Lowell power Value Series Guide

Pure Sine Wave, Line Interactive UPS
Value Series
Models UPSV-700, UPSV-1000, UPSV-1500, UPSV-2000
User & Installation Manual
power
TM
(Rev 3/15/17)

Lowell UPSV Series Manual
Page 2
Table of Contents
Important Safety Warning............................................................................3
Transportaon.................................................................................................................................3
Preparaon......................................................................................................................................3
Installaon.......................................................................................................................................3
Hardware Installaon......................................................................................................................3
Maintenance, Service, and Faults...................................................................................................4
Storage........................................................................................................5
Basic Operaon............................................................................................5
Front and Top Panel Descripon......................................................................................................5
LCD Indicators..................................................................................................................................6
Troubleshoong...........................................................................................7
Fault Reference Codes....................................................................................................................8
Specicaons...............................................................................................9
Shipping List................................................................................................9
Obtaining Service.......................................................................................10
LimitedWarranty........................................................................................11

Lowell UPSV Series Manual
Page 3
Important Safety Warning
This manual contains important safety instrucons. Please read and follow all instrucons carefully during installa-
on and operaon of the unit. Read this manual thoroughly before aempng to unpack, install, or operate your
UPS.
Transportaon
• Please transport the UPS system only in the original package to protect against shock and impact.
Preparaon
• Condensaon may occur if the UPS system is moved directly from cold to warm environment. The UPS
system must be absolutely dry before being installed. Please allow at least two hours for the UPS system
to acclimate the environment.
• Do not install the UPS system near water or in moist environments.
• Do not install the UPS system where it would be exposed to direct sunlight or near heater.
• Do not block venlaon holes in the UPS housing.
Installaon
How to determine the power requirements of your equipment
1. Ensure that the equipment plugged into the baery power-supplied outlets does not exceed the UPS
unit’s rated capacity. If rated unit capacies are exceeded, an overload condion may occur and
cause the UPS unit to shut down or the fuse blow.
2. There are many factors that can aect the amount of power that your computer system will require.
For opmal system performance keep the load below 80% of the unit’s rated capacity.
Hardware Installaon Guide
1. Your new UPS may be used immediately upon receipt. However, recharging the baery for at least 8
hours is recommended to ensure that the baery’s maximum charge capacity is achieved. Charge loss
may occur during shipping and storage. To recharge the baery, simply leave the unit plugged into an AC
outlet. The unit will charge in both the on and o posion.
2. With the UPS unit o and unplugged, connect the computer, monitor, and any externally powered
data storage device.
3. Plug the UPS into a 2 pole, 3 wire grounded receptacle (wall outlet). Make sure the wall branch outlet
is protected by a fuse or circuit breaker and does not service equipment with large electrical demands.
• To prevent the risk of re or electric shock, install in a temperature and humidity controlled indoor area
free of conducve contaminants. (See the specicaons for the acceptable temperature and humidity
range.)
• To reduce the risk of overheang the UPS, do not cover the UPS’ cooling vents and avoid exposing the unit
to direct sunlight or installing the unit near heat eming appliances such as space heaters or furnaces.
• Do not aach non-computer-related items, such as medical equipment, life-support equipment, micro-
wave ovens, or vacuum cleaners to UPS.
• Do not plug the UPS input into its own output.
• Do not allow liquids or any foreign object to enter the UPS. Do not place beverages or any other liquid-
containing vessels on or near the unit.
• In the event of an emergency, press the OFF buon and disconnect the power cord from the AC power

