LOGO SILVER Scooter LG1 User manual

THE SCOOTER THAT COMBINES ADVANCED TECHNOLOGY WITH STYLE.
CONVENIENT AND EASILY MANOEUVRABLE WITH A POWER FOLDING SWITCH.
Find this notice
at www.logo-silver.fr

P·2
CONTENTS
I. INTRODUCTION........................................................................................................... 4
II. SPECIFICATION AND STRUCTURE ......................................................................... 5
TILLER CONSOLE.................................................................................................................. 6
SPECIFICATIONS.................................................................................................................... 6
III. ASSEMBLY.......................................................................................................................... 7
OPENING THE PACKING BOX.......................................................................................... 7
FRONT HEAD ADJUSTMENT............................................................................................. 7
FOLDING WITH THE POWER SWITCHES .................................................................... 7
CHARGING YOUR BATTERIES .......................................................................................... 8
CHARGING YOUR BATTERIES WITH THE OFF-BOARD CHARGER..................... 8
NEW BATTERY USE............................................................................................................... 8
IV. OPERATION..................................................................................................................... 9
TILLER CONSOLE.................................................................................................................. 9
POWER SWITCH ................................................................................................................... 9
THROTTLE CONTROL LEVER........................................................................................... 10
SPEED ADJUSTMENT KNOB .............................................................................................. 10
BATTERY CONDITION INDICATOR .............................................................................. 10
OFF-BOARD CHARGER....................................................................................................... 11
PIN CHARGER SOCKET ...................................................................................................... 11
V. CARE AND MAINTENANCE ...................................................................................... 12
GENERAL GUIDELINES........................................................................................................ 12

P·3
VI. SAFETY............................................................................................................................... 13
SAFETY CHECK PRIOR TO USING YOUR SCOOTER ................................................ 13
WEIGHT LIMITATION .......................................................................................................... 13
INCLINE INFORMATION .................................................................................................... 13
OUTDOOR DRIVING SURFACES..................................................................................... 14
MANUAL MODE..................................................................................................................... 14
ELECTROMAGNETIC INTERFERENCES ......................................................................... 14
TO AVOID AN INJURY, PLEASE OBSERVE THE FOLLOWING SAFETY TIPS......... 15
WEATHER PRECAUTIONS ................................................................................................. 15
VII. WARRANTY..................................................................................................................... 16
FIVE YEAR WARRANTY ........................................................................................................ 16
COVERED BY WARRANTY................................................................................................ 16
NOT COVERED BY WARRANTY..................................................................................... 16

P·4
Read and follow all instructions, warnings,
and notes in this manual before attempting
to operate your mobility scooter for the
rst time. If there is any information in
this manual which you do not understand,
or if you require additional assistance for
assembly or operation, please contact your
authorized local service provider.
Your safety when operating this product
depends upon whether you thoroughly
follow the instructions, cautions and
warnings in this manual. Our company is
not liable for any damages and/or injuries
resulting from individual unsafe operation
or failure to follow the instructions,
cautions and warnings in this manual.
The symbols below in this manual are used
to identify warnings, notices and operation
instructions.All of them are very important
to your safety. It is strongly recommended
to read and understand them completely
and carefully.
The mobility scooters combine
advanced technology with modern style.
The structure of quick assembly and
disassembly is convenient for daily storage
or placed in the trunk of your vehicle while
travelling.We are certain that the design
features and trouble-free operation will
ensure your daily life is more convenient.
This mobility scooter is suitable for
the disabled, elderly and inrm who
are mobility challenged but of normal
intellectual capacity. Max. load is 75Kg.
This is an indoor product, and suitable for
driving indoors and outdoors on smooth
ground (not for grassland, gravel, slopes of
more than 9 degrees, main roads, or rainy
conditions ...).
This is an N3458 model product. Here ,
the “N” indicates an indoor mobility
scooter,“3” means the code of category
of products,“4” indicates the number of
wheels, ”58” means the serial number of
this model.
We appreciate your comments and
suggestions about this manual, your
evaluations on the safety and reliability of
this product and also of the service of the
authorized provider.
WARNING!
Failure to heed the warnings in the manual may result in personal
injury.
CAUTION!
Failure to heed the cautions in the manual may result in damages to
the mobility scooter.
I. INTRODUCTION

