Logik L2HDVD11 User manual

DVD Player with
LED Display
Instruction Manual
L2HDVD11
L2HDVD11_IB_final110330.indd 1 30/03/2011 3:45 PM

L2HDVD11_IB_final110330.indd 2 30/03/2011 3:45 PM

Contents
Unpacking......................................................................................................................................5
Product Overview..........................................................................................................................6
Front Panel ................................................................................................................................................................ 6
Rear Panel.................................................................................................................................................................. 6
Remote Control ....................................................................................................................................................... 7
Battery Installation for the Remote Control.................................................................................................. 9
Remote Control Operation Range.................................................................................................................... 9
Connections .................................................................................................................................10
Audio / Video Connections ...............................................................................................................................10
Audio Connections Only (Optional)...............................................................................................................11
Connecting to the Mains Socket.....................................................................................................................11
Compatible Disc Types ................................................................................................................12
Supported Formats..............................................................................................................................................12
Region Code ...........................................................................................................................................................12
Start Up ........................................................................................................................................13
Basic Playback..............................................................................................................................13
Stop Playback.........................................................................................................................................................13
Previous and Next.................................................................................................................................................13
Fast Forward and Fast Reverse.........................................................................................................................14
Pause Playback ......................................................................................................................................................14
Single Step Playback............................................................................................................................................14
Volume Adjustment.............................................................................................................................................14
Advanced Playback .....................................................................................................................15
OSD............................................................................................................................................................................15
Title ............................................................................................................................................................................15
Subtitle Language ................................................................................................................................................15
Repeat.......................................................................................................................................................................15
Slow ...........................................................................................................................................................................15
Source .......................................................................................................................................................................16
A-B Repeat...............................................................................................................................................................16
GOTO.........................................................................................................................................................................16
Program....................................................................................................................................................................16
Zoom.........................................................................................................................................................................16
Angle.........................................................................................................................................................................16
Audio Channel .......................................................................................................................................................17
L2HDVD11_IB_final110330.indd 3 30/03/2011 3:45 PM

JPEG File Playback .......................................................................................................................17
Image Rotation......................................................................................................................................................17
Zoom.........................................................................................................................................................................18
Thumbnail Preview ..............................................................................................................................................18
System Setup ...............................................................................................................................19
General Setup Page.....................................................................................................................19
TV Display................................................................................................................................................................19
Angle Mark .....................................................................................................................................................20
OSD (On Screen Display) Language...............................................................................................................20
Closed Captions.....................................................................................................................................................20
Screen Saver ...........................................................................................................................................................20
Last Memory...........................................................................................................................................................20
Audio Setup Page ........................................................................................................................21
Analog Audio Page...............................................................................................................................................21
Digital Audio Page................................................................................................................................................21
Dolby Digital Setup Page............................................................................................................21
Dual Mono...............................................................................................................................................................21
Dynamic ...................................................................................................................................................................21
Video Setup Page ........................................................................................................................22
Video Output..........................................................................................................................................................22
Resolution................................................................................................................................................................22
Color Setting...........................................................................................................................................................22
HDMI Setup.............................................................................................................................................................22
Preference Setup Page................................................................................................................23
TV Type .....................................................................................................................................................................23
Audio.........................................................................................................................................................................23
Subtitle .....................................................................................................................................................................23
Disc Menu................................................................................................................................................................23
Parental.....................................................................................................................................................................24
Password..................................................................................................................................................................24
Default ......................................................................................................................................................................24
Maintenance ................................................................................................................................25
Hints and Tips ..............................................................................................................................26
Specications...............................................................................................................................27
Safety Warnings...........................................................................................................................28
L2HDVD11_IB_final110330.indd 4 30/03/2011 3:45 PM

5
Unpacking
Remove all packaging from DVD Player. Retain the packaging. If you dispose of it
please do so according to local regulations.
Remote Control
(P.N.: 8.50.1.R9040058RR)
DVD Player
Instruction Manual
(P.N: L2HDVD11-IB-001)
Quick Start Guide
(P.N: L2HDVD11-QSG-001)
Thank you for purchasing your new Logik DVD Player with LED Display.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it oers. You will also
nd some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
DVD Player with
LED Display
Instruction Manual
L2HDVD11
L2HDVD11_IB_final110330.indd 5 30/03/2011 3:45 PM

6
Product Overview
Front Panel
1 2 3 4 5
Rear Panel
1. Disc Tray
To load a disc into the disc drive.
2. OPEN/CLOSE button
To open and close the disc tray.
3. PLAY/PAUSE button
To start playback/stop playback
momentarily
4. STOP button
To stop playback.
1. SCART Output
Connects a SCART cable to a TV or a
monitor equipped with a SCART video
input terminal.
2. Component Video Output
Connects the component video cables
to the Y Pb Pr input of the TV.
3. VIDEO Output
Connects a composite VIDEO cable to
the DVD player’s VIDEO socket to the
video input socket on the TV.
4. HDMI Output
Connects an HDMI cable to a TV, a
monitor or an AV amplier equipped
with an HDMI input terminal.
5. STANDBY button
To turn the power on or restores the
DVD player to standby mode.
6. Display Screen
Shows information about the current
status of the DVD player.
7. Memory Card Slot
Connection for SD/MMC/MS cards.
8. USB Slot
Connection for a USB Flash Drive.
5. 2 Channels Audio Output
Connects audio cables to a stereo
system equipped with an AUDIO
input terminal.
6. COAXIAL Output
Connects a coaxial cable to the
COAXIAL socket of the DVD player to
the corresponding coaxial IN socket
on an AV amplier.
7. S-Video Output
Connects a S-Video cable to the
S-Video input of the TV.
6 7 8
1 2
5
3
64 7
L2HDVD11_IB_final110330.indd 6 30/03/2011 3:45 PM

