LOWE'S HUGGER 41530 User manual

Questions, problems or missing parts? Before returning this item to your retailer, call our customer service department
at 1-877-706-3267, Monday - Thursday, 8am - 6pm, Friday, 8am - 5pm EST.
9312 • 013118
28” HUGGER
CEILING FAN
MODEL # 41530

2
Hardware Kit
Owner’s
Manual
PACKAGE CONTENTS HARDWARE CONTENTS
Mounting Bracket
Motor Housing
Bracket Screw zp
Bracket Screw (x 2)
Motor
Switch Housing Motor Screw (x 10)
Light Kit
Thumbscrew
E26-Base LED Bulb
Glass Bowl
Blade Balancing Kit
Blade Arm (x 5)
Blade Screw (x 15)
Blade Washer (x 15)
Wire Connector (x 3)
Pull Chain Extension (x 2)
Blade (x 5)
Some extra hardware has been included.
The quantity listed above is the number
required for installation.

3
TABLE OF CONTENTS
PREPARATION
Before beginning the assembly of this product, ensure all parts are present. Compare all parts with the package contents list and hardware contents
list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 120 minutes
Tools required for assembly (not included): Phillips Screwdriver, Pliers, Safety Glasses, Step Ladder, and Wire Strippers
Helpful Tools (not included): AC Tester Light, Tape Measure, Wiring Handbook and Wire Cutters
Package Contents .....................................................................................................2
Hardware Contents ....................................................................................................2
Preparation ..........................................................................................................3
Assembly Instructions ..................................................................................................5
Operating Instructions .................................................................................................9
Safety Information ....................................................................................................10
Care and Maintenance ................................................................................................10
Troubleshooting......................................................................................................11
Warranty ...........................................................................................................12

4
PREPARATION
7 ft.
min.
30 in.
min.
1. Turn o󰀨 power.
Turn o󰀨 the power to the fan at the breaker
box and the wall switch.
2. Choose suitable location.
Ensure the blades will be at least 30 inches
from any obstructions and the blades will be
at least 7 feet above the oor.
Failure to disconnect the power supply
prior to installation may result in serious
injury or death.
See page 10 for complete description of
cautions and warnings.
4

1. Install the mounting bracket.
Secure the mounting bracket to the outlet
box (not included) using the two mounting
screws supplied with outlet box.
Warning: To reduce the risk of re, electrical
shock, or personal injury, mount the fan to
the outlet box marked “acceptable for fan
support”.
2. Install lower bracket.
Note: Remove the wire restraint from the
wire on top of the lower bracket.
Remove the preassembled bracket screw
from the lower mounting bracket and the two
bracket screws from the mounting bracket.
Insert the tab of the lower mounting bracket
into the slot in the upper mounting bracket.
3. Secure lower bracket.
Secure the lower bracket to the mounting
bracket using the three previously removed
bracket screws.
5
ASSEMBLY INSTRUCTIONS
Bracket
Screw
Mounting
Bracket
Mounting Bracket
Lower
Bracket
Bracket
Screw

6
Black (live)
White (neutral)
Bare/Green (ground)
Black Blue White
Green
4. Connect wiring.
Connect supply and fan wires with wire connectors according to the
diagram and these steps:
• Connect the green wire from the lower mounting bracket to the bare/
green (ground) supply wire.
• Connect the white wire from the fan to the white (neutral) supply
wire.
• Connect the blue and black wires from the fan to the black (hot)
supply wire.
Note: If there is a second hot/power wire coming from the outlet box,
connect it to the blue (light power) fan wire for separate light and fan
control.
Note: The black fan wire is the power for the fan. The blue fan wire is
the power for the light. The green fan wires is the ground. Ensure no
bare wire or wire strands are visible after making connections. Place
the Green and White wire connections on the opposite side of the
outlet box from the Black and Blue wire connections.
ASSEMBLY INSTRUCTIONS
Warning: Do NOT use a full-range
dimmer to control the fan speed.
Wire Connector

