LMS 1 Series User manual

Cooled Incubators
Series 1, 3 & 4
Instruction Manual

2
Instruction Manual for LMS Cooled Incubators
Series 1, 3 & 4
Series 1 Models
305 -60 litre capacity
303 -180 litre capacity
250 -250 litre capacity
Series 3 Models
100 -90 litre capacity
200 -227 litre capacity
300 -290 litre capacity
400 -450 litre capacity
Series 4 Models
600 -600 litre capacity
1200 -1200 litre capacity

3
INTRODUCTION
We thank you for purchasing a LMS Cooled Incubator, which we trust, will give you many years of
satisfactory service.
Manufactured in the United Kingdom using the finest materials and modern production techniques
your Cooled Incubator has already undergone extensive testing in our factory.
For correct operation it is essential that you observe the operating and maintenance instructions in this
manual.
EXPLANATION OF SYMBOLS USED
Electrical Earthing Point
Electrical Hazard Warning
(Mains Electrical Supply Within)
Exhibited where an internal power socket is fitted
General Safety Instructions
The physical and chemical properties of your load should be carefully considered with regard to the
effect this may have on the LMS Cooled Incubator. They are not internally sparkfree (available on
certain models) or explosion proof. Therefore solvents and/or chemicals which may form a flammable
mixture together with air are unsuitable for these cabinets; otherwise considerable damage can occur.
Transportation
Series 1: If these cabinets have to be carried it is recommended that at least 2 people assist and
that gloves should be used on all occasions. The cabinet should be kept upright.
Series 3 & 4: These cabinets are supplied on pallets and it is recommended that these are moved by
pallet truck or fork lift by competent persons, including someone to assist in
stabilizing the load. The cabinet should be kept upright.
Serial Number Plate
The Serial Number Plate contains the year of manufacture, in the following format: -
xxxx/99x = year of manufacture 1999
xxxx/01x = year of manufacture 2001
Aux. Circuit

4
LMS COOLED INCUBATORS
Quick Start Instructions
Commissioning
•Remove all packing materials (CARE: door keys wrapped in shelf packaging).
•Check for signs of external damage (this must be reported to the supplier
immediately).
•Check supply voltage and cycles to ensure it is in accordance with your supply.
•Before connecting to the mains, please allow the Incubator to stand for a
minimum period of 24 hours to allow the refrigerant to settle after transportation
(CARE: failure to comply with this instruction may cause damage to this
instrument and invalidate the guarantee).
•After 24 hours you may switch the incubator on and start your application.
•Please ensure refrigeration switch on the rear of the unit is switched on.
•Maintain a minimum 100mm air gap around the incubator and ensure it is not
situated in direct sunlight.
Temperature Control
•The digital controller has been factory tuned for optimum performance and set at
20ºC.
To obtain the required temperature:
Press and hold the * button, this will display the set point (with the
programmable temperature controller the set point is the lower of the two
displays in orange) –press either the ? to increase or ? to decrease. When
the desired set point is reached release the * button. The incubator will now
start to react to your new set point temperature.
Temperature Controller with Programming
It is necessary to write a program before a program can be run. There are no stored
programs within the temperature controller at delivery unless this has been specified
otherwise. See general programming information Section 5

5
CONTENTS
Section 1: General Description
1.1 Introduction
1.2 Construction
1.3 Temperature Control
1.4 Cooling
1.5 Air Flow
Section 2:Initial Examination and Installation
2.1 Commissioning
2.2 Controls
2.3 Temperature Control
2.4 Indicator & Control Layout
Section 3:Optional Extras Where Fitted
All Models
3.0 Automatic Dual Temperature Cycling
3.1 Automatic Defrost
3.2 High/Low Alarm Option
3.3 Inner Perspex Door
3.4 Chart Recorder
Section 4: Maintenance & Repair
4.1 Equipment Ratings
4.2 Replacement of Fluorescent Lamps (When Fitted)
4.3 Routine Maintenance
Section 5: Guarantee
5.1 Terms & Conditions for LMS Guarantee
Section A: General Programming Information For Programmable Models
A.1 Introduction
A.2 Assigned Functions
A.3 Heating Function
A.4 Alarm Function
A.5 Illumination Function
A.6 Computer Connection
A.7 Programming Tips
A.8 A Program
A.9 Programming with Audible Alarm System
A.10 Audible Alarm System & Single Set Point Controller
A.11 Programming with Illumination
A.12Time
A.13 Extending Time
A.14 Set Point Ramp Rate
Section B: Programming Guides & Examples

