LMI 241 Series Quick guide

101 N. Alloy Dr.
Fenton, MI 48430
Ph [phone]
Fax [phone]
[e-mail]
Research, Development and Manufacturing of Precision Measuring Systems
CONFIGURATION and MASTERING for the
LMI 241 or LMI 241-B to the LMI 440 or ASI DataMyte 501
2
3
4
1
Required Equipment:
1LMI 440 or ASIDataMyte 501
2LMI 241 or 241-B transducer
3LMI 720 master block
4LMI 6025 6 pin – 6 pin cable
This instruction will outline:
I. GAGE CONFIGURATION .........................................................................................................2
Flush Condition.........................................................................................................................2
Gap Condition ...........................................................................................................................6
II. MASTERING INSTRUCTIONS .................................................................................................9
III. Verification of the Mastering .....................................................................................................11
Flush Verification ...................................................................................................................11
Gap Verification......................................................................................................................12
Form: CA 030 1-4-05 R:\Quality\Calibration Instructions\CA 030.docR:\Quality\Calibration Instructions\CA
030.doc
Page 1 of
13

101 N. Alloy Dr.
Fenton, MI 48430
Ph [phone]
Fax [phone]
[e-mail]
Research, Development and Manufacturing of Precision Measuring Systems
I. GAGE CONFIGURATION
Section I is a one time setup. After a successful gage configuration is finished there should be no
need to repeat section I. It is recommended to store a copy of the gage files onto a personal
computer or laptop. Consult the collector manual or, if purchased, the TranSend manual for
further details.
Flush Setup
This configuration will produce a negative value for flush when the tip extends beyond the
nominal (master) point. To reverse the values enter -10 in step 10.
1. Press <menu> to turn on the collector.
2. Press ▼to highlight “Gage”.
3. Press <enter>.
Form: CA 030 1-4-05 R:\Quality\Calibration Instructions\CA 030.docR:\Quality\Calibration Instructions\CA
030.doc
Page 2 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
It is recommended to assign simple user name to the gage files such as; flush, margin, etc. This
will help to identify different setups.
4. To assign the gage file name, press ▲or ▼to highlight “G2”* in the “Gage List” and press
<enter> on the collector.
*G2 has the ability to support “sub files”. These are files that allow multiple styles or
configurations of gages to be used by the same collector. To create sub files highlight G2 and press
►►, this will create a sub file of G2a. Each press of ►► creates another sub file. The balance of
this instruction will be based on G2
5. Use the ▲,►,◄, or ▼to highlight the first character of the new file name then press
<enter>, repeat the process until the gage file name is spelled. Then press ►► to accept the
new name.
6. Press the ►to “Configure”, by
default the screen may read as
follows.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 3 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
7. The “Configure Gages” screen needs to be set as follows. Failure to set this screen properly
may cause undesired results.
8. If changes to this screen are needed, press ▲or ▼to highlight either “Type”, “Master Type”,
“Master With”, or “Zero Before Read” then press <enter> to toggle the different choices.
9. To make changes to the “Scale” or “Zero Master” press ▲or ▼to highlight “Scale” or “Zero
Master” and press <enter>. This will bring up the numeric keypad. Key in the new value and
press ►► to accept.
“Gage Port G2” must
be matched to “Master
with G3” to calibrate
both flush and gap at
the same time.
If the “Gage Port” is
set to “G2a” then the
“Master” needs to be
G3a
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 4 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
10. Key in the desired value buy using the ▲, ▼, ►, or ◄to highlight the first number, press
<enter>. Repeat until the number is completed and press ►► to accept the new value.
11. Once the “Configure Gages” screen is set press ◄and a pop up will appear if any changes
were made. Highlight “Save to current gage” and press <enter> if the changes were
intentional. If a setting was changed by mistake or you were not done in “Configure Gages”
highlight “Cancel” and press <enter>.
Flush configuration is complete.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 5 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
Gap Setup
This configuration will produce a negative value for flush when the tip extends beyond the
nominal (master) point. To reverse the values enter -10 in step 10.
11. To assign the gage file name, press ▲or ▼to highlight “G3”* in the “Gage List” and press
<enter> on the collector.
*G3 has the ability to support “sub files”. These are files that allow multiple styles of gages to be
used by the same collector. To create sub files highlight G2 and press ►►, this will create a sub
file of G3a. Each press of ►► creates another sub file. The balance of this instruction will be
based on G3
12. Use the ▲,►,◄, or ▼to highlight the first character of the new file name then press
