LS Industrial Systems SV-iV5 Series User manual

i
Safety instructions
Thank you for purchasing LS Vector Drives!
SAFETY INSTRUCTIONS
To prevent injury and property damage, follow these instructions.
Incorrect operation due to ignoring instructions will cause harm or damage.
The seriousness of which is indicated by the following symbols.
WARNING
Do not remove the cover while power is applied or the unit is
in operation.
Otherwise, electric shock could occur.
Do not run the inverter with the front cover removed.
CAUTION This symbol indicates the possibility of
in
j
ur
y
or dama
g
e to
p
ro
p
ert
y
WARNING This symbol indicates the possibility of
death or serious injury
■The meanin
g
of each s
y
mbol in this manual and on
y
our equipment
is as follows.
This is the safety alert symbol.
Read and follow instructions carefully to avoid dangerous situation.
This symbol alerts the user to the presence of “dangerous voltage”
inside the product that might cause harm or electric shock.
■After reading this manual, keep it in the place that the user always
can contact easily.
■This manual should be given to the person who actually uses the
products and is responsible for their maintenance.
This symbol indicates the instant death or
serious injury if you don’t follow instructions
DANGER

ii
Safety instructions
Otherwise, you may get an electric shock due to high voltage termi-
nals or charged capacitor exposure.
Do not remove the cover except for periodic inspections or
wiring, even if the input power is not applied.
Otherwise, you may access the charged circuits and get an electric
shock.
Wiring and periodic inspections should be performed at
least 10 minutes after disconnecting the input power and af-
ter checking the DC link voltage is discharged with a meter
(below DC 30V).
Otherwise, you may get an electric shock.
Operate the switches with dry hands.
Otherwise, you may get an electric shock.
Do not use the cable when its insulating tube is damaged.
Otherwise, you may get an electric shock.
Do not subject the cables to scratches, excessive stress,
heavy loads or pinching.
Otherwise, you may get an electric shock.
CAUTION
Install the inverter on a non-flammable surface. Do not
place flammable material nearby.
Otherwise, fire could occur.
Disconnect the input power if the inverter gets damaged.
Otherwise, it could result in a secondary accident and fire.
After the input power is applied or removed, the inverter will
remain hot for a couple of minutes.
Otherwise, you may get bodily injuries such as skin-burn or damage.
Do not apply power to a damaged inverter or to an inverter
with parts missing even if the installation is complete.
Otherwise, electric shock could occur.
Do not allow lint, paper, wood chips, dust, metallic chips or

iii
Safety instructions
other foreign matter into the drive.
Otherwise, fire or accident could occur.
OPERATING PRECAUTIONS
1) Transport and Installation
zBe sure to carry inverter in a proper way suitable for its weight, or it may result
in damage to inverter.
zDo not pile up inverters above allowable limit.
zBe sure to install the inverter as directed in this instruction manual.
zDo not turn off the power supply to the damaged inverter.
zDo not open the front cover while carrying the inverter.
zDo not place the heavy material on the inverter.
zThe direction of installation should be observed properly as criterions specified
in this manual show.
zMake sure that you should not put screw, metal material, water, oil and the in-
flammable something else.
zKeep in mind that inverter is very vulnerable to drop from the mid air and strong
shock.
zBe certain to use the inverter under the following conditions.
Ambient temperature - 10 ~ 40 ℃ (Non-frozen)
Humidity Below 90% RH (Dewdrop should not be
formed)
Storage temperature - 20 ~ 65 ℃
Ambient condition Free of corrosive gas, inflammable gas, oil-
waste and dust
Environment
Altitude/vibration Below 1000m above sea level, Below
5.9m/sec²(=0.6g)
2) Wiring works
zDo not connect phase-leading capacitors, surge filter, radio noise filter to the
output of inverter.
zOutput terminals (terminals named U, V, W respectively) should be connected
in a proper phase sequence.
3) Adjustment before starting trial operation
zBe sure to check relevant parameters for the application before starting trial
operation.
4) Directions
zBe sure not to approach the machine when retry function is selected. The ma-
chine may start working suddenly.
zStop key on the keypad should be set to be in use. For safety, additional emer-
gency stop circuit should be required.
zInverter restarts if alarm condition is cleared while FX/RX signal is on. There-
fore, be sure to operate the alarm reset switch after checking if FX/RX signal is
off.
zNever modify the inverter for inappropriate use.
zMotor may not be protected by electronic thermal protection.

