iS7 EtherNet/IP User Manual
SV-iS7 Series
User Manual

iS7 Ethernet Option Manual
1
Safety Precaution
First thank you for using our iS7 Ethernet Option Board!
Please follow the following safety attentions since they are intended to prevent
any possible accident and danger so that you can use this product safely and
correctly.
Safety attentions may classify into ‘Warning’ and ‘Caution’ and their meaning is
as following:
Symbol
Meaning
WARNING
This symbol indicates the possibility of death or
serious injury.
CAUTION
This symbol indicates the possibility of injury or
damage to property.
The meaning of each symbol in this manual and on your equipment is as follows.
Symbol
Meaning
This is the safety alert symbol.
Read and follow instructions carefully to avoid
dangerous situation.
This symbol alerts the user to the presence of
“dangerous voltage” inside the product that might
cause harm or electric shock.
After reading this manual, keep it in the place that the user always can contact.
This manual should be given to the person who actually uses the products and is
responsible for their maintenance.
WARNING
Do not remove the cover while power is applied or the unit is in
operation.
Otherwise, electric shock could occur.
Do not run the inverter with the front cover removed.
Otherwise, you may get an electric shock due to high voltage terminals or
charged capacitor exposure.
Do not remove the cover except for periodic inspections or wiring,
even if the input power is not applied.
Otherwise, you may access the charged circuits and get an electric shock.
Wiring and periodic inspections should be performed at least 10
minutes after disconnecting the input power and after checking the

iS7 Ethernet Option Manual
2
WARNING
DC link voltage is discharged with a meter (below DC 30V).
Otherwise, you may get an electric shock.
Operate the switches with dry hands.
Otherwise, you may get an electric shock.
Do not use the cable when its insulating tube is damaged.
Otherwise, you may get an electric shock.
Do not subject the cables to scratches, excessive stress, heavy
loads or pinching.
Otherwise, you may get an electric shock.
CAUTION
Be cautious when handling CMOS elements on the option board.
It may cause a failure due to static electricity.
When changing and connecting communication signal lines,
proceed the work while the inverter is turned off.
It may cause a communication error or failure.
Make sure to connect the inverter body to the option board
connector accurately coincided each other.
It may cause a communication error or failure.
Make sure to check the parameter unit when setting parameters.
It may cause a communication error.

iS7 Ethernet Option Manual
3
Table of Contents
Table of Contents......................................................................................................3
1. Introduction........................................................................................................4
2. Ethernet Technical Features ..............................................................................4
3. Product Constituents .........................................................................................4
4. The External and Mounting of Ethernet Option Module......................................5
5. Network Connection ..........................................................................................7
6. Network Cable Standard....................................................................................8
7. Ethernet Option and Related Keypad Parameters .............................................9
8. Inverter Communication Address.....................................................................15
9. Modbus/TCP Frame ........................................................................................15
10. Ethernet IP.......................................................................................................21
11. Lost Command................................................................................................39
12. LED Information and Troubleshooting..............................................................41

iS7 Ethernet Option Manual
4
1. Introduction
Ethernet communication option module connects the iS7 inverter to the
Ethernet network. It supports 2 kinds of protocol, Modbus/TCP and
EtherNet/IP.
Controlling and monitoring of inverter can be done by PLC sequence program
or any Master Module. Since Ethernet which constitutes Internet has been
used and IPv4 has been supported, wherever Internet can be done, controlling
and monitoring is possible. But, Ethernet network of the factory has to be
connected to Internet through Gateway.
With simple wiring, installation time can be reduced and maintenance
becomes easier.
2. Ethernet Technical Features
3. Product Constituents
This product is consisting of the Ethernet communication module, a screw and
User Manual.
Transmission Speed
100Mbps
Transmission Method
Baseband (Half, Full Duplex)
Max. Extended Distance between
Nodes
100m (Node - Hub)
Max. Node Number
Hub connection
Auto Negotiation
Supported
Max. Frame size
1500 Bytes
Communication Zone Access Method
CSMA/CD
Frame Error Checking Method
CRC32
Recommended Connecting Socket
3 Socket
Recommended Cable
UTP, FTP, STP
(Refer to page 6 for details.)

iS7 Ethernet Option Manual
5
4. The External and Mounting of Ethernet Option Module
(1) The External of Ethernet option module
(2) LED Composition
Green
LED0
Red
LED1
2Color
LED2
2Color
LED3

iS7 Ethernet Option Manual
6
(3) Mounting the communication option module on iS7 inverter
①Remove the cover of the iS7 inverter.
②iS7 communication option After connecting the EtherNET / IP communication
option to the connection part, tighten the screws (2 pieces).
③iS7 inverter and EtherNET / IP communication option have been concluded.
Do not install or remove the EtherNET / IP communication option while the
iS7 inverter is powered on.
Install or remove the EtherNET / IP communication option after the voltage of
the capacitor of the inverter is completely discharged.
Make sure that the inverter main unit and the option connector match exactly.

