Lloydspharmacy StopSnoring Advance LSS1 User manual

User Manual
Model LSS1
StopSnoring
Advance
Available accessories
Last revised: 23/06/2010

1
2
3
4
5 - 9
10
11
12 - 14
15 - 16
17
Introduction
Parts
General Warnings and Safety
Instructions for Use
Battery Information
Specification
Troubleshooting and Frequently Asked Questions
Maintenance and Cautions
Warranty
Contents

2
Thank you for purchasing the Lloydspharmacy StopSnoring Advance.
This product is an approved Class IIA medical device. Snoring is a common social problem and it is
estimated that, in the UK, up to 40% of the population snore, not to forget the millions of partners
who suffer disturbed sleep as a result. If you are a snorer or share a room with someone who snores
then you’ll know how it feels to be tired, day in and day out. Not only will you suffer with a lack of
sleep but in the long term, snoring can cause high blood pressure and increase the risk of heart attacks
and strokes. Snoring most commonly occurs when people sleep on their back or remain in the same
position. A change in sleeping position can often stop a person snoring. If your body mass index (B.M.I.)
is greater than 25 you are overweight. This can be a major factor in snoring and Lloydspharmacy
recommends that you need to lose weight and adopt a healthy exercise routine, not only to help stop
snoring but also to prevent other diseases caused by obesity.
The Lloydspharmacy StopSnoring Advance is worn on the wrist and works by a bio-feedback process,
so whenever it detects 3 or more consecutive snores it sends a weak electrical impulse (massage
wave) to the person wearing it. The electrical impulses are pain free and aren’t enough to wake, simply
enough to help them change their sleeping position, reducing snoring and hence ensuring a restful
nights sleep. Before using the Lloydspharmacy StopSnoring Advance, please read the instructions
included in this user manual carefully.
It may take a few nights to get used to this device, however, you will soon experience the benefits.
Introduction

3
K<JK
This StopSnoring Advance package includes:
• Wrist strap
• Self - adhesive gel pads (3 sets)
• Manual
• Moist alcohol wipes (3)
Parts
ON/OFF switch /
intensity level
Self-adhesive
gel pads
Test button LED indicator
Battery cover (1 x AAA
battery - not included)
StopSnoring
Advance

4
1. This device is NOT suitable for people with pacemakers or other implanted medical devices,
or for people with heart rhythm problems equipments (e.g. ECG monitors and ECG alarms)
2. Heart disease patients SHOULD NOT use this device except under the advice of their doctor.
3. The StopSnoring Advance is not suitable for people who suffer with Sleep Apnoea.
4. Do not use this device during pregnancy except with a doctors consent.
5. Patients with acute or infectious diseases should consult their doctor before use.
6. Patients with severe skin diseases should consult their doctor before use.
7. Do not use this device on swollen, infected, or inflamed areas, or on skin eruptions, eg. phlebitis,
thrombophlebitis, varicose veins, etc.
8. Do not place the device in the mouth, neck and eyelid region.
9. Do not use in close proximity (e.g. 1 meter) to a short wave or microwave therapy equipment.
General Warnings and Safety

5
Instructions for Use
1. Sticking On the Gel Pads
a. Use the moist alcohol wipe to clean the two black rubber pads on the back of
the device (as shown in picture I)
How Does It Work
Three or More
Consecutive Snores
StopSnoring Advance
Detects Snoring
Small Massage Wave
Applied to Skin Natural Reflex Snoring Stops by
Biofeedback Reaction
I
StopSnoring
Advance

6
b. Remove the self-adhesive gel pads from the pack. Peel off the side of plastic film that
has print on it (as shown in picture II, III)
c. Stick the gel pads onto the black rubber pads on the back of the StopSnoring Advance
(as shown in picture IV). Press in a circular motion to ensure better adhesion, and wait
for 15 minutes (as shown in picture V). After 15 minutes slowly peel away the plastic
film before use (as shown in picture VI).
IV
V
VI
Instructions for Use

2. Adjusting the Wrist-Band
a. After attaching the gel pads, place the StopSnoring Advance one inch below the wrist like a
watch. Use the wrist strap to tighten/loosen it and then secure into position using the fastener.
b. Tighten and fix this end of the strap.
Note: Do not pull the strap too tightly; it could result in poor circulation. The device functions
best when touching the skin gently.
3. Using the Device
a. Test the function of the device before use. Switch on the power and adjust the intensity to level 1.
b. Press the test button three times in a row. Check that the LED indicator (green light) is flashing.
The device will release a weak electrical impulse that lasts for about 5 seconds. You can adjust the
intensity to the level that you feel comfortable with.
1 inch
Instructions for Use
7
StopSnoring
Advance
StopSnoring
Advance