iv
Safety instructions
zDo not start or stop the inverter by the magnetic contactor installed at the in-
put of inverter.
zNoise filter should be used for the minimization of troubles by electro-
magnetic noise. Electronic equipments close to the inverter should be pro-
tected against the damage caused by troubles.
zBe sure to install the AC reactor at the input of inverter in case of input voltage
unbalance. Otherwise, generator or phase-leading capacitors may be destroyed
by the harmonic current from inverter.
zIf 400V class motor is used with the inverter, insulation-enforced motor should
be used or countermeasures against the suppression of micro-surge voltage
generated by the inverter should be carried out. Otherwise, micro-surge volt-
age is generated across input terminal for the motor and this voltage lowers al-
lowable insulation break-down voltage and then, may cause the destruction of
the motor.
zBe sure to set the parameters once more, in case of initialization of parameters,
all values of parameters is set to values of factory setting.
zHigh speed operation can be set easily, therefore be sure to check the perform-
ance of motor or machine before changing parameter value.
zDC braking function cannot produce a zero-servo torque. If required, additional
equipment should be installed.
zWhen inverter trip or emergency stop (BX) occurs without keypad connected,
LED on the control board will blink by the interval of 0.5 sec. But LED will blink
by 1 sec when keypad is connected.
5) Countermeasure against malfunction troubles
zIf inverter is damaged and then gets into uncontrollable situation, the machine
may lead to the dangerous situation, therefore to avoid this situation, be sure
to install the additional equipments such as brake.
6) Maintenance, inspection and parts replacement
zDo not perform the megger (insulation resistance check) test on the control
board.
zPlease refer to Chapter 7 (intervals for parts replacement).
7) Disposal
z Handle the inverter as an industrial waste when disposing of it.
8) General instructions
Many of the diagrams and drawings in this instruction manual show the inverter without
a circuit breaker, a cover or partially open. Never run the inverter like this. Always place
the cover with circuit breakers and follow this instruction manual when operating the
inverter.

v
Table of Contents
Safety Instructions ----------------------------------------------------------------------------------------------------------- i
Chapter
1 Introduction
1.1 Key features --------------------------------------------------------------------------------------------- 1
1.2 Inverter nameplate and model ------------------------------------------------------------------------ 2
Chapter
2 Specifications
2.1 Standard specification ----------------------------------------------------------------------------------- 3
2.2 Common specification ---------------------------------------------------------------------------------- 4
Chapter
3 Installation and wiring
3.1 Wiring precaution --------------------------------------------------------------------------------------- 5
3.2 Basic wiring ---------------------------------------------------------------------------------------------- 7
3.3 Power circuit terminal ---------------------------------------------------------------------------------- 9
3.4 Control circuit terminal --------------------------------------------------------------------------------- 14
3.4.1 Control terminal layout ---------------------------------------------------------------------------- 14
3.4.2 Control terminal description ---------------------------------------------------------------------- 14
3.4.3 Wiring Control terminal --------------------------------------------------------------------------- 16
3.4.4 Caution on Encoder wiring ----------------------------------------------------------------------- 16
3.4.5 Wiring and jumper setting for Complementary or Open Collector -------------------------- 17
3.4.6 Wiring and jumper setting for Line Drive ------------------------------------------------------- 17
3.4.7 Jumper setting for Analog Input ---------------------------------------------------------------- 18
Chapter
4 Trial Operation
4.1 Keypad description -------------------------------------------------------------------------------------- 19
4.2 Keypad display description ---------------------------------------------------------------------------- 20
4.3 Setting of Parameter values --------------------------------------------------------------------------- 21
4.4 Parameter group ---------------------------------------------------------------------------------------- 22
4.5 Auto-Tuning ---------------------------------------------------------------------------------------------- 24
4.5.1 Motor and Encoder parameter setting ---------------------------------------------------------- 24
4.5.2 Rotational Auto-tuning ---------------------------------------------------------------------------- 25
4.5.3 Standstill Auto-tuning ----------------------------------------------------------------------------- 27
4.6 Pulse encoder check ------------------------------------------------------------------------------------ 28
4.7 Operation by Keypad ----------------------------------------------------------------------------------- 29
4.8 Operation by Terminal ---------------------------------------------------------------------------------- 30
Chapter
5 Parameter List
5.1 Display group (DIS_[][]) ------------------------------------------------------------------------------- 33
5.2 Input/output group (I/O_[][]) ------------------------------------------------------------------------ 34
5.3 Parameter group (PAR_[][]) --------------------------------------------------------------------------- 37
5.4 Function group (FUN_[][]) ---------------------------------------------------------------------------- 38
5.5 Control group (CON_[][]) ------------------------------------------------------------------------------ 39
5.6 User group (USR_[][]) --------------------------------------------------------------------------------- 40
5.7 2nd function group (2nd_[][]) ------------------------------------------------------------------------- 41
Chapter
6 Parameter description
6.1 Display group (DIS_[][]) ------------------------------------------------------------------------------- 42
6.1.1 DIS_00(Motor control status monitoring) ------------------------------------------------------ 42
6.1.2 DIS_01 ~ 03(user display 1, 2, 3) -------------------------------------------------------------- 42
6.1.3 DIS_04(Process PID Controller) ----------------------------------------------------------------- 44
6.1.4 DIS_05(Fault display) ----------------------------------------------------------------------------- 44
6.1.5 DIS_06(User group display selection) ---------------------------------------------------------- 45

