Logic ML350G-10 User manual

ML350 Manual
The not so quick, quick start guide.
Version 1, Published 10/18/2017
ML350G-10 Manual
US Oce
Phone: [phone]
Email: [email protected]
www.logicsupply.com
EU Oce
Phone: [phone]
Email: [email protected]
www.logicsupply.com

ML350G-10 Industrial Computer
2
ML350 Quick Start Guide
1 - About Logic Supply.................................................................3
Contact Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 - Legal Disclaimer ...................................................................4
3 - Safe Use and Installation Instructions................................................5
4 - What’s In The Box..................................................................6
5 - System Overview ..................................................................7
5.1 - System Diagram................................................................7
 5.2-SystemSpecications ...........................................................8
5.3 - Mounting Hole Pattern ..........................................................9
5.4 - Mounting Guide ...............................................................10
6 - Motherboard Overview............................................................11
6.1 - Jumpers and Headers Guide ....................................................12
 6.2-ConguringJumpers ...........................................................13
6.3 - Onboard Headers .............................................................14

ML350G-10 Industrial Computer
3
1 - About Logic Supply
LogicSupplyispoweringinnovationwithhighlycongurableembeddedandIoTcomputersengineeredforre-
liability. Businesses worldwide depend on our solutions to operate in the toughest environments while tapping
intotheevolvingIndustrialInternetofThings.
ThisguidewillintroduceyoutotheML350G-10industrialfanlesscomputerandthesystemspecications.For
technical questions or support, please reach out via our contact information below.
Youhavealotofchoiceswhenchoosingcomputerhardware.TheLogicSupplyTeamwantstothankyoufor
trustingourcomponentstomeetyourapplicationneeds.TheML350G-10istheresultofinputfrompartners
likeyou.We’veworkedhardtocreateasystemthatmeetsthevariedneedsofindustrialandIoTcomputing
andwe’vemanufacturedthissystemunderourstrictqualityassuranceandimmunitystandardstoserveyou
best. If you have any concerns about the quality or performance of this product, please contact us directly or
visit our support page.
Contact Information
Logic Supply Global
35ThompsonStreet,
SouthBurlington,VT05403
USA
[phone]
[email protected]
Logic Supply Europe
Handelskade49,
2288BARijswijk,
TheNetherlands
[phone]
[email protected]