7
5. Install motor housing.
Temporarily lift the motor housing to the
upper mounting bracket to determine which
two motor housing screws in the sides of
the mounting bracket align with the slotted
holes in the top edge of the motor housing.
Partially loosen the two motor housing
screws that align with the slotted holes.
Remove the other two motor housing
screws from opposite sides of the mounting
bracket.
6. Secure motor housing.
Slide the motor housing over the motor,
aligning the slotted holes in the motor
housing with the loosened motor housing
screws in the mounting bracket. Twist the
motor housing to lock into place. Then re-
insert the two previously removed motor
housing screws and securely tighten all four
screws.
7. Attach blades to blade arms.
Partially insert three blade screws along with
the three blade washers through one blade
and into the blade arm. Tighten each screw
with a Phillips screwdriver (not included),
starting with the one in the middle. Repeat
this step for remaining blades and blade
arms.
ASSEMBLY INSTRUCTIONS
Motor
Housing
Screw
Motor
Housing
Screw Blade Screw
Blade Washer
Blade Arm

8
8. Install blade arms.
Remove the 10 preassembled motor screws
from the underside of the motor. Secure
the blade arm to the underside of the motor
using motor screws. Completely secure
each blade arm to the motor before moving
to the next.
9. Install bulb and glass globe.
Install the E26-base LED bulb into the
socket. Then, loosen the thumbscrews on
the light kit. Lift the glass globe to the light
kit, tightening the loosened thumbscrews to
secure.
10. Attach the pull chain extension
to the pull chain.
Note: When facing the reverse switch, the
pull chain for the fan is on the right and the
pull chain for the light is on the left.
Installation is complete. Turn on power to
the fan at the breaker box and at the wall
switch.
ASSEMBLY INSTRUCTIONS
Motor Screw
Glass Globe
Thumbscrew
Pull Chain Extension
Bulb

9
OPERATING INSTRUCTIONS
9
Pull Chain Operation
The fan pull chain has four positions to
control fan speed. One pull is HIGH, two is
MEDIUM, three is LOW and four turns the
fan OFF.
The light pull chain has two positions to
control the light, ON and OFF.
Note: When facing the reverse switch, the
pull chain for the fan is on the right and the
pull chain for the light is on the left.
Reverse Switch Operation
Using a ceiling fan will allow you to raise your
thermostat setting in summer and lower your
thermostat setting in winter without feeling a
di󰀨erence in your comfort.
Note: Wait for the fan to stop before moving the
reverse switch.
In warmer weather, push the reverse switch down
to display a sun icon, which will result in downward
airow creating a wind chill e󰀨ect.
In cooler weather, push the reverse switch up to
display a snowake icon, which will result in upward
airow that can help move stagnant, hot air o󰀨 the
ceiling area.
Fan Pull Chain
Reverse
Switch
Reverse
Switch
Light Pull Chain

10
SAFETY INFORMATION
CARE AND MAINTENANCE
Please read and understand this entire manual before attempting to assemble, operate or install the product.
• Before you begin installing the fan, disconnect the power by removing fuses or turning o󰀨 the circuit breakers.
• Make sure all electrical connections comply with local codes, ordinances, the National Electrical Code and ANSI/NFPA 70-199. Hire a qualied electrician or consult a
do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.
• Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades to the oor and at least 30 in. from the end of the blades to any
obstruction.
• The net weight of the fan is 9.48 pounds.
DANGER: When using an existing outlet box, make sure the outlet box is securely attached to the building structure and can support the full weight of the fan.
Failure to do this can result in serious injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan after installation is complete.
WARNING: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp edges.
WARNING: Using a full-range dimmer switch to control fan speed will cause a loud humming noise from the fan. To reduce the risk of re or electric shock, do NOT
use a full-range dimmer switch to control the fan speed.
WARNING: To reduce the risk of re, electric shock or personal injury, mount the fan to an outlet box marked “ACCEPTABLE FOR FAN SUPPORT” and use the
mounting screws provided with the outlet box. Most outlet boxes commonly used for the support of lighting xtures are not acceptable for fan support and may need to
be replaced. Consult a qualied electrician if in doubt. Secure the outlet box directly to the building structure. The outlet box and its support must be able to support the
moving weight of the fan (at least 35 lbs.).
WARNING: To reduce the risk of re, electric shock or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire
and two lead wires from the fan. If your house wire is larger than 12-gauge and/or there is more than one house wire to connect to the two fan lead wires, consult an
electrician for the proper size wire connectors to use.
WARNING: To reduce the risk of re, electric shock or personal injury, do not bend the blade arms when installing them, balancing the blades or cleaning the fan.
Do not insert objects between the rotating fan blades.
WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use of parts OTHER than those provided with this fan will void the warranty.
CAUTION: Be sure the outlet box is properly grounded or a ground (green or bare) wire is present.
CAUTION: Carefully check all screws, bolts, and nuts on the fan assembly ensure they are secured.
At least twice each year, lower the canopy to check the downrod assembly and tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth
to avoid scratching the nish. Clean the blades with a lint-free cloth.
Important: Shut o󰀨 the main power supply before you begin any maintenance task. Do NOT use water or a damp cloth to clean the fan.

