Logik LFC50S10 User manual

Fridge Freezer
Instruction Manual
LFC50S10
LFC50W10
LFC50S_W10_IB_final110309.indd 1 09/03/2011 6:07 PM

LFC50S_W10_IB_final110309.indd 2 09/03/2011 6:07 PM

Contents
Unpacking.................................................................................................................................... 4
Installation ................................................................................................................................... 5
Location ..................................................................................................................................................................... 5
Reversing the Door Swing................................................................................................................................... 5
Levelling the Unit ................................................................................................................................................... 8
Cleaning Before Use .............................................................................................................................................. 8
Before Using Your Unit.......................................................................................................................................... 8
Product Overview........................................................................................................................ 9
Operation ................................................................................................................................... 10
Switching On Your Unit ......................................................................................................................................10
Adjusting the Temperature...............................................................................................................................10
Noises Inside the Unit .........................................................................................................................................11
Shopping for Chilled Foods ..............................................................................................................................11
Tips for Keeping Food Perfect in the Unit....................................................................................................11
Shopping for Frozen Foods...............................................................................................................................11
Preparations for Freezing...................................................................................................................................12
Defrosting Frozen Food......................................................................................................................................12
Cleaning ..................................................................................................................................... 13
Defrosting ...............................................................................................................................................................13
Cleaning the Interior and the Exterior of the Unit....................................................................................13
Cleaning Tips..........................................................................................................................................................13
Maintenance .............................................................................................................................. 14
Changing the Internal Light .............................................................................................................................14
Care When Handling / Moving the Unit.......................................................................................................14
Servicing..................................................................................................................................................................14
Switching O for Long Periods of Time........................................................................................................14
Disposal...................................................................................................................................... 14
Specication .............................................................................................................................. 15
Safety Warnings......................................................................................................................... 16
LFC50S_W10_IB_final110309.indd 3 09/03/2011 6:07 PM

4
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
The Main Unit
Thank you for purchasing your new Logik Fridge Freezer.
We recommend that you spend some time reading this instruction manual in order
that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction manual
for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Adjustable Glass Shelf x 2
P.N.: 503602010054
Salad Bin
P.N.: 501116810058
Small Freezer Drawer x 2
P.N.: 501117010010
Large Freezer Drawer
P.N.: 501116810057
Egg Tray
P.N.: 501100000612
Ice Tray
P.N.: 501117810109
Instruction Manual
P.N.: LFC50S-W10-002
Upper Fridge Door Shelf
P.N.: 501116810055
Midde Fridge Door Shelf
P.N.: 501116810054
Lower Fridge Door Shelf
P.N.: 501116810056
LFC50S_W10_IB_final110309.indd 4 09/03/2011 6:08 PM

Location
When selecting a position for your unit you should make sure the floor is flat and firm, and the room
is well ventilated with an average room temperature of between 16°C and 32°C. Avoid locating your
unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the
electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly. This unit is not designed for use in a garage or outdoor installation. Do not drape the unit
with any covering.
When installing the unit, ensure that 2 cm of free space is left at both sides and 3 cm at the rear of
the unit. The door can be opened to the right or the left, depending on what better suits the location.
Please ensure there is adequate space for the door to fully open.
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• If you want to have the door swing reversed, we recommend that you contact a qualified
technician. You should only try to reverse the door yourself if you believe that you are
qualified to do so.
• All parts removed must be saved to do the reinstallation of the door. You should rest the
unit on something solid so that it will not slip during the door change process. Do not lay
the unit flat as this may damage the coolant system. Ensure the unit is unplugged and
empty.
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• To take the door off it is necessary to tilt the unit backwards. You should rest the unit on
something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door. You should rest the
unit on something solid so that it will not slip during the door reversing process.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
1. Remove the top right hinge cover.
INSTALLATION
5
LFC50S_W10_IB_final110309.indd 5 09/03/2011 6:08 PM

3. Remove the top left screw cover.
4. Remove the fridge door.
Unscrew
5. Take off the middle hinge by removing the
screws.
6. Lift the freezer door up and move it away.
7. Remove the screws’ covers and place them to
the opposite side.
2. Undo the screws. Then remove the hinge bracket.
Unscrew
Remove
INSTALLATION
6
LFC50S_W10_IB_final110309.indd 6 09/03/2011 6:08 PM

8. Tilt the unit carefully. 2 people are required to
tilt the unit during the door reversing process.
Unscrew Screw
9. Remove the screws and bottom hinge. Then
remove the adjustable feet from both side
and reattach them to the opposite side.
10. Place the freezer door back on.
11. After replacing the freezer door, screw the
middle hinge back onto the opposite side of
the unit.
Screw
Ensure the freezer door is aligned
horizontally and vertically, so that the
seals are closed on all sides before finally
tightening the hinge.
12. Place the fridge door back on. Ensure the
fridge door is aligned horizontally and
vertically so that the seals are closed on all
sides before finally tightening the top hinge.
13. Insert the hinge bracket and screw it to the
top of the unit.
14. Use a spanner to tighten it if necessary.
15. Put the hinge cover and the screw cover back.
Double check that the door is aligned
correctly and all the seals are closed
on all sides. If necessary, re-adjust the
levelling feet.
INSTALLATION
7
LFC50S_W10_IB_final110309.indd 7 09/03/2011 6:08 PM

Levelling the Unit
To do this use the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using
a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the shelves, drawers and salad bin.
Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time to settle.
INSTALLATION
8
LFC50S_W10_IB_final110309.indd 8 09/03/2011 6:08 PM

9
Product Overview
Thermostat Control Dial
Lower Fridge
Door Shelf
Middle Fridge
Door Shelf
Upper Fridge
Door Shelf
Freezer
Door
Salad Bin
Adjustable
Feet
Freezer
Drawers
Ice Tray
(Inside the
drawer)
Adjustable
Glass
Shelves
Internal
Light
Egg Tray Ice Tray
LFC50S_W10_IB_final110309.indd 9 09/03/2011 6:08 PM

10
Operation
Switching On Your Unit
1. Connect the mains cable to the mains socket. The
internal temperature of your unit is controlled by a
thermostat. There are seven settings, of which position
7is the coldest and position 0turns the unit off.
2. Adjust the thermostat control dial to the desired
position, bear in mind that the higher the number, the
lower the temperature. Position 4 is the recommended
setting when operating at normal room temperature
(between 16°C and 32°C).
3. The unit may not operate at the correct temperature if
it is in a particularly hot or a particularly cold room, or
if you open the doors often.
4. To ensure that the unit is cool enough to sufficiently
chill and freeze your food wait 24 hours before filling it
with food.
5. If you are concerned that your unit is not being kept
cold enough and wish to check the temperature
you will need a special fridge/freezer thermometer.
These are available from most supermarkets and
hardware shops. Place the thermometer in the centre
of either the fridge or freezer compartment and leave
overnight. The correct temperature for the fridge
compartment should be an average of 5°C. The correct
temperature for the freezer compartment should be
-18°C or lower.
Adjusting the Temperature
The internal temperature of the unit is controlled by a thermostat. The recommended position is between
1 to 4 for colder working environments (i.e. during winter) and between 5 to 7 for hotter environments.
Please adjust according to the environment.
1
OFF
7
6
5
4
3
2
LFC50S_W10_IB_final110309.indd 10 09/03/2011 6:08 PM