ML350G-10 Industrial Computer
4
2 - Legal Disclaimer
Intellectual Property Notice:Allmaterialincludingbutnotlimitedto,text,designspecications,graphics,
logos, reference, images, drawings, and software including this document and the product itself (together and
separately) is owned, controlled by, licensed to, or used with permission by Logic Supply, Inc., Logic Supply
BV, Interlogic, Inc. or the authorized agents and representatives (Collectively “Logic Supply”) and is protected
bycopyright,trademark,andotherintellectualpropertyrights.Nopartofthismanualmaybereproduced,
transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of
documentationbythepurchaserforbackuppurpose,withoutthewrittenconsentofLogicSupply.Products
andcorporatenamesappearinginthismanualmayormaynotberegisteredtrademarksorcopyrightsoftheir
respectivecompanies,andareusedonlyforidenticationorexplanationandtotheowners’benet,without
intent to infringe. Information in this document is subject to change without notice.
Legal Disclaimer: Specicationsandinformationcontainedinthismanualarefurnishedforinformation-
al use only and subject to change without notice, and should not be constructed as a commitment by Logic
Supply. Logic Supply assumes no responsibility for any errors or omissions that may appear in this manual.
Withrespecttothecontentsofthismanual,allisprovided“asis”andLogicSupplydoesnotprovidewarranty
ofanykind,eitherexpressedorimplied,statutoryorotherwiseandexpresslydisclaimsallimpliedwarranties
ofnoninfringement,merchantability,andtnessforaparticularpurpose.INNOEVENTSHALLLOGICSUPPLY,
ITSDIRECTORS,OFFICERS,EMPLOYEES,ORAGENTSBELIABLEFORDIRECT,INDIRECT,SPECIAL,INCIDENTAL,
SPECULATIVEORCONSEQUENTIALDAMAGESARISINGFROMTHEUSEORINABILITYTOUSETHISPRODUCTOR
DOCUMENTATION,EVENIFADVISEDOFTHEPOSSIBILITYOFSUCHDAMAGES.INPARTICULAR,LOGICSUPPLY
SHALLNOTHAVELIABILITYFORANYHARDWARE,SOFTWARE,ORDATASTOREDORUSEDWITHTHEPRODUCT,
INCLUDINGTHECOSTSOFREPAIRING,REPLACING,INTEGRATING,INSTALLINGORRECOVERINGSUCHHARD-
WARE,SOFTWARE,ORDATA.Unlessotherwiseexpresslyagreedtoinwriting,thesale,use,etc.ofanyandall
Logic Supply products is governed exclusively by the terms and conditions of purchase (www.logicsupply.com/
company/support/terms-conditions) and/or other written agreements executed by Logic Supply. Unless other-
wise expressly agreed to in writing, any and all disputes arising between Logic Supply and the customer shall
be governed by the laws of the State of Vermont, USA and the State of Vermont shall be the exclusive venue for
the resolution of any such disputes.
Regulatory Compliance: ThisdigitaldeviceisdesignedtocomplywithallapplicableFCCRulesPart15and
CEcompliancerequirementsforelectronicequipment.Formoredetailedoradditionalregulatorycompliance
information, please see the relevant product page at www.logicsupply.com or contact Logic Supply directly at
[email protected].
Copyright © 2018 by Logic Supply, Inc. All rights reserved.

ML350G-10 Industrial Computer
5
3 - Safe Use and Installation Instructions
WARNING:ThereisdangerofexplosioniftheCMOSbatteryisreplacedincorrectly.
Wireless
Ifthisproductwasconguredwithawirelessdevice,theFCCandICIDswillbedetailedonalabelonthechassis.
1.Donotopenormodifythedevice.ThedevicehasbeentestedandcomplieswithFCCandCEregulations.Modicationofthe
devicewillvoidthesecertications.
2. Install the device securely. Be careful handling the device to prevent injury and do not drop.
3. Wallorceilingmountingdevicerequiresuseofamountingplateorpairofmountingbrackets.Plateorbracketsmustbeof
metalconstructionandhaveaminimumthicknessof1mm.
4. UseM3x0.5mmFlatHeadscrewstoattachmountingplateormountingbracketstothreadedholesonbottomofchassis.
Screwsshouldbeminimumlengthof4mm.Ad1mmofscrewlengthforeverymmofadditionalthicknessofplateorbracket
beyond 1.5mm.
5. Operational temperature must be between 0-40°C with a noncondensing relative humidity of 10-90%.
6.Thedevicecanbestoredattemperaturesbetween0-60°C.
7.Keepthedeviceawayfromliquidsandammablematerials.
8.Donotcleanthedevicewithliquids.Thechassiscanbecleanedwithacloth.
9. Allow at least 2 inches of space around all sides of the device for proper cooling. If device is mounted to vertical surface then
recommendeddeviceorientationissothatheatsinknsallowairtoriseunobstructed.Alternativeorientationsmayresultin
reduced operational temperature range.
10.Thisdeviceisintendedforindooroperationonly.
11. UseULlistedexternalpowersupplywithratedoutput9Vdc,4.0Amin.to24Vdc,1.5Amin.,NECClass2,orLPSoutputor
equivalent.
12.Installthedeviceonlywithshieldednetworkcables.
13. Serviceandrepairofthedevicemustbedonebyqualiedservicepersonnel.Thisincludesbutisnotlimtedtoreplacementof
CMOS battery. Replacement CMOS bettery must be of same type as original.
14. Proper disposal of CMOS battery must comply with local governance.

