Logitech HARMONY 520 User manual

Harmony 520
User Manual version1.2

Harmony 520 User Manual
Table of Contents
INTRODUCTION...........................................................................................................................................1
GETTING TO KNOW YOUR HARMONY REMOTE...............................................................................................2
BEGINNING THE ONLINE SETUP PROCESS.....................................................................................................3
USING YOUR HARMONY REMOTE...........................................................................................................4
USING THE GLOW BUTTON...........................................................................................................................4
DISPLAYING HELP ON YOUR HARMONY REMOTE ...........................................................................................4
Types of Help Available.........................................................................................................................5
Using the Harmony Assistant ................................................................................................................5
SELECTING AN ACTIVITY...............................................................................................................................6
CONTROLLING INDIVIDUAL DEVICES..............................................................................................................6
CUSTOMIZING YOUR HARMONY REMOTE .............................................................................................7
CUSTOMIZING THE DISPLAY ON THE HARMONY REMOTE ................................................................................8
Changing the Behavior of Buttons within an Activity.............................................................................8
Adding Custom-Labeled Buttons...........................................................................................................9
CHANGING THE SETTINGS FOR YOUR HARMONY REMOTE ..............................................................................9
LEARNING INFRARED (IR) COMMANDS ..........................................................................................................9
Using the Infrared Sensor....................................................................................................................10
Naming an Infrared Command ............................................................................................................10
GETTING ADDITIONAL HELP ..................................................................................................................12
Finding Answers to Your Questions ....................................................................................................12
Troubleshooting Your Harmony Remote.............................................................................................12
v. 1.2 page i

Harmony 520 User Manual
Introduction
Congratulations on the purchase of your Harmony remote! True system control is now at your fingertips.
This User Manual will introduce you to the basic online setup process, customizations and main features
of your Harmony remote.
If in doubt about how to set up your Harmony remote, follow the information and instructions using the
Logitech Harmony remote software (also referred to as Harmony remote software).
The Harmony remote is an Internet-powered universal remote control. Your Harmony remote can control
most devices that understand infrared (IR) signals.
The configuration of your Harmony remote is simple:
• You will be prompted to answer questions about your entertainment devices to create your own
personal Harmony remote configuration.
• Your answers will provide us with a description of the entertainment devices you want to control,
how they are set up, and your preferences for controlling them.
• If one of your devices is not in the Harmony remote's database, the Harmony remote software will
learn about your device and add it to your configuration.
• Once you have told us about your devices, you will then be guided through setting up Activities.
Creating Activities is simple: you will be prompted to indicate the devices you use within an
Activity and how you want to control specific features, such as the volume, within that Activity.
 An Activity is a set of commands the Harmony remote sends to your entertainment system
to turn on the necessary devices.
 Once you have selected an Activity, you are in Activity mode, and the functionality of each
button on your Harmony remote is automatically configured for that Activity.
 Additionally, the display buttons will give you access to other commands for that Activity,
which cannot be set to the standard buttons.
Example
For the Watch Television Activity, the Harmony remote sends commands to your entertainment
system to turn on the necessary devices so you can watch television. The remote will
automatically be configured for the Activity based on the answers you selected during the online
setup process for the Activity.
At the end of the setup process, you will have your own configuration loaded in your Harmony remote.
Use your Harmony remote software to:
• Customize any of your Harmony remote’s features.
• Add more entertainment devices.
• Add more Activities.
v. 1.2 page 1

Harmony 520 User Manual
Getting to Know Your Harmony Remote
Many of the Harmony remote's buttons are standard remote buttons. However, there are buttons and
other hardware that may not be so familiar to you. The extra buttons and hardware give you access to the
special features of the Harmony remote.
USB Connector: Connect one end of the USB cable to this connector and
the other end to your computer so that you can download your configuration
using the Harmony remote software.
OFF: Turns all devices off with one button press.
Display: Shows a list of your Activities and devices, help, infrared (IR)
commands and any available listings.
Display Buttons: Use the buttons at the side of the display to select the
corresponding command.
Left/Right Arrow: Allows you to view more options on the display.
Activities: Press Activities to view a list of Activities you have added. Press
the display button next to the Activity you want and the Harmony remote will
set up your entertainment system.
Devices: Lists all your devices on the display, and allows you to select and
directly control any device.
Help: Asks you simple questions so that your Harmony remote can fix
problems you are having within an Activity.
Guide: Gives you access to view program listings, if you have a device with
this feature.
Info: Gives you additional information on program listings, if you have a
device with the Guide feature.
Exit: Exits from the Guide feature.
Menu: Gives you access to the menu system on a device, if you have a
device with this feature.
Prev: Goes to previous television channel.
Glow: Turns on and of the backlight on the Harmony remote.
Infrared Learning Port: The Harmony remote uses this port to learn
commands from your original remote.
v. 1.2 page 2

