LLOYTRON F2610GR User manual

MODELS: F2610GR
OPERATING INSTRUCTIONS
700w Mini Oil
Radiator

2
FEATURES
thank you
Thank you for the purchase of this quality LLOYTRON product. Used carefully and in accordance with the
instructions enclosed, it should give you trouble free service over a long period of time. Please keep these
instructions for future reference.
• Adjustable thermostatic control
• Frost watch protection
• Handle for easy movement
• Wide stable base
• Indicator light
SPECIFICATIONS
Operating Voltage: 220-240v ~ 50Hz
Power Consumption: 700w

3
IMPORTANT SAFEGUARDS AND PRECAUTIONS
SAVE THESE INSTRUCTIONS
• Save these instructions.
• Read all instructions carefully
• For Household Use only. Not intended for commercial use.
• Only for use indoors.
• Do not use outside or in damp conditions.
• Before plugging into mains socket, check whether supply line voltage and current rating are in
compliance with the rated electrical parameters shown on the rating label.
• Keep away from hot surfaces, such as gas or electric hobs and ovens etc
• Do not use for any purposes other than the appliances intended use.
• This appliance is not intended to be operated by means of an external timer or separate remote control system.
• To prevent damage to the mains cord, do not let it pass over sharp corners, edges or hot surfaces.
• If the supply cord is damaged, do not use. Check before each use!
• The supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.
• Do not use if any part of this appliance is damaged in any way.
• Always unplug when not in use.
• To prevent against the risk of electric shock, do not submerge any part of this appliance in water, unless
advised in this manual.
• Thisapplianceshouldonlybeusedonaatsurface.
• Do not cover the appliance whilst in operation.
WARNING! To avoid overheating, DO NOT COVER the heater!
- Do not use in bathrooms or in the vicinity of a bathtub, shower, or near a washbasin.
- Do not use near water.
- Do not use in vehicles.
- Donotusenearcombustibleitems,suchasgasoline,paint,ammableliquids,clothes,furnitureor
curtains etc.
- Keep at least 100cm away from any wall or other objects, including people.
- Do not use this heater with a programmer, timer or any other device that switches the heater on
automatically,sinceareriskexistsiftheheateriscoveredorpositionedincorrectly.
-Alwayskeeponoor.
- Do not use with extension lead unless rated at 15A or higher.
- Always check the product for transit damage before operation. If damaged, DO NOT USE!
- Caution should be heeded near hot surfaces on this appliance.
- Keep away from children.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children shall not play with this appliance.
• Cleaning and user maintenance shall not be made
by children without supervision.

4
LOCATION OF CONTROLS
1. Heat Controls
2. On / Off Switch
3. Carry Handle
4. Wide Base
2
4
1
3

5
OPERATION
WARNING - DO NOT OPERATE IF THERE ARE SIGNS OF OIL LEAKAGE.
OPERATION:
1. Select a location indoors for the heater, away from electrical power cords, curtains and other
furnishings. DO not place the heater directly beneath an electrical outlet or against paperboard
 orlow-densitybreboard.
2. Push the power switches to the off position and turn the thermostat low before plugging in the
radiator.
3. Plug the heater into AC Mains outlet.
4. The Heat Setting is controlled by the dial.
5. Switch the heater on.
The operating temperature is selected by adjustment of the thermostat.
6. Todeterminethecorrectoperatingtemperatureforyourconditions,whenyourstswitchthe
unit on, turn the thermostat to its maximum position. When the unit reaches the required
temperature, slowly turn down the thermostat, until the unit switches off. The temperature will
now be kept constant. When the temperature falls the unit will come on again
CAUTION: THIS UNIT SHOULD ONLY BE OPERATED IN AN UPRIGHT POSITION.
AUTOMATIC SAFETY CUT OFF
A thermal overload protector is built in to prevent the unit from overheating. When the unit exceeds the
speciedoperatingtemperature,theheaterwillautomaticallyshutoff.Itwillonlyresumeoperationwhen
the user resets the unit.
RESETTING THE HEATER
1. Turn the heat setting to the OFF position.
2. Unplug the heater and wait 10-15 minutes for the unit to cool down.
3. Inspect and remove any objects on or neighbouring to the heater that may cause high temperature.
4. After 10-15 minutes, plug the unit in again and operate normally.

6
MAINTENANCE:
This appliance has been designed to operate over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper care and regular cleaning.
WARNING! Before performing any maintenance or cleaning on this appliance, disconnect the appliance
from the electricity supply.
MAINTENANCE:
1. Any ventilation slots should be occassionally cleaned with a clean, dry paint brush.
2. The exterior surface should be cleaned with a damp cloth only.
DO NOT USE STEEL WOOL, SCOURING PADS OR ABRASIVE CLEANERS ON NON-STICK SURFACES.
CLEANING AND CARE

7
WEEE/ENVIRONMENTAL PROTECTION
Disposal of Electrical and Electronic Equipment
Do not dispose of this product with household waste. For the proper treatment, recovery and
recycling please take this product to the appropriate waste collection point. If you are unsure
where this may be, please contact your local authority. Improper disposal may be harmful to
the environment.
Yourapplianceoperateson220-240V~50HzACMainsandcomesttedwitha3-pinBSIApprovedplug,so
thatitisreadyforusebysimplypluggingintoACMains.Shouldyouneedtochangeorretaplug,proceed
as follows: -
IMPORTANT:
The wires in the mains lead are coloured in accordance with the following code:
BLUE: NEUTRAL (N)
BROWN: LIVE (L)
GREEN AND YELLOW: EARTH (E)
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The BLUE wire must be connected to the terminal which is marked with the letter “N” or coloured BLACK.
The BROWN wire must be connected to the terminal which is marked with the letter “L” or coloured RED.
The GREEN AND YELLOW wire must be connected to the terminal which is marked with the letter “E”, the
symbol or coloured GREEN.
DO NOT CONNECT EITHER WIRE TO THE EARTH TERMINAL OF A 3-PIN PLUG
Always ensure that the Mains Cord is located into the Plug through the Cord Guard or Cable Clamp, and that
the Cord Guard screws are tightened to clamp the Cord (outer sheath and inner coloured wires) in position
inthePlug.MakesurethePlugtopisalsottedsecurely.
The supply cord cannot be replaced. If the supply cord is damaged, the appliance should be scrapped.
5A FUSE
(L) LIVE
(N) NEUTRAL
(E) EARTH
UK PLUG REWIRING
This appliance must be protected by a 5 Amp fuse in a 13 Amp type (BS1363) plug.
Should you need to replace the fuse, use only an ASTA approved BS1362 fuse.

call: 08454 81 8808
email: [email protected]
web: www.lloytronhelpdesk.com
If you have any queries about this product, there are three ways to contact our customer service department:
TondmoredetailsonawiderangeofLloytronproductspleasevisitourwebsiteatwww.lloytron.com
Lloytron plc, Laltex House, Leigh Commerce Park, Greenfold Way, Leigh, Lancashire, WN7 3XH. England, U.K
CUSTOMER SERVICES
2011/65/EC