8
Note: Due to variations in skin sensitivity, you may not feel the electrical impulse. If this is the case,
press the test button 3 times in repetition, and adjust the intensity to the level that you feel
comfortable with. If you still do not feel the impulse when you set the highest intensity, rotate
the unit around your wrist so that it sits on the inner side of your wrist instead.
4. Understanding the LED light:
When you wear the SnoreStop Advance on your wrist, the LED will change from “red” to “green”,
meaning that the device has proper contact with your skin and you can start using it. If the LED
still shows a red light, the device does not have proper contact with your skin. Adjust the wrist
strap until the LED indicator light is green. If the device still does not work, please refer to
Troubleshooting and Frequently Asked Questions (pages 12-14) and Maintenance and Cautions
(pages 15-16).
Instructions for Use
StopSnoring
Advance
StopSnoring
Advance

9
The device’s unique design can automatically detect snores above 65 dB when there are no other
loud background noises. Background noises should be below 55dB when using the StopSnoring
Advance.
5. After Use
To prevent damage of the self-adhesive gel pads: Unhook the wrist strap and gently remove the
device from your wrist. After you take off the device, stick the plastic film back on to the gel pads.
This prevents contamination of the pads with dusty particles and will enhance their lifespan. This
device will automatically switch off after 8 hours. In order to maximize the battery life, turn the
power off after you wake up. If used most nights, we recommend that you replace the gel pads after
30 nights of usage.
Instructions for Use
StopSnoring
Advance

10
Battery Information
Inserting the Battery
To insert the battery, open the battery compartment, observing correct polarity. Insert the battery,
then replace the cover of the battery compartment. It is recommended that you use high quality
batteries for optimum performance.
The unit requires 1 x AAA battery (not included).

11
Specifications
Pulse amplitude : Fixed 180µA peak into 1,000 Ω load
Pulse rate : Fixed 0.2 Hz
Pulse width : Fixed 800µs, Voltage adjustable 2.5-14V,
peak into 1,000 Ωload
Wave form : Asymmetrical bi-phasic square pulse
Power source : 1.5 Volt AAA battery (not included)
Detective timer : 8 hours auto off
Operation environment : 50˚F ~ 104˚F( 10˚C ~ +40˚C ), 30 ~ 85 % RH
Storage environment : -4˚F ~ 122˚F (-20˚C ~ +50˚C), 10 ~ 95 % RH
Transport environment : 14˚F ~ 122˚F (-10˚C ~ +50˚C), 35 ~ 85 % RH
Maximum wrist strap length: 22cm approx.
(All electrical specifications are ± 20% 1,000 Ωload)
• Design and specifications are subject to change without notice.
Note: This Class IIA medical device complies with the Electromagnetic
Compatibility Requirement of EN 60601-1-2 as specified in
EEC Directive 93/42/EEC.

12
Troubleshooting and Frequently Asked Questions
1. Q : Does the StopSnoring Advance really work ?
A: Snoring is caused by the collapse of the upper airway whilst asleep causing the airway to narrow.
When we sleep, our muscles are relaxed. As air moves through the narrow airway during breathing,
it causes the soft tissues of the throat (tonsils, soft palate & uvula) to vibrate. This vibration creates
the sound of snoring. Generally, snoring can be reduced if the snorer changes his/her sleeping
position or is given a slight nudge by his/her partner. Based on this concept, the StopSnoring Advance
is designed to reduce snoring by biofeedback. When snores are detected, the device will output a 5
second pulse onto superficial skin. Snoring may then be reduced in the following ways: i.) the snoring
person changes his/her sleeping position, or ii.) muscle tension in the throat is increased back to a
normal position as a reflex to the gentle massage wave.
Note: If you have a serious medical condition, refer to our introduction and general warnings and
safety sections. Use only as directed. If any unusual symptoms appear, discontinue treatment and
see your doctor. Proper use of the StopSnoring Advance requires self-discipline, careful application
and time to train reflexes.
2. Q: What is dB ? How do I know whether StopSnoring Advance can be used in my home?
A: A dB (decibel) is a unit of measurement of the intensity of sound. An environment having a sound
intensity of above 70 dB continuously is considered a very noisy background. You would not normally
live in this environment. The design of StopSnoring Advance targets the source of indoor background
noise. You may read the following table to see the optimal sleeping conditions for use.

