Lucent Technologies PacketStar PSAX 4500 User manual

Doc. No.: 255-700-156
PacketStar®
PSAX 4500 Multiservice Media
Gateway User Guide
Issue 1, August 2001
System Software Release 7.0

Copyright © 2001 by Lucent Technologies. All rights reserved.
For trademark, regulatory compliance, and related legal information,
see the "Copyright and Legal Notices" section.

255-700-156 iii
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Copyright and Legal Notices
Copyright
Copyright © 2001 by Lucent Technologies. All rights reserved.
This material is protected by the copyright laws of the United States and
other countries. It may not be reproduced, distributed, or altered in any
fashion by any entity (either internal or external to Lucent Technologies),
except in accordance with applicable agreements, contracts or licensing,
without the express written consent of the originating organization and the
business management owner of the material.
This document was prepared by the Information Design and Development
Team of Lucent Technologies, PacketStar®PSAX Products. Offices are located
in Landover, Maryland, USA.
Trademarks
7R/E, APX-8000, CellPipe, ConnectReach, ConnectStar, and STINGER are
trademarks; and PacketStar, AQueView, Lucent Technologies, and the Lucent
Technologies logo are registered trademarks of Lucent Technologies in the
USA. Other product and brand names mentioned in this guide are
trademarks or registered trademarks of their respective owners.
Warranty Information
Software and Hardware Limited Warranties
Lucent Technologies provides a 90-day limited software warranty, and a one-
year limited hardware warranty on this product. Refer to the Software License
and Limited Warranty Agreement and the Lucent Technologies InterNetworking
Systems Global Warranty that accompanied your package for more
information.
Every effort has been made to ensure that this document is complete and
accurate at the time of release, but information is subject to change. Lucent
Technologies assumes no responsibility or liability for errors or inaccuracies
that may appear in this guide.

Copyright and Legal Notices
Warranty Information
iv 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Warranty Warnings
!CAUTION:
Modifying or tampering with PSAX chassis components may void your
warranty. Any modification to this equipment not expressly authorized
by Lucent Technologies may void your granted authority to operate such
equipment.
!CAUTION:
Air vents in the PSAX chassis are provided to aid in ventilation and to
protect from overheating. These vents must be regularly inspected by
the user and cleared of dust and blockage. Equipment failure associated
with improper maintenance or suspected failure to adhere to proper
ventilation procedures as described above will void your warranty.
!CAUTION:
You must replace an air filter having an accumulation of dust to ensure
adequate airflow through the PSAX chassis. Reduced airflow could result
in damaging heat buildup within the chassis.
• Periodically inspect the air filter for accumulated dust and replace the
filter as needed. At a minimum, quarterly inspection is recommended.
Equipment failure due to inadequate airflow voids your equipment
warranty.
• Use only filters supplied by Lucent Technologies in your PSAX chassis.
Use of other filters voids your equipment warranty.
!CAUTION:
When inserting modules into the chassis, slide them gently, not
forcefully. Excessive force may cause the modules to be seated
improperly in the chassis, and result in possible damage to the module or
the chassis. Install or remove modules one at a time. Doing this aids in
preventing the PSAX 4500 system from indicating any erroneous failure
messages, and allows the PSAX 4500 system to reinitialize and display
the accurate configuration of the module that is inserted.
!CAUTION:
Shipping the chassis with removable modules installed may cause
damage to the chassis and the modules. Damage to any of the
components in the system resulting from shipping the chassis with
removable modules installed could void your warranty. Only Lucent-
authorized personnel should ship the PSAX 4500 chassis with a module
installed.