7
Remote Control
1. STANDBY
To turn the power on or restore the
DVD player to standby mode.
2. SETUP
To display the Setup Menu of the
DVD player.
3. 0–10+
To select the numeric items in a
menu.
4. F.REV
To fast reverse during playback.
F.FWD
To fast forward during playback.
5. PLAY
To play the DVD disc.
6. STOP
To stop the playback.
7. TITLE
To go back to the previous menu or
show the title menu. (If it is available
in the DVD features)
8. CURSOR
To move up, down, left and right in
the Setup Menu.
9. AUDIO
To change the audio mode.
10. ZOOM
To enlarge the picture on the TV.
11. ANGLE
To switch / change the camera angle
during playback. (If it is available in
the DVD features)
12. ASPECT
Press repeatedly to switch the aspect
ratio between 16:9, 4:3 PANSCAN, 4:3
LETTERBOX and WIDE SQUEEZE.
13. SOURCE
To switch between DVD, USB,
Memory Card as the input source.
14. MUTE
To mute and restore your DVD sound
output.
15. NTSC/PAL
Press repeatedly to select a TV type,
NTSC or PAL.
1
2
3
4
5
6
7
8
9
10
11
13
15
12
14
L2HDVD11_IB_final110330.indd 7 30/03/2011 3:45 PM

8
31
30
28
26
25
24
23
22
21
20
19
18
17
16
29
27
16. OPEN/CLOSE
To open or close the DVD disc tray.
17. A-B RPT
To repeat playback between 2
particular points on a disc.
18. OSD (On screen Display)
To display the disc information.
19. VOLUME +/–
To increase and decrease the volume.
20. GOTO
To search and start playback from a
selected point on the disc.
21. NEXT
To skip to the next title, chapter or
track.
PREV
To return back to the previous title,
chapter or track.
22. PAUSE
To pause the playback.
23. SUBTITLE
To switch between dierent subtitle
languages. (Available languages
depend on the DVD features)
24. ENTER
To conrm the selection
25. MENU
To enter or exit the disc contents menu.
26. STEP
To play or move the playback forward
frame by frame.
27. V-MODE
To Switch the video output mode.
28. REPEAT
To select between dierent repeat
modes – REPEAT CHAPTER, REPEAT
TITLE, REPEAT ALL.
29. PROG
To program and view the selected
starting point of a chapter and title in
the DVD disc.
30. RESOLUTION
Press repeatedly to select a resolution.
31. SLOW
Press repeatedly for slow-motion
forward and reverse playback in
dierent speeds.
L2HDVD11_IB_final110330.indd 8 30/03/2011 3:45 PM

9
2. Insert two AAA size batteries. Make
sure to match the (+) and (–) ends of
the battery compartment.
Battery Installation for the Remote Control
1. Press and lift the back cover up to
open the battery compartment of
the remote control.
3. Close the battery compartment cover.
Handling the Batteries
• Improper or incorrect use of batteries may cause corrosion or battery leakage,
which could cause re, personal injury or damage to property.
• Only use the battery type indicated in this manual.
• When the batteries are exhausted, the remote will not function. Replace both
batteries at the same time with new ones.
• Do not install new batteries with used ones and do not mix dierent types of
batteries.
• Do not dispose of used batteries as domestic waste. Dispose of them in
accordance with local regulations.
Handling the Remote Control
• Take care of your ngernails when you press and hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of excessive
heat.
• Remove the battery from the remote control when not in use for a long period
of time, as it could cause corrosion or battery leakage and may result in physical
injury and/or property damage including re.
Remote Control Operation Range
Point the remote control at the DVD player no more than
2 metres from the remote control sensor and within 40° of
the front of the DVD player. The operating distance may
vary depending on the brightness of the room. Within about 2 m
20° 20°
L2HDVD11_IB_final110330.indd 9 30/03/2011 3:45 PM

10
Connections
Audio / Video Connections
1. Connecting to a TV with an HDMI Cable
Use an HDMI cable (not supplied) to connect between the DVD player’s HDMI OUT
and the TV’s HDMI IN.
2. Connecting to a TV with a SCART Cable
Use a SCART cable (not supplied) to connect between the DVD player’s SCART OUT
and the TV’s SCART IN.
3. Connecting to a TV with a Component Video Cable
Use a component video cables (not supplied) to connect the Y Pb Pr outputs of
this unit to the corresponding Y Pb Pr inputs of a TV/monitor. Use audio cables (not
supplied) to connect between the DVD player audio output (Audio Left - White,
Audio Right - Red).
4. Connecting to a TV with AV Cable
Use audio/video cables (not supplied) to connect between the DVD player’s
AUDIO/VIDEO OUT and the TV’s AUDIO/VIDEO IN. (Audio Left = White, Audio Right
= Red and Video = Yellow)
5. Connecting to a TV with a S-Video Cable
Use a S-Video cable (not supplied) to connect the S-Video output of this unit to the
S-Video input of a TV/monitor. Use audio cables (not supplied) to connect between
the DVD player audio output (Audio Left - White, Audio Right - Red).
If your DVD player will not be connected to a stereo system or an AV
receiver, a SCART or an HDMI connection is sucient for both audio and
video connections between your DVD player and TV.
Television
1
2
3 4
5
345Audio Cable
(not included)
HDMI Cable
(not included)
SCART Cable
(not included) S-Video Cable
(not included)
Video Plug of AV Cable
(not included)
Component Video Cable
(not included)
(All cables not supplied.)
L2HDVD11_IB_final110330.indd 10 30/03/2011 3:45 PM