13
Typical Indoor background noise StopSnoring Advance sensor
Above 65 dB (within 50 cm from TV) May Activate
60 dB (within 1 m from TV) Seldom Activated
55 dB (within 1m from air-conditioner) Seldom Activated
No ActivationBelow 55 dB
Remarks: Under normal conditions, your home’s indoor background noise will be 30~50 dB.
3. Q: Why does the intensity feel so weak during the testing procedures?
A: This may be due to three reasons: difference in sex, age and weight. Skin impedance will also
cause variances in skin sensitivity. The intensity of the output impulse lies within the safe range.
If your attention is diverted, you may also experience a low-intensity feeling. The skin’s nerves
are more sensitive during the night. Since the device is designed to be used at night, you may
have the lower intensity feeling when testing the device in the day. Check the gel pads to see
if you have forgotten to attach them, or if they should be replaced due to extended use. If you
cannot feel any of the impulses, even after adjusting the intensity to the highest level, wear the
StopSnoring Advance on your inner wrist instead.
Troubleshooting and Frequently Asked Questions

14
4. Q: When I ‘simulate’ the snores in a silent background, why does the device not work?
A: Since the StopSnoring Advance special biosensor is designed according to the biophysical
properties of snoring, you can try to ‘simulate’ it by saying a long 1, 2, 3 or producing 3
consecutive snores with the same frequency and at least above 65 dB.
5. If the LED indicator does not light up during the testing procedure, please check the following:
• Is the battery installed correctly? (observe correct polarity).
• Is the battery’s energy low? If so, please replace with a new one.
6. If the points mentioned above are checked, and the device still does not work correctly, consult
your local Lloydspharmacy.
• Always use the specified accessories provided. The use of other parts not approved by the
manufacturer may be hazardous. Do not try to repair the device! There are no user serviceable
parts inside.
Troubleshooting and Frequently Asked Questions

15
Maintenance and Cautions
Maintenance
1. The self-adhesive gel pads should be kept clean. In order to maintain the device’s
performance, DO NOT rub the gel pads with your hands, a wipe, or cotton wool.
2. The gel pads tend to lose their adhesion over time, therefore weakening the intensity level.
Moisten finger with a few drops of water and rub it gently against the gel pads to improve
contact.
3. If moistening the gel pads does not improve the signal, replace the old pads with a pair of
new ones. Refer to pages 5 and 6, section 1 : Sticking on the Gel Pads. For the best results we
recommend that you replace the gel pads after 30 nights of usage.

16
Cautions
1. The intensity level should be adjusted to ZERO before use.
2. DO NOT wear the device if the self-adhesive gel pads are not attached correctly. Also,
when you are pressing the test button, DO NOT touch the black rubber pads or gel pads
with your fingers.
3. DO NOT wash your hands when you are wearing the device. It is not waterproof.
4. When you are wearing the wrist strap, DO NOT pull the strap too tightly; it could result in
poor circulation or will shorten the lifespan of the device.
5. DO NOT use with other medical electronic devices AT THE SAME TIME.
6. The device should be kept out of the reach of children.
7. Batteries should be handled under adult supervision. If batteries leak and come into contact
with the skin or eyes, wash well with clean water. Do not use rechargeable batteries. Please
follow manufacturer’s instructions regarding safe use and disposal of batteries.
Maintenance and Cautions

17
Harvard Medical Devices Ltd.
Unit 1301-2, 13th Floor, Railway Plaza,
39 Chatham Road South, Tsimshatsui,
Kowloon, Hong Kong.
Kinetik Medical Devices Ltd.
Made in P.R.C.
www.lloydspharmacy.com
Harvard House, The Waterfront, Elstree Road,
Elstree, Herts WD6 3BS, UK
Do not dispose of electrical and electronic equipment
with your normal household waste.
Please contact your local council regarding how and where
to dispose of these products in your area.
Warranty
This product is guaranteed for a period of one year from the date of purchase against mechanical
and electrical manufacturing defects. There are no user serviceable parts inside the device. Any
attempted repair by unauthorised personnel will invalidates the warranty. This does not affect your
statutory rights.

User Manual
Model LSS1
StopSnoring
Advance
Available accessories
Last revised: 23/06/2010