255-700-156 v
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Copyright and Legal Notices
Regulatory Standards Compliance
!CAUTION:
You must maintain a minimum 10.16 cm (4 in.) of clearance around the
chassis for adequate airflow. Failure to adhere to this space requirement
may result in equipment failure due to overheating. Failure to provide a
minimum of 10.16 cm (4 in.) of clearance between this unit and any other
device/structure will void your warranty.
Regulatory Standards Compliance
The PacketStar®PSAX 4500 Multiservice Media Gateway, model 45S00, is
compliant with the listed safety, electromagnetic compatibility (EMC) and
telecommunications standards. Applicable statements are provided in the
next subsection.
Safety
The PacketStar®PSAX 4500 Multiservice Media Gateway, model 45S00, is
compliant with the following safety standards.
•UL 1950, Third Edition Product Safety (USA)
•CSA 22.2 No. 06950-00 Product Safety (Canada)
•EN 60950:1992+A1:1993+A2:1993+A3:1995+A4:1997 +A11:1997
(Europe)
•NOM (Mexico)
•CB-Scheme – IEC 60950:1991+A1:1992+A2:1993+A3:1995+A4:1996
(International)
Electromagnetic Compatibility
The PacketStar®PSAX 4500 Multiservice Media Gateway, model 45S00, is
compliant with the following electromagnetic compatibility (EMC) standards.
•FCC Part 15 Class A (USA)
•ICES-003, Issue 3:1998 Class A (Canada)
•EN 55022:1998 Class A (Europe)
•EN55024:1998 (Europe)
•EN 300 386-2:1997 Class A (Europe)
•VCCI Class A (Japan)
•CISPR 22:1997 Class A (International)
•CISPR 24:1997 (International)

Copyright and Legal Notices
Regulatory Statements
vi 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Telecommunications
The PacketStar®PSAX 4500 Multiservice Media Gateway, model 45S00, is
compliant with the following telecommunications standards.
•FCC Part 68 (USA)
•CS-03 Issue 8 (Canada)
•ETSI TBR 12:1993+A1:1996 (Europe)
•ETSI TBR 13:1996 (Europe)
•ETSI TBR 24:1997 (Europe)
•JATE (Japan)
Regulatory Statements
USA Regulatory Statements
FCC Part 15 This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy, and, if not installed
and used in accordance with this guide, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference; in this case, you would be required to
correct the interference at your own expense.
All cables used to connect to peripherals must be shielded and grounded.
Operation with cables, connected to peripherals, that are not shielded and
grounded may result in interference to radio and television reception.
The user is cautioned that any changes or modifications not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Part 68 This equipment complies with Part 68 of the FCC rules. On the back of the
PSAX chassis is a label that contains the FCC registration number, in addition
to other information. You must provide this information to the telephone
company, if they request it. The FCC requires Lucent Technologies to
provide you with the following information:
1. This equipment has digital service interface capabilities using RJ-48C
and RJ-48H connectors. The facility interface codes with which this
equipment complies for digital services are as follows: 04DU9-BN,
04DU9-DN, 04DU9-1KN, and 04DU9-1SN. This equipment has loop
start interface capabilities using an RJ-11C connector. The facility

255-700-156 vii
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Copyright and Legal Notices
Regulatory Statements
interface code with which this equipment complies for service is 02LS2.
The service order codes for this equipment are 6.0F for the T-1 interface
and 9.0Y for the loop start interface.
2. An FCC-compliant telephone network interface jack is built into this
equipment and is compatible with interconnections that are Part 68
compliant.
3. The REN for the Voice 2-Wire Office module when used in this
equipment is 0.7B.
4. If this equipment causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of
service might be required. But if advance notice is not practical, the
telephone company will notify you as soon as possible. Also, you will be
advised of your right to file a complaint with the FCC if you believe this
is necessary.
5. The telephone company might make changes in its facilities, equipment,
operations, or procedures that could affect the operation of this
equipment. If this happens, the telephone company will provide
advance notice for you to make necessary modifications to maintain
uninterrupted service.
6. If you experience trouble with this equipment, or need repairs or
warranty information, please refer to the Lucent Technologies
InterNetworking Systems Global Warranty that accompanied your PSAX
product shipment for instructions on obtaining technical support in your
area.
If this equipment is causing harm to the telephone network, the
telephone company might request that you disconnect the equipment
until the problem is resolved.
7. This equipment has no user-serviceable parts.
This equipment cannot be used on public coin telephone service provided by
the telephone company. Connection to party line service is subject to state
tariffs. Contact your state public utility commission, public service
commission, or corporation commission for information.
UL 1950 This product is UL Listed only when supplied with the following assemblies:
•PSAX 4500 Chassis Assembly, model 45S00
•-48 V dc Power Supply module, model 23N11 (two required)
•Stratum 3–4 modules, model 45N05 (two required)
•Up to two CPU modules, consisting of the following;
~CPU/CPU2 module, model 20N20
~CPU/CPU2 module, model 20Pnn (where nn may be 19–26)

