Livoo DOM323 User manual

Instruction manual
WWW.LIVOO.FR
Reference : DOM323
Version : 1.4
Language : Englis
Vertical grill

Instruction manual
1
You ave purc ased a product LIVOO brand and we t ank you. We take great care in design, ergonomics and
ease of use of our products. We ope t at t is product will give you complete satisfaction.
T is instruction manual is available too on our website www.livoo.fr
SAFETY ADVICES
PLEASE, TAKE TIME TO READ WELL THE
INSTRUCTIONS FOR USE PARTICULARLY BEFORE
THE FIRST USE.
A misuse of t e appliance can damage it or urt
t e user. Assure t at you use t e appliance for t e
use for w ic it is designed, we refuse any
responsibilities as for t e damages by an incorrect
use or a bad manipulation.
1. C eck t at your mains voltage corresponds to
t at stated on t e appliance.
2. T e safety instructions do not by t emselves
eliminate any danger completely and proper
accident prevention measures must always be
used.

Instruction manual
2
3. Never leave t e appliance unsupervised w en
in use. Keep out of reac of c ildren or
incompetent persons.
4. If t e power cord is damaged, it must be
replaced by t e manufacturer, its service or
similarly qualified persons in order to avoid a
azard (*).
5. Do not pass t e cord over objects wit s arp
edges and keep it at a distance from, ot
objects and bare flames. Always pull on t e
plug to disconnect it from t e feed source.
6. For extra protection it is possible to equip your
ome’s electrical system wit a residual
current circuit breaker wit voltage break at 30
mA max mum. Ask your electrician for avise
7. Make sure t at t e cord or t e extension cable
is not at risk of being pulled inadvertently nor
of being topped over by anyone at t e time of
use.

Instruction manual
3
8. W en you use an extension cable. Make sure
t at it is adapted to t e appliance essential
consumption. Contrary to t is, t e extension
cable or t e plug risks over eating.
9. Only use t e appliance for domestic purposes
and in t e way indicated in t e instructions.
10.Never immerse t e base of your appliance in
water or any ot er liquid for any reason
w atsoever. Never place it into t e
dis was er.
11.In case t e appliance accidentally falls into
water disconnect it immediately. Have it
c ecked by an expert before re-using, if you do
not do t is you run t e risk of electrocution.
12.Never try to open t e casing yourself
13.Do not use t e appliance if your ands are
damp if t e oil is wet, or if t e appliance itself
is damp.

Instruction manual
4
14.Do not touc t e plug if your ands are damp
or wet.
15.Never use t e appliance near ot surfaces.
16.Before cleaning, always unplug t e appliance
from t e power supply.
17.Never use t e appliance outside and always
place it in a dry environment.
18.Never use accessories t at are not
recommended by t e producer. T ey could
constitute a danger to t e user and risk to
damage t e appliance.
19.Never move t e appliance by pulling t e cord.
Make sure t e cord cannot get caug t in any
way. Do not wind t e cord around t e
appliance and do not bend it.
20.Stand t e appliance on a table or flat surface.
21.Unplug t e appliance w en not in use.

Instruction manual
5
22.It is absolutely necessary to keep t is
appliance clean at all times as it comes into
direct contact wit food.
23.Regarding t e instructions for cleaning
surfaces in contact wit food, t anks to refer
to t e below paragrap “Cleaning” in t e
manual.
24.Make sure t e appliance is unplugged before
inserting, removing or cleaning one of t e
accessories. It is absolutely necessary to
remove t e accessories before cleaning t em.
25.T e appliance is not intended to be operated
by means of external timer or separate remote
control system.
26.Keep t is manual wit t e appliance. If t e
appliance is to be used by a t ird party, t is
instruction manual must be supplied wit it.
27.T is appliance can be used by c ildren aged
from 8 years and above and persons wit

Instruction manual
6
reduced p ysical, sensory or mental
capabilities or lack of experience and
knowledge if t ey ave been given supervision
or instruction concerning use of t e appliance
in a safe way and understand t e azards
involved. C ildren s all not play wit t e
appliance. Cleaning and user maintenance
s all not be made by c ildren unless t ey are
older t an 8 years and supervised.
28.Keep t e appliance and its cord out of reac of
c ildren less t an 8 years.
29.T is appliance is intended to be used in
ouse old and similar applications suc as:
•staff kitc en areas in s ops, offices and
ot er
working environments
•farm ouses
•by clients in otels, motels and ot er
residential type environments