6
Section 1
GENERAL DESCRIPTION
1.1 INTRODUCTION
The standard range of LMS cooled incubators comprises of nine models, all of
which are available with a range of optional extras to suit individual
requirements. A further two models, 410XAL and 610XAL, which have
special built in features, are also available. Details on request.
1.2 CONSTRUCTION
The outer case of all models in Series 1 and 3 is of sheet steel finished in
white stoved enamel. Foam insulation is used, to ensure maximum insulation
against external ambient temperature. The internal liner of models in Series 1
is of a high impact vacuum formed plastic with a minimum of crevices, and all
corners are radiused. Models in Series 3 have an unobstructed working space
fabricated from polished stainless steel complete with multi position plastic
moulded shelf supports, which allow the three white plastic coated steel
shelves to be randomly positioned to suit individual requirements.
All cooled Incubators within the LMS Series 1 and 3 range incorporate both a
door lock and magnetic gasket with all control features being set into a control
panel and positioned so as to minimise the risk of accidental alteration. Series
4 models have both a stainless steel exterior and interior and come with 5
stainless steel shelves (model 600) and 10 stainless steel shelves (model 1200).
1.3 TEMPERATURE CONTROL
The temperature control method utilises a controller offering digital selection
and readout of temperature.
1.4 COOLING
Cooling is provided by a hermetically sealed refrigeration system which can be
independently switched off for defrosting purposes, or for operation at
temperatures 10ºC or more above ambient. All LMS Cooled Incubators
comply with the latest CFC-free regulations.
1.5 AIR FLOW
A full air flow system is used. The airflow being at low velocity but high
volume.
Section 2

7
INITIAL EXAMINATION AND INSTALLATION
2.1 COMMISSIONING
(i) Remove all packing materials.
(ii) Check for signs of external damage (this MUST be reported
immediately to the Carrier and Supplier).
(iii) Check that the electrical supply details on the information Rating Plate,
which is fitted to the rear panel, are in accordance with the available
electrical supply.
(iv) All cooled incubators are supplied with a 3 pin moulded plug, which if
not suitable may be replaced by an electrician or other competent
person. Connect conductors as follows: BROWN to live, BLUE to
neutral, GREEN/YELLOW to earth.
(v) Position the cooled incubator so that approximately 100mm of free
space exists around the cooled incubator.
(vi) Adjust levelling foot or feet (depending on model) so that the cooled
incubator sits firmly. Lockable castors (where fitted) MUST be locked.
(vii) Please ensure that the refrigeration switch, which is fitted on the rear
panel on the right hand side, is in the ON position (down).
(viii) After the cooled incubator has been sited allow 24 hours before
switching on.
2.2. CONTROLS –Common to All Models
2.2.1 Fuse
A 1.25" TYPE F cartridge fuse in a screw fitting carrier is located at
the rear of the control compartment adjacent to the Serial Number plate
on which the fuse value is indicated.
2.2.2. Refrigeration Switch
To the rear of the control compartment on the right hand side is the
refrigeration isolator switch. This switch should always be in the ON
position (down) except (A) when the cooled incubator is to be used at
prolonged periods set at an operating temperature of 10ºC or more
above ambient, or (B) when defrosting the cooled incubator.
2.2.3 Non-Adjustable Overheat Protection Device