vi
Table of Contents
6.2 Input/output group (I/O_[][]) ------------------------------------------------------------------------ 46
6.2.1 Jump code (I/O_00) ------------------------------------------------------------------------------- 46
6.2.2 Multi-function Input Terminal -------------------------------------------------------------------- 46
1) I/O_01 ~ 07(Multi-function input terminal P1 ~ P7 define) ------------------------------- 46
2) I/O_08(Reversal of Multi-function input terminal) ------------------------------------------ 57
3) I/O_09(Low Pass Filter Time Constant for the Terminals) --------------------------------- 57
4) I/O_10Inversion of Multi-function aux contact output ------------------------------------- 57
6.2.3 Multi-function analog input ----------------------------------------------------------------------- 58
1) I/O_11 ~ 25
(Definition of Multi-function analog input terminal, Gain, Bias, LPF time constant) ------ 58
2) Adjusting Gain and Bias by Keypad ----------------------------------------------------------- 60
6.2.4 Multi Function Outputs (MFO) ------------------------------------------------------------------- 61
1) I/O_41 ~ 43
(Multi-function aux contact output (AX1 ~ AX2) and Open collector (OC1) output setting----- 61
2) I/O_46(Fault Output Relay (30A, 30B, 30C)) ----------------------------------------------- 66
3) I/O_59 ~ 61(Overload trip enable, level, time) --------------------------------------------- 66
6.2.5 Analog output -------------------------------------------------------------------------------------- 66
6.3 3 Parameter group (PAR_[][]) ------------------------------------------------------------------------ 68
6.3.1 Jump code (PAR_00) ------------------------------------------------------------------------------ 68
6.3.2 Parameter group function ------------------------------------------------------------------------ 68
1) PAR_01(Parameter initialize) ------------------------------------------------------------------ 68
2) PAR_02 ~ 03(All Parameter Read/Write) ----------------------------------------------------- 68
3) PAR_04(Parameter Lock) ----------------------------------------------------------------------- 69
4) PAR_05(Password) ------------------------------------------------------------------------------- 69
6.3.3 Motor parameters setting ------------------------------------------------------------------------- 70
1) PAR_07(Motor rating setting), PAR_08(Motor cap. Selection of user) ------------------- 70
2) PAR_09(Motor Cooling method) --------------------------------------------------------------- 70
3) PAR_10 ~ 13(pulse number of Encoder, direction, Error detection, LPF) ------------------ 70
6.3.4 PAR_14, PAR_15(Encoder error detection time, encoder error reference speed) -------- 71
6.3.5 Auto-tuning ----------------------------------------------------------------------------------------- 73
1) Motor and Encoder parameters setting for Auto-tuning ------------------------------------ 73
2) Rotational Auto-tuning -------------------------------------------------------------------------- 74
3) Standstill Auto-tuning --------------------------------------------------------------------------- 76
4) Motor parameters -------------------------------------------------------------------------------- 78
5) Auto tuning error message --------------------------------------------------------------------- 79
6.4 Function group (FUN_[][]) ---------------------------------------------------------------------------- 81
6.4.1 Jump code (FUN_00) ------------------------------------------------------------------------------ 81
6.4.2 Operating method select -------------------------------------------------------------------------- 81
1) FUN_01(RUN/STOP source select) ----------------------------------------------------------- 81
2) FUN_02(Speed setting method) --------------------------------------------------------------- 82
3) FUN_03(Stop method) ------------------------------------------------------------------------- 82
6.4.3 FUN_04(Motor Max Speed Reference) ---------------------------------------------------------- 82
6.4.4 Multi-step speed and Dwell Speed setting methods ------------------------------------------ 82
1) FUN_12 ~ 19(Multi-step speed 0 ~ 7) -------------------------------------------------------- 82
2) FUN_20(JOG speed command) ---------------------------------------------------------------- 82
3) FUN_21 ~ FUN_22(Dwell Speed, Time) ------------------------------------------------------ 83
6.4.5 Accel/Decel pattern and time selection --------------------------------------------------------- 84
1) FUN_33(Accel/Decel reference speed) -------------------------------------------------------- 84
2) FUN_40 ~ 47(Accel/Decel time 1 ~ 4) ------------------------------------------------------- 84
3) FUN_36 ~ 39(S curve ratio during Accel/Decel 1 ~ 2) ------------------------------------- 85
4) FUN_48(Deceleration time for zero speed selection) --------------------------------------- 87
5) FUN_49(Zero speed deceleration time) ------------------------------------------------------- 87
6) FUN_51(Decel time when BX is ON) ---------------------------------------------------------- 88
7) FUN_52(Pre-excitation) ------------------------------------------------------------------------- 88
8) FUN_53(Hold Time) ---------------------------------------------------------------------------- 88
6.4.6 Electronic Thermal (Motor
I
T
2) Selection ---------------------------------------------------- 89

