Lorex VANTAGE LDC6050 User manual

Lorex Technologies Inc.
Copyright © 2011 Lorex Technologies Inc.
As our products are subject to continuous improvement, Lorex reserves the right to modify product
design, specifications and prices, without notice and without incurring any obligation. E&OE
Cable Extension Options
SECURITYCAMERA
Problem Solution
No Picture/Signal • Ensure your TV is on the correct input channel.
Common terms of an input channel: INPUT, AV
CHANNEL, LINE1, LINE2, AUX.
• If your camera is connected to a VCR/DVR, ensure it is
properly connected to your TV/Monitor.
• Ensure connections are properly connected.
• Ensure all the camera power supply is plugged in.
Picture is too bright • Ensure your camera isn’t pointed directly at a
source of light (e.g sun or spot light).
• Slide the sunshade (bullet cameras only)
forward to block excess light.
• Move your camera to a different location.
Picture is too dark • If using during the day, the camera may not
be getting enough light. Slide the sunshade
backwards to let in more light. Check the
brightness and contrast settings of the device
your camera connects to (TV/Monitor/DVR).
Night Vision is not work-
ing
• The night vision activates when light levels
drop. The area may have too much light.
Picture is not clear • Check the camera lens for dirt, dust,
spiderwebs. Clean the lens with a soft, clean
cloth.
• Make sure that the cable run is within the
limitations specified in the section ' Cable
Extension Options'
Bright spot in video when
viewing camera at night • Night vision reflects when pointing a camera
to a window. Move the camera to a different
location.
BNC connection does
not connect to my TV • Use a BNC to RCA adapter at the end of the
extension cable.
Troubleshooting
Option Cable Type
1Regular BNC
(supplied with
camera)
180ft / 55m 3
2'RG59' or
'Coax' or '
Coaxial' BNC
(sold separately)
300ft / 92m 5
3Lorex Universal
Cable
(sold separately)
300ft / 92m 3
Max. Cable
Run Distance
Notes:
1. For optimal performance, consider using option 2 or 3. Preference for using
the same cable type for the entire distance.
2. Cable run recommendation based on typical camera power consumption
(up to 500mA). For specialty cameras with higher current consumption,
maximum cable run may be reduced. Consider providing power to the
camera at the camera side rather then at the end of the extension cable.
3. Indicators that your cable run may be too long:
• Video is permanently Black & White (even during day time)
• Video is distorted
Max. # of
Extensions
English Version 3.0
Image Sensor 1/3" Sony Super HAD™ II
Video Format / Pixels
Horizontal Resolution
Video Output
IR / Night Vision Range
Field of View (diagonal)
Minimum Illumination
Termination
NTSC: 768(H)×494(V)
600 TVL
Comp. 1.0 Vpp @ 75ohm
70 Degrees
0 LUX (IR LEDs on)
Video: BNC Female
Power: Barrel Female
Lens / Lens Mount 4.0 mm F2.0 / Fixed
Camera Specifications
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
www.lorextechnology.com
IT’S ALL ON THE WEB!
Extend the cable run for your camera up to 300ft or more
depending on the cable type used. See table below:
Operating Temperature 14°F ~ 122°F
(-10°C ~ 50°C)
Power Requirement 12V DC ±10%
Power Consumption 220 mA or 2.7W max
Weight (with stand) 0.9lbs. / 0.5 kg
12 IR LED/40 ft. (12 m)**
Environmental Rating IP 66*
4.2 in/106mm
3.2in /
81mm
*Not intended for submersion in water. Installation in a sheltered location
recommended.
**IR Illumination range under ideal conditions. Objects at or beyond this
range may be partially or completely obscured, depending on the camera
application.
QUICK START GUIDE
LDC6050
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades

Setup Diagram
Before Installing The Camera
• Decide whether to run the cables through the wall/ceiling (drilling required), or along
the wall/ceiling.
• If you run the cables along the wall/ceiling,
you must run the cables through the
opening in the camera base, then tuck the
cable into the cable notch on the base.
This will keep the camera base flush to the
wall/ceiling when mounted.
To install the camera:
1. Remove the three screws
located on the outer ring of the Dome Cover using the Allen
key (included).
2. Mount the Camera Base to the ceiling or wall using the
provided screws.
3. Position the Ball Camera at the desired position and angle.
4. Position the Dome Cover ovcr the Ball Camera. Holding the
cover firmly in place, use the Allen key to tighten the screws
on the outer ring of the Dome Cover.
Cable notch
ATTENTION - Test all connections and ensure the camera is working
correctly prior to permanent installation by temporarily connecting the
camera(s) and cable(s) to the viewing/recording solution.
Tighten the dome
cover using the
Allen key.
Contents
Features
1x Super Resolution Color Camera
3 x Mounting screws / 1 x Allen key
1x 60ft. BNC/Power Extension Cable
1x BNC to RCA Adaptor
1x Power Adapter
• Point the camera where there is the least amount of
obstructions (ie tree branches).
• Install the camera in a location that is difficult for
vandals to reach.
• Secure cabling so that it is not exposed or easily cut.
• Connect your system and cameras to a back-up power
supply. This ensures the system continues to record
during power outtages.
Installing The Camera
Warning / Caution
1. Read this guide carefully and keep it for future reference.
2. Follow all instructions for safe use of the product.
3. Use the camera within given temperature, humidity and voltage levels noted
in Camera Specifications.
4. Do not disassemble the camera.
5. Do not point the camera directly towards the sun or a source of intense light.
6. Use only the supplied regulated power supply. Use of a non-regulated, non-
conforming power supply can damage this product and voids the warranty.
7. The supplied extension cable is rated for surface mounting only.
Cables for in-wall / floor-to-floor installations are sold separately.
WARNING - A REGULATED UL/CSA APPROVED power supply is
REQUIRED for use with this camera. Use of a non-regulated, non-conforming
power supply can damage this product and voids the warranty.
3
Video (BNC)
Power
• 600TV line resolution for unmatched video quality
• Latest Sony Super HAD™ 2nd generation Image Sensor
• Advanced Noise Reduction for crystal clear Night Vision
• Improved recording storage efficiency by up to 30%
• Dual glass design prevents IR light reflection
• Wide angle lens for wide area coverage
• Weatherproof, vandal resistant aluminum housing*
• Flexible camera design for wall and ceiling mounting
Connect the BNC and
power connectors to the
camera.
Connect the BNC connector to the
video input of the monitor/DVR,
and connect the included power
connector to a power adapter.
Male power connector
BNC
To Camera: To Monitor/ DVR:
Female power connector
Connecting The Camera
*Not intended for submersion in water. Installation in a sheltered location
recommended.
Installation Tips DVR/CCTV MONITOR
Video IN
TV/VCR
Video IN
Attach the included BNC to RCA adapter to connect the
extension cable to RCA inputs (i.e. for a TV connection).
BNC to RCA Adapter
BNC to RCA Adapter