Lowell UPSV Series Manual
Page 4
4. Depress the power switch to turn the unit on. The LCD indicator light will illuminate and the unit will
“beep”.
5. To maintain opmal baery charge, leave the UPS plugged into an AC outlet at all mes.
6. To store your UPS for an extended period, cover it and store with the baery fully charged. Recharge
the baery every three months to ensure baery life.
Maintenance, Service, and Faults
• The UPS system operates with hazardous voltages. Repairs may be carried out only by qualied mainte-
nance personnel.
• Cauon - risk of electric shock. Even aer the unit is disconnected from the mains (building wiring outlet),
components inside the UPS system are sll connected to the baery and electrically live and dangerous.
• Before carrying out any kind of service and/or maintenance, disconnect the baeries and verify that no
current is present and no hazardous voltage exists in the terminals of high capability capacitor such as
BUS-capacitors.
• To avoid electrical shock, turn o the unit and unplug it from the AC power source before servicing the
baery.
• Only persons who are adequately familiar with baeries and with the required precauonary measures
may replace baeries and supervise operaons. Unauthorized persons must be kept well away from the
baeries.
• Cauon - risk of electric shock. The baery circuit is not isolated from the input voltage. Hazardous volt-
ages may occur between the baery terminals and the ground. Before touching, please verify that no
voltage is present!
• Baeries may cause electric shock and have a high short-circuit current. Please take the precauonary
measures specied below and any other measures necessary when working with baeries:
»Remove wristwatches, rings and other metal objects
»Use only tools with insulated grips and handles.
• When changing baeries, install the same number and same type of baeries.
• Do not aempt to dispose of baeries by burning them. This could cause baery explosion.
• Do not open or destroy baeries. Escaping electrolyte can cause injury to the skin and eyes. It may be
toxic.
• When replacing baeries, replace with the same type and number of baeries or baery packs.
• Do not dismantle the UPS system.
• A baery can present a risk of electrical shock and high short-circuit current. The following precauons
should be observed when working on baeries:
»Remove watches, rings, or other metal objects.
»Use tools with insulated handles.
»Wear rubber gloves and boots.
»Do not lay tools or metal parts on top of baeries.
»Disconnect charging source prior to connecng or disconnecng baery terminals.
»Determine if baery is inadvertently grounded. If inadvertently grounded, remove source from
ground. Contact with any part of a grounded baery can result in electrical shock. The likelihood
of such shock can be reduced if such grounds are removed during installaon and maintenance.

Lowell UPSV Series Manual
Page 5
Storage
1. First turn o your UPS and disconnect its power cord from the wall outlet. Disconnect all cables con-
nected to the UPS to avoid baery drain.
2. The UPS should be stored in a cool dry locaon.
3. Make sure the baery is fully charged before the UPS is stored.
4. For extended storage in moderate climates, the baery should be charged for 12 hours every 3
months by plugging the power cord into the wall receptacle and turning on the main switch. Repeat it
every 2 months in high temperature locaons.
Basic Operaon
Front and Top Panel Descripon
1. Input Circuit Breaker
The circuit breaker provides opmal overload protecon.
2. AC Inlet
Connect to ulity power through the input power cord.
(IEC320 C14 for 700VA/1000VA/1500VA, IEC 320 C20 for 2000VA)
3. AC outlet
The UPS provides outlets for connected equipment to insure temporary uninterrupted operaon during
a power failure and against surges and spikes.
4. USB Port
This port allows connecon and communicaon from the USB port on the computer to the UPS unit.
5. Power On/O Buon
Press the power Buon to turn the UPS ON or OFF.
6. Seng Buon
The audible alarm can be turned o/on by pressing this buon 3s.
7. LCD Display
The LCD will display the UPS status.

Lowell UPSV Series Manual
Page 6
Denions for Illuminated LCD Indicators
LCD Indicators
AC INPUT(Voltage)
V
OUTPUT(Voltage)
V
Inial
Line mode
Bat-mode
Baery capacity
Load capacity
Fault
Sound disable
(Press the seng key 3s to disable and enable the buzzer sound)

