Logik LFC55W12 User manual

Frost Free Fridge Freezer
Instruction Manual
LFC55W12

Contents
Unpacking.................................................................................................................................... 4
Installation ................................................................................................................................... 5
Location ..................................................................................................................................................................... 5
Reversing the Door Swing................................................................................................................................... 5
Levelling the Unit ................................................................................................................................................... 9
Cleaning Before Use .............................................................................................................................................. 9
Before Using Your Unit.......................................................................................................................................... 9
Interior Accessories................................................................................................................................................ 9
Product Overview...................................................................................................................... 10
Operation ................................................................................................................................... 11
Switching On Your Unit ......................................................................................................................................11
Adjusting the Temperature...............................................................................................................................11
Noises Inside the Unit!........................................................................................................................................11
Shopping for Chilled Foods..............................................................................................................................12
Tips for Keeping Food in the Unit...................................................................................................................12
Shopping for Frozen Foods ..............................................................................................................................12
Preparations for Freezing...................................................................................................................................13
Defrosting Frozen Food......................................................................................................................................13
Cleaning ..................................................................................................................................... 14
Defrosting ...............................................................................................................................................................14
Cleaning the Interior and the Exterior of the Unit....................................................................................14
Cleaning Tips..........................................................................................................................................................14
Maintenance .............................................................................................................................. 15
Changing the Internal Light .............................................................................................................................15
Care When Handling / Moving the Unit.......................................................................................................15
Servicing..................................................................................................................................................................15
Switching O for Long Periods of Time........................................................................................................15
Disposal...................................................................................................................................... 15
Specications............................................................................................................................. 16
Safety Warnings......................................................................................................................... 17

4
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Logik Fridge Freezer.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
The Main Unit
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Fridge Glass Shelf x 3
P.N.: 50360201028K
Salad Bin
P.N.: 501122010113
Small Freezer Drawer x 3
P.N.: 501124810062
Large Freezer Drawer
P.N.: 501108330011
Small Fridge Door Shelf x 2
P.N.: 501113040097
Egg Tray
P.N.: 501119710072
Instruction Manual
P.N.: LFC55W12-001
Large Fridge Door Shelf
P.N.: 501113040096
Ice Tray
P.N.: 501113810004

INSTALLATION
5
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
When installing the unit, ensure that 200 mm of free space is left at both sides, 200 mm at
the rear and 300 mm at the top of the unit. The door can be opened to the right or the left,
depending on what better suits the location. Please ensure there is adequate space for the
door to fully open.
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe
that you are qualified to do so.
• All parts removed must be saved to do the reinstallation of the door. You should
rest the unit on something solid so that it will not slip during the door change
process. Do not lay the unit flat as this may damage the coolant system. Ensure
the unit is unplugged and empty.
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• To take the door off it is necessary to tilt the unit backwards. You should rest the
unit on something solid so that it will not slip during the door reversing process.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
1. Tilt the unit slightly towards the rear and
prop it securely. Two people are required
to tilt the unit during the door reversal
process.
Installation

INSTALLATION
6
2. Remove the 2 screws on the back.
3. Lift the top cover away from the fridge.
4. Remove the three screws, then remove
the upper hinge that holds the door in
place. Lift the upper door and place it
on a padded surface to prevent it from
scratching.
5. Swap the bottom bushing and bottom
bushing cap of the upper door. The
bottom bushing key must be in the
correct position to allow it to be inserted
correctly.
2. Remove the 2 screw covers first, then
undo the screws underneath.

INSTALLATION
7
6. Take off the middle hinge by removing
the screws. Lift the lower door and place
it on a padded surface to prevent it from
scratching.
Remove the screws’ covers and place
them to the opposite side.
7. Swap the bottom bushing and bottom
bushing cap of the lower door. The
bottom bushing key must be in the
correct position to allow it to be inserted
correctly.
8. Remove the lower screws, hinge bracket
and adjustable feet from the unit bottom.
9. Remove the screw-type adjustable feet
from another side of the unit bottom and
transfer it to the corresponding position
on the opposite side of the unit bottom.
10. Reattach the two lower screws, hinge
bracket and adjustable feet to the
opposite side of the unit bottom. Loosely
secure. Carefully set the lower door back
into place, sliding it onto the bottom
hinge.
unscrew
unscrew unscrew
screw screw

INSTALLATION
8
11. After placing the freezer door, screw the
middle hinge back onto the opposite
side of the unit. Middle hinge
12. Carefully set the upper door back into
place. Ensure the fridge door is aligned
horizontally and vertically so that the
seals are closed on all sides before finally
tightening the top hinge.
13. Insert the hinge bracket and screw it to
the top of the unit.
14. Use a spanner to tighten it if necessary.
15. Put the top cover back on and fix it in
place with the screws.
16. With the door closed, check that the
door is aligned horizontally and vertically
and that the seals are closed on all sides
before finally tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
Ensure the freezer door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before finally tightening the hinge.

INSTALLATION
9
Levelling the Unit
To do this adjust the two levelling feet at the front of the
unit.
If the unit is not level, the doors and magnetic seal
alignments will not be covered properly.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is
working properly and to allow it time to fall to the correct temperature. Your unit should not
be overfilled.
Interior Accessories
Various glass or plastic storage shelves are included with your appliance – different models
have different combinations.
You should always slide one of the full size glass storage shelves into the lowest set of
guides, above the fruit and vegetable containers, and keep it in this position. To do this, pull
the storage shelf forward until it can be swivelled upwards or downwards and removed.
Please do the same in reverse to insert the shelf at a different height.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the
unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time
to settle.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the shelves,
drawers and salad bin. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
In order to make the most of the volume of the fresh food storage compartment
and frozen-food storage compartment, the user can remove one or more shelves
and/or drawers, according to your daily use.

10
Product Overview
Egg Tray Ice Tray
Freezer Drawers
Thermostat
and Bulb
Fridge Glass
Shelves
Salad Bin
Fridge
Door
Shelves
Adjustable
Feet