vii
Table of Contents
6.4.7 Inverter switching frequency select ------------------------------------------------------------- 90
1) FUN_57(Inverter switching frequency select) ----------------------------------------------- 90
2) Setting range and factory setting of switching frequency --------------------------------- 90
6.4.8 Power ON Start Selection (FUN_58) ------------------------------------------------------------ 91
6.4.9 Restart after fault reset (FUN_59) ------------------------------------------- ------------------- 91
6.4.10 Restart After Fault Reset ------------------------------------------------------------------------ 92
1) FUN_60(Number of auto restart try) ---------------------------------------------------------- 92
2) FUN_61(Delay time before Auto restart) ----------------------------------------------------- 92
6.4.11 Wait time for restart upon stop ---------------------------------------------------------------- 93
6.4.12 Overspeed error detection (FUN_63,FUN_64) ----------------------------------------------- 93
6.5 Control group (CON_[][]) ------------------------------------------------------------------------------ 94
6.5.1 Jump code (CON_00) ----------------------------------------------------------------------------- 94
6.5.2 Control mode select (CON_01) ------------------------------------------------------------------ 94
6.5.3 Application mode (CON_02) ---------------------------------------------------------------------- 94
6.5.4 Automatic Speed Regulator : ASR --------------------------------------------------------------- 94
1) CON_05(ASR LPF Time Constant 1) -------------------------------------------------------- 94
2) CON_08(ASR LPF Time Constant 2) -------------------------------------------------------- 94
3) CON_03 ~ 04(ASR PI Gain 1) ------------------------------------------------------------------ 95
4) CON_06 ~ 07(ASR PI Gain 2) ------------------------------------------------------------------ 95
5) CON_09(Ramp time for ASR gain Transfer) ------------------------------------------------- 95
6) CON_10(Motor Speed at the time of ASR Gain Transfer) ---------------------------------- 95
6.5.5 Process PID Control ------------------------------------------------------------------------------- 97
6.5.6 Draw Control ---------------------------------------------------------------------------------------- 99
6.5.7 Droop Control --------------------------------------------------------------------------------------- 101
6.5.8 Torque Control -------------------------------------------------------------------------------------- 103
1) CON_26(Torque Reference Source Selection) ----------------------------------------------- 103
2) CON_32(Torque Bias Source select) ---------------------------------------------------------- 103
3) CON_35(Torque Balance) ---------------------------------------------------------------------- 104
4) Torque Bias Enable/Disable --------------------------------------------------------------------- 104
5) CON_34(Torque Bias F/F) ---------------------------------------------------------------------- 104
6) CON_28 ~ 31
(Torque Limit Define, Torque Limit during FWD RUN /REV RUN/Regenerating) ----------- 104
7) Torque Current reference ----------------------------------------------------------------------- 105
6.5.9 Speed Search (CON_49) -------------------------------------------------------------------------- 106
6.6 User group (USR_[][]) --------------------------------------------------------------------------------- 107
6.6.1 Jump code (USR_00) ------------------------------------------------------------------------------ 107
6.6.2 Macro ------------------------------------------------------------------------------------------------ 107
1) USR_01(Macro Init) ------------------------------------------------------------------------------ 107
2) USR_02(User Save) ------------------------------------------------------------------------------ 107
3) USR_03(User Recall) ---------------------------------------------------------------------------- 107
6.6.3 User code define (USR_04 ~ 67) -------------------------------------------------------------- 107
6.7 2nd group (2nd_[][]) ----------------------------------------------------------------------------------- 109
6.7.1 Jump code (2nd_00) ------------------------------------------------------------------------------- 109
6.7.2 2nd motor control mode selection (2nd_01) --------------------------------------------------- 109
6.7.3 2nd motor speed setting -------------------------------------------------------------------------- 109
6.7.4 2nd motor parameters related to acceleration and deceleration ---------------------------- 110
6.7.5 2nd motor parameters related to the pulse encoder ----------------------------------------- 110
6.7.6 2nd motor parameters ---------------------------------------------------------------------------- 110
6.7.7 2nd motor miscellaneous parameters ----------------------------------------------------------- 110

viii
Table of Contents
Chapter
7 Periodic inspection
7.1 Precautions ----------------------------------------------------------------------------------------------- 111
7.2 Check points --------------------------------------------------------------------------------------------- 111
7.3 Parts replacement --------------------------------------------------------------------------------------- 112
Chapter
8 Troubleshooting and maintenance
8.1 Fault display --------------------------------------------------------------------------------------------- 113
8.2 Fault status and history -------------------------------------------------------------------------------- 114
8.3 Fault reset ------------------------------------------------------------------------------------------------ 114
8.4 Troubleshooting ----------------------------------------------------------------------------------------- 115
Appendix
A Accessories ------------------------------------------------------------------------------------------------- 125
B Dimensions ------------------------------------------------------------------------------------------------- 127
C Encoder division option card ---------------------------------------------------------------------------- 132
D Braking resistor and braking unit ----------------------------------------------------------------------- 134
E Control block diagram ------------------------------------------------------------------------------------ 136

