Logik L16FANM11 User manual

16" Pedestal Fan with
Gun Metal Finish
Instruction Manual
L16FANM11
L16FANM11_IB_RC130125_Annie.indd 1 13年1月25日 下午5:47

L16FANM11_IB_RC130125_Annie.indd 2 13年1月25日 下午5:47

Contents
Unpacking����������������������������������������������������������������������������������������������������������������������4
Product Overview����������������������������������������������������������������������������������������������������������5
Assembling Your Fan �����������������������������������������������������������������������������������������������������6
How to Use Your Fan������������������������������������������������������������������������������������������������������8
Cleaning �������������������������������������������������������������������������������������������������������������������������8
Hints and Tips ����������������������������������������������������������������������������������������������������������������8
Specication ������������������������������������������������������������������������������������������������������������������8
Safety Warnings�������������������������������������������������������������������������������������������������������������9
L16FANM11_IB_RC130125_Annie.indd 3 13年1月25日 下午5:47

GB-4
Safety Warnings
1� Your fan should be used in such a way that it is protected from moisture, e.g. condensation, splashed water, etc. Do not
place or store your fan where it can fall or be pulled into water or any other liquid.
2� Do not place any objects on top of the fan. Stand the fan on a stable, level surface during use. Do not allow your fan to
sit on top of the mains cable.
3� Do not remove any fixed covers. Never use this appliance if it is not working properly, or if it has been dropped or
damaged. Always contact a qualified technician to carry out repairs.
4� Do not press the buttons on the control panel with anything other than your fingers.
5� If the fan is knocked over during use, turn off the unit and unplug it from the mains supply immediately.
6� Do not operate your fan in the bathroom.
7� Do not use hazardous chemicals to clean or come into contact with the fan. Never attempt to use the fan without the
base parts assembled or in a horizontal position.
8� This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
9� Children should be supervised to ensure that they do not play with the appliance.
10� If the mains cable is damaged it must be replaced by the manufacturer, its service agent , or similarly qualified persons
in order to avoid a hazard.
11� Ensure that the fan is switched off from the mains supply before removing the guard.
L16FANM11_IB_RC130125_Annie.indd 4 13年1月25日 下午5:47

GB-5
Unpacking
Remove all packaging from the Iron. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Thank you for purchasing your new Logik Pedestal Fan.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this instruction manual in order that you fully understand
all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
Motor X 1
P.N.: S0001
Stand X 1
P.N.: S0002
Round Base X 1
(including 4 Screws
and 4 Buttery Nuts)
P.N.: S0006
Front Guard X 1
P.N.: S0003
Blade X 1
P.N.: S0005
Rear Guard X 1
P.N.: S0004
Base Cover X 1
P.N.: S0007
Instruction Manual X 1
P.N.: S0008-V2
If items are missing, or damaged please contact Partmaster (UK only).
Tel: 0844 800 3456 for assistance.
16" Pedistel Fan with
Gun Metal Finish
Instruction Manual
L16FANM11
L16FANM11_IB_RC130125_Annie.indd 5 13年1月25日 下午5:47

GB-6
Product Overview
Speed Dial
Oscillating Control
Mains Power Plug
Height Adjustment
Screw
Stand
Stand Cover
Base
L16FANM11_IB_RC130125_Annie.indd 6 13年1月25日 下午5:47

GB-7
• Avoid using your fan in hazardous areas.
• Do not use your fan if it has not been fully assembled. Make sure that the screws that hold the base parts
and the main unit together are tightened securely.
Assembling Your Fan
3. Unscrew and take off the Thumbscrew and Height
Adjustment Nut from the Stand. Slide the Stand Cover
down the column to rest on the Base. Pull out the
Extension Tube and refit the Height Adjustment Nut.
The Height Adjustment Nut must be fully tightened
before assembling the motor section to the stand.
1. Unscrew the 4 Screws, 4 Butterfly Screws and the
Underpan Weight from the Base.
4. Fit the Motor section to the Stand and tighten the
Thumbscrew. The thumbscrew must be fully tightened
before the fan is operated. Remove the fibre glass sleeve
from the shaft and unscrew the Guard Retaining Nut.
Thumbscrew
Thumbscrew
Guard
Retaining
Nut
Screws
Underpan
Weight
Round
Base
Butterfly
Screws
Height
Adjustment
Nut
Stand Cover
Stand
Extension Tube
2. Pass the Stand Cover through the Stand. Use the 4
Screws and 4 Butterfly Screws to attach the Stand, and
the Underpan Weight to the Base.
L16FANM11_IB_RC130125_Annie.indd 7 13年1月25日 下午5:47