Harmony 520 User Manual
Beginning the Online Setup Process
Once you have installed the Logitech Harmony remote software, you will be guided through a series of
question-and-answer steps to complete each of the five main steps of the online setup process:
1. Login Information: Create your login information.
2. Check Connection: Ensures your computer and your Harmony remote are communicating
properly.
3. Set Up Devices: Helps you provide us with information about the devices in your personal home
theater system.
4. Set Up Activities: Helps you provide us with information about the way your devices work
together to perform Activities (e.g. Watch Television Activity).
5. Update Remote: Updates your remote with your personal settings.
Note: When using the Harmony remote software, click Help to view specific help for the step you
are at.
v. 1.2 page 3

Harmony 520 User Manual
Using Your Harmony Remote
This section provides you with information that will help you use your remote.
Using the Glow Button
Press the Glow button to light up or turn off the display backlight. To determine the length of time the
backlight stays on:
1. Connect your Harmony remote to your computer to start the Harmony remote software.
2. Click
Remote Preferences.
3. Select Settings.
4. Click Next.
Note: Shaking or tilting the Harmony remote will not light up the display backlight. Users must
press the Glow button to light up the display backlight. The remote will go into Deep Sleep mode
when the remote detects no motion for two hours. The remote will begin motion sensing in Deep
Sleep mode, and any motion or movement in front of the remote will trigger the glow.
Displaying Help on Your Harmony Remote
From time to time when you select an Activity, the Activity may not work. This can happen when the
Harmony remote sends many infrared commands to set up all your devices for an Activity, but one or
more devices are not receiving some commands. The Harmony remote is then "out of sync" with your
devices (e.g. it thinks one of your devices is on, but it is turned off). Some of the reasons the Harmony
remote can become "out of sync" with your system are:
• Someone walks between the Harmony remote and your entertainment system while an Activity is
starting.
• You point your Harmony remote away from your system while an Activity is starting.
• There is an object blocking the line-of-sight between your Harmony remote and the system.
• You are very far away from your entertainment system.
You will need to use the Help button on your Harmony remote to resynchronize the remote with your
devices. Before resynchronizing, ensure the cause of the problem has been addressed.
Example
Remove all obstructions so that the entertainment devices can receive the infrared commands
from the Harmony remote.
v. 1.2 page 4

Harmony 520 User Manual
To resynchronize:
1. Press the Help button.
2. Answer the questions on the remote’s display by selecting Yes or No. If you answer no to any
question, the Harmony remote will resend the necessary command and ask you the same
question again.
When you are done, the Harmony remote will be "in sync" with your devices again.
Types of Help Available
You can customize the Help button on your Harmony remote to provide one of the following types of help:
• Smart help
Asks questions about the devices that are on during a specific Activity.
• Full help
Asks questions about all the devices in your help system.
Select Full help if you find devices that aren’t being controlled the way you want them to, and the help on
the remote is not asking you questions about these devices.
To select the type of help you want:
1. Connect your Harmony remote to your computer to start the Harmony remote software.
2. Click
Remote Preferences.
3. Select
Settings.
4. Click Next.
Using the Harmony Assistant
Extra help is available from your remote by turning on the Harmony Assistant.
To turn on/off this feature using the Harmony remote software:
1. From
Home in the Harmony software, click Remote Preferences.
2. Select
Settings.
3. Click Next.
While the Help button helps you solve device problems within an Activity, the Harmony Assistant
teaches you how to use your Harmony remote. The following is an example of the type of help the
Harmony Assistant offers:
v. 1.2 page 5