P·5
g. 1
Your scooter consists mainly of the following
parts: scooter body, seat unit, controller,
motors, batteries, brake lever, drive wheels
and anti-tip wheels (see g. 1).
II. SPECIFICATION AND STRUCTURE
Drive Wheel
Mode Lever
Anti-tip Wheel
Backrest
Seat Unit
Lithium Battery
Control Lever
Handlebar
Fold/Unfold button

P·6
g. 2
TILLER CONSOLE
II. SPECIFICATION AND STRUCTURE
Power switch
Battery condition indicator
Speed adjustment Knob
Control lever
Overall size (LxWxH) 950x460x850mm
Folding size(LxWxH) 870x460x400mm
Seat height 350mm
Seat width 360mm
Backrest height 285mm
Scooter weight(with batteries) 23.8Kg
Max. speed ≤6km/h
Braking distance on the at ≤1500mm
Min. turning radius ≤2000mm
Load capacity 100kg
Max. range ≥18km
Max. incline 9°
Motor 24V/150W
Lithium Battery 24V/10AH
Max. output current of controller 45A
Max. output current of charger 2A
Front wheels Ination-free tyre, O.D. of 200mm
Rear wheels Ination-free tyre, O.D. of 200mm
SPECIFICATIONS
Table 1:

P·7
g. 3 g. 5
1 2 3
g. 4
III. ASSEMBLY
OPENING THE PACKING BOX
Open the packing box, take off all protective liness, and then take the folded scooter out
from the box.Twist off the lock, then push the unfold button to extend the scooter.
Press A and C rst, then press B for folding, and D for unfolding. (g. 3)
The scooter is successfully unfolded when you hear the “click”.
Press the fold button, and then lift the scooter slightly to fold it.
FRONT HEAD ADJUSTMENT
The fasteners on the side of the front of the scooter can be loosened up and down according
to the user’s height. (g. 4)
FOLDING WITH THE POWER SWITCHES (SEE FIG.5)
1 - Standby power port
2 - Power switch (“I” means power on,“O” means power off protection,“II” means standby
power). Press the power switch to “O” when the mobility scooter is in idle.
3 - Folding button (“I” means unfold, “II” means fold).
Note:The tiller console can be adjusted forward and backward.The height of the tiller
console can also be adjusted by the fastener on the side of the tiller according to your needs.
WARNING!
Please pull out the key before adjusting the scooter. Never adjust it
while driving.

P·8
III.ASSEMBLY
CHARGING YOUR BATTERIES
Charging is important for the batteries, and the off-board charger provided by us can simply
and quickly charge the batteries of this mobility scooter.
Note: If the scooter can’t be unfolded as the battery has been depleted, connect the charger
to a standby power port and press the power switch to “II” (see 3 g. 5), then the scooter
can be unfolded.
WARNING! You must charge your scooter’s battery with the supplied
off-board battery charger. Do not use an automotive-type battery charger.
CHARGING YOUR BATTERIES WITH THE OFF-BOARD
CHARGER:
• Make sure the scooter is powered off.
• Plug the output connector of the off-board charger into the 3-pin charger power
socket.(see g.6)
• Plug the input connector of the off-board charger into the electrical wall outlet.(220V)
• When the red light on the charger turns on this indicates that the Scooter is charging.
• When charging is nearly nished, the green light turns on. You should continue to
charge the batteries for 1 to 2 hours.
• It’s suggested to charge the batteries for 6 to 8 hours.
• Please unplug the power cord and charger when the battery is fully charged.
NEW BATTERY USE
To break-in new batteries for maximum efciency, please follow the notes below:
• 1. Fully charge any new battery prior to its initial use.This brings the battery up to
about 90% of its peak performance level;
• 2.After 4 to 5 charging cycles, the battery will top off at 100% charge and last for an
extended period.
• 3. If the battery of your scooter needs to be replaced, please purchase the battery with
the following specication:

P·9
g.6
type Deep-cycle sealed lithium battery
size 218x166x59mm
voltage 24V
capacity 10AH
The battery can be charged off the scooter.
IV. OPERATION
TILLER CONSOLE
The tiller console houses all of the controls needed to drive your scooter, including the key
switch, the speed adjustment knob, throttle control lever, battery condition indicator, etc.
With all of the controls on the console you can control the various motions of your scooter.
POWER SWITCH (SEE FIG.2)
The light on the battery gauge turns on when the key is fully inserted into the key switch,
and it turns off when the key is removed.
WARNING! Do not use the key switch to stop your scooter unless in an
emergency.
WARNING! When at rest, power down your scooter to prevent
unintended motion.