Copyright and Legal Notices
Regulatory Statements
viii 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
•Up to fifteen I/O, server, or blank faceplate modules consisting of the
following:
~1-Port Channelized DS3 CES module, model 23N61
~1-Port Channelized DS3 Multiservice module, model 23N60
~1-Port Channelized STS-1e T1 module, model 23N62
~1-Port DS3 Frame Relay module, model 20N03
~1-Port DS3 IMA module, model 23N68
~1-Port OC-12c/STM-4c 1+1 APS/MSP Multimode module, model
23N72
~1-Port OC-12c/STM-4c 1+1 APS/MSP Single-Mode module, model
23N73
~1-Port OC-3c 1+1 APS Multimode module with AQueMan, model
20N72
~1-Port OC-3c 1+1 APS Single-Mode module with AQueMan, model
20N73
~1-Port OC-3c Multimode module with AQueMan, model 20N12
~1-Port OC-3c Multimode module with Traffic Shaping, model 20N14
~1-Port OC-3c Single-Mode module with AQueMan, model 20N13
~1-Port OC-3c Single-Mode module with Traffic Shaping, model 20N15
~1-Port STM-1 1+1 MSP Multimode module, model 20N92
~1-Port STM-1 1+1 MSP Single-Mode module, model 20N93
~1-Port STM-1 Multimode module with AQueMan, model 20N62
~1-Port STM-1 Multimode module with Traffic Shaping, model 20N64
~1-Port STM-1 Single-Mode module with AQueMan, model 20N63
~1-Port STM-1 Single-Mode module with Traffic Shaping, model 20N65
~2-Port DS3 ATM module, model 20N02
~2-Port E3 ATM module, model 20N22
~3-Port Channelized DS3/STS-1e CES module, model 23N03
~3-Port Unstructured DS3/E3 CES module, model 23N02
~4-Port Quadserial module, model 23N07
~4-Port Voice 2-Wire Office module, model 20N32
~5-Port Ethernet module, model 20N40
~6-Port DS1 IMA module, model 20N33
~6-Port E1 IMA module, model 20N34
~6-Port Enhanced DS1 module, model 20N36
~6-Port Enhanced E1 module, model 20N56
~6-Port Multiserial module, model 20N07
~8-Port Voice 2-Wire Station module, model 20N30
~12-Port Medium-Density DS1, model 23N64
~21-Port High-Density E1 module, model 23N66