Harmony 520 User Manual
Example
If any devices are not set up correctly, press “Help” now.
Selecting an Activity
View the Activities you have added by pressing the Activities button. The display will then list the
Activities you have added. Press the corresponding display button next to the Activity you want to start.
As a default, when you select an Activity, you will see a message on the remote’s
display reminding you to keep the remote pointed at your entertainment system
while the Activity starts. This helps ensure that all infrared (IR) signals are
properly sent.
To turn on/off the “Starting Activity” message:
1. Connect your Harmony remote to your computer to start the Harmony
remote software.
2. Click
Remote Preferences.
3. Select Settings.
4. Click Next.
Controlling Individual Devices
Press Devices to enter device mode. Device mode gives you access to all the possible commands for
each device included in your Harmony remote configuration. To access device mode you do not need to
be in an Activity. However, you should never need to use device mode during normal use of your
Harmony remote. This mode should only be used to send a specific command to a specific device.
You can eliminate the use of device mode by customizing your Activities.
Example
You can put commands on the display or customize specific buttons for the commands.
See Customizing Your Harmony Remote.
At any time, press Devices to switch into device mode. Once in this mode, the Harmony remote will
display a list of all the devices you have in your configuration. Select a device from the list and the
Harmony remote will only control the device features for the device.
Example
If you choose Television as the device, the number, volume and channel buttons will all control
your television.
Press Devices to return to Activity mode.
v. 1.2 page 6

Harmony 520 User Manual
Customizing Your Harmony Remote
Customize your Harmony remote from Home in the Harmony remote software.
Use the Harmony remote software to:
Troubleshoot
• Click Troubleshoot when your Harmony remote isn’t controlling your system correctly.
view Activities
• Click Activities to add or delete Activities.
• Click an Activity icon to change the specific settings (e.g. the name of an Activity) for an Activity.
Example
To have more than one Activity of a given type (e.g. If you have both a cable converter and a
satellite receiver, you can add a second Watch Television Activity) click Add an Activity. When
you're done, rename the Activities to help you distinguish between them (e.g. For the Watch
Television Activity you could rename one from "Watch Television" to "Watch Cable" and the
other to "Watch Satellite".)
view Devices
• Click Devices to add or delete entertainment devices.
• Click a device icon to change the specific settings for a device you have already set up.
view Remote Preferences
• Click Remote Preferences to change the remote’s settings.
Get Support
• Click Get Support to view a list of support tools and services we offer.
Update Remote
• Click Update Remote after you have made changes your configuration or settings. This will
ensure you have the latest configuration and settings on your Harmony remote.
v. 1.2 page 7

Harmony 520 User Manual
Customizing the Display on the Harmony Remote
This section provides information that will help you to customize the commands and options listed on the
Harmony remote’s display.
Changing the Behavior of Buttons within an Activity
When you select an Activity, the Harmony remote will:
• Turn on all the correct entertainment devices
• Set the device inputs correctly
• Set up the remote’s buttons to control the Activity
Based on our knowledge of how each of your devices is controlled, the Harmony remote will make its
best effort to match all the buttons you need to control an Activity.
However, there may be some commands you want to add to buttons or list on the display. Commands
can be added to buttons quickly and easily by customizing any Activity to change the behavior of buttons.
To change the behavior of buttons:
1. Connect your Harmony remote to your computer to start the Harmony remote software.
2. Click
Activities.
3. Click an Activity.
4. Click
Change the Behavior of Buttons to view the:
 Buttons that have a command associated with them
 Device being controlled
 Command being sent to the device
v. 1.2 page 8

