Lorex Vantage LZC7091 User manual

www.lorextechnology.com
10X PAN-TILT-ZOOM CAMERA
LZC7091
Copyright © 2012 Lorex Technology Inc.
Instruction Manual
English Version 3.0
RETAIL INDUSTRY BUSINESS
BUSINESS HOME OUTDOOR

Thank you for purchasing the LOREX Super+ Resolution 10X PTZ
Speed-Dome Camera.
This manual refers to the following models:
• LZC7091

For the latest online manual and to learn about our complete range of
accessory products, please visit our website at:
www.lorextechnology.com
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN DURING OPERATION
CAUTION: NO USER SERVICABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the products ' enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF THE PLUG TO THE WIDE SLOT AND FULLY INSERT.

NEED HELP?
CONTACT US FIRST
2 Easy Ways to Contact Us
Please make sure to register your product at www.lorextechnology.com
to receive product updates and technical support.
DO NOT RETURN THIS PRODUCT TO THE STORE
SEP 12 2012 - R14
North America:
Customer Service (for warranty matters): 1-888-425-6739 (1-888-42-LOREX)
Tech Support (for technical/installation issues): 1-877-755-6739 (1-877-75-LOREX)
Mexico: 001-800-681-9263, 001-800-514-6739
International: [phone] (Example: From the UK, dial 00 instead of +)
By Phone:
Online:
For all other matters, visit www.lorextechnology.com
Product Support is available 24/7 including product information, user
manuals, quick start up guides and FAQ’s at
www.lorextechnology.com/support

SEP 12 2012 - R14
¿NECESITA AYUDA?
COMUNÍQUESE PRIMERO
CON NOSOTROS
BESOIN D’ASSISTANCE?
COMMUNIQUEZ D’ABORD
AVEC NOUS
2 façons simples de communiquer
avec nous :
En Amérique du Nord :
Service à la clientèle (pour tout ce qui concerne la garantie) :
1-888-425-6739 (1-888-42-LOREX)
Soutien technique (pour les questions d’ordre technique ou relatives à
l’installation) : 1-877-755-6739 (1-877-75-LOREX)
Mexique : 001-800-681-9263, 001-800-514-6739
International : [phone]
(par exemple : à partir du Royaume-Uni, composez le 00 au lieu de +)
Par téléphone :
Veuillez enregistrer votre produit sur le site
www.lorextechnology.com afin de recevoir des mises à jour
et le soutien technique pour votre produit.
Pour toutes les autres questions,
visitez www.lorextechnology.com
À votre disposition 24/7, le soutien pour les produits comprend
les renseignements sur les produits, guides d’utilisation, guides
de départ rapide et FAQ :
www.lorextechnology.com/support
En ligne :
Hay 2 maneras fáciles de comunicarse
con nosotros:
Norte América:
Atención al cliente (para asuntos de la garantía):
1-888-425-6739 (1-888-42-LOREX)
Asistencia técnica (para asuntos técnicos o de instalación):
1-877-755-6739 (1-877-75-LOREX)
Mexico: 001-800-681-9263, 001-800-514-6739
Internacional: [phone]
(Ejemplo: Desde el Reino Unido, marque el 00 en lugar del +)
Por teléfono:
Apoyo al cliente está disponible 24/7, incluyendo
información del producto, manuales para el usuario, guías
de inicio rápido y preguntas más frecuentes en:
www.lorextechnology.com/support
En línea:
Por favor, registre su producto en www.lorextechnology.
com para recibir actualizaciones del producto y
asistencia técnica.
Para todo lo demás, visite
www.lorextechnology.com
NO DEVUELVA ESTE PRODUCTO A LA TIENDA NE RETOURNEZ PAS CE PRODUIT AU MAGASIN
VIEW YOUR WORLD™
VOIR VOTRE MONDEMD
VEA SU MUNDO™

SEP 6 2012 - R8
LOREX IS COMMITTED TO FULFILLING YOUR SECURITY NEEDS
• We have developed user friendly products and documentation.
Please read the Quick Start Guide and User Manual before you
install this product.
• Consumer Guides and Video Tutorials are available on our web
site at www.lorextechnology.com/support
• If you require further installation assistance, please visit
www.lorextechnology.com/installation or contact a
professional installer.
• Please note that once the components of this product have been
unsealed, you cannot return this product directly to the store
without the original packaging.
THIS PRODUCT MAY REQUIRE PROFESSIONAL INSTALLATION
BEFORE YOU START
Please make sure to register your product at www.lorextechnology.com
to receive product updates and technical support

