LNS TRYTON 112 Installation and operation manual

ENG

START UP MANUAL 1
TRYTON 112 CNC
E-1
TABLE OF CONTENTS
1. SETTINGS RELATED TO INSTALLATION 2
1.1 End of bar position 2
1.2 Top-cut position 4
2. MECHANICAL SETTINGS 2
2.1 Changing the collet 6
2.2 Feed pressure and speed 7
2.3 Adjusting the jaws 8
2.4 Hybrid barrel (option) 10
3. LATHE SET-UP 12
3.1 Spindle reduction tubes 12
3.2 Profiled bars 12

2START UP MANUAL
TRYTON 112 CNC
1. SETTINGS RELATED TO INSTALLATION
1.1 End of bar
The end of bar position determines the moment when the bar feed enters the loading cycle
Regardless of the length of the bars, or parts, the end of bar position is always the same.
Usually, the end of bar position is adjusted as closely as possible behind the clamping
system of the lathe (approximately 5 mm or a 1/4" behind the chuck jaws or collet pads).
The length of the remnant may vary :
CThe minimum remnant length (Min) is obtained when the feeding pusher is just behind
the clamping device while the last part is being machined.
CThe maximum remnant length (Max) is obtained when there is not enough material for
machining an additional part (Lp - 1 mm).
Maximum remnant length = Lp - 1 mm + Min

START UP MANUAL 3
TRYTON 112 CNC
Regulation :
In manual, advance the pusher to just behind the chuck jaw, to the desired end-of-rod
position (see previous illustration).
•To the rear of the bar-feeder, undo the fixing screw (A) holding the end-of-rod probe
support (B) (SQ8).
•Slide the support (B) forwards (1) or backwards (2) until the probe indicator light
comes on.
1. The length of the remnant increases
2. The length of the remnant decreases
•Fix in that position.
•Draw back the pusher then advance it again to ensure that it stops in the set position.
Screw-cutters and lathes with mobile headstocks
•Set the end-of-bar 5 mm
behind the chuck jaw, when
the headstock is in the rear-of-
part position.

4START UP MANUAL
TRYTON 112 CNC
1.2 Top-cut position
During the loading cycle, the bar is automatically loaded and positioned into the spindle,
outside the clamping device of the lathe (chuck or actuator).
This positioning corresponds to avalue (Z) programmed by the operator, which is equal to
the distance between the measuring cell and the position of the material in the lathe
clamping device.
With this system, the setting is the same for any bar length.

START UP MANUAL 5
TRYTON 112 CNC
Setting :
Important : Before handling the barfeeder, stop the lathe at the end of part cycle !
1. Press the [STOP] key.
2. Press the [MENU] key.
The display reads :
PARAMETERS RELATED
TO START UP
3. Press the key attributed to the icon [PAGE DOWN].
The display reads :
SETTINGS FOR
POSITIONING
4. Press the key attributed to the icon [ENTER].
The display reads :
POSITION OF THE CUT OFF
(TOP CUT) **** MM
5. Enter the new value with the numerical keys
6. To validate the new TOP CUT position, keep [ENTER] pressed until the icon
disappears.
7. To exit the set mode, press the [MENU] or [STOP] key.

6START UP MANUAL
TRYTON 112 CNC
Note :
If one of the
elements has
to be
replaced, the
pusher may
nonetheless be
stripped.
Once the
replacement
parts have
been fitted, it
will have to be
reglued
2. MECHANICAL ADJUSTMENTS
2.1 Changing the collet
The pushers are delivered assembled and the various components that make them up are
glued together.
Only the collet is interchangeable according to the diameter of bar.
Procedure :
Important: Before any manipulation, stop the lathe at the end of a piece!
1. Press the [STOP] key.
2. Press the [MENU] key.
The display reads :
PARAMETERS RELATED TO
START-UP
3. Press the key corresponding to the [ENTER] icon.
The following text appears on screen :
MATERIAL DIAMETER
4. Advance the pusher out of the connector with the stationary control.
5. Unscrew (1) the collet (A) of the rotating ferrule (B), then strip (2) the elements.
Install the new collet.
6. With the stationary control, move pusher back into the connector.
7. To exit adjustment mode, to press the [MENU] or [STOP] key.

START UP MANUAL 7
TRYTON 112 CNC
Note :
When
machining
tubes, it is
recommended
to plug the
rear end of
the material
so that the oil
from the bar-
feeder and the
cutting fluid
do not mix
To order collets, indicate the article number, followed by the desired internal diameter.
Exterior collet Ø Article No. Interior collet Ø Barrel
6016.15.043 max. 5 mm 45 tubes (*)
7016.15.033 max. 6 mm 36 tubes (*)
10 016.15.023 max. 8.5 mm 24 tubes (*)
12 016.15.013 max.11 mm 24 tubes (*)
Example : 016.15.043 / 2.5
Recommended collet tightening range : ± 0.03mm
(*) It is possible to replace the barrel and so to increase or decrease the capacity of the bar-
feeder. Other elements such as the connector must also be replaced. Instructions
indicating the replacement procedure is delivered with the material..
2.2 Feed pressure and speed
To adjust the feed pressure and speed, the bar-feeder must be in automatic mode. Block the
pusher at the exit of the barrel then proceed as follows :
•The hydraulic pressure indicated on the manometer (A), can be set to between 0.8 and
5 bar, according to the diameter of the bars and the guidance tubes. Screwing down the
regulator (B), increases the pressure.
•The feed speed can be adjusted to between 50 and 200mm per sec. Close the regulator
(C) slowly until the pressure falls. Reopen until the pressure stabilises. In this position,
the feed speed is at its minimum. To increase it, unscrew the regulator (C).
Important:Forthepressuretobe adjusted,thespeedregulator mustnotbe closed
completely