P·10
IV. OPERATION
THROTTLE CONTROL LEVER (SEE FIG. 2)
This lever allows you to control the forward and reverse speed of your scooter up to the
maximum preset with the speed adjustment knob.
Pull the left end of the control lever throttle backwards, the brake is disengaged and the
scooter will move backward; Pull the right end of the control lever throttle backwards, the
brake is disengaged and the scooter will move forward.
The larger the rotating angle of the lever is, the faster the speed of your scooter.
When you release the lever completely, it automatically returns to its initial position, i.e. the
stop position, and engages your scooter’s brake to slow the scooter until it stops completely.
WARNING! If your scooter moves unexpectedly, please release the
throttle control lever immediately. The scooter will automatically stop
unless the lever is defective.
SPEED ADJUSTMENT KNOB (SEE FIG.2)
This knob allows you to preset and limit your scooter’s maximum speed. Maximum forward
speed: 6km/h, maximum reverse speed: 3km/h.
CAUTION! Before you master the operation, please drive it at a low
speed.
BATTERY CONDITION INDICATOR (SEE FIG.2)
When your scooter is powered up, this indicator shows the remaining capacity of the
batteries in 3 colors:
• Green: the battery is fully charged.
• Yellow: the electricity is running out, and the battery needs to be charged.
• Red: the battery is depleted, and it needs to be charged immediately.

P·11
OFF-BOARD CHARGER
Take out the battery of its slot, you can charge it with the off-board charger through a
3-pin charger socket inside the battery box.
MODE LEVER
There is a mode lever at the lower right of the seat base, shown in g.1. Whenever you do
not want to move your scooter with the motor, you can put it in manual mode.
Push the manual mode lever to disengage the drive motor (manual mode).
Push backward on the manual mode lever to reengage the drive motor (drive mode).
• When your scooter is in manual mode, the brake system is disengaged. In this case, the
control system will automatically cut off the forward or backward function.
• Never sit on your scooter when it is in manual mode.
• Never put your scooter in manual mode on an incline. Failure to do so may cause
personal injury.
WARNING! When your scooter is in drive mode, the mode lever must
be pulled backward, i.e. in drive mode, so as to guarantee the brake
system works normally. Failure to do so may cause personal injury or
damage to the scooter.
PIN CHARGER SOCKET(SEE FIG.6)
This socket is used to connect the off-board charger.When charging, this socket stops your
scooter from moving.
WARNING!
Incorrect connection may cause damage to the charger, connectors and
circuits.

P·12
V. CARE AND MAINTENANCE
GENERAL GUIDELINES
Avoid knocking or bumping all control parts;
• Avoid prolonged exposure of your scooter to extreme conditions, such as over
heating, cold or moisture; Keep the tiller console clean;
• Check all connectors to ensure they are connected rmly and securely;
• Check all electrical connectors including the charger’s connectors. Make sure they are
tight and not corroded. Put the battery at within the battery box;
• Pull out the key switch each time after usage to avoid unnecessary capacity
consumption;
• The scooter has a power saving facility, when you stop using it for up to 20 minutes,
the power shuts off automatically. If you need to drive again, please pull out the key and
reinsert it to restart;
• The body shroud has been sprayed with a clear sealant coating.You can apply a light
coat of a car wax to retain its high-gloss appearance;
• All wheel bearings are lubricated and sealed.They require no further lubrication;
You should perform a safety check before each use to make sure your scooter operates
smoothly and safely. It’s suggested that your scooter should be checked weekly, monthly and
biannually according to the items in table 2.
Table 2:
Inspection items At any time Weekly Monthly Biannually
All parts •
Turning, driving, preset and
disassembly etc.
•
Brake system •
Connections •
Battery condition •
Tire condition •
Motors •
Devices •
Cleaning •

