LOFTNESS Bad Ax 60BA1 User manual

Model Number:
Serial Number:
Date of Purchase:
200505 Rev. C 04.26.19
Bad Ax
Skid Loader Disc Mulcher
60BA1 •60BA2
Owner’s Manual and Parts Book
(Originating with Serial Number
85-170 thru 85-185)

LOFTNESS SPECIALIZED EQUIPMENT, INC.
LIMITED WARRANTY POLICY
The limited warranty policy begins upon delivery of the unit to the original customers.
All Loftness products have a one (1) year limited warranty. The XLB10 Grain Bag Loader has a two (2) year limited warranty.
If any Loftness product is used as rental equipment, or in a commercial application, the limited warranty period is for only 30 days
from the delivery date to the original customers.
Loftness Specialized Equipment, hereinafter referred to as LOFTNESS, a manufacturer of quality machinery since 1956, warrants
new LOFTNESS machinery and/or attachments at the time of delivery to the original purchaser, to be free from defects in material and
workmanship when properly set up and operated in accordance with the recommendations set forth in the LOFTNESS Operator’s
Manual.
LOFTNESS’ liability for any defect with respect to accepted goods shall be limited to repairing the goods at an authorized dealer or
other LOFTNESS designated location, or replacing them as LOFTNESS shall elect. The above shall be in accordance with
LOFTNESS warranty adjustment policies.
WARRANTY REQUIREMENTS
.smialcytnarrawllaetadilavottnempiuqEdezilaicepSssentfoLotdenruterdnatuodellifebtsummrofnoitartsigerytnarraW
To receive a warranty claim, a return authorization from LOFTNESS must be obtained. The failed part may then be returned in an
.gnicivresrofyrenihcamgninruternehwderrucnisegrahcyreviledrothgierfedulcnitonseodytnarrawsihT.sutatsderepmatnu
Dealer mileage, service calls and pick-up/delivery charges are the customer’s responsibility.
LIMITATIONS OF WARRANTY
LOFTNESS products are designed to provide years of dependable service when proper use and maintenance is adhered to. The
potential for misuse in many applications exists; therefore, a limited warranty is provided as follows.
This warranty shall not apply to any machine or attachment which shall have been repaired or altered outside the LOFTNESS factory
or authorized LOFTNESS dealership or in any way so as in LOFTNESS’ judgment, to affect its stability or reliability, nor which has
been subject to misuse, negligence or accident, nor to any machine or attachment which shall not have been operated in accordance
with LOFTNESS’ printed instructions or beyond the company recommended machine rated capacity. LOFTNESS may elect to have
an area representative evaluate the condition of the machine before warranty is considered.
In addition, this limited warranty provides no coverage for general wear or maintenance items, misuse, environmental conditions and/
or contamination for which they were not designed or not intended, including but not limited to the following items:
•Use of machine beyond its rated capacity;
•Improper knife replacement;
•Missing knives;
•Striking foreign objects
•Lack of lubrication
•Failures caused by running in an “out-of-balance” condition;
•Tires;
•Conveyors;
•Auger wear;
•Saw blades; and
•Brakes and brake pads.
EXCLUSIONS OF WARRANTY
Except as otherwise expressly stated herein, LOFTNESS makes no representation or warranty of any kind, expressed or implied. The
implied warranty of merchantability and fitness for a particular purpose are excluded from this limited warranty. The
remedies set forth in this warranty are the only remedies available to any person under this warranty. LOFTNESS shall have no
liability to any person for incidental, consequential or special damages of any description, whether arising out of express or implied
warranty or any other contract, negligence, or other tort or otherwise. This exclusion of consequential, incidental and special damages
is independent from and shall survive any finding that the exclusive remedy failed of its essential purpose. Upon purchase, the buyer
assumes all liability, all personal injury and property damage resulting from the handling, possession or use of the goods by the buyer.
No agent, employee or representative of LOFTNESS has any authority to bind LOFTNESS to any affirmation, representation or
warranty concerning its machinery and/or attachments except as specifically set forth herein.
April 2017

