LOWE'S 51866 User manual

9854 • 053123 1
52” CEILING FAN
Owner’s Manual
Model #51866, 51867
To obtain service, please contact the Service Department:
1-877-706-3267, 8 a.m. - 5 p.m. Central, Monday - Friday.
RATED FOR
DAMP LOCATION

PACKAGE CONTENTS
2
HARDWARE CONTENTS
1. Canopy
2. Canopy Cover
3. Mounting Bracket Screw
(x4)
4. Mounting Bracket
5. Downrod
6. Downrod Clip
7. Downrod Pin
8. Yoke Cover
9. Set Screw (x2)
10. Motor Screw (x6)
11. Motor Assembly
12. Fitter Plate
13. Fitter Plate Screw (x3)
14. Switch Housing Plate
15. Switch Housing Screw (x3)
16. Switch Housing
17. Blade Balancing Kit
18. Blade (x3)
19. Blade Arm (x3)
20. Hardware Kit
21. Owner’s Manual
AA. Wire Connector (x3)
BB. Blade Screw (x9)
CC. Blade Washer (x9)
DD. Pull Chain Extension
JJ. Secondary Support Screw
KK. Support Washer
LL. Screw Cap (x9)
MM. Secondary Spring Washer
Unpack your fan and check the contents. You should have
the following items:
PACKAGE CONTENTS
HARDWARE CONTENTS
Note: Some extra hardware has been included. The quantity
listed above is the number required for installation.
HARDWARE CONTENTS
CC LLDDAA
TOOLS REQUIRED (not included)
Tools required for assembly: Electrical tape, Phillips Screwdriver, Pliers, Safety Glasses, Step Ladder, Wire Cutters
and Wire Strippers
Helpful Tools: AC Tester Light, Tape Measure, and Wiring Handbook
Hardware Kit
Owner’s
Manual
JJ
KK MM
12
11
9
8
10
7
6
5
4
16
19
20
21
BB
17
18
13
3
14
15
2
1

3
A. 13.1 in. B. 10.7 in. C. 6.54 in. D. 5.13 in.
DIMENSION REFERENCE
MOUNTING OPTIONS
Two Mounting Options
Downrod Mount
Angled Ceiling Mount (Up to 16 degrees)
Choose one of the following mounting options:
Downrod Mount is best suited for ceilings 8 ft. or higher. For taller ceilings you may want to use a longer
downrod (not included).
Angled Ceiling Mount is best suited for angled or vaulted ceilings. A longer downrod is sometimes necessary
to ensure proper blade clearance from the ceiling. If using the angle mount, check to ensure the ceiling angle is
not steeper than 16°.
C
D
B
A

4
READ ALL SAFETY INFORMATION AND INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN INSTALLING THE
FAN AND SAVE INSTRUCTIONS.
This fan is intended for indoor or damp locations. It is not suitable for outdoor locations.
All set screws of the fan must be checked and retightened where necessary before installation.
To reduce the risk of personal injury, do not bend the blade brackets when installing the brackets, balancing
the blades or cleaning fan. Do not insert foreign objects in between rotating fan blades.
Before changing the fan direction, turn o the fan and wait for the fan blades to stop completely.
The safeguards provided by these safety instructions and by the separate installation instructions are not
meant to cover all possible conditions and situations that may occur. It must be understood that common
sense, caution and care are factors which can not be built into this product. These factors must be supplied
by the person(s) installing, caring for and operating the fan.
The fan weight is Net Weight: 12.28 lb (5,57kg). Be sure the outlet box (not included) is securely attached
to the building structure and is marked “Acceptable For Fan Support”. Failure to do so can result in serious
injury.
SAFETY INSTRUCTIONS
CAUTION:
WARNING:
To avoid risk of electric shock, be sure to shut o power at the main fuse or circuit breaker box before
installing or servicing this xture. Turning o the electrical power by using the light switch is not
sucient to prevent electrical shock.
To reduce the risk of injury, install the fan so that the blades are at least 7 feet (2.1 Meters) above the
oor and at least 18 inches (0.5 Meters) from the tip of the blades to the wall.
To reduce the risk of re, electric shock, or personal injury, mount to outlet box marked “acceptable for
fan support” and use mounting screws provided with the outlet box.
The installation has to be in accordance with the national electrical code, ANSI/NFPA 70-1999 and
local codes. If you are unfamiliar with the methods of installing electrical wiring, seek the services of a
qualied licensed electrician.
Using a full-range dimmer switch to control fan speed will cause a loud humming noise from the fan. To
reduce the risk of re or electric shock, do NOT use a full-range dimmer switch to control the fan speed.
CARE AND MAINTENANCE
At least twice each year, lower the canopy to check the downrod assembly, and then tighten all screws on the fan.
Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the nish. Clean the blades
with a lint-free cloth.
Important: Shut o the main power supply before you begin any maintenance tasks. Do not use water or a damp
cloth to clean the ceiling fan.