Lowell UPSV Series Manual
Page 7
Troubleshoong
Problem Possible Causes Remedy
Abnormal
Mains normal but not
works in AC mode
1. AC Input missing 1. Check AC input connecon.
2. Input Breaker is tripped 2. Unplug the power cord of the UPS then
press the circuit breaker knob.
The UPS will not turn
on.
The on/o Buon is designed to prevent
damage by rapidly turning it o and on.
Turn the UPS o. Wait 10 seconds and
then turn the UPS on.
The unit is not connected to an AC outlet. The unit must be connected to a 100-
127V 50/60Hz outlet.
The baery is worn out. Contact technical support.
Mechanical problem.
Outlets do not provide
power to equipment
Circuit breaker is tripped due to overload
Turn the UPS o and unplug at least one
piece connected equipment. Unplug the
power cord of the UPS then press the
circuit breaker knob
Baeries are discharged Allow the unit to recharge for at least 4
hours.
Unit has been damaged by a surge or spike. Contact technical support.
Alarm code A51
Site Fail:
Line and neutral conductors of UPS Input
are reversed or the Ground is disconnect-
ed.
Check the input plug and socket.
Alarm code A56
Baery low:
Baery capacity is low, UPS will turn o
soon
1. Shut o non-essenal equipment.
2. Save your data and turn o the com-
puter.
Alarm code A64
Overload:
Your equipment requires more power than
the UPS can provide.
1. Shut o non-essenal equipment.
Alarm code A68 Over Temperature 1. Shut o non-essenal equipment.

Lowell UPSV Series Manual
Page 8
Fault Codes
Fault
Fault code E09 Output Short :
Output circuit short.
1. Shut down the UPS
2. Your aached equipment may have
problems, please remove them and check
again.
Fault code E14
Overload:
Your equipment requires more power than
the UPS can provide.
It will shutdown.
Shut o non-essenal equipment. If this
solves the overload problem, the UPS will
transfer to normal operaon.
Fault code E18 Fan fail :
Fan has been damaged.
1.Shut down the UPS
2.Replace the fan
Fault code E19 Over Temperature
1. Shut down the UPS. Restart the UPS
to Check the fan for operaon and if the
venlaon hole has been covered
2. Contact technical support for repair.

Lowell UPSV Series Manual
Page 9
Specicaons
Shipping List
1. Line cord
2. Rack Ears (can be used as pedestals)
3. USB cable
MODEL NUMBER UPSV-700 UPSV-1000 UPSV-1500 UPSV-2000
CAPACITY Power rang 700VA (420W) 1000VA (600W) 1500VA (900W) 2000VA (1200W)
INPUT Voltage nominal 120VAC
Voltage range 82-148VAC
Frequency 50/60Hz auto sensing
OUTPUT Voltage 120VAC
Waveform Pure sine wave
Transfer me (typical) 2–6ms
Eciency Up to 96% ECO mode, 93% buck and boost mode
Harmonic distoron 2% @ 100% linear load; 5% @ 100% non-linear load
BATTERY Baery type Sealed, maintenance-free lead acid
Baery quanty & size (1) 12V 9AH (2) 12V 7AH (2) 12V 9AH (2) 12V 9AH
Charging current 1A max
Typical recharge 4 hours to 90%
PHYSICAL Dimensions (W x D x H) 17.2" x 16.1" x 3.5"
Weight 24 lbs 27.3 lbs 36.5 lbs 36.5 lbs
Line cord (removable) 6, 5-15P to C13 6, 5-20P to C19
Receptacles (8) NEMA 5–15R
ENVIRONMENT Operang temperature 32–104°F (0–40°C)
Audible noise < 40dBA < 45dBA
Altude 11,500  above sea level
APPROVALS cTUVus, RoHs
WARRANTY 3 years electronics, 3 years baery warranty (USA and Canada)
COMMUNICATIONS INTERFACE USB
INCLUDED IN BOX Line cord, rack ears, USB cable