Bad Ax Disc Mulcher OM
Table of Contents
Warranty
Table of Contents
Ordering Code
Ordering Code.................................................................. 1
Bad Ax Disc Mulcher (Example) ................................................. 1
Introduction
Owner Information............................................................... 3
Warranty Policy ................................................................. 3
Serial Number Location........................................................... 3
Manual Storage ................................................................. 3
Bad Ax Features ................................................................ 4
Safety Instructions
Safety First .................................................................... 5
Owner’s Responsibility ........................................................... 5
Mandatory Shut-Down Procedure................................................... 6
Safety Rules ................................................................... 6
Operating Safety ............................................................. 6
Maintenance Safety........................................................... 7
Hydraulic Safety ............................................................. 8
California Proposition 65 Warning................................................... 8
Bad Ax Identification ............................................................. 9
Safety Decal Locations .......................................................... 10
Set-up Instructions
Positioning the Pusher Bar ....................................................... 13
Installing the Bad Ax to the Loader ................................................. 14
Checking Disc Rotation.......................................................... 14
Checking Disc Speed ........................................................... 15
Adjusting Disc RPM (Linde Motor) ................................................. 16
Operating Instructions
Getting Started ................................................................ 17
Operation..................................................................... 17
Overview .................................................................. 17
General Cutting Instructions ................................................... 17
Hydraulic Hose Storage ......................................................... 18
Maintenance
General Maintenance ........................................................... 19
Break-In Schedule.............................................................. 19
Maintenance Schedule .......................................................... 19
Lubrication.................................................................... 19
Grease Points Location ....................................................... 19

Bad Ax Disc Mulcher OM
Table of Contents
Maintenance (Cont’d)
Removing Motor Covers ......................................................... 20
Left Side Motor Cover ........................................................ 20
Right Side Motor Cover....................................................... 20
Front/Top Motor Cover ....................................................... 20
Coupler Element Replacement .................................................... 21
Motor Removal ................................................................ 21
Tooth Removal and Installation .................................................... 22
Tooth Holder Removal and Assembly ............................................... 22
Tooth Rotation ................................................................. 22
Disc Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Storage ...................................................................... 23
End of Season .............................................................. 23
Beginning of the Season ...................................................... 23
GPM Chart.................................................................... 24
Adjustable Displacement Piston Motor 5000 PSI ................................... 24
Troubleshooting................................................................ 25
Parts Identification
Driveline...................................................................... 30
Disc with Cutters (N149529) ...................................................... 32
Lubrication, Drive Bearing ........................................................ 33
Hydraulics, Linde Motor ......................................................... 34
Linde Motor (200460) ........................................................... 36
Hydraulics, Connecting .......................................................... 37
Manifold (200689) .............................................................. 38
Pusher Bar.................................................................... 39
Motor Covers.................................................................. 40
Infeed and Outfeed ............................................................. 41
Cutting Teeth, Deck ............................................................. 42
Manual Holder ................................................................. 43
Machine Decals and Signs ....................................................... 44
Appendix
Specifications ................................................................. 47
Dimensions ................................................................... 48
Torque Specifications ........................................................... 49
Inches Hardware and Lock Nuts ................................................ 49
Metric Hardware and Lock Nuts ................................................ 50

1Bad Ax Disc Mulcher OM
Ordering Code
Ordering Code
Bad Ax Disc Mulcher (Example)
The ordering code will consist of two numbers (machine size), two letters (machine type), and one letter (motor system).
An example for a disc mulcher of this type would be as shown below.
SIZE
60 = 60" Cut
TYPE
BA = Bad Ax
MOTOR SYSTEM
1 = Linde Variable Displacement
60BA1