ML350G-10 Industrial Computer
6
4 - What’s In The Box
ML350 Built & Tested System
Any Selected Accessories
Ifyoupurchasedadditionalitemssuchasspecicmountingbrackets,
power supplies or antennas, they will be located in the system box or
within the outer shipping carton.
All drivers and product guides can be found on the corresponding
product page at www.logicsupply.com.
+

ML350G-10 Industrial Computer
7
5 - System Overview
5.1 - System Diagram
Power Button
Antenna
(Optional)
Antenna
(Optional)
GbLAN GbLAN
(Optional)
USB 2.0
DisplayPort
CEC
Power In
USB C USB 3.0 Audio
In/Out
COM
(Optional)

ML350G-10 Industrial Computer
8
5.2 - System Specications
N3350 N4200
Processor and Chipset IntelApolloLakewithintegratedgraphics
Memory 1 x 204-pin DDR3L SO-DIMM up to 8GB
Audio Controller RealtekALC283audiocodec
Expansion
Full-size/half-sizemPCIewithPCIe,SATA,andUSBsignal 1
Full-sizemPCIewithPCIeandUSBsignal 1
Full-sizemPCIewithSATAandUSBsignal 1
Rear I/O
DisplayPort,Version1.2(HDMICECoption,supportsdualmodeandMST) 2
GbELAN 1 2
USB2.0 4
Front I/O
USB3.0 2
USB type C 3.1 1
Audiojack;line-in/out 1
Power button 1
Onboard I/O
USB2.0 pin header (2 USB supported) 1
RS-232/422/485 pin header 2
SATApower 1
CECheader 1
ATmodejumperheader 1
RTCbatteryheader 2
Ambient temperature header 1
Super I/O Controller NCT6793D
LAN Controller RTL8111G
BIOS BIOSresidentinaSerialPeripheralInterface(SPI)Flashdevice
SupportforAdvancedCongurationandPowerInterface(ACPI)andSystemManagementBIOS(SMBIOS)
Environment
OperatingTemperature:0°C~40°C
Operationhumidity:10%~90%
StorageTemperature:0°C~60°C
Storagehumidity:5%~95%
Dimensions 196 x 121 x 37mm
Mounting Wall,DIN,VESA-75/100.(Additionalmountinghardwarerequired)
Certications
CE(EN55022,EN55032,EN55024,EN60950-1)
FCCpart15b,ClassA
RoHS,WEEE
UL/IEC62368-1,UL/IEC60950-1

ML350G-10 Industrial Computer
9
5.3 - Mounting Hole Pattern
210.6 mm
223.4 mm
76.2 mm
40.5 mm
12.7 mm
3.7 mm
Ø4.5mm
Ø4.6 mm
Ø8 mm

ML350G-10 Industrial Computer
10
5.4 - Mounting Guide
Wall Mounting
Step 1:Attachwallmountbracketstochassis
Step 2:Markandprepholesinsurfaceformounting
Step 3: Fastensystemtosurface
VESA Mounting
Step 1:Install4VESAScrewsintoyourdisplay/surface
Step 2:AttachVESAbrackettothechassis
Step 3: Hangcombinedsystemandbrackettodisplay/surface
DIN Rail Mounting
Step 1:Attachwallmountingbracketstothechassis
Step 2:AttachDINRailClipstothemountingbrackets
Step 3:ClipsystemtotheDINRail

ML350G-10 Industrial Computer
11
6 - Motherboard Overview
Power ButtonUSB CUSB 3.0Audio
In/Out
LAN2 LAN1
(Optional)
USB 2.0
DisplayPort 2DisplayPort 1 Power In
Power In Header
Battery Header
CECHeader
Memory Slot
HeatsinkMounting
Board Mounting
AT/ATXJumper
COM Header
COM Header
Debug Header
FanHeader
SATAPower
Ambient Header
USB Header
Clear CMOS Jumper
mPCIe/mSATA mSATA mPCIe
1
14
11
12
13
25
24
15 16
17
18
19
20
21
23
22
27
2 345
67
8
9
26
10

