Logik LUR55S13 User manual

Instruction Manual
Undercounter Fridge
LUR55S13

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 5
Installation .................................................................................................................................... 6
Location..................................................................................................................................................................... 6
Reversing the Door Swing.................................................................................................................................. 6
Space Requirements............................................................................................................................................. 9
Levelling the Unit................................................................................................................................................... 9
Cleaning Before Use.............................................................................................................................................. 9
Before Using Your Unit......................................................................................................................................... 9
Interior Accessories............................................................................................................................................... 9
Product Overview....................................................................................................................... 10
Operation .................................................................................................................................... 11
Switching On Your Unit......................................................................................................................................11
Adjusting the Temperature ..............................................................................................................................11
Noise Inside the Unit! .........................................................................................................................................11
Tips for Keeping Food in the Unit ..................................................................................................................11
Cleaning ...................................................................................................................................... 12
Defrosting the Fridge Compartment............................................................................................................12
Defrosting the Freezer Compartment..........................................................................................................12
Cleaning the Interior and the Exterior of the Unit ...................................................................................12
Cleaning Tips .........................................................................................................................................................12
Maintenance ............................................................................................................................... 13
Changing the Internal Light.............................................................................................................................13
Care When Handling / Moving Your Unit ....................................................................................................13
Servicing .................................................................................................................................................................13
Switching O for Long Periods of Time .......................................................................................................13
Disposal....................................................................................................................................... 13
Specications.............................................................................................................................. 14

4
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• Keep ventilation openings in the appliance enclosure clear of
obstructions.
• Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
• Do not use electrical appliances inside the food storage compartments
of the unit, unless they are of the type recommended by the
manufacturer.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as radiators
or res as refrigerant and vesicant are burnable.
• Young children should be supervised to ensure that they do not play
with the unit.
• Do not damage the refrigerant circuit (applicable only for appliances
with refrigeration circuits which are accessible to the user).
• The unit must be maneuvered by a minimum of 2 persons.
• This unit is not intended for use by persons (including children) with
reduced sensory or mental capabilities, or lack of experience and
knowledge unless they have been given supervision or instructions
concerning the use of the unit by a person responsible for their safety.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store volatile or ammable substances in the unit.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.

5
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local
regulations.
The following items are included:
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Adjustable Glass Shelf Salad Bin Cover
The Main Unit
Salad Bin Egg Tray
Lower Door Shelf
Ice Tray
Upper Door Shelf x 2
* All images in this instruction manual are for indication only; please refer to your individual unit for
details.

INSTALLATION
6
Location
When selecting a position for your unit you should make sure the oor is at and rm, and the room is well
ventilated with an average room temperature of between 16°C and 38°C. Avoid locating your unit near a heat
source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption.
Extreme cold ambient temperatures may also cause the unit not to perform properly. This unit is not designed
for use in a garage or outdoor installation. Do not drape the unit with any covering.
When installing the unit, ensure that 40 mm of free space is left at both sides, 15 mm at the rear and 20 mm
at the top of the unit. The door can be opened to the right or the left, depending on what better suits the
location. Please ensure there is adequate space for the door to fully open.
Reversing the Door Swing
Tools required: Phillips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• If you want to have the door swing reversed, we recommend that you contact a qualied
technician. You should only try to reverse the door yourself if you believe that you are qualied to
do so.
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• To take the door o it is necessary to tilt the unit backwards. You should rest the unit on
something solid so that it will not slip during the door reversing process.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit at as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
1. Tilt the unit slightly towards the rear and prop it
securely. Two people are required to tilt the unit
during the door reversal process.
Installation

INSTALLATION
7
3. Remove the 2 screws on the back.
4. Lift the top cover away from the fridge.
5. Remove the three screws, then remove the
upper hinge that hold the door in place. Lift
the door and place it on a padded surface to
prevent it from scratching.
6. Swap the bottom bushing and bottom bushing
cap of the upper door. The bottom bushing key
must be in the correct position to allow it to be
inserted correctly.
2. Remove the 2 screw covers rst, then undo the
screws underneath.
7. Remove the lower screws, hinge bracket and
adjustable feet from the unit bottom.
unscrew unscrew

INSTALLATION
8
screw screw
8. Remove the screw-type adjustable feet from
another side of the unit bottom and transfer it
to the corresponding position on the opposite
side of the unit bottom.
9. Reattach the two lower screws, hinge bracket
and adjustable feet to the opposite side of the
unit bottom. Loosely secure.
10. Carefully set the upper door back into place.
Ensure the fridge door is aligned horizontally
and vertically so that the seals are closed on all
sides before nally tightening the top hinge.
Insert the hinge bracket and screw it to the top
of the unit.
11. Use a spanner to tighten it if necessary.
13. With the door closed, check that the door is
aligned horizontally and vertically and that
the seals are closed on all sides before nally
tightening the bottom hinge. Re-adjust the
levelling feet as needed.
12. Put the top cover back and x it in place with
the screws.

INSTALLATION
9
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the door and magnetic seal alignments
will not be covered properly.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a
‘wrung-out’ sponge or cloth. Wash the shelves and salad bin in warm soapy water and dry completely before
replacing in the unit. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working properly and
to allow it time to fall to the correct temperature. Your unit should not be overlled.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant uid needs time to settle.
Interior Accessories
Various glass or plastic storage shelves are included with your appliance – dierent models have dierent
combinations.
You should always slide one of the full size glass storage shelves into the lowest set of guides, above the fruit
and vegetable containers, and keep it in this position. To do this, pull the storage shelf forward until it can be
swivelled upwards or downwards and removed.
Please do the same in reverse to insert the shelf at a dierent height.
In order to make the most of the volume of the fresh food storage compartment and frozen-food
storage compartment, the user can remove one or more shelves, drawers, out of the appliance,
according to your daily use.
Space Requirements
The unit’s door must be able to open fully as shown.
xxx = xxx - xxx
xx - xx
xxx - xxx
xxx
xxx - xxx
min xxx
xxx
xxx = xxx - xxx

10
Product Overview
Ice TrayEgg Tray
Adjustable
Glass Shelf
Internal Light
and Thermostat
Control Dial
Salad Bin Cover
Salad Bin
Freezer
Compartment
Lower Door
Shelf
Levelling Feet
Upper
Door
Shelves