2Bad Ax Disc Mulcher OM

3Bad Ax Disc Mulcher OM
Owner Information
Thank you for your decision to purchase a Bad Ax Disc
Mulcher from Loftness. To ensure maximum performance
of your machine, it is mandatory that you thoroughly study
the owner’s manual and follow its recommendations.
Proper operation and maintenance are essential to
prevent injury or damage and to maximize machine life.
The Loftness Bad Ax Disc Mulcher is an effective, reliable
machine ideally used for land clearing, vegetation control,
forest fire prevention and more. The 60 inch diameter
disc can cut down trees up to 14 inches in diameter with
a maximum material size of 6 in. (15.2 cm) allowed above
the disc. For best results, operate the machine as low to
the ground as possible without the teeth striking ground
or other obstructions. Lifting or tilting the disc mulcher
increases the risk of flying debris. Because of the high
speed of the disc, the life of the teeth will be reduced
if it is operated in rocky terrain or in areas where many
obstacles are present. Areas to be cleared should be
free of debris such as rocks, bottles, large branches etc.
The teeth cut and pulverize the grass, weeds, brush and
small trees.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws, and in compliance with
on-product labeling and these instructions.
Make sure that all personnel have read this owner’s
manual and thoroughly understand safe and correct
operating, installation and maintenance procedures.
Continuous improvement and advancement of Loftness
products may result in changes to your equipment
that may not be reflected in this publication. Loftness
reserves the right to make product improvements to the
machine at any time. Although great care has been taken
to ensure the accuracy of this publication, Loftness does
not assume any liability for errors or omissions.
Warranty Policy
Be sure to read and understand the Warranty Policy at
the beginning of this manual. It is also important that you
fill out the Warranty Registration form(s) completely with
your dealer so as not to void the warranty.
Serial Number Location
The arrows above indicate the location of the serial
number tag (1) and the location of the serial number
stamped into the frame (2).
Always use your model and serial number when
requesting information or when ordering parts.
Manual Storage
Keep the owner’s manual and the entire documentation
packet in the manual holder (1) provided on your disc
mulcher. Remove the two bolts (2) and remove the cover
(3) to gain access. The owner’s manual must be available
for all operators.
Introduction

4Bad Ax Disc Mulcher OM
Introduction
Bad Ax Features
• Piston Motor
• 30-45 GPM up to 5000 PSI
• 70-120 Hydraulic Horsepower Required
• 60 inch Diameter Disc - 1.25 in. Max Thickness
• No Welding on Disc - Fully Machined
• 1000 RPM - 185+ MPH Tip Speed
• Direct-drive with Wrapflex Coupler
• Quadco Reversible Teeth
• Bolt-on Replaceable Tooth Mounts
• Heavy-duty, Custom Bearing Housing
• 80 mm Spherical Roller Bearings
• Bearing Anti-wrap Protection
• Premium Strength Steel Body & Disc
• Bolt-on Infeed and Discharge Assemblies
• Controlled Discharge Deflector
• Adjustable Tree-pusher Bar
• Claw Hooks on Pusher Bar
• Dual Re-cutter Bars
• Pressure Gauge to Monitor Capacity
• Anti-cavitation Shut Down Circuit
• Universal Skid-Steer Mount
• Hoses included (couplers not included)

5Bad Ax Disc Mulcher OM
Safety First
In the owner’s manual and on decals used on the
machine the words DANGER, WARNING, CAUTION,
IMPORTANT, and NOTE are used to indicate the
following:
DANGER: This word warns of immediate hazards which,
if not avoided, will result in severe personal injury or
death. The color associated with Danger is RED.
WARNING: This word refers to a potentially hazardous
situation which, if not avoided, could result in severe
personal injury or death. The color associated with
Warning is ORANGE.
CAUTION: This word refers to a potentially hazardous or
unsafe situation that, if not avoided, may result in minor
or moderate injury. It may also be used to alert against
unsafe practices. The color associated with Caution is
YELLOW.
IMPORTANT: Highlights information that must be
heeded.
NOTE: A reminder of other related information that needs
to be considered.
If Safety Decals on this machine are ISO two panel
pictorial, decals are defined as follows:
• The first panel indicates the nature of the hazard.
• The second panel indicates the appropriate
avoidance of the hazard.
• Background color is YELLOW.
• Prohibition symbols such as and STOP if used,
are RED.
Be certain all machine operators are aware of the
dangers indicated by safety decals applied to the
machine, and be certain they follow all safety decal
instructions. Contact Loftness for safety decal
replacement.
Loftness cannot anticipate every possible
circumstance that may involve a potential hazard. The
warnings in this owner’s manual are not all inclusive.
Owner’s Responsibility
Due to the potential danger of flying debris, it is the owner’s
responsibility and is “ABSOLUTELY MANDATORY that
IMPACT-RESISTANT SHIELDING” be installed on the
machine to protect the operator.
It is ABSOLUTELY MANDATORY that all personnel read
and follow all safety precautions before operating the
machine and attachment.
Make sure that all personnel have read this owner’s
manual, and thoroughly understand safe and correct
installation, operation, and maintenance procedures.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws; and in compliance with
on-product labeling and this owner’s manual instructions.
Make sure that all personnel know how to stop the
machine and attachment by disengaging all controls.
See “Mandatory Shut-Down Procedure” on page 6.
Make sure the attachment is installed on the machine
correctly before being placed in service. At regular
intervals thereafter, the attachment should be serviced
in accordance with procedures outlined in this owner’s
manual.
Safety Alert Symbol
This message alert symbol identifies
important safety messages on the machine
and in the owner’s manual. When you see this
symbol, be alert to the possibility of personal
injury and carefully read the message that
follows.
Safety Instructions