1
1. Introduction
Chapter 1 - Introduction
1.1 Key Features
zCurrent Controlled Vector Control Inverter with Speed Sensor using IGBT as Power Semiconductor Device.
zTension/Torque Control and Wide Variety of Process Control
zProcess PI Control, Draw Control, Droop Control etc.
zAuto-tuning of Motor Parameters for Precise Speed/Torque Control: Rotational/Standstill mode
zEncoder error (H/W and S/W) detection function
zInverter Application
Application Applicable Machine/System Features
zSteel Strip Tension Control
zPaper Mill Wide Range of Speed
Control
zTextile
zFilm
zCoater
Process Control
zPrinting Machine
zLifts (Elevators) High Speed Operation
zParking High Starting Torque
Positioning
zStacker Crane Wide Range of Speed
Control
zCrane
Hoisting Control
zHoist
zMachine Tool High Speed Operation
zWire Drawing High Starting Torque
Machine Control
zExtruder Positioning
zConveyor High Speed Operation
Others zIndustrial Washing Machine Positioning
This instruction manual is designed for LS STARVERT-iV5 series Vector Control
Inverters, which have excellent characteristics in speed and torque control with pulse
encoder mounted on the shaft of 3 phase induction motor, and covers installation,
maintenance, wiring and operation for these inverters.

2
1. Introduction
1.2 Inverter Nameplate and Model
1.2.1 Inverter Nameplate (Example)
1.2.2 Inverter Model Name
zLS STARVERT Series
zMax. Applicable Motor
022 : 2.2kW ~ 2200 : 220kW
ziV5 Series
zInput Voltage
2 : 200V Class (200 ~ 230V) , 4 : 400V Class (380 ~ 480V)
zBuilt-in DB Circuit
DB : Built-in DB Circuit (DB Resistors Integrated)
Blank : No Built-in DB Circuit (Use external DB Unit)
zMD : Mold Type (11~22kW)
(All of the specifications other than the dimension
based on the specifications of the metallic cover type 11~22kW class.)
zInput Voltage
(380V) : 380V Input Voltage – Greater than 30kW
Blank : Below 22kW (200V/400V)
Inverter Model Name
Input Power Source Specifications
Inverter Output Specifications
Bar Code
Serial Code
SV [][][]iV5-2DB
INPUT 200 - 230 V 3 Phase
[][][]A 50/60Hz
OUTPUT 0-InputV 3Phase
[][][]A 0 – 3600rpm
[][][]HP / [][][]kW
[][][][][][][][][][][]
LS Industrial S
y
stems Co.
,
Ltd
,
KOREA
SV [][][] i
V
5 - 2 DB (MD) (380V)

3
2. Specification
Chapter 2 - Specification
2.1 Standard Specification
2.1.1 200V Class
SV[][][]iV5-2(DB) 022 037 055 075 110 150 185 220 300 370
[HP] 3 5 7.5 10 15 20 25 30 40 50
Max. applicable
motor output (1) [kW] 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
Capacity [kVA](*2) 4.5 6.1 9.1 12.2 17.5 22.5 28.2 33.1 46 55
Rated current [A] 12 16 24 32 46 59 74 88 122 146
Speed 0 ~ 3600rpm (Vector control)
Output
Voltage 200 ~ 230V(*3)
Voltage 3φ200 ~ 230V (-10% ~ +10%)
Input
Frequency 50 ~ 60Hz (±5%)
Inverter weight [kg(lbs)] 6(13) 6(13) 14(30) 14(30) 28(61) 28(61) 28(61) 28(61) 42(93) 42(93)
2.1.2 400V Class
SV[][][]iV5-4(DB) 022 037 055 075 110 150 185 220 300 370
[HP] 3 5 7.5 10 15 20 25 30 40 50
Max. applicable
motor output (1) [kW] 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37
Capacity [kVA](*2) 4.5 6.1 9.1 12.2 18.3 22.9 29.7 34.3 46 57
Rated current [A] 6 8 12 16 24 30 39 45 61 75
Speed 0 ~ 3600rpm (Vector control)
Output
Voltage 380 ~ 480V(*3)
Inverter weight [kg(lbs)] 6(13) 6(13) 14(30) 14(30) 28(61) 28(61) 28(61) 28(61) 45(99) 45(99)
SV[][][]iV5-4(DB) 450 550 750 900 1100 1320 1600 2200
[HP] 60 75 100 120 150 175 215 300
Max. applicable
motor output (1) [kW] 45 55 75 90 110 132 160 220
Capacity [kVA](*2) 70 85 116 140 170 200 250 329
Rated Current [A] 91 110 152 183 223 264 325 432
Speed 0 ~ 3600 rpm (Vector control)
Output
Voltage 380 ~ 480V(*3)
Inverter weight [kg(lbs)] 63(139) 63(139) 68(150) 98(216) 98(216) 122(269) 122(269) 175(386)
Voltage 3φ380 ~ 460V (-15% ~ +10%)(*4)
Input Frequency 50 ~ 60 Hz (±5%)
Note)
1. It represents the output capacity of maximum applicable motor in case LG-OTIS 4- pole motor is used.
2. Rated capacity (=√3*V*I) is calculated based on 220V for 200V class, 440V for 400V class.
3. Maximum output voltage cannot be generated above specified input voltage.
4. Derate the rated current by 10% when the input voltage is in the range of 507 ~ 528V.
※The electrical specifications of the MD type (2.2~22kW Class) are the same as the above.
SV[][][]iV5-2/4DB(MD) 055 075 110 150 185 220
Inverter weight [kg(lbs)] 7.7(16.9) 7.7(16.9) 13.7(30.2) 13.7(30.2) 20.3(44.7) 20.3(44.7)