255-700-156 ix
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Copyright and Legal Notices
Regulatory Statements
Canadian Regulatory Statements
ICES-003 This Class A digital apparatus complies with Canadian ICES-003.
NMB-003 Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
CS-03 Issue 8 The Industry Canada label identifies certified equipment. This certification
means that the equipment meets certain telecommunications network
protective, operational, and safety requirements. The Department does not
guarantee that the equipment will operate to the user’s satisfaction.
Before installing this equipment, the user should ensure that it is permissible
to be connected to the facilities of the local telecommunications company.
The equipment must also be installed by using an acceptable method of
connection. In some cases, the company’s inside wiring associated with a
single-line individual service may be extended by means of a certified
connector assembly (telephone extension cord). The customer should be
aware that compliance with the above condition may not prevent
degradation of service in some situations.
Repairs to some certified equipment should be made by an authorized
maintenance facility designated by the supplier. Any repairs or alterations
made by the user to this equipment or equipment malfunctions might give
the telecommunications company cause to request the user to disconnect the
equipment.
For their own protection, usersshould ensure that the ground connections of
the power utility, telephone lines, and internal metallic water pipe system are
connected together. This precaution may be particularly important in rural
areas.
!CAUTION:
Users should not attempt to make such connections themselves, but
should contact the appropriate electric inspection authority or
electrician.
~Alarm module, model 20N79
~DSP2 Voice Server module, model 20N27
~DSP2A Voice Server module, model 20N29
~DSP2B Voice Server module, model 20N28
~DSP2C Voice Server module, model 23N27
~DSP2D Voice Server module, model 23N29
~PSAX 1250/2300 I/O or CPU Blank Faceplate, model 20N87
~Route Server module, model 20N41
~Tones and Announcements Server module, model 23N28

Copyright and Legal Notices
Regulatory Statements
x255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
The Ringer Equivalence Number (REN) assigned to the Voice 2-Wire Office
module denotes the percentage of the total load to be connected to a
telephone loop, which is used by the device, to prevent overloading. The
termination on a loop may consist of any combination of devices subject only
to the requirement that the total of the REN of all devices does not exceed 5.
The REN for the Voice 2-Wire Office module when used in the PSAX system
is 0.7B.
SH-03 Version 8 Le label Industrie Canada permet de reconnaître les équipements
homologués. Cette homologation indique que l’équipement satisfait
certaines règles de protection, d’exploitation et de sécurité des réseaux de
télécommunications. Le ministère de l’Industrie ne garantit pas que
l’équipement fonctionnera à la satisfaction de l’utilisateur.
Avant d’installer cet équipement, l’utilisateur doit s’assurer qu’il est permis
de le connecter aux installations de la compagnie de télécommunications
locale. L’équipement doit également être connecté suivant une méthode
convenable. Dans certains cas, il sera nécessaire de prolonger le câblage
intérieur de la ligne d’abonné de la compagnie au moyen d’un connecteur
homologué (rallonge de téléphone). L’abonné doit savoir que, dans certaines
situations, la conformité aux dispositions ci-dessus ne prévient pas
nécessairement la dégradation du service.
La réparation de certains équipements homologués doit être assurée par un
atelier agréé désigné par le fournisseur. Toute réparation ou altération
effectuée par l’utilisateur ou tout mauvais fonctionnement de cet
équipement peut donner à la compagnie de téléphone des raisons de
demander audit utilisateur de déconnecter celui-ci.
Pour leur propre sécurité, les utilisateurs doivent veiller à ce que les mises à
la terre de l’alimentation secteur, des lignes téléphoniques et du système
intérieur de conduites d’eau métalliques soient raccordés ensemble. Cette
précaution peut s’avérer particulièrement importante dans les zones rurales.
!CAUTION:
Les utilisateurs ne doivent pas tenter d’effectuer eux-mêmes ces
raccordements, mais doivent prendre contact avec un électricien ou
organisme de vérification compétent.
Le nombre équivalent de sonnerie (REN) attribué au module central bifilaire
(Voice 2-Wire Office) correspond au pourcentage de la charge totale à
connecter à un circuit téléphonique bifilaire; il est utilisé par l’appareil pour
prévenir la surcharge. Le circuit peut être terminé par n’importe quelle
combinaison d’appareils, à la seule condition que le total des REN de ces
derniers ne dépasse pas cinq.
Lorsqu’il est utilisé dans le système PSAX, le module central bifilaire possède
un REN de 0,7 B.