6Bad Ax Disc Mulcher OM
Mandatory Shut-Down Procedure
• Stop the machine and attachment on a level surface
and lower the attachment to the ground.
• Move throttle to idle position.
• Disengage all power to the attachment.
• Shut off engine and remove the key.
Wait until the disc has stopped completely before
inspecting the attachment.
Safety Rules
These are general safety considerations. Additional
precautions may be necessary to operate your
machine in a safe manner. Be certain you are operating
your machine in accordance with all safety codes,
OSHA rules and regulations, insurance requirements
and local, state, and federal laws.
Operating Safety
• Do not start, operate, or work on this attachment until
you have carefully read and thoroughly understand
the contents of this manual and the operator’s
manual for your loader.
• Read and observe all warnings decals on the machine
before attempting to operate the attachment. Do not
attempt to operate this attachment unless all factory
devices and decals are in place. Keep safety decals
clean of dirt and grime. Keep all guards, shields and
decals in place.
• Become familiar with and know how to operate all
safety devices and controls on the machine and
attachment before attempting to operate. Know how
to stop the machine and attachment before starting
it.
• Do not allow anyone to operate the attachment
until he or she has read the owner’s manual and is
completely familiar with all safety precautions and
controls. Keep the work area clear of all unauthorized
personnel.
• Because of the potential safety hazard to eyes from
hydraulic leaks and/or flying debris, use of protective
eyewear is absolutely mandatory for operator and
others in the work area.
• Do not wear loose hanging clothes, neckties or
jewelry around rotating parts. Long hair is to be
placed under a cap or hat. These precautions will
help prevent you from becoming caught in any
moving parts on the machine and attachment.
• Do wear safety glasses, ear protection, respirators,
gloves, hard hats, safety shoes and other protective
clothing when required.
• Do not allow persons under the influence of alcohol,
medications, or other drugs that can impair judgment
or cause drowsiness to operate or maintain the
machine.
• Never allow children to operate the equipment.
• Keep children, bystanders and other workers off
and away from the machine and attachment during
operation. No riders allowed.
• Use the handholds and step plates when getting on
and off the machine to prevent falls. Keep steps and
platform cleared of mud and debris.
• Always have an operator in the machine while the
attachment is in operation. Never leave the machine
and attachment running and unattended.
• Keep your feet on the pedals, (floor plates) seat belt
fastened snuggly and seat bar lowered, (if equipped),
when operating the attachment.
• Always use an approved roll bar and seat belt for
safe operation. Overturning a machine without a roll
bar and seat belt can result in injury or death.
• Operate the attachment only from the operator’s
seat.
• Before leaving the operator’s position for ANY
reason or allowing anyone to approach the machine
and attachment, always perform the mandatory
shutdown procedure.
• Keep hands and feet clear! Never step over or climb
over the attachment while the engine is running;
entanglement could occur.
• Disengage auxiliary hydraulics and place all machine
controls in neutral and engage the parking brake
before starting the engine.
• Remove from area of operation all foreign objects
such as bottles, rocks, wire, etc., that might become
tangled in the disc, causing damage to the machine
or be thrown striking other objects.
Safety Instructions

