Lovencare Bumps User manual

“Bumps” Folding Walker
!
ITEM: BP 8677
IMPORTANT: PLEASE READ INSTRUCTIONS
CAREFULLY AND KEEP FOR FUTURE REFERENCE!
Instruction Manual

WARNING
2
Read all instructions before assembly and use of this walker. Keep instructions for
future use. The child may be hurt if you do not follow these instructions.
IMPORTANT SAFETY INFORMATION
How to keep your child safe while using this product.
NEVER LEAVE CHILD UNATTENDED. ALWAYS KEEP CHILD IN VIEW WHILE USING
WALKER.
CAUTION: Toys intended to be assembled by adult!
Strings can cause strangulation. DO NOT place items with a string around child’s
neck, such as hood string or pacier cords. DO NOT suspend strings over product
or attach strings to toys.
WARNING: The child will be able to reach further and move faster than before
when in the baby walking frame.
STAIR HAZARD
Avoid serious injury or death. Block stairs & steps securely before using this
walker.
Use only on at surfaces free of objects that could cause this walker to tip over.
Never use near stair steps, thresholds, hills, roadways, or pools.
To avoid burns, keep child away from hot liquids, stoves, radiators, space heaters,
replaces, etc.
Discontinue using this walker should it become damaged or broken.
Never carry this walker with child in it. Never adjust seat while child is in product.
Do not lift or carry by “Tray”, “Music tray,” or toys.
Do not use this walker until baby can sit up unassisted.
To reduce the chance of child slipping out of seat, check that both feet of child
touch the oor.
Discontinue using this walker when your child can stand unaided or walk
unassisted.
Prevent collisions with glass, doors, windows, and furniture.
This baby walking frame should be used only for short periods of time
(e.g.20 mins.)
Do not use replacement parts other than those approved by the manufacturer
or distributor.
Only use this walker if your child MEETS ALL of the requirements below:
1. Can support body weight with legs.
2. Weight is between 15 and 26 pounds, not intended for children who can walk
by themselves of weight more than 26.45 pounds(12 kg).
3. Height is less than 32 inches (80 cms).
To maintain stopping performance, clean friction strips regularly with damp cloth.
Cleaning:
Clean with a damp sponge or cloth and mild detergent. Do not use abrasives or
bleach.
IMPORTANT!
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE

3
TOOL NEEDED: Phillips Screwdriver
PART S
BUMPS MODEL ONLY /
Seat Pad x1
Walker Unit x1
Seat Back x1
Front Casters x2
Rear Wheels x2
Axles x2
Nuts x2
Music Tray x1 Plush Arch Toy x1

4
TOOL NEEDED: Phillips Screwdriver
PART S/
Arch Toy x1
Music Tray x1
Music Insert x1
Music Insert Toys x2
Spinner Toys x2
M3 Bolt x2
Nuts x2
BUMPS+ MODEL ONLY BUMPS+2 MODEL ONLY
BUMPS+3 MODEL ONLY

STEP 1
5
1. Flip base over to expose
underside.
2. Insert the stem of one of
the front casters into the
hole in one of the front
corners.
snaps (locks) into place.
Pull up on caster to make
sure it is locked in place.
4.Repeat for the other caster.
CAUTION:
Be sure the caster is inserted
fully into the base. The top lip
of the caster threads should
Nothing below this lip should
be visible.

STEP 2
6
1. Locate rear wheel opening in
base of the walker. Insert one
rear wheel as shown.
2. Align holes of wheel with
corresponding axle holes on
the base of the walker. Plastic
expose the axle hole.
3. Slide metal axle into holes until
the head of it passes the plastic
tab and clicks into place.
4. Repeat for other wheel.

STEP 3
7
1
2
3
4
5
1. The walker is in the
folded position when
removed from the box.
2. To unfold walker, pull
up on the tray. Raise
upward until the vertical
leg tabs lock into the
base.
3. Rotate top tray forward.
4. Insert the front leg into
the slot in the base. Press
down on the top tray until
the front leg button locks
into the base.
5. Insert the seat back into
the slots on the tray, see
diagram. Pull up on the
seat back to ensure that it
is securly locked into
place.