255-700-156 xi
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Copyright and Legal Notices
Regulatory Statements
European Union Regulatory Statement
CE-Marking Hereby, Lucent Technologies declares that the PacketStar®PSAX 1250
(-48 V dc), PSAX 2300, PSAX 4500, and PSAX AC 60 (-48 V dc) Multiservice
Media Gateways are in compliance with the essential requirements and other
relevant provisions of the following Council Directives:
•Low Voltage 72/23/EEC
•Electromagnetic Compatibility (EMC) 89/336/EEC
•Radio Equipment and Telecommunications Terminal Equipment
1999/5/EC
The Lucent PacketStar®PSAX Multiservice Media Gateways deployed in the
European Economic Area (EEA) are intended for connection to E1, E3,
STM-1, and STM-4c networks. The EC Declarations of Conformity may be
viewed or printed at the following public-access Internet site:
http://www.lucent.com/ins/doclibrary
EU-regulativer
CE-mærkning Lucent Technologies erklærer hermed at PacketStar®PSAX 1250 (-48 V dc),
PSAX 2300, PSAX 4500, and PSAX AC 60 (-48 V dc) Multiservice Media
Gateways overholder kravene i følgende EU-direktiver:
•Lavspændingsdirektivet 72/23/EEC
•EMC-direktivet 89/336/EEC
•Direktivet om radio og teleterminaludstyr 1999/5/EC
Lucent PacketStar®PSAX Multiservice Media Gateways, anvendt i EØS
(Europæiske Økonomiske Samarbejde) skal forbindes med E1, E3 STM-1 og
STM-4c netværk. EU-overensstemmelseserklæringen er at finde på følgende
internetside hvorfra den også kan udskrives:
http://www.lucent.com/ins/doclibrary
Behördliche Standard-CE-Kennzeichnung für die Europäische Gemeinschaft
Hiermit erklärt Lucent Technologies, dass die PacketStar®PSAX 1250 (-48
V DC), PSAX 2300, PSAX 4500 und PSAX AC 60 (-48 V DC) Multiservice
Media Gateways die notwendigen Anforderungen und anderen relevanten
Vorschriften der folgenden Council-Direktiven einhalten:
•Niederspannungsdirektive 72/23/EEC
•Elektromagnetische Verträglichkeit (EMC) 89/336/EEC
•Funkgeräte und Funkverkehr-Endeinrichtungen 1999/5/EC
Die Lucent PacketStar®PSAX Multiservice Media Gateways, die in der
Europäischen Gemeinschaft im Einsatz stehen, dienen zum Anschluss an
folgende Netztypen: E1, E3, STM-1 und STM-4c. Die Konformitätserklärung