SEP 6 2012 - R8
LOREX SE COMPROMETE A SATISFACER
SUS NECESIDADES EN SEGURIDAD
LOREX S’ENGAGE À RÉPONDRE À VOS
BESOINS EN MATIÈRE DE SÉCURITÉ
ESTE PRODUCTO PUEDE EXIGIR UNA IN-
STALACIÓN PROFESIONAL
CE PRODUIT PEUT NÉCESSITER UNE
INSTALLATION PROFESSIONNELLE
• Nous avons conçu et développé une documentation
et des produits extrêmement conviviaux. Veuillez
lire le Guide de départ rapide et le Guide
d’utilisation avant d’installer ce produit.
• Des guides pour consommateurs et des tutoriels
vidéo vous sont offerts sur notre site Web :
www.lorextechnology.com/support
• Si vous avez besoin de plus d’assistance pour
l’installation de ce produit, veuillez visiter le site
www.lorextechnology/installation ou communiquez
avec un installateur professionnel.
• Veuillez prendre note que lorsque vous avez déballé
les pièces et composantes de ce produit, vous ne
pouvez pas retourner celui-ci directement au
magasin sans son emballage original.
• Favor de leer la guía de instalación rápida y la
guía del usuario antes de instalar este product.
• Puede conseguir las guías del consumidor y los
cursos en enseñanza video sobre el Internet
visitando www.lorextechnology.com/support
• Si necesita ayuda para la instalación, visite
www.lorextechnology.com/installation o contacte
un especialista en instalaciones.
• Favor de notar que una vez que los componentes
de este producto han sido removidos del
embalaje, no podrá devolver este producto
directamente a la tienda.
AVANT DE
COMMENCER
ANTES DE
EMPEZAR
www.lorextechnology.com
Veuillez enregistrer votre produit sur le site
www.lorextechnology.com afin de recevoir
des mises à jour et le soutien technique pour
votre produit.
Cerciórese de por favor colocar su producto
en www.lorextechnology.com para recibir
actualizaciones y la información del producto
y soporte técnico.
VIEW YOUR WORLD™
VOIR VOTRE MONDEMD
VEA SU MUNDO™

i
English
Features
• Latest Sony EXview™ II image sensor for best-in-class low
light performance1
• Sony Effio™ video image processor delivers up to 700TV
lines of resolution
• 10X Optical Zoom and 10X Digital Zoom to focus in on even
the finest details
• Complete area coverage with 360 degrees per second
panning speed
• Program preset viewing points when connected to a DVR
• ClearNight technology with Digital Noise Reduction
improves low light performance and recording efficiency by
up to 30%
• Accurate colors with Lorex’s automatic light filtering
technology
• Weatherproof (IP66) rated using included wall mount2
• Connects to any Lorex Eco™ or Edge™ series DVR for local
or remote operation
• Removable camera base for easier and safer installation
• 100ft all-in-one connection cable included for installation
location flexibility
1 This camera features an ultra-low light sensitive image sensor and therefore does
not feature Infra-Red LEDs. The camera requires ambient lighting (for example,
street/building lighting, star or moon light) to render a night time image. In total
darkness (zero Lux) the camera will not produce a night time image and therefore the
camera should not be installed in completely dark areas.
2 Wall mount required for outdoor installation. Not intended for submersion in water.
Installation in a sheltered location recommended.
As our products are subject to continuous improvement, Lorex reserves the right to
modify product design, specifications and prices, without notice and without incurring
any obligation. E&OE

ii
Safety Instructions
• Read this guide carefully and keep it for future reference.
• Follow all instructions for safe use of the product and handle
with care.
• Use the camera within given temperature, humidity, and
voltage levels noted in the Technical Specifications.
• Camera is rated for outdoor use and is weatherproof using
included wall mount only. For indoor installations, camera
may be directly attached to a ceiling.
• Camera is not intended for submersion in water. Installation
under a sheltered environment is recommended.
• Do not disassemble the camera.
• Do not point the camera directly towards the sun or a source
of intense light.
• Use only the supplied regulated power supply. Use of a
non-regulated, non-conforming power supply can damage
this product and voids the warranty.
•Make sure toinstallthecamerainalocationthatcansupport
the camera weight.
• Make sure there are no live electrical cables in the area
where you plan to mount the camera.
• Periodic cleaning may be required. Use a damp cloth only.
Do not use anything other than water to clean the dome
cover, as chemicals such as acetone can permanently
damage the plastic.

