Lockton MDL2100 User manual

Digital Lock
Art. MDL2100
8000 Code
Combinations
Left or Right
Handed Door
No Batteries
Required
Easy
Installation Press Button
Code
Easy Combination
Change
Holdback Option
(Lock Latch Open)

Art. MDL2100
pre-set code here
Record your factory
CY
X
5
4
3
Z
0
9
8
2
16
7
Content of box
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
OUTSIDE
INSIDE
RIGHT HAND LEFT HAND
1. Digital Exterior Code Pad Assembly
2. Digital Interior Handle Assembly
3. Neoprene Seals. x 2
4. Latchbolt (60mm standard)
5. Spindles x 3 (only one is used)
6. Fixing Interior Code Pad screws x 4
7. Wood Screws x 4. Use with Latchbolt
and Strikeplate.
8. Latchbolt Support Post.
9. Colour code tumblers x 4 Spare
10. Tweezers
11. Strike Plate
12. Strike Box
13. Code Card
Align the bottom of the template
page 914mm from floor. Fold the
template on the dotted 60mm
backset line to suit the deadlatch
assembly supplied.
Tape the template to the door.
Viewed from the outside
(Code Pad Side)
eg. your door is right
handed if the hinges are
on the right.
9 10
13
7 8
1211
6
54
321
2) Apply the Template
1) Select Handing
Applying the template

Art. MDL2100
Preparing the door / Installing the Latch & Strike
DRILL TEMPLATE AT BACK OF BOOK
.
a. b. c.
a. b. c.
1. MARK DOOR 2. DRILL HOLES
3. INSTALL LATCH
4. INSTALL STRIKE
MARK CENTRE
OF DOOR FOR
25mm HOLE
MARK
6 x 10mm HOLE
60 or 70mm
BACKSET
Mark center of door
edge as indicated
on template. Mark
center hole on door
face through guide on
template.
4 x 10mm HOLE 25mm HOLE
Drill all 6 x 10mm holes through the
door. It is recomended that the holes
be drilled from both sides to prevent
splitting.
Drill 25mm hole in center of door edge
for the latch.
Insert latch in hole
keeping it parallel to face
of door. Mark outline and
remove latch
Chisel 3mm deep or
until latch face is flush
with the door edge
Insert latch and tighten
screws
(NOTE: Latchbolt
bevel must face to
closing direction)
Close door until latchbolt touches jamb
to locate strike in jamb and center line of
strike. Open door and extend line from
mark to door stop. Measure one half
of door thickness from door stop and
vertically mark drill point center for strike.
Drill 25mm hole 12.7mm
deep in door jamb on
drill point for strike
CAUTION: To ensure proper lockset
function. Hole in jamb must be drilled a
full 12.7mm deep.
Cut out jamb 1.5mm
deep for strike. install
& tighten screws
GUARD BOLT
STRIKE
Guardbolt stops against
strike, as illustrated,
preventing forcing when door
is closed. Adjustable tang on
strike permits bending in or
out to fit between door and
eliminate being too loose.
Backset 60mm
(2 x 10mm)
(Optional
70mm latch
available)
Door thickness
(35-50mm)
(4 x 10mm)
130
Lockcase
Outline of
10mm Hole
Outline of
rubber seal
through the door and clear a slot
Drill 4x10mm holes
17.5
Fold along the edge of the door
(Match to length of LATCH)
10mm Hole
60mm
Fitting template
Cut Along Dotted Line
35mm Thick Door
50mm Thick Door
3) Door Preparation and Strike Installation
2 x 10mm HOLE
Closing direction