Copyright and Legal Notices
Regulatory Statements
xii 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
für die Europäische Gemeinschaft kann auf folgendem, öffentlich
zugänglichem Internet-Site eingesehen oder ausgedruckt werden:
http://www.lucent.com/ins/doclibrary
¥²³²·¸¯¢ q¶¢¸½´³ ¸¬» }½¶º´¥¿¯» ²º·¬»
tµ¥²·¬ CE © ¸³ ´¥¶¢², ¬ Lucent Technologies, ¨¬°µ²© ¢¸ ¸¥ PacketStar® PSAX1250
(-48Vdc), PSAX2300, PSAX4500, ¯¥ PSAXAC60 (-48Vdc) Multiservice Media
Gateways ©²¥¶±³²¡¾³²¸¥ ±© ¸» ¦¥·¯» ¥´¥¸·©» ¯¥ °³´» ·¼©¸¯»
¨¥¸®©» ¸º² ¨¬«µ² ¸³½ t½±¦³½°¡³½
•¥±¬° ¸·¬ 72/23/EOK
•H°©¯¸¶³±¥«²¬¸¯ ·½±¦¥¸¢¸¬¸¥ (EMC) 89/336/EOK)
•¥¨³ªº²¯¢» ©®³´°·±¢» ¯¥ }®³´°·±¢» ¸©¶±¥¸¯³¤ ¸¬°©´¯³²º²µ²
999/5/EK
¥ Lucent PacketStar® PSAX Multiservice Media Gateways, ´³½ ¼³½²
¸³´³¹©¸¬¹©¡ ·¸³² }½¶º´¥¿¯¢ ¯³²³±¯¢ µ¶³ (}}y) ´¶³³¶¡¾³²¸¥ «¥
·¤²¨©·¬ ±© ¸¥ ¨¡¯¸½¥ E, E3, STM, ¯¥ STM-4c.  m¬°µ·©» }²¥¶±¢²·¬»
¸¬» } ±´³¶³¤² ²¥ ´¶³¦°¬¹³¤²  ²¥ ¸½´º¹³¤² ¥´¢ ¸¬² ´¥¶¥¯¸º ´¶³·¸
·¸³ ¯³²¢ ¸³´³¹©·¡¥ ¸³½ ²¸©¶²©¸
http://www.lucent.com/ins/doclibrary
Euroopan unionin sääntelystandardi
CE-merkki Lucent Technologies vakuuttaa täten, että PacketStar®PSAX 1250 (-48 V dc),
PSAX 2300, PSAX 4500 ja PSAX AC 60 (-48 V dc) Multiservice Media
Gatewayt täyttävät seuraavien neuvoston direktiivien keskeiset vaatimukset
ja asiaankuuluvat määräykset:
•Pienjännite 72/23/EY
•Sähkömagneettinen yhteensopivuus (EMC) 89/336/EY
•Radiolaitteet ja telepäätelaitteet 1999/5/EY
Lucent PacketStar®PSAX Multiservice Media Gatewayt, joita käytetään
Euroopan talousalueella, on tarkoitettu liitettäväksi E1-, E3-, STM-1- ja
STM-4c-verkkoihin. EU:n vaatimustenmukaisuusvakuutus voidaan nähdä
tai tulostaa seuraavalta julkiselta Internet-sivulta:
http://www.lucent.com/ins/doclibrary
Norme réglementaire de l’Union européenne
Label CE Lucent Technologies déclare en ceci que les passerelles de média
multiservices PacketStar®PSAX 1250 (-48 V c.c.), PSAX 2300, PSAX 4500 et

255-700-156 xiii
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Copyright and Legal Notices
Regulatory Statements
PSAX AC 60 (-48 V c.c.) sont conformes aux exigences essentielles et autres
dispositions pertinentes des directives suivantes du Conseil :
•Basse tension 72/23/CEE
•Compatibilité électromagnétique (CEM) 89/336/CEE
•Matériel radio et terminaux de télécommunications 1999/5/CE
Les passerelles de média multiservices PacketStar®PSAX de Lucent,
commercialisées dans l’Espace économique européen sont destinées aux
connexions à des réseaux E1, E3, STM-1 et STM-4c. Les déclarations de
conformité CE peuvent être consultées ou imprimées à partir du site Internet
d’accès public :
http://www.lucent.com/ins/doclibrary
Normativa dell’Unione Europea
Apposizione del
marchio CE La Lucent Technologies dichiara che i gateway multiservizio PacketStar®
PSAX 1250 (-48 V dc), PSAX 2300, PSAX 4500 e PSAX AC 60 (-48 V dc),
rispondono ai requisiti essenziali ed ad altre norme rilevanti delle seguenti
direttive del Consiglio:
•Direttiva 72/23/CEE “Basse tensioni”
•Direttiva 89/336/CEE sulla compatibilità elettromagnetica
•Direttiva 1999/5/CE riguardante le apparecchiature radio e le
apparecchiature terminali di telecomunicazione
I gateway multiservizio Lucent PacketStar®PSAX impiegati nell’area
economica europea (EEA), sono concepiti per il collegamento con reti E1, E3,
STM-1 e STM-4c. Le dichiarazioni di conformità CE possono essere stampate
o visionate presso il seguente sito Internet di pubblico accesso:
http://www.lucent.com/ins/doclibrary
Norm van de Europese Unie
CE-markering Lucent Technologies verklaart hierbij dat de PacketStar®PSAX 1250
(-48 V dc), PSAX 2300, PSAX 4500, en PSAX AC 60 (-48 V dc) Multi Service
Media Gateways voldoen aan de essentiële vereisten en andere relevante
bepalingen van de volgende Richtlijnen van de Raad:
•Laagspanning 72/23/EEG
•Elektromagnetische compatibiliteit (EMC) 89/336/EEG
•Radioapparatuur en telecommunicatie-eindapparatuur 1999/5/EG
De Lucent PacketStar®PSAX Multi Service Media Gateways die in de
Europese Economische Ruimte (EER) zijn ingezet, zijn bestemd voor
aansluiting op E1, E3, STM-1 en STM-4c netwerken. DE EU-verklaringen