iii
TABLE OF CONTENTS
English
1. Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. Connecting the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.1 Default Protocol Information . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
3. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.1 Installation Tips and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . .6
3.2 Extension Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3.3 Wall Mount Installation (Indoor/Outdoor) . . . . . . . . . . . . . . . . . .8
3.4 Ceiling Install (Indoor Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
4. Controlling the PTZ Camera with your DVR . . . . . . . . 15
4.1 Initial Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
4.2 Controlling the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
4.3 PTZ Presets and PTZ Cruise . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
4.4 Setting PTZ Presets on the ECO2 DVR . . . . . . . . . . . . . . . . . . . .18
4.5 Selecting PTZ Presets on the ECO2 DVR . . . . . . . . . . . . . . . . . .19
4.6 Deleting PTZ Presets on the ECO2 DVR . . . . . . . . . . . . . . . . . . .19
4.7 Starting / Stopping PTZ Cruise on the ECO2 DVR . . . . . . . . . . .19
5. Changing Protocol Information. . . . . . . . . . . . . . . . . . . 20
5.1 Accessing the DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
5.2 Setting the Camera ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
5.3 Setting the Camera Protocol and Baud Rate . . . . . . . . . . . . . . .23
6. Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . 24
7. Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

iv

1
Getting Started
English
1. GETTING STARTED
100ft BNC/Power/
RS485 Cable
Mounting Screw Kit
12V DC Power Adapter
Instruction Manual
Camera
Wall Mount Kit Foam Pad
Before you start, ensure you have received all the items listed below:

2
Connecting the Camera
2. CONNECTING THE CAMERA
It is recommended to connect the camera to your DVR and
test the PTZ controls before permanent installation.
6-Pin
Connector
BNC Video
DVR Video Input
RS485
Red: +
Black: -
Power
Power
adapter
1
2
3
4
DVRRS485
Ports
Camera
1. Connect the 6-pin connector on the extension cable to the camera.

3
Connecting the Camera
English
• To do this, you must remove the camera from the case. Rotate the
dome cover counterclockwise to remove. Remove the base
attachment screws (3x) and remove the camera base. See illustration
below.
Dome
cover
Base attachment
screws
Camera
Camera base
Removing the camera from the case
NOTE: Do not use force when pulling out the 6-pin connector. The 6-pin
connector has a release latch under the connector. Press the latch when
disconnecting it from the camera.
Release latch
2. Connect the power connector on the extension cable to the included
power adapter and connect the power adapter to a surge protector or
wall outlet.
3. Connect the RS485 connectors to the RS485 ports on the alarm block
on your DVR. The layout of the alarm block may differ depending on
your DVR model (common terms include RS485, RS422, or PTZ).

4
Connecting the Camera
• The RS485 connectors are a pair
of bare 24-gauge wires. The red
wire is positive (+) and is
connected to the +port on the
RS485 section of the alarm
block, and the black wire is
negative (-) and is connected to
the -port.
Spring loaded lock alarm block
Screw lock alarm block
Insert a
screwdriver and
then insert wires
+ / - RS485 Ports
+ / - RS485 Ports
Tighten screws
above ports to
secure wires
• Most DVR’s either use screws or
a spring loaded lock to hold the
RS485 wires in place. For a
spring loaded lock, Insert a
screw driver or small object into
the lock, insert the wires, and
then remove the screwdriver to
lock the wires in place.
• If the wires can be easily removed, they may become disconnected
and affect control of the camera. Use wire strippers (not included) to
expose more of the wires if needed.
4. Connect the BNC video connector to an available Video IN port on the
DVR.