7Bad Ax Disc Mulcher OM
Safety Rules (Cont’d)
Operating Safety (Cont’d)
• The adjustable push bar could contact the machine
in some positions. Before starting the power unit,
set the push bar in the most forward position, then
slowly rotate the attachment back while an assistant
checks for clearance. Repeat this process in the
other settings to determine which positions are
usable with your machine.
• Never attempt to make any adjustments while the
attachment is running or the key is in the “ON”
position in the machine. Before leaving the operator’s
position, disengage power to the attachment, shut
off engine and remove ignition key.
• Repeated impact of the teeth with hard objects can
cause excessive wear and damage to the skid loader
or attachment. Be sure to maintain recommended
ground clearance as specified in this manual.
• Should excessive vibration occur, disengage the
auxiliary hydraulics immediately and shut off engine.
Do not continue to operate the attachment until the
problem has been determined and corrected.
Maintenance Safety
• Do not work on this attachment until you have
carefully read and thoroughly understand the
contents of this manual and the operator’s manual
for your loader.
• Before inspecting, cleaning, lubricating, adjusting
or servicing any part of the attachment, always
exercise the Mandatory Shut-Down Procedure.
See “Mandatory Shut-Down Procedure” on page
6. After service has been performed, be sure to
restore all guards, shields and covers to their original
position.
• Never attempt to lubricate, or make any adjustments
while the skid loader or attachment is running, or the
key is in the “ON” position in the machine. Before
leaving the operator’s position, disengage power to
the attachment, shut off engine and remove ignition
key.
• When performing any maintenance, make sure the
area is clear of any distracting objects. Keep work
areas clean and free of grease and oil to avoid
slipping or falling.
Safety Instructions
• Before working under the attachment, be certain it is
securely blocked!
• Do not smoke while servicing the machine.
• Do not touch loader or any attachment parts which
might be hot from operation. Allow such parts to
cool before attempting to maintain, adjust or service.
• Make sure all controls, (levers, pedals and switches),
are in NEUTRAL position before starting the engine.
• Before leaving the operator’s position for ANY
reason or allowing anyone to approach the machine
and attachment, always perform the mandatory
shutdown procedure.
• Periodically check all guards, shields and structural
members. Replace or repair anything that could
cause a potential hazard.
• Do not replace components or parts with other than
factory-recommended service parts. To do so may
decrease the effectiveness of the machine and/or
void the warranty.
• It is the operator’s responsibility to be aware of
machine and attachment operation and work area
hazards at all times.
• Never operate the attachment without adequate
light and visibility.
• Keep hands and feet clear! Never step over or climb
over the attachment while the disc is engaged or the
engine is running; entanglement could occur.
• Operators are responsible to know the location
and function of all guards and shields including
but not limited to the drive and disc. Operators are
responsible to make certain that all guards are in
place when operating the machine and attachment.
• Operators are responsible to be aware of safety
hazard areas and follow instructions on warning,
caution, or danger decals applied to the machine.
• Know the area before operating the machine. Be
aware of power lines or other equipment.

8Bad Ax Disc Mulcher OM
Safety Rules (Cont’d)
Hydraulic Safety
WARNING: Contact with high pressure
fluids may cause fluid penetration and burn
hazards. Fluid that is under pressure can
penetrate body tissue. Fluid penetration can
cause serious injury and possible death. If
fluid is injected into the skin, seek medical
attention immediately!
• Always wear safety goggles or glasses when working
on hydraulic system to avoid eye injury.
• The hydraulic system is under high pressure. Make
sure all lines and fittings are tight and in good
condition. These fluids escaping under high pressure
can have sufficient force to penetrate skin and cause
serious injury.
• Never check for leaks by using any part of your body
to feel for escaping fluid.
• To prevent serious personal injury from escaping
high pressure fluid, never attempt to inspect, service
or disassemble any part of the hydraulic system until
all pressure has been relieved from the system.
California Proposition 65 Warning
WARNING: This product can expose you to
Mineral Oil, which is known to the State of
California to cause cancer. For more
information, go to www.p65warnings.ca.gov.
A decal with this warning statement is adhered to the
machine. If the decal should become worn or missing,
replace immediately.
Safety Instructions