Art. MDL2100
A
B
.
Interior Handle
Assembly
HANDING
(POSITION A)
SCREWS
BLACK
(POSITION B)
Viewed from
the outside
SPINDLE SHOULD ENGAGE
DOOR HUNG ON RIGHT
THE LATCH AS ABOVE
SPINDLE SHOULD ENGAGE
THE LATCH AS ABOVE
DOOR HUNG ON LEFT
.
STOPPER
LATCH
TURN THE HANDLE DOWN TO
RETRACT THE LATCH AND SLIDE
THE LATCH STOPPER TO KEEP
THE LOCK UNLATCHED.
Fit the latch support post in
the back of the digital code
pad assembly. Hole A for right
hand hung door and hole B for
left hand hung door.
Three spindles are provided. Select the spindle length
to suit the door thickness.
* For door thinknesses less than 35mm use the shorter
spindle (75mm). For door thinknesses of 35-50mm
use the longer spindle (85mm) or (100mm).
* Position spindle centrally through the latch hub to
suit door handing.
PIN HERE
HAND DOOR
FOR LEFT
LOCATE
HANDING
HANDING
PIN
PIN
PLATE
COVER
SCREWS
HANDING
BLUE The digital exterior code pad
assembly is usually factory set
for right hand door handing
and the digital Interior code
pad is set for left hand door
handing (The outer knob will
turn freely in an anticlockwise
direction and resist clockwise
turning).
To change for a left hand door:
* Remove the two BLUE
screws and handing pin cover
plate.
* Remove the handing pin
and replace it in the hole
horizontally opposite.
* Replace handing pin cover
plate.
* Check that the outer knob now turns freely in a
clockwise direction and resists anticlockwise turning
The Digital Interior Handle
Assembly is usually factory set
for right hand door handing.
(The Handle will turn freely
in an anticlockwise direction
only).
To change for a left hand door:
* Remove BLACK handing
screw from position A and
relocate it in position B.
* Check that the inside handle now turns freely in a
clockwise direction only.
* For door thinknesses
less than 48mm use
the shorter screws
(36mm).
* Fit the neoprene
seals to both the
exterior code pad
and Interior handle
assemblies.
* Hold the exterior
code pad assembly
onto the door with the
Select the fixing screws to suit the door thinkness.
spindle in position and ensuring that the latch support
post engages the hole in the deadlatch assembly.
* Locate the Interior handle assembly on the inside of
the door engaging the spindle in the handle hub.
* Screw both sides together using the fixing bolts top
and bottom.
* Before final tightening of fixing screws make sure the
lock is vertical. Test the mechanism to ensure that the
lock functions correctly and moves easily.
DO NOT overtighten the fixing screws-this may cause
distortion and lead to poor operation.
IMPORTANT :
CHECK THAT THE CODE WORKS TO AVOID A
LOCKOUT BEFORE CLOSING THE DOOR.
4) Fit Latch Support Post
5) Handing the Digital Code Pad
Assembly
6) Handing the Digital Interior Handle
Assembly
7) Positioning the Spindles
8) Mounting the Lock
9) Latch Stopper
Installation Guide

Art. MDL2100
7
C
Z
0
9
8
6
2RED
square cut
square cut
Y
X
5
4
3
BLUE
1
Changing the Code number
BLUE
square
KEYLESS
TUMBLER
BLUE
cut
RED
cut
RED KEY
square
TUMBLER
CODE
PLATE SCREWS
PLATE
CODE
RED
push button
square cut
outside outside
number
1. Remove the lock from
the door.
2. Remove the 4 RED code
plate retaining screws
from the back of the
code pad assembly. Take
extra care to keep the
lock body on a flat
surface when removing
the code plate to avoid
spilling the small code
module components
3. From the factory code
setting, there are 5 RED
coloured key “active”
Code tumblers and
8 BLUE coloured
“keyless” code tumblers
plus 1 neutral code
tumbler in the “C”
position (this is the code
clearing tumbler and
must not be removed).
4. Push and hold the “C”
button. Never attempt
to remove the “C” button
code tumbler. With the
“C” button held down,
remove one or more
code tumblers using the
tweezer supplied.
5. Note the dierent shapes
of the code tumblers
before re-inserting them
into the code module.
RED and BLUE code tumblers have the square cut
low and high respectively. WHEN REPLACING CODE
TUMBLERS THE SQUARE CUT MUST ALWAYS FACE
THE OUTSIDE OF THE LOCK BODY.
6. Establish and write down your new code & insert
the appropriate coloured tumbler next to the
code numbers in the module. DO NOT LEAVE ANY
TUMBLER POSITION EMPTY. With the spare tumbler
provided in the screw pack you can reduce or increase
your code to 4 or 6 digits.
7. Replace the code plate and secure with the 4 RED
retaining screws.
8. Check the code by pressing the “C” button followed by
the code number.
9. The knob should turn freely in both directions. If not
return to step 4
10. Reinstall the lock. Place the spare colour code
tumblers in a safe place with the instructions and code.
IMPORTANT:
BEFORE CHANGING CODES THE
“C” BUTTON MUST BE DEPRESSED
AND HELD IN THE DOWN POSITION
THROUGHOUT CODE CHANGING
PROCEDURE. FAILURE TO DO THIS
WILL DAMAGE THE CODE MODULE.
SIMILAR DAMAGE WILL OCCUR
IF CODES ARE NOT RE-INSERTED
CORRECTLY. PLEASE REFER TO
CODE CHANGE INSTRUCTIONS. AS A
GUIDELINE RED OR BLUE SHOULD
ALL BE IN LINE IF CODES ARE
CORRECTLY INSERTED.

F

130
Lockcase
Outline of
10mm Hole
Outline of
rubber seal
through the door
and clear a slot
Drill 4x10mm holes
17.5
Fold along the edge of the door
(Match to length of LATCH)
10mm Hole
60mm
Fitting template
Cut Along Dotted Line
35mm Thick Door
50mm Thick Door