11
TROUBLESHOOTING
The fan does not move.
The fan is noisy.
The fan wobbles
excessively.
The fan operates correctly
but the lights are not
working.
1. Firmly push the reverse switch completely up or down. The fan will not move with the switch in the middle
position.
2. Make sure the wall switch is turned on.
3. Ensure power is on at wall switch and breaker box
4. Turn the power o󰀨 and check all wire connections at the ceiling outlet box.
1. Check and tighten all screws that hold the fan blades to the blade arms and motor.
2. Replace any blade that is cracked or damaged.
3. Do not use a variable-speed wall control to control the fan speed.
4. Ensure the outlet box is securely mounted to the building structure.
5. Ensure the mounting bracket is securely mounted to the outlet box.
1. Tighten all screws that hold the fan blades to the blade arms and blade arms to motor.
2. Switch one blade with a blade from the opposite side. Or balance the fan using the blade balancing kit.
3. Turn o󰀨 power. Loosen the canopy and verify that the mounting bracket is secure to the electrical outlet box. The
mounting bracket must be ush without movement against the outlet box.
4. Use a longer downrod or move the fan to another location if fan blade is too close to the ceiling.
5. Ensure the mounting bracket is securely mounted to the electrical outlet box.
6. Tighten the mounting bracket is securely mounted to the outlet box.
1. Install new bulbs.
2. Ensure the single-pin connectors from the switch housing to the light kit are connected properly.
3. Turn the power o󰀨 and check all wire connections between the fan and outlet box.
PROBLEM CORRECTIVE ACTION

12
LIFETIME LIMITED WARRANTY
The manufacturer warrants this fan to be free from defects in workmanship and materials present at time of shipment from the factory for a lifetime
from the date of purchase by the original purchaser. The retailer also warrants that all other fan parts, excluding any glass or acrylic blades, to be
free from defects in workmanship and material at the time of shipment from the factory for a period of one year after the date of purchase by the
original purchaser. The manufacturer agrees to correct such defects without charge or at its option replace the ceiling fan with a comparable or
superior model.
To obtain warranty service, present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the product are your
responsibility. Any damage to any part such as by accident or misuse or improper installation or by a󰀩xing any accessories, is not covered by this
warranty. The manufacturer assumes no responsibility whatsoever for fan installation during the limited lifetime warranty. Any service performed by
an unauthorized person will render the warranty invalid.
Due to varying climate conditions, this warranty does not cover any changes in brass nish, including rusting, pitting, corroding, tarnishing or peeling.
Brass nishes of this type give their longest useful life when protected from varying weather conditions. Any glass provided with this fan is not
covered by the warranty.
Any replacement of defective parts from the ceiling fan must be reported within the rst year from the date of purchase. For the balance of the
warranty, call our customer service department for return authorization and shipping instructions so that we may repair or replace the ceiling fan.
Any fan or parts returned improperly is the sole responsibility of the purchaser. There is no other expressed warranty. The manufacturer disclaims
any and all warranties. The duration of any implied warranty which cannot be disclaimed is limited to the time period as specied in the expressed
warranty. The manufacturer shall not be liable for incidental, consequential, or special damages arising out of or in connection with product use or
performance except as may otherwise be accorded by law. This warranty gives specic legal rights, and you may also have other rights which vary
from state to state.
This warranty supersedes all prior warranties.
Note: A small amount of “wobble” is normal and should not be considered a defect.