Downrod
Clip
Set Screw
Yoke
Downrod
Pin
Downrod
5
Phillips-head Motor Screw
ASSEMBLY INSTRUCTIONS
1
3
Mounting Bracket Screw
2
4
2. Loosen all four mounting bracket screws located on
the mounting bracket and completely remove the two
screws from the round holes in the canopy. Save the
screws for later. Remove the canopy from the mounting
bracket. Then, install the mounting bracket to the outlet
box (sold separately) using the screws and washers
provided with the outlet box.
WARNING: To reduce the risk of re, electric shock,
or personal injury, mount to the outlet box marked
“acceptable for fan support” and use the mounting
screws and washers provided with the outlet box.
3. Remove the 6 Phillips-head motor screws from the top
part of the motor and save the motor screws for blade
arm installation.
1. Turn OFF the electrical power at the main fuse or
circuit breaker.
DANGER: Failure to disconnect the power supply prior to
installation may result in serious injury or death.
4. Remove the downrod clip and downrod pin from the
downrod. Then, loosen but do not remove the two set
screws at the top of the yoke.

6
Tab
Slot
Downrod
7. Install the ball end of the downrod into the opening
of the mounting bracket. Rotate the downrod until the
tab in the mounting bracket is seated in the slot in the
downrod ball.
WARNING: The fan and/or downrod should not rotate
in the mounting bracket, if installed correctly. Failure
to align the slot in the downrod ball with the tab on
the mounting bracket may result in fan falling causing
serious injury or death.
ASSEMBLY INSTRUCTIONS
Mounting
Bracket
Downrod Pin
Downrod Clip
Yoke
Downrod
Set Screw
Canopy
Braided
Cable
Yoke Cover
Downrod
Yoke
7
6
5
6. Slide the downrod into the yoke of the motor
assembly, align the holes, then re-install the downrod
pin and downrod clip. Secure with the two set screws
and slide the yoke cover down until it rests on top of the
motor assembly.
Note: With wiring extending out of the downrod,
measure 8 inches of lead wire and cut the excess wire
with wire cutters (not included). Then strip 1/2” of
insulation from the end of each wire.
WARNING: Do not cut braided cable.
5. Feed the wires and braided cable coming from the
yoke through the yoke cover, canopy and downrod.

7
ASSEMBLY INSTRUCTIONS
Secondary
Support
Screw
Open Loop Support Washer
Secondary
Spring
Washer
10
9. Install secondary support screw, secondary spring
washer, and support washer partly into the side of the
brace installed in the ceiling. Then lift the braided cable
up and over the ceiling brace and place the open loop of
the braided cable around the secondary support screw.
Note: The ceiling support brace may not be accessible
from below. If not, it must be accessed from above.
Important: The braided cable must make a complete
circle around the support brace to secure the fan.
10. Tighten the secondary support screw securing the
braided cable.
9
8
Secondary
Support Screw
Braided Cable
Outlet
Box
Brace
SECONDARY HANGING SYSTEM
For installation in the United States: Building codes
in the U.S.A. do not require installation of a Secondary
Hanging System. If desired, the braided cable can be cut
and removed using wire cutters (sold separately). Skip to
Step 11.
For installation in Canada: In compliance with building
codes in Canada, installation of the Secondary Hanging
System is required.
8. Feed the loop of the braided cable, preassembled to
the motor assembly, up through the outlet box mounted
in the ceiling.

