Lowry GSOFR2003 User manual

1500 Watt Oil Filled Radiator
User manual
Model number: GSOFR2003
Please read these instructions carefully and keep them for future reference

Contents
Page
Unpacking your appliance..………............................
Safety instructions..................................................
Feature diagram......................................................
Wheel base assembly………………………………………….
Using your appliance…..……….................................
Cleaning and care...................................................
Problem solving......................................................
Connection to the mains supply.............................
Guarantee.….….……………………………………………………
2
3
6
7
8
11
12
13
14

Unpacking your Appliance
Before you use your appliance
1. Remove all the packaging.
2. Check the appliance after unpacking for any visual damage such as:
●Misaligned or damaged cabinet parts
●Damage to the controls
●Damage to the plug or cable
●If you can see any damage do not use the Appliance
The appliance should not be used if it has been dropped or there are any visible signs of
damage.
This appliance must be placed on a solid stable surface, away from walls, cabinets,
furniture, curtains, etc. Position the appliance with minimum spacing of 100cm from the
top and sides, front and back.
2

Safety instructions
When using electrical appliances, basic safety precautions should always be observed,
including the following:
➢Read all instructions.
➢Check that the your mains voltage corresponds with the rating on the appliance.
➢The appliance must not be left unattended while it is connected to the mains supply.
➢Do not touch hot surfaces. Use the handle or the controls.
➢To protect against electrical shock do not immerse cord, plug, or appliance in water or other
liquid. Do not operate with wet hands.
➢Do not let the cord hang over the edge of a worktop, table etc.or touch hot surfaces.
➢Do not operate any appliance with a damaged cord or plug, or after the appliance
malfunctions or is dropped or damaged in any manner. The supply cord cannot be replaced. If
the cord is damaged the appliance should be scrapped.
➢The use of accessory attachments not recommended by the appliance manufacturer may
cause fire, electric shock or injury.
➢This appliance must not be immersed
➢To disconnect remove the plug from the mains outlet. Do not pull the plug out by the cord.
3

Safety instructions
4
➢Never remove parts from the appliance, such as the feet, screws and so on.
➢Never use the appliance near a bath, shower or a swimming pool.
➢Never place flammable objects or clothing on top of the appliance.
➢Allow a 100cm safe area around the appliance on the top and sides, front and back.
➢Never use the appliance in a room with explosive gas such as petrol, or while using any kinds of
flammable glues, sprays or solvents.
➢Prevent overheating of the appliance by keeping the air inlets and outlets clean and free of anything
that may cause blockage. Check all inlets and outlets from time to time for accumulated dust. DO NOT
COVER.
➢Do not place any part of your body near the air inlet, outlet or on the fins ,to avoid personal injury,
electric shock or fire.
➢If overheating should occur, the built-in overheating safety device will shut the appliance off.
➢Do not insert any foreign objects into the ventilation.
➢Keep all ventilation clear of any draped fabric or curtains.
➢The appliance must not be located immediately below a mains socket. Do not use the appliance
with a programmer, timer or any other device that switches the appliance on automatically. A fire risk
exists if the appliance is covered or positioned incorrectly.

Safety instructions
5
➢Do not operate this appliance for anything other than its intended use.
➢This appliance is not intended for commercial use.
This product is intended for household use only. Do not use outdoors.
This product is only intended for heating and cooling.
Warning: it is hazardous for anyone other than a competent person to carry out any service or
repair operation which involves the removal of a cover which gives protection against
exposure to electrical parts.
This heater is filled with a precise quantity of special oil. Repairs requiring opening of the oil
container are only to be made by the manufacturer or his service agent who should be
contacted if there is an oil leak.
When scrapping the heater, follow the regulations concerning the disposal of oil.
Warning: children should not use this appliance. Close supervision is necessary when any
appliances are used near children.
Warning: this appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to make sure that they do not play
with the appliance.

Feature diagram
6
Warning - Do not touch hot surfaces, do not block openings or cover appliance.
Thermostat Control Power setting
Cord storage
Ventilation
Carry handle
Castor wheels
Oil filled fins

Wheel base assembly
7
Warning - Do not touch hot surfaces, do not block openings or cover appliance.
Turn the heater upside down
Position the 2 x wheel base assemblies
between the end fins
Tighten the 4 x wing nuts and turn the heater the
right way.
Attach the wheel base assemblies to the heater
using the 2 x U-bolts and 4 x wing nuts supplied

Using your Appliance
8
1. Before connecting your appliance to the mains socket, position the appliance upright on
the floor, at least 90cm away from the wall, away from curtains, furniture or wall
coverings.
2. Insert the mains plug into a suitable 13Amp mains socket.
3. Turn the Power Control to the ‘I’ or ‘II’ position. The appliance has 2 power settings. You
can select one or both power settings. The power switch lights will illuminate when they
are working.
Power Control Position
O - Power OFF
I (Left Hand switch)- Low heat ON
II (Right Hand switch) - Medium heat ON
I & II –High heat ON