Instruction manual
7
•bed and breakfast type environments
(*) Competent qualified electrician: after sales department of t e producer or importer or any person w o
is qualified, approved and competent to perform t is kind of repairs in order to avoid all danger. In any
case you s ould return t e appliance to t is electrician.
T is logo means t at t e indicated part
w ere it is affixed is liable to get very ot
during use
SPECIAL MEASURES

Instruction manual
8
WARNING : HOT S RFACE
1. T e surfaces can be very ot during use. Do
not touc ot surfaces. Use t e knobs. Do not
store or place any ot er item on top of t e
grill. Use extreme caution w en removing drip
pan or disposing of ot grease or ot er ot
liquids.
2.
Extreme caution s ould be used w en opening
and closing t e door
3. Never line any part of t e oven wit aluminum
foil. T is may cause over eating and damage
t e unit.
4. Use extreme caution w en using containers
t at are not made of glass or metal.
5. Extreme care s ould be taken w en removing
t e broiler pan or discarding t e ot grease in

Instruction manual
9
t e appliance. Splas es can occur wit t e
risk of burns.
6. W en operating t e grill keep at least 10 to
15cm of space on all sides of t e grill to
allow for adequate air circulation.
7. Do not clean wit metal scouring pads.
Pieces can break off t e pad and touc
electrical parts, creating a risk of electric
s ock.
8. A fire may occur if t e grill is covered,
touc ing, or near flammable material,
including curtains, draperies, w en in
operation. Do not store any item on top of
t e grill w en in operation, or before t e
grill cools down.
9. Do not store any materials, ot er t an
manufacturers recommended accessories,
in t is grill w en not in use.

Instruction manual
10
10. Always wear protective, insulated mitts
w en inserting or removing items from t e
ot grill.
Information :
T e unit will never start before you close t e
door well (Make sure t at t e metallic tongue
well gets in touc wit t e internal button, a
click as to be listened closing t e door) and
t e inner blue lig t is off.
DESCRIPTION
A: Top ousing
B: Base station
C: Heating element
D: Door andle
E: Glass door
F: Timer
G: Indicate lig t
H: Rotisserie spit
I: End fork
J: Kabob
K: Upper support (Kabob)L: Bottom support (Kabob)
M: Drip pan

Instruction manual
11
SPECIFICATIONS
Voltage: 220-240V~ 50-60Hz
Power: 1500W
Capacity: 21 liter
USING YOUR APPLIANCE
Before your First se
Place your grill on a level surface suc as a countertop or table. Be sure t at rear surface of t e grill is against
t e wall and ot er surface away from wall. Remove all stickers from t e grill. Remove Drip Pan, Rotisserie
Spit, Forks and kabobs and was t em in warm, soapy water or in t e dis was er. Dry t oroug ly before
placing in t e oven.
T e door andle is removable, in order to let you take it out and clean t e inside of unit. Before
you use t e oven, please assembly t e andle yourself by t e following assembly instruction
picture.
W en you are ready to use t e grill, be sure t at t e TIMER Control is in t e “Off” position and unplugged.
We recommend a trial run to familiarize yourself wit your grill and to eliminate any protective substance or
oil t at may ave been used for packing and s ipping. Plug t e cord into a 220volt AC outlet. Set t e TIMER
Control to “20” minutes. A small amount of smoke and odor may be detected. T is is normal.
To avoid scratc ing, marring, discoloration or fire azard, do not store anyt ing on top of t e oven, especially
during operation.
sing Your Grill for Rotisserie
1. Place one rotisserie fork on t e end of t e rotisserie spit opposite t e point wit t e tines facing t e
center and tig ten t e screw slig tly.
2. Slide t e pointed end of t e rotisserie spit t roug t e center of t e food to be cooked.