8
This device is fitted within the air mixing chamber to safeguard the
cooled incubator should a fault condition of overheating develop.
Operation of this device will be indicated by the Red ‘safety’ neon light
on the front panel being illuminated. In the event of this happening the
cooled incubator must be switched off until the reason for the fault
condition is established and the fault itself is rectified.
2.3 TEMPERATURE CONTROLLER
The Digital Controller has been factory tuned for optimum performance. To
obtain the required operational temperature press and hold the * button, the set
point temperature will be displayed (with the programmable temperature
controller the set point temperature, is the lower of the two displays, in
orange). To alter the set point temperature press and hold the * button and
press either the σor τbuttons as required, σto increase temperature, τto
decrease. When the desired set point temperature is achieved, release the *
button. The interior temperature of the cooled incubator will now be displayed
and will gradually adjust until the set point temperature is reached.
2.4 INDICATOR & CONTROL LAYOUT
Series 1 and 3
The Red ‘safety’ neon only illuminates when an over temperature fault
condition occurs –see Section 2.2.3.
The Temperature Controller display will be continuously illuminated whilst
the cooled incubator is connected to a mains electrical supply.
Series 4
The Red ‘safety’ neon only illuminates when an over temperature fault
condition occurs –see Section 2.2.3.
The Green neon light and Temperature Controller display will be
continuously illuminated whilst the cooled incubator is connected to a mains
electricity supply.
Section 3

9
OPTIONAL EXTRAS WHERE FITTED
ALL NON PROGRAMMABLE MODELS
3.0 AUTOMATIC TEMPERATURE CYCLING
On these models, the digital controllers are mounted either side of a time clock
and will be illuminated in turn according to the time clock settings. (NB –On
changeover the controller will briefly indicate 18.8.8 for few seconds –this is
quite normal).
Changing from one controller to the other is done automatically by a time
switch which can be one revolution every 24 hours or one revolution every 7
days, depending on whether a 24 hour or 7 day clock is fitted.
After removing the time switch cover, time settings can be adjusted by pulling
outwards the segments and reinserting them according to requirements.
To set the time initially, the clock hands can be turned forwards in time
(clockwise) but not backwards (anti clockwise).
3.1 AUTOMATIC DEFROST
On Series 3 and optionally on Series 1, the cabinet is set to defrost for a
duration of 10 minutes in every 6 hours. This defrost will give a slight rise in
air temperature. If this rise should create any problems the defrost can be
over-ridden by the defrost isolator switch at the back of the electrics
compartment. On Series 4 the defrost occurs 4 times every 24 hours;
duration is controlled by the ice build up internally.
On Series 1 and Series 3 cabinets, any defrost water drains away to a tray
mounted on the compressor. On Series 4 cabinets the water drains into a tray
(supplied) which must be fitted in the special tracks mounted underneath the
cooled incubator during installation. On all models this water evaporates
harmlessly away.
3.2 HIGH/LOW ALARM OPTION
The high/low alarm is a manually adjusted alarm option fitted to the
instrument’s front panel.
In the event of an alarm condition, the following action will be taken:
An audible alarm will sound and a secondary safety system will be activated,
preventing the cooled incubator temperature from rising above or falling
below the set alarm limits.

10
3.3 INNER PERSPEX DOOR
On incubators fitted with this feature and depending on the temperature
difference between the inner working chamber and the space between the
inner and outer doors, some slight twisting may occur.
3.4 CHART RECORDER
Chart Paper Loading (see below)
1. Remove front bezel by simultaneously pressing the retaining
catches on each side.
2. To gain access to the chart paper cassette (1). First unlock the
meter assembly by moving the locking lever (2) to the left and
hinge outwards. Remove cassette by gripping firmly and
pulling forward.
3. To load chart paper. First fit spindle (3) into new roll of chart
paper. Clip roll into spindle retaining slots (4) on the cassette
with the paper unrolling from the bottom. With the chart
retaining bracket (5) lifted, feed the paper onto the sprocketed
paper driving wheels (6). Close chart retaining bracket (5) and
check paper feed by operating the manual feed wheel (7).
4. Replace cassette to engage chart drive gear (9) and close hinged
meter assembly ensuring that the locking lever (2) latches
closed.
Caution: Take care not to damage the meter pointer or imprint stylus when
closing the meter assembly.
Operation (see figure below)
Load chart paper as previously described. If required, the meter pointer/stylus
(8) can be set to mechanical zero, with power off, by carefully turning the zero
adjustment screw (11).
LMS Chart Recorder