8START UP MANUAL
TRYTON 112 CNC
Note :
To load
shaped bars,
the feeder
must be fitted
with the
appropriate
gripping jaws
2.3 Setting the jaws
The mobile vice jaws must be adjusted to every change of diameter.
CPlace one or more bars of the new diameter in the barrel.
CIndex the barrel to bring a bar (A) into line with the feeder collet.
CAdvance (1) the connector to about half of its travel.
CPull the bar and move it up to the collet
CLoosen the locking knobs (B) of the upper and lower jaws of the mobile vice
CLoosen the nuts (C) then the bolts (D) of the upper and lower jaws (E), so that theyopen
(2).

START UP MANUAL 9
TRYTON 112 CNC
CDraw back (3) the mobile vice (F), until the roller bearings are on the flats of the cam.
CScrew (4) the bolt (D) until the bar, resting on the lower jaw, is centred on the collet.
CScrew (5) the bolt (D) of the upper jaw until it is resting against the bar. Tighten by an
extra half-turn so that the bar is securely held between the jaws. Ensure that the bar is
still centred in the collet.
CTighten the nuts (C).
CTighten the bolts (B).
CReturn the bar to the loading position.
CAdvance the mobile vice.
CAdvance the connector and check that the bar is gripped and correctly inserted into the
collet.
CThen, move the connector back to check that the rod is correctly extracted.

10 START UP MANUAL
TRYTON 112 CNC
2.4 HYBRID barrel (optional)
Important: Before any manipulation, stop the lathe at the end of a piece!
•Slide the protective cover forwards
•Press the [STOP] key.
•Press the [MENU] key.
The display reads :
PARAMETERS RELATED TO
START-UP
•Press the key corresponding to the [ENTER] icon.
The display reads :
CHANGE COLLET
•Press key F4, which corresponds to the [PAGE DOWN] icon.
The display reads :
CHANGE CAPACITY
•Press the key corresponding to the [ENTER] icon.
Use the stationary control to advance the connector to its foremost position, until the cam
bears on the roller bearings from behind.
1. Remove the cotter-pin.
2. Remove the ferrule
3. Unscrew the bolt (C) and remove the connector block (D), taking care not to damage
the cable (E). Place the connector block on the support provided for that effect.
4. Unscrew the cable (E) from the pusher (F).

START UP MANUAL 11
TRYTON 112 CNC
Note :
Pushers of
12.7 mm
diameter have
no reduction
tubes.
If the reduction tube can be extracted from the rear of the bar-feeder, swing out the rear
protective plate (I), and continue with point 5.
KIf thereisanyobstacle (wall,machine, etc.)preventingtheremovalofthereductiontube
at the rear, proceed as follows:
Undo the fixing screws (K) and remove the guide (L). Loosen the screws (M) that hold
the connector in the bearings. Extract the connector sideways then proceed with the
replacement of the reduction tube (G) as explained in points 5 to 7.
Then install the connector on the bearings and fix with the screws (M). Refit the
guide (L).
5. Extract the reduction tube (G) with the pusher to the inside, then insert the new
reduction tube (H).
Fit the cable (E) to the new pusher, reassemble the connector block (D) and secure it
with the bolt (C).
6. Fit the new ferrule (I).
7. Secure the ferrule with the cotter-pin (A).
8. More the connector to its rearmost position with the stationary control.
9. Index the barrel by one tube by pressing the LOAD button on the stationary control.

12 START UP MANUAL
TRYTON 112 CNC
Note :
To load
shaped bars,
the feeder
must be fitted
with the
appropriate
gripping jaws.
3. PUTTING THE LATHE INTO OPERATION
3.1 Spindle reduction tubes
Theefficiencyof thebarguiding whileinrotationinthelatheisdeterminedbythe clearance
between the spindle reduction tube and the rotating bar. The greater the clearance is, the
more frequent the vibrations are.
Using reduction tubes helps to decrease this clearance. Guiding is thus improved, but, in
addition, the insertion of the bar into the clamping device of the lathe is made much easier.
The inside diameter of the reduction tubes should be chosen in terms of the diameter of the
bar (diameter of the bar + 1 mm), but should always be larger than that of the diameter of
the feeding pusher.
Spindle reduction tubes are available from LNS, upon request
3.2 Shaped bars (hex and square)
It is possible to install abushing, inside the clamping device, with the same inside profile
(+ 0.2 mm) as the bar.
The rear of this collet and the front of the bars should be flat.
During the loading cycle, a slight rotation of the spindle (about 30 RPM) is desirable.
