Lowell power UPS6-350LI Guide

Lithium Ion UPS
Model UPS6-350LI
User & Installation Manual
power
TM
(Rev 5/24/18)

Lowell #UPS6-350LI Manual
Page 2
Table of Contents
Package Contents.........................................................................................3
Product Introducon....................................................................................3
ProductOverview.........................................................................................3
Installaon & Inial Startup.........................................................................3
Indicators & Alarm Condions......................................................................4
Important Safety Instrucons: (Save These Instrucons)...............................4
Troubleshoong...........................................................................................5
Specicaons...............................................................................................6
Obtaining Service.........................................................................................7
Limited Warranty.........................................................................................8

Lowell #UPS6-350LI Manual
Page 3
Package Contents
You should be receiving the following items inside the package:
• UPS Unit
• Local Monitoring Soware CD
Product Introducon
Thank you for selecng this Uninterrupble Power Supply (UPS). It provides you with protecon for connected
equipment. Please read this manual before installing the UPS6-350LI as it provides important informaon that
should be followed during installaon and maintenance of the UPS and baeries, allowing you to correctly set up
your system for the maximum safety and performance. Included is informaon on customer support and service, if
it is required. If you experience a problem with the UPS, please refer to the Troubleshoong secon in this manual
to correct the problem. If the problem is not corrected, please collect informaon so that the Technical Support
personnel can more eecvely assist you.
Product Overview
The UPS6-350LI advanced design combines the benets of lithium powered UPS and advanced surge suppression
technology. Slim form factor (just 1.25”), wall mounng, and easy access receptacles make the UPS6-350LI ideal
for mounng behind thin display screens used in hotels, restaurants, hospitals, campuses, airports and other com-
mercial areas.
While the compact design is appealing to the digital signage industry, it is also excellent for providing protecon to
kiosks, gaming machines, computers, point-of-sale equipment, and small printers.
Front View Rear View
Installaon & Inial Startup
Note: Before installaon, inspect the unit and packaging to make sure that nothing inside has been damaged.
Connect UPS to Ulity and Charging
Before the inial use of the UPS, plug the UPS input cord into a wall outlet and turn the UPS on by pressing the

Lowell #UPS6-350LI Manual
Page 4
Power switch on the back of the UPS. For best results, the baeries in the UPS should be charged for at least 8
hours before use. The UPS charges its baery while it is connected to AC ulity power and powered on.
Connecng the Loads
Plug the loads to be supported by the UPS into the output receptacles on the front of the UPS. Simply turn the
power switch on the UPS on and the devices connected to the UPS will be protected by the UPS unit.
Turn UPS ON / OFF
To turn the UPS unit on, press the power buon on the UPS and hold for three seconds. To turn the UPS unit o,
press the power buon and hold for one second.
Connecng Local Monitoring Soware (oponal)
If it is desired to use the Local Monitoring Soware, and if your UPS is equipped with USB communicaons, con-
nect a USB cable from your computer to the UPS, and install the soware from the CD.
Indicators & Alarm Condions
Condion Visual Indicator Alarm
AC mode LED illuminated No Audible Alarm
Baery mode LED ashes every 10 seconds Audible Alarm sounds every 10
seconds
Low baery mode LED ashes every 1 second Audible Alarm sounds every 1
second
Fault LED is illuminated Audible Alarm is connuous
Alarm for over temperature protec-
on
LED ashes every 0.5 seconds No Audible Alarm
Important Safety Instrucons: (Save These Instrucons)
CAUTION! (UPS having Internal Baeries): Risk of electrical shock – Hazardous live parts inside this unit are ener-
gized from the baery supply even when the input AC power is disconnected.
CAUTION! (No User serviceable Parts): Risk of electrical shock, do not remove cover. No user serviceable parts
inside. Refer servicing to qualied service personnel.
CAUTION! (Non-isolated Baery supply): Risk of electric shock, baery circuit is not isolated from AC input, haz-
ardous voltage may exist between baery terminals and ground. Test before touching.
WARNING! Unit intended for installaon in a controlled environment.
CAUTION! Do not dispose of baeries in a re, the baery may explode.
CAUTION! Do not open or mulate the baery, released electrolyte is harmful to the skin and eyes.
CAUTION! A baery can present a risk of electric shock and high short circuit current. The following precauon
should be observed when working on baeries:
• Remove watches, rings or other metal objects.
• Use tools with insulated handles.