STEP 4
8
1
2
3
4
1. Push crotch portion of seat
pad inside out to form seat,
so that the fabric is on inside
of seat pad.
2. Place seat pad into seat ring
located on tray. Align it so
that high back support aligns
with back of seat ring.
3. Insert the 8 round tabs on the
seat pad into slots located
around the seat ring.
Slide tabs through holes.
4. Turn tray up side down. Pull
tabs and align into grooves.
You may have to push tabs
from top of walker to properly
fasten.
TEST:Push down hard on seating
area of seat pad to make sure seat
is securely in place.
CAUTION: Do not use walker if all
tabs are not secured properly,
otherwise child may fall through
walker.

STEP 5
9
To raise the height of the seat:
Grip the buckle on the rear of the
seat pad. Pull the loose end of
the webbing away from the
buckle until the correct heigh is
achieved. You may need to place
the child in the seat several times
before the correct height is
achieved.
To lower the height of the seat:
Push the button on the top of the
buckle inwards (A) and hold.
Feed the webbing through the
buckle (B) until the seat is the
correct height. You may need to
place the child in the seat several
times before the correct height is
achieved.

Before tting the music insert
you will need to t the batteries.
Unfasten the screw in the battery
cover using a X-head screwdriver.
Insert two ‘AA’ batteries, ensure
that the batteries are tted the
correct way round.
Ret the battery cover and tighten
screw.
10
STEP 6aSTEP 6b
QuietLoud
Slide the switch on the
back of the music insert
music or loud music.
on the front of the music
tunes.
BUMPS MODEL ONLY

11
STEP 6cSTEP 6d
Slot the plush arch toy into
the round holes on the main
tray, see diagram.
Make sure both lock hooks
snap into the lock hook holes.
Slot the music tray as
shown in the diagram.
From the underside of
the tray, screw the two
nuts onto the protrud-
ing ends of the music
tray.

12
STEP 6aSTEP 6b
BUMPS+ MODEL ONLY
battery
battery
QuietLoud
Slide the switch on the back
of the music insert along for
, quiet music or loud
music.
Pr
the front of the music insert for
rent tunes.
Befor
will need to fit the batteries.
Unfasten the screw in the battery
cover using a X-head screwdriver.
Insert two ‘AA’ batteries, ensure
that the batteries ar
correct way round.
Rry cover and tighten
the screw.

13
STEP 6cSTEP 6d
Slot the two music insert toys
into the holes in the ends of
the music insert.
Slot the music insert as shown
in the diagram.
From the underside of the tray,
screw the two nuts onto the
protruding ends of the music
insert toys.
Finally, fasten the screw in the
hole by the nuts to ensure it is
secured.

Before tting the music insert
you will need to t the batteries.
Unfasten the screw in the battery
cover using a X-head screwdriver.
Insert two ‘AA’ batteries, ensure
that the batteries are tted the
correct way round.
Ret the battery cover and tighten
screw.
14
STEP 6aSTEP 6b
Slide the switch on the
back of the music insert
music or loud music.
on the front of the music
tunes.
BUMPS+2 MODEL ONLY
QuietLoud

15
STEP 6cSTEP 6d
Slot the plush arch toy
into the round holes
on the main tray,
see diagram.
Make sure both lock
hooks snap into the lock
hook holes.
Slot the music tray as
shown in the diagram.
From the underside of
the tray, screw the two
nuts onto the protrud-
ing ends of the music
tray.
1
2

16
STEP 6
Position the two spinner
toys into the round holes
on the tray, see diagram.
Push the spinner toys
into the holes until the
studs on the ends of the
spinner toys lock over the
housings on the underside
of the tray and cannot
.
BUMPS+3 MODEL ONLY

STEP 7
2
5
4
3
17
THE WALKER FOLDS
EASILY FOR TRAVEL
& STORAGE.
1. Remove electronic toys
from the tray.
2. Release the front leg from
the base by pressing the
leg release button and
front leg.
3. Fold the front leg under
the tray until it locks onto
the tray itself.
4. Rotate the tray down and
to the rear of the walker.
5. Press leg release button
on each rear leg. Fold legs
forward.

18
NOTE: To maintain
stopping performance,
clean friction strips regularly
with damp cloth.
STEP 8
Care & maintenance
1. Wipe plastic parts with a damp cloth using mild soap.
2. Machine wash seat pad in cold water in gentle cycle. Do not use harsh detergents or bleach.
Do not dry clean.
3. Air or line dry.
4. To maintain stopping performance, clean friction strips regularly with damp cloth.

19
.
Contact Us:
Love N Care Pty Ltd.
297-299 Canterbury Rd, Revesby
NSW 2212 Australia
Contact No: 02 9774 4655
Fax: [phone]
Email: [email protected]
Website: www.lovencare.com.au
