Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
Thank you for purchasing your new Logik Fridge Freezer.
You must spend some time reading this instruction manual in order that you fully
understand all the operational features it offers.
You must read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Fridge Glass Shelves x 3
P.N.: 47002779
Lower Fridge Shelf x 1
P.N.: 47002780
Vegetable Drawers x 2
P.N.: 42037484
Large Freezer Drawer
P.N.: 42037485
Small Freezer Drawers x 2
P.N.: 42037487
Egg Trays x 2
P.N.: 42000227
Instruction Manual
P.N.: 52039621
The Main Unit Ice Tray x 1
P.N.: 42031617
Catcher Left/ Combi
P.N.: 42053683
Middle Hinge Screw Cap (Big)
P.N.: 42032778
Bushing Cap
P.N.: 42031578
LFC60W11_IB_final110511.indd 4 11/05/2011 9:59 AM

Location
When selecting a position for your unit you should make sure the floor is flat and firm, and the room
is well ventilated with an average room temperature of between 16°C and 32°C. Avoid locating your
unit near a heat source, e.g. cooker, boiler or radiator (must be at least 50 cm away). Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures may
also cause the unit not to perform properly. This unit is not designed for use in a garage or outdoor
installation. Do not drape the unit with any covering.
When installing the unit, ensure that 2 cm of free space is left at both sides and 3 cm at the rear of
the unit. The door can be opened to the right or the left, depending on what better suits the location.
Please ensure there is adequate space for the door to fully open.
Reversing the Door Swing
Tools required: Phillips style screwdriver / Flat bladed screwdriver / Craft knife
• The unit must be manoeuvred by a minimum of 2 persons.
• If you want to have the door swing reversed, we recommend that you contact a qualified
technician. You should only try to reverse the door yourself if you believe that you are
qualified to do so.
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• All parts removed must be saved to allow you to refit the door.
• Do not lay the unit flat as this may damage the coolant system.
• You will need 2 people to handle the unit during assembly.
1. Unscrew the two screws which are fixing the
middle hinge.
2. Carefully remove the fridge and freezer doors
by pulling the middle hinge towards you to
release the hinge, the top door may need
lifting to allow this. Lower the top door off the
top hinge pin. Lift the bottom door off the
bottom hinge pin.
INSTALLATION
5
LFC60W11_IB_final110511.indd 5 11/05/2011 9:59 AM

12
4. Unscrew the bottom hinge fixing screws and
remove it. Remove the plastic washer.
5. Unscrew the pin of the bottom hinge from
Hole 1, rotate the bottom hinge 90° and screw
the pin into Hole 2.
6. Remove the tape covering the fixing holes on
the unit and the fixing holes of the bottom
hinge. Screw the bottom hinge to the bottom
left side of the unit. Replace the plastic washer
removed above.
7. Remove the screw cap cover and the 2 screw
hole caps on the left. Use the craft knife or
flat bladed screwdriver carefully to avoid
damaging the finish of the unit or yourself.
8. Insert the caps to the right side. (You will find
new caps, if needed, in the user instruction
bag.)
3. Tip and support the unit (be careful not to
damage the cooling circuit) to allow you to
get your hands underneath the kickplate.
Remove the kick plate by pulling the bottom
down and forward off the fixing clips.
Hole Hole
INSTALLATION
6
LFC60W11_IB_final110511.indd 6 11/05/2011 9:59 AM

9. Unscrew the two top hinge cover screws and
remove. Using a craft knife carefully remove
the section of the cover shown. Replace the
top hinge cover and ensure the top hinge
fixing holes are visible. Fix with the screws
removed earlier.
10. Unscrew the top hinge pin from the right side.
11. Screw the top hinge pin into the left side.
12. Swap the freezer door top bushing (The
bushing key must be in the correct position
to allow it to be inserted correctly.) and top
bushing cap. (You can find the new bushing
caps, if neeeded, in the user instruction bag)
13. Remove the freezer door bottom bushing
and bottom stopper (do not rotate) from
the right and then insert/fix them (You may
need to clear the screw holes of excess foam
insulation.) to the left side. (The bushing key
must be in the correct position to allow it to
be inserted correctly.)
INSTALLATION
7
LFC60W11_IB_final110511.indd 7 11/05/2011 9:59 AM

16. Remove the plastic washer. Turn the middle
hinge 180º, replace the washer on the upper
pin. Assemble the freezer door and fridge
door together with the middle hinge (Reverse
operation of item 2) Fix the middle hinge by
tightening the screws.
17. Finally, by using a craft knife cut the left
side of the kick plate where marked and
reassemble onto the fixing clips.
15. Unscrew the right door catcher and remove.
Refit the left door catcher (You may need
to clear the fixing holes of excess foam
insulation.) and screw down. (The left door
catcher can be found in the user instruction
bag).
Unscrew
Screw
14. Remove the fridge door top bushing and
insert it into left hole. (The bushing key must
be in the correct position to allow it to be
inserted correctly.)
INSTALLATION
8
LFC60W11_IB_final110511.indd 8 11/05/2011 9:59 AM

Levelling the Unit
To do this use the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal
alignments will not be covered properly.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate of soda. Then rinse with warm water
using a damp sponge or cloth. Wipe completely dry before replacing the shelves and drawers. Clean
the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time to
settle. You may damage the cooling circuit if the unit is turned on too soon
INSTALLATION
9
LFC60W11_IB_final110511.indd 9 11/05/2011 9:59 AM

10
Product Overview
Fridge Glass
Shelves
Fridge Door
Shelves
Lower Fridge
Door Shelf
Freezer Door
Thermostat and
Control Dial
Vegetable
Drawers
Lower
Fridge Shelf
Small
Freezer
Drawers
Large
Freezer
Drawer
Egg TrayIce Tray
LFC60W11_IB_final110511.indd 10 11/05/2011 9:59 AM