<enter>, repeat the process until the gage file name is spelled. Then press ►► to accept the
new name.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 6 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
13. Press the ►to “Configure”, by default
the screen should read as follows.
14. The “Configure Gages” screen needs to be set as follows. Failure to set this screen properly
may cause undesired results. The top screen shows a standard LMI 241 configuration, the
bottom screen shows a standard 241-B configuration.
Configure Gage setup for LMI 241 gap
“Gage Port G3” must
be matched to “Master
with G2” to calibrate
both flush and gap at
the same time.
This configuration will
produce a negative value
when the LMI 241 is
extended from the master
point (nominal). To make
the LMI 241 read positive
when extended from the
nominal change the scale
to “-10”
Configure Gage setup for LMI 241-B gap
This configuration will
produce a 3mm value
when the LMI 241 is at
the master point
(
nominal
)
.
“Gage Port G3” must
be matched to “Master
with G2” to calibrate
both flush and gap at
the same time.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 7 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
15. If changes to this screen are needed, press ▲or ▼to highlight either “Type”, “Master Type”,
“Master With”, or “Zero Before Read” then press <enter> to toggle the different choices.
16. To make changes to the “Scale” or “Zero Master” press ▲or ▼to highlight “Scale” or “Zero
Master” and press <enter>. This will bring up the numeric keypad. Key in the new value and
press ►► to accept.
17. Key in the desired value buy using the ▲, ▼, ►, or ◄to highlight the first number, press
<enter>. Repeat until the number is completed and press ►► to accept the new value.
18. Once the “Configure Gages” screen is set press ►and a pop up will appear if any changes
were made. Highlight “Save to current gage” and press <enter> if the changes were
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 8 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
intentional. If a setting was changed by mistake or you were not done in “Configure Gages”
highlight “Cancel” and press <enter>.
Configuration of the LMI 440 or ASIDataMyte 501 is complete.
II. MASTERING INSTRUCTIONS
1. Connect the transducer to Gage Port 2/3 of the data collector.
2. Press <Menu> to turn on the collector.
3. Press ▼to highlight “Gage”.>.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 9 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
4. Press <enter>.
5From the gage list use the ▲or ▼keys on the data collector to choose gage file G2 and press
◄on the collector.
6“Master” will be highlighted in screen
header and “G2” is identified as “Gage
Port”. If G2 is not the Gage Port press
the ►► or ◄◄ until G2 appears.
“Master”
highlighted
“G2” is the
Gage Port
7. Extend the flush tip and gap peg of the LMI 241 or 241-B. With "Master Low" highlighted on
the collector, press <enter>.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 10 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
8. Fully compress the flush tip and gap peg of the LMI 241 or 241-B. With "Master Hi"
highlighted on the collector press <enter>.
9. Place the gage in the LMI 720 master block, retract the gap peg so it will insert into the gap slot.
With "Master Zero" highlighted on the collector press <enter>.
Mastering for the 241-BW series is complete.
III. Verification of the Mastering
This process can be performed to verify the mastering of the LMI 241 or 241-B after being
mastered.
Flush Verification
Value reading
for Flush
extended
Gage Port
“G2”
1. With the flush tip
extended, observe
the value in the
“Master Gages”
screen of “Gage
Port G2” in the
collector.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 11 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
2. Retract the
flush tip,
Observe the
value in the
“Master Gages”
screen of “Gage
Port G2 in the
collector.
Value reading
for Flush
extended
3. Add the results of step 1 and step 2 together (disregard the minus sign), the result must be
10.00mm +/- 0.04mm. This example step 1 is -5.002 and step 2 is 5.002, added together
without the minus sign equals 10.004mm.
4. Insert the gage
into the master
block and observe
the value in the
“Master Gages”
screen of “Gage
Port G2 in the
collector.
Gap Verification
Value reading
for flush in
the master
p
osition
Ga
g
e
p
ort “G3”
5. Press ►►
on the
keypad of
the collector
to change
the display
from G2 to
G3.
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 12 of
13

E-mail support
[e-mail] LMI Corporation Phone support [phone]
Form: CA 030 December 28,
2004 R:\Quality\Calibration Instructions\CA 030.doc Page 13 of
13
6. With the gap peg extended, observe the value in the “Master Gages” screen of “Gage Port
G3” in the collector.
LMI 241 reading LMI 241-B reading
Value reading
for Gap
extended
7. Retract the gap peg, observe the value in the “Master Gages” screen of “Gage Port G3” in the
collector.
LMI 241 reading LMI 241-B reading
Value reading
for Gap
retracted
8. Add the results of step 6 and step 7 together (disregard the minus sign), the result must be
10.00mm +/- 0.04mm. This example step 6 is -4.502 and step 7 is 5.502, added together
without the minus sign equals 10.004mm.
9. Insert the gage into the master block and observe the value in the “Master Gages” screen of
“Gage Port G2 in the collector.
LMI 241 reading LMI 241-B reading
Value reading
for gap in the
master
p
osition
Verification Complete