GB-8
5. Set the Rear Guard in the proper position (handle
uppermost) and screw on the Guard Retaining Nut
until tight.
6. Install the Blade onto the shaft and screw on the Blade
Retaining Screw until tight
Clips
Front Guard
Rear Guard
Blade Retaining
Screw
7. Open the Clips on the Front Guard and place the Front
Guard onto the Rear Guard (align locking screw holes)
and close the Clips.
8. Secure both guards firmly by aligning the guard collar
correctly and tightening the locking screw and nut.
L16FANM11_IB_RC130125_Annie.indd 8 13年1月25日 下午5:47

GB-9
How to Use Your Fan
Cleaning
Hints and Tips
Turn the Speed Dial for the required fan speed.
The following settings are available:
0- Off
1- Low Speed
2- Intermediate Speed
3- High Speed
1� To make the fan head oscillate, push the Oscillating Control down. To
stop the oscillation, pull the Oscillating Control up.
Use a short, damp cloth to wipe the outer body of the unit. Never completely cover the unit with water or use chemicals or
detergents as they could damage the unit in some way.
Speed Dial
Oscillating
Control
PROBLEM SOLUTION
The force of air coming from the
unit is weak.
Adjust the speed to a higher setting.
The unit does not work. Check that the plug is connected correctly and that the unit is
turned on at the mains supply.
Other abnormal conditions. Disconnect the fan from the wall and consult a repair specialist.
2� Adjust the tilt of the fan head to the desired angle by holding the
handle and pushing gently up or down on the fan guard.
L16FANM11_IB_RC130125_Annie.indd 9 13年1月25日 下午5:47

GB-10
Specications
Model L16FANM11
Rated Voltage 230 V
Rated Frequency 50 Hz
Input Power 70 W
Maximum Fan Flow Rate (F) 57.78 m3/min
Fan Power Input (P) 63.00 W
Service Value (SV) 0.92 (m3/min)/W
Standby Power Consumption (Psb)0.00 W
Seasonal Electricity Consumption (Q) 20.16 kWh/a
Fan Sound Power Level (Lwa)62.70 dB(A)
Maximum Air Velocity (c)2.62 meters/sec
Measurement Standard for Service Value
Commission Regulation (EU) No 206/2012
IEC 60879:1986
EN 50564:2011
EN 60704-2-7: 1998
EN 60704-1: 1997
Features and specifications are subject to change without prior notice.
L16FANM11_IB_RC130125_Annie.indd 10 13年1月25日 下午5:47

NOTE: If you require a replacement for any of the items listed below, please quote their corresponding part numbers:
Replacement Part Part Number
Motor S0001
Stand S0002
Front Guard S0003
Rear Guard S0004
Blade S0005
Round Base S0006
Base Cover S0007
Screw S0009
Butterfly Screw S0010
Underpan Weight S0011
Stand Cover S0012
Thumbscrew S0013
Height Adjustment Nut S0014
Guard Retaining Nut S0015
Blade Retaining Screw S0016
DSG Retail Ltd. (co. no. 504877)
Maylands Avenue, Hemel Hempstead, Herts., HP2 7TG, UK
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end of its
life separately from your household waste. There are separate collection
systems for recycling in the EU.
For more information, please contact the local authority or your retailer
where you purchased the product.
(P.N.: S0008-V2)
Visit Partmaster.co.uk today for the
easiest way to buy electrical spares and
accessories. With over 1 million spares
and accessories available we can deliver
direct to your door the very next day.
Visit www.partmaster.co.uk or call 0844 800 3456 (UK customers only) Calls charged at
National Rate.
L16FANM11_IB_RC130125_Annie.indd 11 13年1月25日 下午5:47