11
Note that the stylus may not move freely if the recorder is in the imprint section of its
operating cycle with the stylus pressed against the chart paper. In this case the
recorder chart motor should be operated for a few seconds until the imprint pressure is
released, or the imprint drive wheel (12) can be manually rotated. The chart paper can
be manually advanced by operating the manual paper feeding wheel (7) to set the
desired zero time position.

12
Section 4 MAINTENANCE & REPAIR
4.1 EQUIPMENT RATINGS
220/240V AC, 50 Hz. Up to 11 amps max. (see rating plate for details). The
cooled incubator is designed to operate in an environment from +10ºC to 30ºC
with a relative humidity from 5 -85% RH non-condensing. Correct
functionality of the cooled incubator or its safety features cannot be guaranteed
if it is used outside these ratings.
4.2 REPLACEMENT OF FLUORESCENT LAMPS (WHEN FITTED)
This must be carried out with the mains power switched off and by a
competent person or engineer. Replacement lamps must be of the same size,
wattage and voltage as originals.
4.3 ROUTINE MAINTENANCE
It is recommended that the cooled incubator be inspected annually by a
competent service engineer. The exterior and interior surfaces can be
maintained in as new condition using standard non-abrasive or non-corrosive
cleaners. Solvent based cleaners must not be used. Switch off during all
cleaning operations. Allow drying before switching on. On Series 3 and 4
cabinets, the condenser should be brushed clean every six months.
A complete defrost is recommended periodically depending on application
To effect a defrost complete the following: -
A. Switch off the cooled incubator at the mains switch.
B. Allow the cooled incubator’s interior to attain ambient temperature by
opening the door.
C. If necessary, to speed up defrosting, start a heating cycle by setting the
temperature to 35ºC and turning the refrigeration off.
D. Allow the cabinet to completely dry-out inside before reusing (the
process usually takes 24 hrs). Please ensure that the cabinet door
remains open during this process.

13
Section 5
TERMS AND CONDITIONS
FOR LMS GUARANTEE
1. Damage on delivery must be reported in writing immediately to LMS.
2. Equipment must be installed as per instructions.
3. Equipment must be used, serviced and maintained as per instructions.
4. Equipment must not be modified electronically or in relation to the
refrigeration/air flow system unless LMS agreement is obtained.
5. Equipment malfunction under the terms of the guarantee must be reported to
LMS.
6. LMS reserves the right to repair or replace damaged on delivery or
malfunctioning equipment.
7. If it is found subsequently that the purchaser of the equipment was responsible
for the damage/malfunction a charge will be made by LMS including any
carriage charges.
8. If it is necessary to return equipment to LMS, the equipment must be packaged
so as to prevent any damage.
9. Guarantee is for 2 years and cannot be passed on to a subsequent equipment
owner.
10. To register for the 2 year Guarantee please complete and return the enclosed
Guarantee Card.
In all cases please quote the following details: -
Model
Serial No.
These details may be obtained from the Serial Number plate on the back of the
instrument.

14
FOR SPARES AND SERVICING
Please contact:
LMS Ltd.
The Modern Forge
Amherst Hill
Riverhead
Sevenoaks, Kent
TN13 2EL
Tel. [phone]
Fax. [phone]
Email: [email protected]
www.lms.ltd.uk

15