8
ASSEMBLY INSTRUCTIONS
Motor Screw
Blade Arm
Blade Screw
Blade Washer
Blade Arm
Blade
Screw Cap
Canopy
Mounting Bracket Screw
J-shaped
Slot
Round
Hole
Black (Hot)
Wire Connector
White (Neutral)
Bare/Green (Ground)
Black Blue White Green
13
14
12
11
WARNING: Do NOT
wire the fan motor
to a variable-speed
(dimmer) wall control.
12. Raise the canopy, ensure the two mounting bracket
screws are aligned with the J-shaped slots in the canopy.
Then turn the canopy in a clockwise direction until the
mounting bracket screws are completely engaged in
the J-shaped slots. Install the two previously removed
mounting bracket screws in the round holes. Securely
tighten all mounting bracket screws.
13. Attach the blade to the blade arm using blade screw,
blade washer, and screw cap from the hardware kit.
Repeat for each blade.
14. Install the blade arm to the top side of the motor
with motor screws previously removed (Step 3, page 5).
Tighten with Phillips screwdriver (not included). Repeat
for each blade arm.
11. Use wire connectors to connect the fan wires to the
power supply wires according to the wiring diagram and
the following instructions:
• Connect the white wire from the fan to the white
(neutral) supply wire.
• Connect the black and blue wires from the fan to the
black (hot) supply wire.
• Connect the green wire from the downrod and
mounting bracket to the bare/green (ground) supply
wire.
Important: After the connections have been made, the
wires should be turned upward and pushed carefully
up into the outlet box. Place the black and white wire
connections on opposite sides of the outlet box.

9
ASSEMBLY INSTRUCTIONS
15. Remove one of the three tter plate screws
preassembled to the tter plate and loosen the other two
but do not remove. Feed the 9-pin connector through
the center hole in the switch housing plate. Align the
keyhole slots in the switch housing plate with the
loosened screws in the tter plate. Turn switch housing
plate clockwise and replace the previously removed tter
plate screw. Tighten all screws.
16. Remove the three switch housing screws from the
top edge of the switch housing plate. Connect the 9-pin
connector from the tter plate to the 9-pin connector
from the switch housing. Then, using the three previously
removed switch housing screws, secure the switch
housing to the switch housing plate.
15
16
17
Fitter Plate Screw
Keyhole Slot
Fitter Plate
9-pin Connector
Switch Housing Plate
9-pin Connector
Switch Housing
Screw
18
18. Turn ON the electrical power at the main fuse or
circuit breaker and the wall switch.
Installation is complete.
17. Attach the pull chain extension to the pull chain.
Switch Housing
Switch
Housing
Plate
Pull Chain Extension

10
Reverse Switch
Fan Pull Chain
OPERATING INSTRUCTIONS
1. Using a ceiling fan will allow you to raise your
thermostat setting in summer and lower your
thermostat setting in winter without feeling a dierence
in your comfort.
In warmer weather, push the reverse switch left which
will result in downward airow creating a wind chill
eect.
In cooler weather, push the reverse switch right
which will result in upward airow that can help move
stagnant, hot air o the ceiling area.
Important: Wait for the fan to stop before moving the
reverse switch. The reverse switch must be set either
completely left or right in order for the fan to function
correctly. If the reverse switch is set in the middle
position, the fan will not operate.
2. The fan pull chain has four positions to control fan
speed. One pull is HIGH, two is MEDIUM, three is LOW
and four turns the fan OFF.
1
2