4
2. Specification
2.2 Common Specification
Items Detailed Specification
Inverter type Voltage source inverter using IGBT
Control method zField oriented vector control inverter usin
g
Encoder feedback
(5.5 ~ 220kW)
Speed control
accuracy
zAnalog setting: ±0.2%(25 ±10℃) of max. Speed
zDigital setting : ±0.01%(0 ~ 40℃) of max. Speed
Speed setting
resolution zAnalog setting: ±0.005% of maximum Speed
zDigital setting: 0.01% of maximum Speed
Cut-off frequency of ASR 50Hz
Torque control accuracy 3%
Time setting 0.00 ~ 6000.0 sec (Time unit can be set)
Combination 4 Combinations of acceleration/Deceleration Time
Control
Accel/
Decel Pattern Linear, S-Curve
Braking method Dynamic braking using external resistors
Braking torque 150%
Braking
Braking resistor External braking resistor should be provided.
Speed settings
zDigital setting via keypad
zMulti-step speed setting by input terminal selection
zAnalog input settings of –10~10V or 4~20mA
zRemote setting by option card
Analog input
z3 channels (AI1, AI2, AI3*)
z-10 ~ 10V, 0~10V, 10 ~ 0V, 40~20mA, 20 ~ 4mA,
(*AI3: -10 ~ 10V, 0~10V, 10 ~ 0V, Motor NTC only)
zSelectable among 9 different user-defined functions
zAi3 (Motor NTC): only available with a LG-OTIS motor used.
Input
Contact input zFX, RX, BX, RST, P1 ~ P7
zSelectable among 29 different user-defined input functions
Analog
output
z2 channels (AO1, AO2)
z-10V ~ 10V Voltage output
zSelectable among 31 different user-defined functions
Contact output z2 channels (1A-1B, 2A-2B)
zFault alarm relay: 1 channel (30A-30C, 30B-30C)
Output
Open Collector 1 Channel (OC1/EG)
Protection
Overcurrent, Overvoltage, Low voltage, Inverter overheat,
Inverter thermal sensor malfunction, Motor overheat, Motor
thermal sensor malfunction, Overspeed, Instantaneous IGBT
gate block (BX), Fuse blown open, External Trip, Pulse encoder
malfunction, Electronic thermal function, Inverter overload,
Ground fault current, IGBT short, Communication error
Installation condition Indoor, Free of Corrosive gas and Direct sunlight
Ambient temperature -10 ~ 40°C (Non-frozen condition)
Humidity Below RH 90% (Dewdrop should not be formed)
Cooling method Forced ventilation by cooling fan
Environment
Altitude, Vibration Below 1000m above sea level, Below 5.9m/s2(=0.6G)

5
3. Installation and wiring
Chapter 3 – Installation and wiring
3.1 Caution on installation
3.1.1 Do not install the inverter in a location where excessive vibration is present.
Be cautious when installing on presses or moving equipment.
3.1.2 Caution on Ambient Temperature
Ambient temperature greatly affects inverter lifetime, therefore be sure to keep the ambient
temperature of installation location at –10 to 40℃.
3.1.3 Install the inverter on the uninflammable material. The inverter operates at high-temperature.
3.1.4 Avoid a humid and hot location.
3.1.5 Install the inverter in a location free of oil mist and dust.
Totally enclosed panel can be used to protect the inverter against that materials.
3.1.6 Secure the installation space enough to protect the inverter against the overheating.
Measurement point of
Ambient temperature
5 cm
5 cm
5 cm
SV-iV5
This chapter describes general items for the installation and wiring of an
inverter and includes instruction for wiring to power terminal and control one
and caution in case of wiring, and also explains the function of each terminal
for both power and control.