iS7 Ethernet Option Manual
7
5. Network Connection
Terminal block for communication cable
※Make sure that cables connected to Pin1 and 2 are twisted together.
※Make sure that cables connected to Pin3 and 6 are twisted together.
Pin No.
Signal
Description
Cable Color
1
TX+
Transmitting data plus (+)
White/Yellow
2
TX-
Transmitting data minus (-)
Yellow
3
RX+
Receiving data plus (+)
White/Green
4
NONE
Not used
Blue
5
NONE
Not used
White/Blue
6
RX-
Receiving data minus (-)
Green
7
NONE
Not used
White/Brown
8
NONE
Not used
Brown
1
8
1
2
3
4
5
6
7
8

iS7 Ethernet Option Manual
8
6. Network Cable Standard
(1) Used frequency band
Category 5 is used. The frequency band is up to 100 MHz, Channel
performance is up to 60MHz and Transmission speed is up to 100Mbps.
(2) Cable type of twisted pair cable
Classi-
fication
Details
Purpose of cable
UTP
(U.UTP)
Unshielded Twisted
Pair cable for high-
speed signal
Maximum 200MHz
Voice + Information (Data)+Low video
signal
FTP
(S.UTP)
Foil screened
Twisted Pair cable
Maximum 100MHz
Electromagnetic interruption (EMI) or
electric stability considered Voice +
Information (Data)
+ Low Video signal
STP
(S.STP)
Shielded Twisted
Pair cable
Maximum 500MHz
Voice +Information(Data)+ Video
signal
75Ω coaxial cable replacement

iS7 Ethernet Option Manual
9
7. Ethernet Option and Related Keypad Parameters
The functions below are the inverter parameters which shows the
information related with the Modbus TCP and EtherNet/IP. In the parameter
column, the “M”stands for the parameters used for Modbus TCP, and “E”
stands for the parameters used for EtherNet/IP.
Related keypad parameter with iS7 Ethernet
Code
Number
Parameter Name
Default
Set
value
Description
Pro-
tocol
CNF-30
Option-1 Type
-
-
Indicates name of the
communication card installed in
the inverter (Ethernet).
M/E
COM-06
FBus S/W Ver
-
-
Indicates version of the
communication card installed in
the inverter.
M/E
COM-09
FBus Led
-
-
Shows the ON/OFF data of the
LED on the Ethernet
communication card.
M/E
COM-10
Opt Parameter1
192
0~255
Sets up the IP Address.
M/E
COM-11
Opt Parameter2
168
0~255
COM-12
Opt Parameter3
0
0~255
COM-13
Opt Parameter4
101
0~255
COM-14
Opt Parameter5
255
0~255
Sets up the Subnet Mask.
M/E
COM-15
Opt Parameter6
255
0~255
COM-16
Opt Parameter7
255
0~255
COM-17
Opt Parameter8
0
0~255
COM-18
Opt Parameter9
192
0~255
Sets up the Gateway Address.
M/E
COM-19
Opt Parameter10
168
0~255
COM-20
Opt Parameter11
0
0~255
COM-21
Opt Parameter12
10
0~255
COM-22
Opt Parameter13
0
0
Sets up the Ethernet
communication rate.
M/E
COM-23
Opt Parameter14
1
0~11
CIP Input Instance
E
COM-24
Opt Parameter 15
1
0~11
CIP Output Instance
E

iS7 Ethernet Option Manual
10
Related keypad parameter with iS7 Ethernet
Code
Number
Parameter Name
Default
Set
value
Description
Pro-
tocol
COM-30
ParaStatus Num
-
0~8
Automatically set up according to
the CIP Input Instance.
E
COM-31
Para Status-1
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-32
Para Status-2
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-33
Para Status-3
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-34
Para Status-4
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-35
Para Status-5
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-36
Para Status-6
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-37
Para Status-7
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-38
Para Status-8
-
0x0000
~0xFFFF
Sets up the inverter data address
which will be read by the client.
E
COM-50
Para Ctrl Num
-
0~8
Automatically set up according to
the CIP Output Instance.
E
COM-51
Para Control-1
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E
COM-52
Para Control-2
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E
COM-53
Para Control-3
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E
COM-54
Para Control-4
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E
COM-55
Para Control-5
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E
COM-56
Para Control-6
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E