P·13
VI. SAFETY
SAFETY CHECK PRIOR TO USING YOUR SCOOTER:
• Check all electrical connections. Make sure they are tight and not corroded.
• Check all connections to the battery box. Make sure they are correct and secure.
• Check the brakes.
• Check the battery capacity. See “IV. OPERATION”.
WEIGHT LIMITATION
WARNING! Exceeding the weight limit voids your warranty and may
result in personal injury and damage to your scooter.
INCLINE INFORMATION
The maximum incline is 9° for your scooter. If a slope is less than this angle, it’s safe for your
scooter to climb up or drive down.
WARNING! When climbing an incline, do not zigzag or drive at an angle
up the face of the incline. Drive your scooter straight up the incline. This
greatly reduces the possibility of a tip or a fall. Always make sure not to
exceed the maximum incline.
WARNING! Don’t drive up or down a potentially hazardous incline(i.e.,
Areas covered with snow, ice, cut grass, or wet leaves).
WARNING! Never drive up or down an incline in reverse. This could cause
personal injury.

P·14
VI. SAFETY
OUTDOOR DRIVING SURFACES
Your scooter is designed to provide optimum stability under normal driving conditions such
as on at cement roads or asphalt roads. However, your scooter can be also driven on dirt
roads. However you should avoid driving on the following roads:
• A surface that you feel unsure about, or uneven pavement.
• Tall grass that can become tangled in the running gear.
• Loosely packed gravel and sand.
MANUAL MODE
Your scooter is equipped with a mode lever that allows the scooter to be manually pushed
by your attendant. For more information, see “IV. OPERATION”.
WARNING! Do not use your scooter in manual mode without an
attendant present .Failure to do so may cause personal injury.
WARNING! Warning! Do not shift in your seat without your attendant’s
help when your scooter is in manual mode. Otherwise this may result in
personal injury. Please ask your attendant for assistance if necessary.
WARNING! Do not place your scooter in manual mode while on an
incline. The scooter may roll downward on its own, causing personal injury.
ELECTROMAGNETIC INTERFERENCE
Radio waves from mobile phones, radio receivers or other transmitters such as radio and
TV stations could affect your scooter’s use if your scooter is in range of their inuence.
Your scooter may malfunction due to their inuences.
WARNING! The electrical devices may be inuenced by the EM. If there
are any abnormal movements of your scooter due to the EM interference,
please turn off the control system immediately and contact your service
provider.

P·15
TO AVOID AN INJURY, PLEASE OBSERVETHE FOLLOWING
SAFETY TIPS
• Ensure that the power is turned off, see “VI. OPERATION”
• Ensure that your scooter is not in manual mode.
• Keep your scooter as near to you as possible.
• Keep the front wheels in the direction you are driving so as to help the stability of your
scooter.
WARNING! Position yourself as far back as possible in the scooter seat to
prevent the scooter from tipping and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such
use may cause your scooter to tip over, causing injury.
WARNING! Avoid putting all of your weight on the footplate. Such use
may cause your scooter to tip over, causing injury.
WEATHER PRECAUTIONS
WARNING! Do not operate your scooter on ice or in slippery conditions.
Such use may adversely affect the performance and safety of your scooter,
resulting in personal injury.
WARNING! Do not expose your scooter to any type of moisture at
any time (rain, snow, mist,...). Such exposure can damage your scooter.
Never operate your scooter if it has been exposed to moisture until it has
dried thoroughly.

P·16
VII. WARRANTY
FIVE-YEAR WARRANTY
Our corporation has passed the ISO9001 and ISO13485 certicate. The quality is guaranteed.
COVERED BY WARRANTY:
Five years warranty on the front and the rear main frames from the date of purchase.
One-year warranty on the following parts from the date of purchase:
• Electric Control system and the controller
• Motor/gearbox assembly
• Charger
• Lithium battery
Warranty service will be performed by your provider in cooperation with our after-service
department.
NOT COVERED BY WARRANTY:
• ABS Shroud and rubber pads.
• Tires
• Seating and upholstery
• Damage caused due to abuse misoperation, accident and negligence
• Damage caused due to improper operation, maintenance and storage
• Business or other abnormal use

P·17

P·18

P·19

by
www.logo-silver.fr
Logo Silver
32 rue de Comboire - 38130 Echirolles - France
Tél. [phone] - [e-mail]