6
3. Installation and wiring
3.1.7 Special care should be taken in case the inverter is to be installed in the panel.
In case more than 2 inverters are to be installed or ventilation fan is to be installed in the panel, make
sure that inverter and ventilation fan is properly installed. If they are poorly installed, it causes the
increase of an ambient temperature and less effective ventilation. Therefore, be sure to keep the ambient
temperature of inverter below the allowable temperature.
3.1.8 Install the inverter tightly not to get loose using proper sized bolt or screw.
Min. 5 cm
Min. 10 cm
Min. 5cm
SV-iV5
Min. 10 cm

7
3. Installation and wiring
3.2 Basic Wiring
SV055, 075, 110, 150, 185, 220iV5-2(DB)
SV055, 075, 110, 150, 185, 220iV5-4(DB)
PE
R
S
T
G
U
V
W
B1 B2
FX
RX
BX
RST
P1(MM0)
P2(MM1)
P3(ATO)
CM
VREF
AI1
5G
IM
3 P AC input
(220/440V)
(50/60Hz)
5G
A+
RA
GE
RB
E
Encoder
(Line Drive
Type)
GE
MCMCCB
FWD run /Stop command
REV run/Stop command
Emergency stop
Fault reset
Multi-function
input 1
Multi-function
input
2
Multi-function
input
3
Common
Potentiometer
10 k ohm, 1/2W
Multi-function
input
24 V
DB Resistor
(optional)
G
Encoder A
Phase input
Note) : Main circuit, : Control circuit
Shield
P4(FHM)
P5(BAT)
P6(BRC)
P7(MCC)
STARVERT - iV5
Multi-function
input
4
Multi-function
input
5
Multi-function
input
6
Multi-function
input
7
AI2
AI3
Power supply
(+10V)
Analog input 1
Analog input 2
Analog input 3
Common
Analog input
(-10 ~ 10V)
(4 ~ 20mA)
(10 ~ 0V)
(20 ~ 4mA)
(
M otor NTC)
Encoder B
Phase input
Power supply (5V)
Common(0V)
Open collector
output
ACR
AO1
AO2
5G
Analog output 1
Analog output 2
Common
Analog
output
(-10 ~ 10V)
30A
30C
30B
1A
1B
2B
2A
Fault relay output
( ~ AC 250V, 1A)
( ~ DC 30V, 1A)
Auxiliary relay
output
( ~ AC 250V, 1A)
( ~ DC 30V, 1A)
Open collector
output
( 24V, 50mA)
OC1
EG
B+
A-
B-
A phase encoder
pulse output
B phase encoder
pulse output
Encoder output
Common
Encoder output
Common

8
3. Installation and wiring
SV300, 370iV5-2
SV300, 370, 450, 550, 750, 900, 1100, 1320, 1600, 2200iV5-4
PE
R
S
T
G
U
V
W
P1 N
FX
RX
BX
RST
P1(MM0)
P2(MM1)
P3(ATO)
CM
VREF
AI1
5G
IM
3 phase AC
input
(220/440V)
(50/60Hz)
5G
A+
RA
GE
RB
E
GE
MCMCCB
24 V
DB Resistor
(Optional)
G
Encoder A
Phase input
Note) : Main circuit, : Control circuit
Shield
P4(FHM)
P5(BAT)
P6(BRC)
P7(MCC)
STARVERT - iV5
AI2
AI3
Encoder B
Phase input
Power supply (+5V)
Common (0V)
Open collector
output
ACR P2
B2
P/B1
N
G
DB Unit
(Option)
30A
30C
30B
1A
1B
2B
2A
Open collector
output
( 24V, 50mA)
OC1
EG
AO1
AO2
5G
Analog
output
(-10 ~ 10V)
A-
B+
B-
FWD run /Stop command
REV run/Stop command
Emergency stop
Fault reset
Multi-function
input 1
Multi-function
input 2
Multi-function
input 3
Common
Multi-function
input
Multi-function
input 4
Multi-function
input 5
Multi-function
input 6
Multi-function
input 7
Potentiometer
10 kohm, 1/2W Power supply
(+10V)
Analog input 1
Analog input 2
Analog input 3
Common
Analog input
(-10 ~ 10V)
(4 ~ 20mA)
(10 ~ 0V)
(20 ~ 4mA)
(Motor NTC)
A phase encoder
pulse output
B phase encoder
pulse output
Encoder output
Common
Encoder output
Common
Fault relay output
( ~ AC 250V, 1A)
( ~ DC 30V, 1A)
Auxiliary relay
output
( ~ AC 250V, 1A)
( ~ DC 30V, 1A)
Multi-function
output 1
Multi-function
output 2
Common
Encoder
(Line Drive
Type)