ML350G-10 Industrial Computer
12
6.1 - Jumpers and Headers Guide
Number Location Function
1 J1_BIOS BIOS Load Default Header/Clear CMOS
2 J2 LAN1Connector
3 J3 LAN2Connector
4 J4 DisplayPort 1
5 J5 DisplayPort 2
6 J6 USBTypeCConnector
7 J7 USB 3.0 Connector
8 J8 Audio Connector
9J9_CEC CECHeader
10 J10 USB 2.0 Connector
11 J11 USB 2.0 Connector
12 J12_USB USB 2.0 Header
13 J13_AT_ATX AT/ATXModeJumper
14 J14_PCIE Mini PCIe (PCIe+USB)
15 J15_MUX MiniPCIe(PCIe+SATA+USB)
16 J16_SATA mSATA(SATA+USB)
17 J18_Power_In 4 Pin Power Connector
18 J20 DC In
19 J21_SATA SATAPowerHeader
20 J22_FAN FANHeader
21 J23_AMBIENT Ambient Sensor Header
22 COM1 Serial Port 1 Header
23 COM2 Serial Port 2 Header
24 XBT1_BATTERY Coin Battery Header
25 XBT2_BATTERY Coin Battery Header
26 SO_DIMM1 Memory Slot
27 DEBUG Debug Header

ML350G-10 Industrial Computer
13
6.2 - Conguring Jumpers
Refertothefollowingdiagramsforconguringjumpersandonboardheaders.
J1_BIOS
TheJ1_BIOSjumperloadsthedefaultBIOSsettings.Shortpins2-3fornormaloperation.Shortpins1-2to
cleartheCMOSandresetthesystemsetupcongurationtodefaultsettings.Ifyouexperiencechallenges
powering up, short pins 1-2 to troubleshoot.
J13_AT_ATX
AT=Autopoweron.
ATX=Noautopoweron.
Clear CMOS Normal
AT Mode ATX Mode

ML350G-10 Industrial Computer
14
6.3 - Onboard Headers
An onboard header is a connection on the motherboard that permits connecting a peripheral component to
an external port on the system
J9_CEC
TheML350G-31canbeconguredwithamodulethatallowsforCECfunctionality.TheJ9_CECconnector
includeswiringconnectionsfortheHDMIConsumerElectronicsControl(CEC).
COM1 and COM2
ThemotherboardincludesthefollowingCOMports:
COM1:I/Oport0x3F8,IRQ4
COM2: I/Oport0x2F8,IRQ3
Power Headers J18_POWER IN
ConnectDCpowerintoJ18_POWERIN.
RS232 RS422 RS485
1 DCD TX(negative) TX(negative)
2RXD# RX(positive) N/A
3TXD# TX(positive) TX(positive)
4DTR RX(negative) N/A
5GND GND GND
6 DSR N/A N/A
7RTS N/A N/A
8CTS N/A N/A
9 RI N/A N/A
10 Key N/A N/A
1V+
2GND
3GND
4V+

ML350G-10 Industrial Computer
15
J12_USB
TheJ12_USBconnectorsupportstwoUSBports.
J23_Ambient Header
TheJ23_AMBIENTconnectorprovidesSystemManagementBus(SMBus)communication.
1SMBusClock
2SMBus Data
3GND
15V_USB
3Data(Negative)
5Data (Positive)
7GND
9Key
25V_USB
4Data(Negative)
6Data (Positive)
8GND
10 None
XBT1_BATTERY and XBT2_BATTERY
ConnectthesystemandbackupbatteriestotheXBT1_BATTERYandXBT2_BATTERYconnectors.
13V
2GND
13V
2GND