Lowell #UPS6-350LI Manual
Page 5
To reduce the risk of electric shock, disconnect the UPS from the main supply before installing a computer inter-
face signal cable. Reconnect the power cord only aer signaling interconnecons have been made.
Servicing of baeries should be performed or supervised by personnel with knowledge of baeries and the re-
quired precauons. Keep unauthorized personnel away from baeries.
The instrucons contained within this safety manual are deemed important and should be closely followed at all
mes during installaon and follow-up maintenance of the UPS and baeries.
CAUTION: The unit has a dangerous amount of voltage. If the UPS indicator is on, the unit’s
outlets may have a dangerous amount of voltage even when not plugged into the wall outlet be-
cause the baery may connue to supply power.
Care should be taken to undertake installaon indoors, free from electrically-conducve parcles
which are under temperature and humidity control, in order to reduce the risk of electric shock.
It is best to disconnect the device using the power supply cord. Ensure that the equipment is
placed in a posion near the outlet where easily accessible.
All servicing on this equipment must be carried out by qualied service personnel.
Before conducng any maintenance, repair, or shipment, rst ensure that everything is turned o
completely and disconnected.
Troubleshoong
Condion Visual Indicator Alarm
No LED display on the front UPS
panel
Low baery Charge the UPS at least 8 hours
Baery fault Replace the baery with the same
type of baery
The UPS is not turned on Press the Power Switch on the front
of the UPS
Alarm connuously sounds when
the AC input is normal
The UPS is overloaded Remove some of the load from the
output of the UPS
UPS fault Return the unit for service
Alarm sounds every 2 seconds
when the AC input is normal
Baery defect Replace the baery with the same
type of baery
Charging circuit is damaged Return the unit for service
When power fails, backup me is
shorter than expected
The UPS is overloaded Remove some of the load from the
output of the UPS
Baery voltage is too low Charge the UPS at least 8 hours
Baery defect Replace the baery with the same
type of baery
The AC input is normal but the blue
LED is ashing
Power cord is loose Reconnect the input power cord
properly

Lowell #UPS6-350LI Manual
Page 6
Specicaons
MODEL NUMBER UPS6-350LI
CAPACITY Power rang 350VA (200W)
INPUT Voltage 120VAC
Frequency 50/60Hz
OUTPUT Voltage 120VAC
Waveform Sine wave (normal), simulated sine wave (baery mode)
Frequency 50/60Hz
Surge suppression 312 joules
Transfer me 2-6ms (typical)
BATTERY Baery type Lithium Iron Phosphate (LiFePo4)
Baery quanty and size (8) 18650 cells, 2400mAh
Baery runme (est) 6 min at 100% load; 14 min at 50% load
PHYSICAL Dimensions (W x D x H) 6.9 x 8.5 x 1.25 in*
Weight 3.4 lbs
Line cord Detachable 5–15P to C13 (3)
Receptacles (3) 5–15R
ENVIRONMENT Temperature 32–104°F (0–40°C)
Humidity 0–90%
Altude 11,500  above sea level
APPROVALS UL-1778, cTUVus, FCC, and RoHS
WARRANTY 5 years electronics, 5 years baery warranty**
COMMUNICATIONS INTERFACE USB
INCLUDED IN BOX ViewPower CD, 5–15P to C13 line cord
*Wall mount brackets add 15mm to each side
**Warranty outside of USA & Canada is three years.