Harmony 520 User Manual
Adding Custom-Labeled Buttons
You can also add any number of custom-labeled buttons to an Activity.
To add a custom-labeled button for an Activity:
1. Connect your Harmony remote to your computer to start the Harmony remote software.
2. Click
Activities.
3. Click an Activity.
4. Click
Change the Behavior of Buttons.
5. Under the Custom Button Label column, type the name for the button label you would like to
appear on the display.
6. Select a command from the list in the appropriate device column, next to the name of the button
you want to set.
7. Click Done.
Note: Custom-labeled buttons are displayed on the Harmony remote’s display from left to right,
top to bottom.
Changing the Settings for your Harmony Remote
Click Remote Preferences, select Settings, and then click Next to change the remote’s settings:
• Turn on/off Harmony Assistant (for additional information, see Displaying Help on Your Harmony
Remote.)
• Select the type of help to display on the remote (for additional information, see Displaying Help on
Your Harmony Remote.)
• Set the backlight timing (for additional information, see Using the Glow Button.)
• Show/Hide the “Starting Activity” message (for additional information, see Selecting an Activity.)
Learning Infrared (IR) Commands
The Harmony remote can learn infrared commands from other remote controls, and should only be used
in situations where the Harmony remote’s database does not already contain an infrared command you
would like to use.
Determine the device you would like to send the infrared command to:
1. Connect your Harmony remote to your computer to start the Harmony remote software.
v. 1.2 page 9

Harmony 520 User Manual
2. Click Devices.
3. Click a device.
4. Click
Learn Infrared Commands.
Using the Infrared Sensor
The Harmony remote has an infrared sensor at the end opposite to the USB connector. The Harmony
remote uses this sensor to learn commands from original device remotes.
• A: Your original remote
• B: Distance between remotes: 5-10 cm (2"-5") apart
• C: Your Harmony remote
The following steps outline what happens when you press a button on your original remote control:
1. The infrared sensor on the Harmony remote learns the infrared signal.
2. The Harmony remote uploads it via the USB cable (and your computer's internet connection) to
the Harmony database.
3. The Harmony remote software will try to find a matching pattern for the infrared signal.
4. If no pattern is found, the signal will be stored as-is in its original format.
5. If a pattern is found, the Harmony remote software converts the signal into a format for
convenient storage.
Either way, the signal is then available for you to assign to a button on your Harmony remote.
Naming an Infrared Command
When the Harmony remote learns an infrared command, give the command a name. This way you can
refer to this command by name in various locations of the online setup process. It is best to use the
default names listed in the Learn infrared commands step so that automatic button function
assignments can be applied to your Harmony remote.
Example
If the Harmony remote learns the volume button infrared commands from your original remote
control, name the commands "VolumeUp" and "VolumeDown" (i.e. with no space, and
capitalization as shown). The Harmony remote software looks for commands with these names to
automatically assign them to the volume up and down buttons on the Harmony remote.
Naming Conventions
When naming a command for which there is no default name under the Learn infrared commands
option, use the following naming conventions to make button assignment and sharing infrared commands
easier:
• Capitalize the start of words (e.g. NextDisc, ModeDigital).
• Start the command name with its main function (e.g. VolumeRearUp, VolumeRearDown,
VolumeFrontUp, VolumeFrontDown). This helps group related commands in lists.
• For infrared commands that select inputs (e.g. on a stereo receiver), start with the prefix "Input".
v. 1.2 page 10

Harmony 520 User Manual
 Do not name the input based on what you have connected to your device, rather name it
based on what it is called on the front of the device, or on the remote control (e.g. InputAux,
InputVideo1, InputTape, InputDVD, InputVCR).
v. 1.2 page 11

Harmony 520 User Manual
Getting Additional Help
The Harmony remote provides you with several features to assist you with:
• Finding answers to your questions quickly and easily.
• Troubleshooting the setup and customization process.
Finding Answers to Your Questions
To help you find answers to your questions quickly and easily, use any of the following features:
Feature Description
Search A support tool that enables you to do a keyword
search.
FAQs (Frequently-Asked Questions) A searchable list of customer questions, with
answers provided by Harmony's support center.
User Manual The User Manual explains the concept of your
Harmony remote and provides information about
setting up and using the remote.
Help button When running the Harmony remote software, click
this button for help specific to the step you are at.
Help button (remote)
Asks you simple questions so the Harmony remote
can automatically fix problems you are having with
an Activity.
Troubleshooting Your Harmony Remote
In addition to the tools listed under Finding Answers to Your Questions, you can use the following
feature:
Feature Description
Troubleshoot To be used when the Harmony remote is not controlling your system
correctly.
If you cannot find the answer to your question(s) or troubleshoot your problem(s), contact your Harmony
Support Team.
v. 1.2 page 12