iS7 Ethernet Option Manual
11
COM-57
Para Control-7
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E
COM-58
Para Control-8
-
0x0000
~0xFFFF
The Client sets up the reference
Inverter Data Address.
E
COM-94
Comm Update
-
-
Updates communication related
keypad parameters.
M/E

iS7 Ethernet Option Manual
12
(1) Option Type (Option card information, CFG-30)
Automatically indicates the type of the communication card presently
installed in the iS7. When the iS7 Ethernet communication card is
installed, “Ethernet”is displayed.
(2) Option Version (Option version information, COM-06)
Automatically indicates the version of the communication card
presently installed in the iS7.
(3) FBus Led (COM-09) –Indication of LED information
Displays the ON/OFF statuses of the 4 LEDs on the communication
card on the keypad parameter COM-09. Looking up the COM-9 FBus
LED with keypad, 4 bits can be seen. In the order of the LED of the
COM-09 (right to left), information is displayed in the said order of CPU,
ERR, LINK2, and LINK1 LED.
If the LED is ON, the bit is 1, and of it is OFF, the bit is 0.
COM-09 LED status example)
(4) Ethernet Option IP Address, Subnet Mask, Gateway Address
(COM-10~21) Setting
The version of IP that Ethernet option supports is v4.
That is, all addresses and masks are represented as decimal, decimal,
decimal, decimal, and each decimal number is between 0 and 255.
Bit
LED Indication
0
1
2
3
CPU LED
ERROR LED
LINK2 LED
LINK1 LED
LINK1 LED
LINK2 LED
ERR LED
CPU LED
OFF
ON
ON
ON

iS7 Ethernet Option Manual
13
(5) Ethernet Speed (COM-22)
Ethernet speed is fixed to 0 without any setting and it is automatically
set to 100Mbps.
(6) CIP Input Instance(COM-23)
This parameter required for EtherNet/IP protocol communication the
format of the inverter state data which are sent by the inverter to the
Client (Originator) during the I/O communication of CIP (Common
Industrial Protocol). See the Assembly Object section of the EtherNet/IP.
Set
Value
Input Instance
Data Size
The number
or Parameter
0
70
4
X
1
71
4
X
2
110
4
X
3
111
4
X
4
141
2
1
5
142
4
2
6
143
6
3
7
144
8
4
8
145
10
5
9
146
12
6
10
147
14
7
11
148
16
8
(7) CIP Output Instance(COM-24)
This parameter required for EtherNet/IP protocol communication the
format of the inverter reference data which are sent by the Client
(Originator) to the inverter for inverter control during the I/O
communication of CIP (Common Industrial Protocol). See the Assembly
Object section of the EtherNet/IP.

iS7 Ethernet Option Manual
14
(8) Para Status (COM-30~38)
This parameter is not used in case of Modbus TCP.
This parameter appears only when the set value of the Input Instance
(COM-17) in the EtherNet/IP is 4 or above.
COM-30 Para Status Num cannot be set up but the number of the set
up parameters of the instance is shown. Enter the address of the
inverter data at the same number as that of the said parameters in the
COM-31~38.
(9) Para Control (COM-50~58)
This parameter is not used in case of Modbus TCP.
This parameter appears only when the set value of the Output Instance
(COM-18) in the EtherNet/IP is 4 or above.
COM-50 Para Ctrl Num cannot be set up but the number of the set up
parameters of the instance is shown. Enter the address of the inverter
data, which will make use of the reference data of the Client (Originator),
at the same number as that of the said parameters in the COM-51~58.
(10) Comm UpDate (COM-94)
At power on, the Option Parameters are expressed by the values set up
in the Option, however, not reflected immediately when set up.
If the Comm Update is set to ‘Yes,’ this value is reflected on the
Modbus/TCP communication card and only this card will be restarted.
Set
Value
Input
Instance
Data
Size
The number
of Parameter
0
20
4
X
1
21
4
X
2
100
4
X
3
101
4
X
4
121
2
1
5
122
4
2
6
123
6
3
7
124
8
4
8
125
10
5
9
126
12
6
10
127
14
7
11
128
16
8

