Logik LTPSKM18 User manual

UNPACKING
SAFETY
Thank you for purchasing your new product.
Please follow this quick start guide for a successful rst time set up.
Read all the safety instructions carefully before use and keep the quick start guide
for future reference.
Medium Tilting
TV Bracket and
Power Starter Kit
Instruction Manual
LTPSKM18
IB-LTPSKM18-211026V4
Currys Group Limited (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
EU Representative
Currys Ireland Limited (259460)
3rd Floor Oce Suite
Omni Park SC, Santry, Dublin 9, Republic of Ireland
Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.
With over 1 million spares and accessories available we can deliver direct to your door
the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only)
Calls charged at National Rate.
Quick Start Guide
WARNING! READ THE FOLLOWING BEFORE STARTING INSTALLATION
• Assembly is required. Installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury
and property damage.
• The supplied TV bracket is only for use on vertical walls constructed from solid brick, solid concrete, solid wood and solid wooden columns.
• It is the installers’ responsibility to verify that the wall will safely support the total load of the TV and the TV bracket. Never exceed the
designated maximum TV load.
• Parts are heavy; take care when handling. For some steps, 2 people are required for installation.
• Check the TV bracket frequently to ensure that it is safe and secure. Additional tools (not included) are required for the installation. Do not
over-tighten screws.
• Keep this instruction manual for future reference.
TV LOAD
30 kg
KG
TV SIZE
Max. 55”
DISTANCE TO WALL
38 mm
VESA COMPLIANCE
100 x 100 – 400 x 400 mm
TILT ANGLE
0° ~ +10°
x 4
A1 x 4 A2 x 4 A3 x 1 A4
x 1
A5 x 2 A6
M8 × 50
× 4
B9
M5 × 15 M5 × 30M4 × 15
× 4
B1
M4 × 35
× 4
B2 × 4 B3 × 4 B4
M6 × 15 M8 × 35
× 4
B8
M6 × 35
× 4
B6
× 4
B5
M8 × 20
× 4
B7
× 4
B10 × 8 B11
M6-M8 × 5 M6-M8 × 10
× 4
B12
M4, M5/M6, M8

24
1
TOOLING
INSTALLATION
3
A4
2 people are required to lift
the unit during assembly.
Use spacers provided for mounting TVs with
curved/recessed backs, recessed mounting
holes, or to allow access to A/V inputs.
Ensure mounting screws are in
the centre of the timber stud.
A1
A2
ø4.5mm
60mm
ø10.5mm
60mm
A3
A1
A3
B1
B6
B2
B7
B3
B8
B4
B9
B5
B12
B10 B11
Screw M4
Screw M8
Screw M5-M6
