;

Instruction Manual
9
Figure 1
If you place the gas cylinder outside the barbecue, the height of the gas cylinder is less than 80 cm and
the width is less than 35 cm, the net weight of the gas cylinder should not exceed 15 kg
Figure 2
How to connect the gas cylinder
This appliance is designed only for use with low pressure butane, propane or their mixture of gases and
a suitable low pressure regulator using a flexible hose. The hose must be attached to the regulator and
the appliance with hose clamps.
Gas Connector
Hose
Gas Cylinder
Regulator
Hose

Instruction Manual
10
Figure 3
Warning: Always check for leaks in the gas line at the connector with soapy water by
terminating all connections.
How to disconnect a gas cylinder
a) xcept in the case of two-cylinder installations with a switching valve, close the gas stopcock if it is
installed on the appliance. Wait until the burner and pilot have extinguished. In installations with a
reversing valve, it is only necessary to close the empty cylinder.
b) Replace the orange safety cap on the empty gas cylinder.
Inserting / changing the batteries (if available)
This appliance is equipped with a battery-operated igniter which ignites the electrodes of one group of
burners (left and right) at a time.
a) Remove the electronic igniter cover by turning it counterclockwise (Fig.1).
b) Insert an LR6/AA into the tube (Fig.2). Observe the correct polarity (+ and -).
c) Screw the cap back on clockwise (Fig.3).
4. Safety Precautions
a) Always check for leaks in the gas line at the connector with soapy water after making connections.
b) The top cover must always be open when lighting the burner.
c) Use oven gloves and sturdy, long-handled utensils when cooking on the grill.
d) Be prepared in case of an accident or fire. Know where the first aid kit and fire extinguishers are and
how to use them.
e) Keep any electrical power cords and the fuel supply hose away from any heated surfaces.
Illustration for barbecue and hose
connection
Illustration for connection of gas cylinder,
regulator and hose

Instruction Manual
11
f) Always cook very carefully.
g) Do not heat any unopened glass or metal containers on the grill. Pressure may build up and cause the
container to burst,
which could
result in serious
personal injury or
damage to the
grill.
Figure 4
W RNING: The black area on the handle (see image above for reference) will become hot
when the gas grill is in use, be careful! Do not touch the black area.
LIGHTING INSTRUCTIONS
Caution: The lid must be open when lighting the burner.
Do not stand with your face directly over the gas grill when lighting it.
Your gas grill will have the following method of ignition:
Pilot gas control ignition (main burner or main burner with side burner or main burner with side burner
and rear burner):
With all gas controls on the gas grill in the "OFF" position, turn the gas cylinder valve to the ignition
position on the regulator. To create a spark you must press the gas control knob (A) and hold it in this
position for 3-5 seconds to allow gas flow and then turn counterclockwise to" HI" (B). You can jump the
spark to the burner ignition tube (C). You will hear a "click" from the igniter and also see an orange
flame coming out of the burner ignition tube on the left side of the burner (D). Continue to hold the gas
control knob for two seconds after the "click", this will allow the gas to flow completely through the
burner tube ( ) and ensure ignition. When the burner is lit, adjacent burners will cross-light when their
knobs are set to "HI". In the "HI" position, the burner flame should be approximately 12-20 mm long
with a minimum orange flame. Turn the gas control knob fully counterclockwise to obtain the minimum
setting. If you have any difficulty lighting your gas grill by following the above steps, contact your dealer
for advice. If you are unable to use the automatic ignition, remove the cooking grate and heat diffuser
(hotplate), and turn the valve counterclockwise 90°，to ignite with a barbecue lighter at a distance of 5
mm from the burner fire hole. Replace the cooking grate and heat diffuser (hotplate), please wear the
flame retardant and heat resistant gloves.
Warning:
If the burner still does not light, turn the gas control knob to " OFF" and
wait 2 minutes for the unburned gas to evaporate before turning the burner back on.
encenderlo.

Instruction Manual
12
Figure 5
STORAG AND CL ANING
Rust spots may appear on the product due to the metallic particles contained in the stainless steel used in the
manufacture of this product. We recommend that you brush them off quickly to limit their spread.
After each firing, wait for the product to cool down completely.
mpty the grease trap and clean your appliance and utensils after each use to avoid a highly flammable and toxic
grease deposit on the cooking surfaces.
Do not use sharp objects or abrasive cleaners on the cooking surface. It is preferable to use a heavy-duty
degreaser.
Do not leave standing water in the appliance; this can lead to rust and rapid deterioration of the materials.
Protect your appliance with a cover if you leave it outside in fine weather. Protect from rain and moisture during
extended periods of non-use.
Before use, check the hose for nicks, cracks and signs of severe wear. Make sure the expiry date has not passed.
Carry out a leak test at the beginning of each season and each time you replace the cylinder to ensure that the
appliance and its connections are working properly.
N V R US AN OP N FLAM TO D T CT GAS L AKS. DO NOT LIGHT TH APPLIANC DURING TH T ST.
Turn all appliance controls to STOP, Connect your gas cylinder correctly, Open the gas cylinder valve.
To detect a leak, brush a solution of equal parts liquid soap and water over all the gas connections (valves, hose,
regulator and hex nut).
If bubbles form anywhere, this indicates a leak.

Instruction Manual
13
G S CYLINDER
The appliance can be used with any gas cylinder of weights between 4.5KGS and 15KGS butane and
3.9KGS to 13KGS propane. The gas cylinder should not be dropped or handled roughly! If the appliance
is not in use, the cylinder must be disconnected. Replace the protective cap on the cylinder after
disconnecting the cylinder from the appliance.
Cylinders must be stored outdoors in an upright position and out of the reach of children. The cylinder
must never be stored where temperatures can reach over 50°C.
The height of the gas cylinder is below the 80cm, and the width is within 35cm.
CLE NING
Performing a "heat cleaning" (by heating the griddle) after each use (for about 15 minutes) will remove
some of the food residue.
OUTSIDE SURF CE
Use mild detergent or baking soda and hot water solution. Non-abrasive scouring powder can be used on
stubborn stains, then rinse with water.
Clean thoroughly with strong hot soapy water solution. Rinse with water and allow to completely dry.
N V R US OV N CL AN R
COOKING PL TE
Remove residues with a brush, scraper and/or sponge, then wash with a soapy water solution. Rinse with
clean water and allow to dry completely.
Clean with a soft cloth and soapy water. Rinse with clean water. Do not use abrasive cleaners, paint
strippers or grill cleaner on the plastic parts.
CÓMO LIMPI R EL ENS MBLE DEL QUEM DOR
Asegúrese de que los tubos de ventilación del quemador estén limpios y que no haya obstrucciones. Le
recomendamos que utilice un limpiador de tuberías para limpiar la zona del tubo venturi.
TROUBL SHOOTING
mergencies Possible cause Prevention/ Solution
Gas leaking from
cracked/cut/burned hose
Damaged hose Turn off gas at LP tank, if hose is cut or
cracked, replace hose. See LP tank lead test
and connection regulator to the LP tank
Gas leaking from LP tank Mechanical failure due to resting or
mishandling
Turn off LP tank valve.
Return LP tank to gas
supplier