iS7 Ethernet Option Manual
15
8. Inverter Communication Address
See Chapter 11. Communication Function, Inverter IS-7 Manual.
9. Modbus/TCP Frame
(1) Modbus/TCP Frame Composition
Generally, Ethernet uses Ethernet II Frame.
MODBUS Application Protocol Header (MBAP Header)
MBAP Header constitution is presented below.
Protocol Data Unit (PDU)
This is the practical data of the Modbus TCP consists of Function Code
and Data.
Details will be described in the “(2) description on the Function Code”
below.
(2) Function Code Description
Modbus TCP is divided into Client and Server. The Client gives
command and the Server responses to the command. Generally,
Clients can be PLC, HMI, or PC and the Server is the inverter.
MBAP Header( 7 bytes)
PDU (5 bytes ~)
Section
Length
Description
Transaction
Identifier
2 Bytes
Unique transmission number, which is
increased by 1 each time the Client sends
Data Frame to the Server.
Protocol Identifier
2 Bytes
Fixed at 0.
Length
2 Bytes
The Data Frame length of the Modbus,
representing the length (in byte unit) from
the Unit Identifier in the MBAP Header.
Unit Identifier
1 Bytes
When the Modbus TCP and Modbus RTU
are connected via gate, Slave number is
indicated. If Modbus TCP only is used, this
is fixed to 0xFF.

iS7 Ethernet Option Manual
16
①Read Holding Registers
The function used to read the data in the Inverter (Server).
Constitution of the frame requested from Client to Server;
Constitution of the frame sent from Server to Master in response;
②Read Input Registers
The function used to read the data in the Inverter (Server).
Constitution of the frame requested from Client to Server;
Requested Frame
Length
Value
Function code
1 Bytes
0x03
Comm. address
2 Bytes
0x0000 ~ 0xFFFF
The number of
data requested
2 Bytes
1~16
(LSIS Inverter standard)
Response Frame
Length
Value
Function code
1 Bytes
0x03
Comm. address
1 Bytes
2 x The requested
number of data
The number of
data requested
The requested
number of data x 2
Bytes
Value of the data of the
given number from the
communication address
Requested Frame
Length
Value
Function code
1 Bytes
0x04
Comm. address
2 Bytes
0x0000 ~ 0xFFFF
The number of
data requested
2 Bytes
1~16
(LSIS Inverter standard)

iS7 Ethernet Option Manual
17
Constitution of the frame sent from Server to Master in response;
③Write Single Register
The function used to change one of the data in the Inverter (Server).
Constitution of the frame requested from Client to Server;
Constitution of the frame sent from Server to Master in response;
Response Frame
Length
Value
Function code
1 Bytes
0x03
Comm. address
1 Bytes
2 x The requested
number of data
The number of
data requested
The requested
number of data x 2
Bytes
Value of the data of the
given number from the
communication address
Requested Frame
Length
Value
Function code
1 Bytes
0x06
Comm. address
2 Bytes
0x0000 ~ 0xFFFF
Data value
2 Bytes
0x0000 ~ 0xFFFF
Response Frame
Length
Value
Function code
1 Bytes
0x06
Comm. address
2 Bytes
0x0000 ~ 0xFFFF
Data Value
2 Bytes
0x0000 ~ 0xFFFF

iS7 Ethernet Option Manual
18
④Write Multiple Register
The function used to change from 1 to 16 of the Inverter (Server) data
consecutively.
Constitution of the frame requested from Client to Server;
Constitution of the frame sent from Server to Master in response;
Requested Frame
Length
Value
Function code
1bytes
0x10
Comm. address
2bytes
0x0000 ~ 0xFFFF
The number of
data to revise
2byte
1~16
(LSIS Inverter standard)
Byte Count
1byte
2 X The number of data
Data value to
revise
The number
of data
x 2 bytes
Data to revise
Response Frame
Length
Value
Function Code
1 Bytes
0x10
Comm. address
2 Bytes
0x0000 ~ 0xFFFF
The number of
data to revise
2 Bytes
1~16
(LSIS Inverter standard)

iS7 Ethernet Option Manual
19
(3) Except Frame
Except Frame is for the response of the Server in case of an error
occurred in the execution of the frame requested by a Client.
Exception Frame Composition
Exception Code Type
Error Frame
Length
Value
Error Code
1bytes
0x80 + Requested
function code from client
Exception Code
1bytes
0x0000 ~ 0xFFFF
Exception Code Type
Code
Description
ILLEGAL FUNCTION
0x01
When unsupported function is
requested
ILLEGAL DATA
ADDRESS
0x02
Request or modification of the
data in unused address
ILLEGAL DATA VALUE
0x03
When trying to modify data to
a value out of the allowable
range
SLAVE DEVICE
FAILURE
0x04
Server has an error (Error in
CAN communication with
Inverter, error in Option
initialization, failure in data
communication with Inverter)
SLAVE DEVICE BUSY
0x06
Server is unable to respond
because it is executing
another process (Inverter
parameter initializing, initial
setting of Option, etc.)
WRITE PERMITION
ERROR
0x20
When trying to change a
parameter which is prohibited
from changing.
(A unique code of LS
Inverters)