Lowell UPSV Series Manual
Page 10
OBTAINING SERVICE
If the UPS requires service:
1. Use the TROUBLESHOOTING section in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach the dealer or if they cannot resolve the problem, call Lowell
Manufacturing Company at [phone]. Technical support inquiries can also be made by email to sales@
lowellmfg.com. Please have the following information available BEFORE calling:
• Your name and address.
• The serial number of the unit.
• Where and when the unit was purchased.
• All of the model information about your UPS.
• Any information on the failure, including LEDs that may or may not be illuminated.
• A description of the protected equipment, including model numbers if possible.
• A representative will ask you for the above information and, if possible, help solve the problem over the
phone. In the event that the unit requires factory service, the representative will issue you a Return Material
Authorization number (RMA).
If you are returning the UPS for service, please follow these procedures:
1. Pack the UPS in its original packaging. If the original packaging is no longer available, ask the Lowell representative
about obtaining a replacement set of packaging material. It is important to pack the UPS properly in order to
avoid damage in transit. Never use Styrofoam beads for a packing material.
2. Include a letter with your name, address, daytime phone number, RMA number, a copy of your original sales
receipt, and a brief description of the problem.
3. Mark the RMA number on the outside of all packages. Lowell Manufacturing cannot accept any package
without the RMA number marked on the outside of the boxes.
4. Return the UPS by insured, prepaid carrier to the address provided by the Lowell representative.
5. Refer to the Warranty statements in this manual for additional details on what is covered.

Lowell UPSV Series Manual
Page 11
LIMITED WARRANTY
Lowell Manufacturing Company warrants Lowell UPS equipment, when properly applied and operated within specied
conditions, against faulty materials or workmanship for a period of three years for UPSV Series products from
the date of purchase. Lowell Manufacturing Company warrants internal batteries for a period of three years
from the date of purchase. For equipment sites within the United States and Canada, this warranty covers repair or
replacement, at the sole discretion of Lowell Manufacturing Company. The customer is responsible for the costs of
shipping the defective product to Lowell Manufacturing Company. Lowell Manufacturing Company will pay for ground
shipment of the repaired or replacement product. This warranty applies only to the original purchaser.
If equipment provided by Lowell Manufacturing Company is found to be Dead-on-Arrival (DOA), Lowell Manufacturing
Company will be responsible for the costs of shipping product to and returning equipment from the customer in a
timely manner as agreed to with the customer, once the customer has requested and received a Return Material
Authorization (RMA) number. DOA equipment is dened as equipment that does not properly function according to
user documentation when initially received and connected in conjunction with proper procedures as shown in the user
documentation or via support provided by Lowell Manufacturing Company personnel or authorized agents.
This warranty shall be void if (a) the equipment is repaired or modied by anyone other than Lowell Manufacturing
Company or a Lowell Manufacturing Company approved third party; (b) the equipment is damaged by the customer,
is improperly used or stored, is subjected to an adverse operating environment, or is operated outside the limits of
its electrical specications; or (c) the equipment has been used or stored in a manner contrary to the equipment’s
operating manual, intended use or other written instructions. Any technical advice furnished by Lowell Manufacturing
Company or a Lowell Manufacturing Company authorized representative before or after delivery with regard to the
use or application of Lowell Manufacturing Company equipment is furnished on the basis that it represents Lowell
Manufacturing Company’s best judgment under the situation and circumstances, but it is used at the recipient’s sole
risk.
EXCEPT AS STATED ABOVE, Lowell Manufacturing Company DISCLAIMS ALL WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCEPT AS STATED ABOVE, IN NO EVENT WILL Lowell Manufacturing Company BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF Lowell Manufacturing
Company UPSV Series EQUIPMENT, including but not limited to, any costs, lost prots or revenue, loss of equipment,
loss of use of equipment, loss of software, loss of data, cost of substitutes, or claims by third parties. Purchaser’s sole
and exclusive remedy for breach of any warranty, expressed or implied, concerning Lowell Manufacturing Company
equipment, and the only obligation of Lowell Manufacturing Company under this warranty, shall be the repair or
replacement of defective equipment, components, or parts; or, at Lowell Manufacturing Company’s sole discretion,
refund of the purchase price or substitution of an equivalent replacement product.