9
3. Installation and wiring
3.3 Power Circuit Terminal
SV022, 037, 055, 075, 110, 150, 185, 220iV5-2(DB)
SV022, 037, 055, 075, 110, 150, 185, 220iV5-4(DB)
R S T U V W G N B2 B1 P
SV300, 370iV5-2
SV300, 370, 450, 550, 750iV5-4
R S T G U V W P1 P2 N
SV900, 1100, 1320, 1600, 2200iV5-4
R S T G U V W P1 P2 N

10
3. Installation and wiring
3.3.1 Power Circuit Terminal Description
Name Function Description
R, S, T 3 Phase input power supply Connected to 3 phase input power supply
1) 200V Class : 200 ~ 230V, 50/60Hz
2) 400V Class : 380 ~ 480V, 50/60Hz
U, V, W Inverter Output Connected to 3 phase induction motor
G Grounding Used for inverter frame earth
B1, B2 Braking Resistor Connected to braking resistor
P1, P2 DC Reator and DB Unit Used for DC Reactor, DB Unit and
DC link common connection
N DB Unit Used for DB Unit and DC link common connection
3.3.2 Cautions to be required for wiring to Power Circuit Terminal
①Connect terminals ( R, S and T) to 3 phase input power supply after checking inverter nameplate
attached on the inverter. Never connect terminals (U, V and W) to 3 phase input power supply. It results in
lethal damage to the inverter.
②Never connect the phase advancing capacitor to the inverter output. If already installed, remove the
phase advancing capacitor clearly.
Input
Voltage
R S T G U V W
Phase
advancing
capacitor
SV-iV5

11
3. Installation and wiring
③Cable between inverter output and motor should be less than 30m long. If cable gets long, surge voltage
appears across motor terminals depending on the cable parameters. Especially, in 400V class motor case,
insulation withstanding voltage may be decreased. Use an insulation-enforced motor when 400V class motor
is used.
④Crimp terminal with insulation cap should be used for the input power supply and the motor.
⑤After finishing wiring, be certain to remove all the wire or cable scraps inside the inverter.
⑥Use the shield cable or twist-paired wire for control circuit terminal. Do not put them into the same wiring
duct for the power terminal.
⑦When wiring is changed after operating the inverter, be sure to check LCD window on the keypad or
charge lamp is turned off. Capacitors inside inverter are charged with high voltage and it may result in lethal
injury.
⑧Below 22kW inverter, B1 and B2 on the power terminal should not be connected to anything else other
than DB resistors.
3.3.3 Main Power Circuit Wire Sizes and Grounding Wire Size
①Main Power Circuit Wire Sizes
If wiring for the main power terminal is not performed properly, it may cause severe damage to inverter or
lethal injury to inverter operator. Be sure to use 600V, 75℃copper wire.
Wire Size
Ring Terminals mm2 AWG
Inverter Capacity Terminal
screw
size
Screw
Torque1
(Kgf.cm) R, S, T U, V, W R, S, T U, V, W R, S, T U, V, W
2.2kW M4 15 2-4 2-4 2 2 14 14
3.7kW M4 15 2-4 2-4 3.5 3.5 12 12
5.5 kW M5 15 5.5-5 5.5-5 5.5 5.5 10 10
7.5 kW M5 15 14-5 8-5 8 8 8 8
11 kW M6 26 14-5 14-5 14 14 6 6
15 kW M6 26 22-6 22-6 22 22 4 4
18.5 kW M8 45 38-8 38-8 30 30 2 2
22 kW M8 45 38-8 38-8 38 30 2 2
200V
30/37 kW M8 100 60-8 60-8 60 60 1/0 1/0
2.2/3.7kW M4 15 2-4 2-4 2 2 14 14
5.5 kW M5 15 5.5-5 5.5-5 3.5 2 12 14
7.5 kW M5 15 14-5 8-5 3.5 3.5 12 12
11 kW M6 26 14-5 14-5 5.5 5.5 10 10
15 kW M6 26 22-6 22-6 14 8 6 8
18.5 kW M8 45 38-8 38-8 14 8 6 8
22 kW M8 45 38-8 38-8 22 14 4 6
30/37 kW M8 100 60-8 60-8 22 22 4 4
45/55 kW M8 100 38-8 38-8 38 38 2 2
75 kW M8 100 60-8 60-8 60 60 1/0 1/0
90 kW M12 300 60-12 60-12 60 60 1/0 1/0
110 kW M12 300 80-12 80-12 80 80 3/0 3/0
132/160 kW M12 300 100-12 100-12 100 100 4/0 4/0
400V
220 kW M12 300 200-12 200-12 2 x 100 2 x 100 2 x 4/0 2 x 4/0