9Bad Ax Disc Mulcher OM
Safety Instructions
Bad Ax Identification

10 Bad Ax Disc Mulcher OM
Safety Decal Locations
Check and replace any worn, torn, hard to read or
missing safety decals on your machine.
Part No. N17013
Part No. N20661
Safety Instructions
Part No. N68724
Part No. N68716
1
2
3
4
5
6
Part No. 4256
Part No. 200491

11Bad Ax Disc Mulcher OM
Safety Decal Locations (Cont’d)
Safety Instructions
Part No. 4334
Part No. N23506
WARNING
SKIN PUNCTURE
HAZARD.
HYDRAULIC LINES.
Protect hands and body
from high pressure fluids.
N23506
7
9
10
8
Part No. N28385
Part No. N28386

12 Bad Ax Disc Mulcher OM
Safety Instructions
Safety Decal Locations (Cont’d)
12
13
Part No. N29769
11
Part No. N17014
Part No. 203264

13Bad Ax Disc Mulcher OM
There are a total of four pusher bar positions available.
Pivot the pusher bar (2) to the desired position and align
the upper hole in the pusher bar side arm with hole “B”,
“C”, or “D” of the side bracket.
When the desired position has been reached, reinstall
the bolt (3) through the side bracket and upper hole of
the pusher bar side arm. Secure with the washer (5) and
nut (4).
NOTE: Use of a punch to assist in aligning and holding
the pusher bar into place until hardware can be
installed may be helpful.
Reinstall nut, bolt, and washer on other side of the disc
mulcher.
Tighten all hardware securely on both sides, including
the pivot bolts (1).
Set-up Instructions
Positioning the Pusher Bar
The Bad Ax will come shipped with the pusher bar
shown in the position below. Follow the instructions in
this section to place the bar into a different operating
position.
NOTE: Positioning the pusher bar requires two people
or the use of an approved lifting device to
support the push bar as it is being adjusted.
Ensure pusher bar is being safely supported before
removing the hardware. Have another person hold the
pusher bar at the center, or use a hoist and strap.
Loosen, but do not remove, bolt (1) in lower hole of
pusher bar arm (2).
Remove nut (3), bolt (4), and washer (5) from the upper
hole of the pusher bar side arm going through hole “A” of
the side bracket. Set the hardware aside.
Repeat on other side of the disc mulcher.
WARNING: The pusher bar is heavy, use two
people, or a hoist and strap, to support the
weight of pusher bar while repositioning.

14 Bad Ax Disc Mulcher OM
NOTE: The hydraulic hose quick couplers shown above
are not supplied with the disc mulcher.
Install the disc mulcher quick couplers to the loader.
NOTE: The case drain quick coupler (1) of the disc
mulcher must be connected to the loader’s
auxiliary hydraulic system for proper operation
of the disc mulcher.
Checking Disc Rotation
Raise the disc mulcher off the ground and place blocks
underneath the skids. Lower the disc mulcher down on
the blocks.
CAUTION: Make sure the blocks are not in
the path of the disc and teeth.
(Continued on following page.)
Installing the Bad Ax to the Loader
Fully raise the attachment-locking levers on the loader
mounting plate.
Tilt the loader mounting plate ahead. Drive forward with
the loader and hook the top edge of the loader mounting
plate under the top flange (1) on the disc mulcher
mounting plate. Be careful not to damage the locking
levers on the loader mounting plate.
Tilt the loader mounting plate back until the disc mulcher
mounting plate is firmly against the loader mounting
plate, but Do Not lift the attachment off the ground.
WARNING: Before you leave the operator’s
seat: Lower the lift arms, put the attachment
on the ground. Stop engine and remove
ignition key. Engage the parking brake.
Fully lower the attachment-locking levers on the loader
mounting plate.
WARNING: Locking-wedge pins must
extend through the holes in attachment-
mounting plate. Levers must be fully down
in the locked over-center position. Failure to
secure wedge pins can allow attachment to
come off, causing serious injury or death.
Set-up Instructions