Lowell #UPS6-350LI Manual
Page 7
OBTAINING SERVICE
If the UPS requires service:
1. Use the TROUBLESHOOTING section in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach the dealer or if they cannot resolve the problem, call Lowell
Manufacturing Company at [phone]. Technical support inquiries can also be made by email to sales@
lowellmfg.com. Please have the following information available BEFORE calling:
• Your name and address.
• The serial number of the unit.
• Where and when the unit was purchased.
• All of the model information about your UPS.
• Any information on the failure, including LEDs that may or may not be illuminated.
• A description of the protected equipment, including model numbers if possible.
• A representative will ask you for the above information and, if possible, help solve the problem over the
phone. In the event that the unit requires factory service, the representative will issue you a Return Material
Authorization number (RMA).
If you are returning the UPS for service, please follow these procedures:
1. Pack the UPS in its original packaging. If the original packaging is no longer available, ask the Lowell representative
about obtaining a replacement set of packaging material. It is important to pack the UPS properly in order to
avoid damage in transit. Never use Styrofoam beads for a packing material.
2. Include a letter with your name, address, daytime phone number, RMA number, a copy of your original sales
receipt, and a brief description of the problem.
3. Mark the RMA number on the outside of all packages. Lowell Manufacturing cannot accept any package
without the RMA number marked on the outside of the boxes.
4. Return the UPS by insured, prepaid carrier to the address provided by the Lowell representative.
5. Refer to the Warranty statements in this manual for additional details on what is covered.

Lowell #UPS6-350LI Manual
Page 8
LIMITED WARRANTY
Lowell Manufacturing Company warrants Lowell UPS equipment, when properly applied and operated within specied
conditions, against faulty materials or workmanship for a period of ve years (USA & Canada) or three years
(outside USA & Canada) for UPS6-Series products from the date of purchase. Lowell Manufacturing Company
warrants internal batteries for a period of ve years from the date of purchase. For equipment sites within the
United States and Canada, this warranty covers repair or replacement, at the sole discretion of Lowell Manufacturing
Company. The customer is responsible for the costs of shipping the defective product to Lowell Manufacturing
Company. Lowell Manufacturing Company will pay for ground shipment of the repaired or replacement product. For
equipment outside the USA and Canada, the warranty does not include shipping to and from Lowell Manufacturing
Company. This warranty applies only to the original purchaser.
If equipment provided by Lowell Manufacturing Company is found to be Dead-on-Arrival (DOA), Lowell Manufacturing
Company will be responsible for the costs of shipping product to and returning equipment from the customer in a
timely manner as agreed to with the customer, once the customer has requested and received a Return Material
Authorization (RMA) number. DOA equipment is dened as equipment that does not properly function according to
user documentation when initially received and connected in conjunction with proper procedures as shown in the user
documentation or via support provided by Lowell Manufacturing Company personnel or authorized agents.
This warranty shall be void if (a) the equipment is repaired or modied by anyone other than Lowell Manufacturing
Company or a Lowell Manufacturing Company approved third party; (b) the equipment is damaged by the customer,
is improperly used or stored, is subjected to an adverse operating environment, or is operated outside the limits of
its electrical specications; or (c) the equipment has been used or stored in a manner contrary to the equipment’s
operating manual, intended use or other written instructions. Any technical advice furnished by Lowell Manufacturing
Company or a Lowell Manufacturing Company authorized representative before or after delivery with regard to the
use or application of Lowell Manufacturing Company equipment is furnished on the basis that it represents Lowell
Manufacturing Company’s best judgment under the situation and circumstances, but it is used at the recipient’s sole
risk.
EXCEPT AS STATED ABOVE, Lowell Manufacturing Company DISCLAIMS ALL WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCEPT AS STATED ABOVE, IN NO EVENT WILL Lowell Manufacturing Company BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF Lowell Manufacturing
Company UPS6 Series EQUIPMENT, including but not limited to, any costs, lost prots or revenue, loss of equipment,
loss of use of equipment, loss of software, loss of data, cost of substitutes, or claims by third parties. Purchaser’s sole
and exclusive remedy for breach of any warranty, expressed or implied, concerning Lowell Manufacturing Company
equipment, and the only obligation of Lowell Manufacturing Company under this warranty, shall be the repair or
replacement of defective equipment, components, or parts; or, at Lowell Manufacturing Company’s sole discretion,
refund of the purchase price or substitution of an equivalent replacement product.