Using your Appliance
9
4. Turn the Thermostat Control to the desired position. It is recommended to select the
highest position to pre heat the appliance. It will take 5 -10 minutes for the appliance to
fully heat up. Please note, this appliance will not operate unless positioned on a flat stable
surface or if the thermostat has been set too low.
5. When the room reaches the desired temperature, turn the Thermostat Control slowly
anti clockwise until the appliance goes off with a ‘click’ sound. The heating elements will
temporarily go off.
6. If the room temperature falls below the desired temperature, the heating elements will
turn on again until the room temperature reaches the desired temperature.
Note: this radiator is oil filled, and will cool down slowly after the power is shut off. Allow the
radiator heater to cool prior to any movement, the built in carry handle should be used for
easy movement.
Thermostat Control
Turn clockwise from MIN ‘ 0 ‘ to MAX ‘6’
position

Using your Appliance
10
Safety Protective Devices
The appliance is fitted with an over heat protection system.
1. Overheat protection - the power to the heating elements will automatically cut off if the
temperature of the heating elements exceeds a certain limit. In the event of overheating,
the heater will stop operating. Switch the appliance off and allow it to completely cool.
The appliance will then resume operating as normal.

Cleaning and care
WARNING: Electrical Shock Hazard.
Before you clean the appliance, disconnect the mains plug from the wall socket.
➢Allow the appliance to cool down completely before cleaning.
➢Do not immerse cord, plug or appliance in any liquid or allow moisture to come into contact
with electrical parts.
➢Clean the outer surface using a moist cloth and wipe over with a dry, soft cloth.
➢Do not use harsh detergents, abrasives or spray on cleaners.
➢Don’t allow water to seep into the openings or come into contact with electrical connections.
➢Allow sufficient drying time before operating again.
➢When the appliance is not in use. We recommend that, the heater is re-packed in its original
packaging and stored in a cool, dry place.
11

Problem Solving
My appliance does not work when I turn it on
1. Check that your appliance is plugged in and the power is turned on at the mains socket.
2. Try another mains socket.
3. Check that the thermostat setting has not been set too low.
4. If the appliance still doesn’t work, do not try to repair it yourself.
If your appliance power is automatically cut off, follow the step below:
1. Unplug your appliance from the mains socket and allow it to completely cool down.
2. Inspect your appliance. If there are any signs of physical damage (e.g. melting, or burning of
the case), do not attempt to use the appliance. Please leave all maintenance work to
qualified personnel.
3. Plug in the appliance and switch it on again. If it cuts off again, move the appliance to a
better ventilated location.
12

Connection to the mains supply
WARNING- THIS APPLIANCE MUST BE EARTHED
This appliance is designed to operate from a mains supply of AC 220V–240V ~50Hz.
Check that the voltage marked on the product corresponds with your supply voltage.
This product is fitted with a 13A plug complying with BS1363 and is fitted with an appropriate fuse
complying with BS1362. Always replace the fuse with one of the same rating. If the plug is unsuitable for
your mains socket or needs to be replaced, please note the following:
Important: The wires in the mains lead must be connected as per the following diagram -
Always ensure that the plug cord grip is fastened correctly.
If your appliance is supplied with a non-rewireable plug, you will find that it incorporates a fuse, the value
of which is indicated either on the base of the plug or on the fuse carrier. Always replace the fuse with
one of the same rating. If you need to remove the plug, cut it from the mains lead and dispose of it. Never
attempt to re-use this plug or insert it into a socket outlet, as there is a very great risk of an electric shock.
Rated voltage: AC 220V–240V ~50Hz
Power consumption: 1500W
13

14
Guarantee
This product is guaranteed for 12 months from the date of the original purchase. If any
defect arises due to faulty materials or workmanship the faulty product must be
returned to the place of purchase.
Refund or replacement is at the discretion of the store.
The following conditions apply:
•The product must be returned to the retailer with the original proof of purchase.
•The product must be installed and used in accordance with the instructions
contained in this instruction guide and any other instructions for use which has been
supplied.
•It must be used for domestic purposes only and for its intended use.
•This guarantee does not cover wear and tear, damage, misuse or consumable parts.
This does not affect your statutory rights.

This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that
the product/batteries should not be disposed of with your general household waste. Only discard electrical/electronic/battery
items in separate collection schemes, which cater for the recovery and recycling of materials contained within. Your co-operation
is vital to make sure the success of these schemes and for the protection of the environment. For your nearest disposal facility,
visit www.recycle-more.co.uk or ask in store for details.
We reserve the right due to possible changes to design to alter the instruction manual without prior notice.
