logika WL-ZSPCNPW-AL-02 User manual

© 2019 Logika Limited
Smart Sound Warner
WL-ZSPCNPW-AL-02
Product Manual
Version 1.0

1
Logika Limited
E
-Centre, Massey University, Gate 5, Oaklands Road
Albany, Auckland 0632, New Zealand
www.logika.nz
·[e-mail]
Introduction
Thank you for choosing Logika. Please take a moment to carefully read through the manual to
ensure safe and proper installation and use.
•Before use, the product must be properly installed as described in this manual by a qualified
technician.
•The product should be used with the supplied accessories.
•Do not disassemble or modify the product.
•Logika is not responsible for any loss due to improper installation or use of this product.
•Please visit our official website at www.logika.nz for more information.
•You can also contact us at the following email address: [e-mail].

2
Device Layout
Packing List
Smart Sound Warner Ceiling-Mounted Base Wall-Mounted Base
Screws (x2) + Wall Plugs (x2) Product Manual Warranty Card
System Indicator
Alarm Speaker
Alarm Light
Multi-Functional Button

3
Features
•Communication Mode: IEEE802.15.4 Zigbee.
•Can be linked to the other devices, like the Smart Panic Button, and sound an audible alarm.
•Strong anti-interference ability, low false alarm rate.
•Activate or deactivate defence through local or remote control via the mobile app.
Specifications
Communication Mode IEEE 802.15.4 (ZigBee/HA1.2)
Antenna Configure Internal Antenna
Power 100-240V AC, 50/60 Hz
Standby Power Consumption/Max ≤0.3 W/2W
Alarm Decibel ≥85dB at 1m
Overall Size (Diameter × Thickness) 98×32 (mm)
Material & Colour PC, White
Flame Retardant Rating UL94 V-0
Working Temperature -10 °C - +45°
Working Humidity ≤95%RH (Noncondensing)
Installation Method Ceiling Type
Net Weight (g) 90g
Storage Temperature -20°C - +60°C

4
Installation Steps
Hardware Installation
There are 3 ways that the Smart Sound Warner can be mounted on the ceiling or wall. Each option is
described below.
Note: The hole for the mains power is 10mm in diameter and the quick connector terminals will
accept 14-22 AWG cables.
Install Option 1
This install option is for the ceiling with a mounting hole between 68mm and 80mm in diameter. For
this option, you will need the main body of the Smart Sound Warner and the Ceiling-Mounted Base.
1) Attach the Smart Sound Warner to the Ceiling-Mounted Base by lining up the slots on the
Smart IR Transmitter to the Lock Plates on the Ceiling-Mounted Base unit. Turn clockwise to
lock them together.
2) Attach the power cable to the connector terminals.
Mounting Slots
Lock plates
Smart Sound Warner Body
Ceiling-Mounted Base
Connect mains cable to terminals

5
3) Pull the Spring mounts up and push the unit through the hole in the ceiling.
Install Option 2
This install option is for mounting without the need for cutting large ceiling holes. For this, you will
need the Smart Sound Warner, Wall-Mounted Base, wall plugs and screws (supplied).
1) Place the base onto the ceiling or wall and mark off where to drill.
2) Drill the holes (5mm) and insert the wall plugs.
3) Screw in the base to the ceiling, feeding the mains cable through the centre.

6
4) Connect the power cable to the Smart Sound Warner unit and attach to the Wall-Mounted
Base attached to the ceiling.
Install Option 3
This install option is similar to Install Option 2 but for situations where the cable can only be fed in
from the side (i.e. not through the ceiling). However, rather than using the Wall-Mounted Base, we
will be using the Ceiling-Mounted Base with the spring mounts removed.
1) Remove the spring mounts from the Ceiling-Mounted Base and place on the ceiling to mark
off the drill holes.
2) Drill the holes (5mm) and insert the wall plugs.
3) Screw in the base to the ceiling, feeding the mains cable through the side, as shown.
4) Connect the power cable to the Smart Sound Warner unit and attach to the base.
Original Location of Spring Mounts

7
Adding the Device to the Smart Home Network
Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the
Logika Smart Mobile App user guide which will take you through the process of adding smart
devices to the system.
Refer to the information below to locate the device in the Device Add screen. Once selected, the app
will walk you through how to add the device to the system.
Device Category:
Security
Device Name:
Smart Siren

8
Device Functions
When the device is first powered on, it will normally automatically attempt to connect to the Zigbee
Smart Home network. The System Indicator light will flash as it’s searching for the network. If it
connects, the light will remain on for 2 seconds and then go out.
If this does not happen, you can manually connect via the mobile app and follow the instructions
below.
Join the Zigbee Network
Press the Multi-Function Button once. The System Indicator light will start flashing, signifying it’s
searching for the network.
When it successfully connects, the System Indicator light will stay solid for 2 seconds then go out.
Quit the Zigbee Network
Long press the Multi-Function Button for 6 seconds. The System Indicator light will flash 4 times and
go out. The device has now been successfully removed from the network and been reset to the
factory defaults.

9
User Guide
It is assumed that you have successfully added the Smart Sound Warner to the Smart Home
Network, using the mobile app. Once done, you can link this device to other sensors via the
Housekeeper Tasks to sound an alarm when the specified conditions are met.
You can link this Smart Sound Warner with multiple devices – Smart PIR Motion Sensor, Gas
Detector, Panic Button, etc.
For instance, you could create a Linkage Task which listens for an alert from your Smart Gas Detector
and set this device as a linked device that would sound the alarm once a gas leak has been detected.
Refer to the Logika Smart Mobile App user manual to see how you can do this.

10
Safety Precautions
• Disable any power prior to connecting the device to the main supply.
• The device must be installed by a qualified electrician.
• Do not disassemble or refit this product or its accessories.
• The device should be mounted in a dry environment. It is not designed to be used
outdoors.

11
Troubleshooting
The device cannot be added to the Zigbee network.
The device may be registered to another network. In rare occasions this can happen if the device
was not removed from the test network at the factory.
Perform the Quit the Zigbee Network procedure mentioned in Device Functions section to clear this
setting. You should now be free to add the device to the local smart network.
The issue you are experiencing is not mentioned here.
Please contact us at [e-mail] with your issue and we will do our utmost to help!