5
Connecting the Camera
English
2.1 DEFAULT PROTOCOL INFORMATION
Unlike standard security cameras, PTZ (pan-tilt-zoom) cameras require
special protocol information to enable a Security DVR to control the
camera movement.
Input the following information into your DVR to enable PTZ controls.
• Default ID: 1
• Default Baud Rate: 2400
• Default Protocol: Pelco-D
For details on setting up your DVR with the PTZ camera, see “Controlling
the PTZ Camera with your DVR” on page 15.
You will not need to change the default protocol information on your
camera unless you are using multiple PTZ cameras or if your DVR does
not support the default settings (see your DVR’s instruction manual for
details). If you need to change the PTZ protocol information, see
“Changing Protocol Information” on page 20.

6
Installation
3. INSTALLATION
3.1 INSTALLATION TIPS AND WARNINGS
Make sure to install the camera in a location that can support
the camera weight.
Make sure there are no live electrical cables in the area
where you plan to mount the camera.
• Camera is rated for outdoor use and is weatherproof using included
wall mount only. For indoor installations, camera may be directly
attached to a ceiling.
• Before installing, connect the camera to the DVR and configure the
PTZ protocol information as needed to ensure that you can control
the camera once installed. It is very difficult to change the protocol
information once the camera is installed.
• Camera is capable of seeing in extremely low light conditions (0.02
Lux), but it cannot see in total darkness. It is recommended to install
the camera where there is some ambient light (e.g. street lighting or
starlight, moonlight, etc.) or leave some lighting on in the area where
the camera is installed.
• To extend the length of the cable, see “Extension Cables” on page 7.
• Mount the camera where the lens is away from direct and intense
sunlight.
• Plan your cable wiring so that it does not interfere with power lines
or telephone lines.
• Ensure that the camera wiring is not exposed or easily cut.
• Mount the camera in an area that is visible but out of reach.

7
Installation
English
3.2 EXTENSION CABLES
• Included cable is 100ft / 30m long.
• Because this is a high-powered PTZ camera, the power adapter must
be connected to included 100ft cable and cannot be extended.
• BNC video and PTZ control (RS485) wires can be extended an
additional 250ft / 76m up to a maximum length of 350ft / 106m. Video
quality may decrease if your extension cables are too long.
• To extend BNC video cable, purchase RG59 coaxial extension cables.
Itisrecommendedtouse video cableswiththefollowing specification:
RG59U 95% Braid 20AWG or better.
• To extend the PTZ control (RS485) wires, purchase a pair of 24-gauge
wires.
• Both RG59 coaxial cable and 24-gauge wires should be available from
your local building supply store.

8
Installation
3.3 WALL MOUNT INSTALLATION (INDOOR/
OUTDOOR)
Make sure to disconnect the power adapter before installing
the camera. Camera will begin moving immediately when
power adapter is connected.
Camera can be installed to a wall using the included wall mount. This
method is suitable for indoor or outdoor installations.
To install the camera:
1. Make sure the O-rings (3x) are
attached to the top of the pendant
cap (spares are included). Firmly
insert the pendant cap on to the
wall mount bracket and twist to
tighten all the way. Insert the
bracket screws (3x) to secure
pendant cap to wall mount
bracket.
1
2. Use the back of the wall mount to
drill holes for the mounting
screws. If you are running cables
through the wall, also drill a hole
for the cables. Run the single end
of the cable through the wall
mount and attach the wall mount
to the wall using the wall
mounting screws (4x) supplied
with the wall mount.
2
NOTE: Use the included drywall anchors if installing in drywall.

9
Installation
English
3. Rotate the camera dome cover
counterclockwise to remove.
3
Dome cover
4. Remove the base attachment
screws (3x) and remove the
camera from the camera base.
Base
attachment
screws
Camera
Camera base
4
5. Remove the rubber plug on the
bottom of the camera base and
run the single end of the cable
through the bottom of the camera
base. Attach the camera base to
the pendant cap using the camera
attachment screws (4x).
5

10
Installation
6. Connect the cable to the camera
(see “Connecting the Camera” on
page 2). Attach the camera to the
base using the base attachment
screws (3x) then reattach the
dome cover by rotating it
clockwise.
6
NOTE: Make sure power adapter is
disconnected before connecting the
6-pin connector. Camera will begin
moving immediately when power
adapter is connected.
7. Remove the protective vinyl sheet
from the dome cover.
7
• For details on DVR setup, see
“ControllingthePTZCamerawith
your DVR” on page 15.