Instruction manual
12
3.
Place t e ot er rotisserie fork on t e ot er end of t e rotisserie spit wit t e tines facing t e roast.
4. Adjust t e roast so t at it is centered on t e rotisserie spit. Make sure t e forks are secure on t e
roast and on t e spit and tig ten t e screws.
5. W en cooking poultry, it may be necessary to secure legs and wings to t e body wit butc ers twine
to make t e roast as compact as possible for smoot movement of t e rotisserie spit.
6. Season or baste t e roast as desired.
7. IMPORTANT! Place t e round drip pan into t e receptacle at t e bottom of t e oven to catc t e
drippings.
8. Put t e solid end of t e rotisserie spit in t e drive socket on located in t e center of t e drip pan.
9. Place t e grooved end on t e spit support on located on t e top interior of t e oven
Solide end
10. Close t e glass door and t e inner blue lig t will be off automatically.
11. Set t e TIMER Control to t e time according to RECIPE. If more t an 1 our, set to “Stay On” and
c eck after t e setting time.
12. W en t e roast is done, turn t e TIMER Control to “Off” and unplug t e oven.
13. Remove t e rotisserie from t e top by lifting up and out towards you. Pull t e bottom part of t e spit
out of t e drip pan receptacle and place onto a carving station.
14. Place t e roast on a cutting board or platter and allow standing for 10-15 minutes, t is allows t e
juices to redistribute t roug out t e roast making for a moister, flavorful roast
15. Using a pot older, loosen t e screws on t e rotisserie forks and remove t e rotisserie spit from t e
roast. Carefully remove t e rotisserie forks and carve t e roast.
sing Your Grill for Kabob
If your grill comes wit Kabob accessories, please follow t e instructions for use.
1. Assembly t e kabobs wit following t e below steps.
Grooved
end

Instruction manual
13
2. Place t e round drip pan into t e receptacle at t e bottom of t e oven to catc t e drippings.
3. Put t e solid end of t e rotisserie spit in t e drive socket on located in t e center of t e drip pan.
4. Place t e grooved end on t e spit support on located on t e top interior of t e grill.
5. Close t e glass door well and t e inner lig t will be off automatically.
6. Set t e TIMER Control to t e time according to recommended Recipe. If more t an 1 our, set to
“Stay On” and c eck after t e s ortest time.
7. W en t e roast is done, turn t e TIMER Control to “Off” and unplug t e grill.
Cooking tips
1. C icken , duck 30~45 minutes
2. Steak 45~60 minutes
3. Kabob 20~30 minutes
4. Fis 20~30 minutes
5. Vegetable 15~20 minutes

Instruction manual
14
CLEANING AND STORAGE
1. Turn t e TIMER Control to “Off” and unplug before cleaning.
2. Allow t e grill and all accessories to cool completely before cleaning.
3. Clean t e outside of t e grill wit a damp clot and dry t oroug ly. Clean stubborn stains wit a
nonabrasive liquid cleaner. Do not use metal scouring pads or abrasive cleaners t at will scratc t e
surface.
4. Clean t e glass door wit a clot or sponge dampened wit warm, soapy water and dry t oroug ly.
5. Was t e drip pan in ot, sudsy water or in t e dis was er. Clean stubborn stains wit a nylon or
polyester mes pad and a mild, nonabrasive cleaner. Rinse and dry t oroug ly.
6. If crumbs and spills ave accumulated on t e bottom of t e grill wipe wit a damp clot and dry
t oroug ly.
7. T e walls on t e inside of t e grill allow food particles or spatters during use to be easily wiped clean.
Remove eavy spatter after use wit a nylon or polyester mes pad, sponge or clot dampened wit
warm water. Blot dry wit a paper towel or soft, dry clot .
8. T e Rotisserie spit and forks (wit out screws attac ed) , kabobs and fis basket can be placed in t e
dis was er or was ed in warm soapy water. Hand was t e screws in warm soapy water and dry
t oroug ly.

Instruction manual
15
Correct disposal of the unit
(Electrical and Electronic Equipment)
(Applicable in t e European Union and t e rest of Europe t at ave adopted separate collection
systems countries)
T e European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE),
requires t at old ouse old electrical appliances must not be disposed of in t e normal
ouse old waste stream. Old appliances must be collected separately in order to optimize t e recovery and
recycling of t e
materials t ey contain and reduce t e impact on uman ealt and t e environment.
T e symbol of t e crossed out dustbin is marked on all products to remind t e obligations of separate collection.
Consumers s ould contact t eir local aut ority or retailer for information concerning t e correct disposal of t eir
product.
• P oto no contractual
• Worried about t e quality of is products t e manufacturer reserves t e rig t to make modifications wit out
advance notice
LIVOO
BP 61071
67452 Mundolsheim - FRANCE