Copyright and Legal Notices
Regulatory Statements
xiv 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
van overeenstemming kunnen worden bekeken of afgedrukt op de volgende
Internet-site met openbare toegang:
http://www.lucent.com/ins/doclibrary
Padrão Regulador da União Europeia
CE-Marcação /
Características A Lucent Technologies vem por este meio declarar que os Concentradores de
Acesso PacketStar®PSAX 1250 (-48 V dc), PSAX 2300, PSAX 4500 e
PSAX AC 60 (-48 V dc) obedecem aos requisitos essenciais e a outras
disposições relevantes das seguintes Directivas do Conselho:
•Baixa Voltagem 72/23/EEC
•Compatibilidade Electromagnética (EMC) 89/336/EEC
•Equipamento de Rádio e Equipamento Terminal de Telecomunicações
1999/5/EC
Os Concentradores de Acesso PacketStar®PSAX da Lucent instalados na Área
Económica Europeia (EEA) foram concebidos para serem ligados a redes do
tipo E1, E3, STM-1 e STM-4c. As Declarações de Conformidade CE podem
ser vistas ou impressas no seguinte sítio de acesso público da Internet:
http://www.lucent.com/ins/doclibrary
Norma reguladora de la Unión Europea
Marcas de la CE Por el presente, Lucent Technologies declara que las pasarelas de medios
multiservicio PacketStar®PSAX 1250 (-48 V cc), PSAX 2300, PSAX 4500 y
PSAX AC 60 (-48 V cc) Multiservice Media Gateways están en conformidad
con los requisitos esenciales y otrasdisposiciones pertinentes de las siguientes
directrices del consejo:
•Bajo voltaje 72/23/EEC
•Compatibilidad electromagnética (EMC) 89/336/EEC
•Equipo de radio y equipo de terminales de telecomunicaciones
1999/5/EC
Las pasarelas de medios multiservicio Lucent PacketStar®PSAX Multiservice
Media Gateways desplegadas en el área económica europea (European
Economic Area, EEA) están destinadas a conectarse en redes E1, E3, STM-1 y
STM-4c. Las declaraciones de conformidad de la CE pueden verse o
imprimirse en el siguiente sitio Internet de acceso público:
http://www.lucent.com/ins/doclibrary
Europeiska unionens standardförordning
CE-märkning Lucent Technologies deklarerar härmed att PacketStar®PSAX 1250
(-48 V likström), PSAX 2300, PSAX 4500, och PSAX AC 60 (-48 V likström)

255-700-156 xv
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Copyright and Legal Notices
Regulatory Statements
Multiservice Media Gateways uppfyller de väsentliga kraven och andra
relevanta bestämmelser som gäller enligt följande Europarådsdirektiv:
•Lågspänning 72/23/EEC
•Elektromagnetisk kompatibilitet (EMC) 89/336/EEC
•Radioutrustning och telekommunikationskopplingsutrustning 1999/5/EC
Lucent PacketStar®PSAX Multiservice Media Gateways, som är placerad i
EEA (European Economic Area), är avsedd för att anslutas till E1, E3, STM-1
och STM-4c nätverk. Europarådets Konformitetsdeklarationer kan ses på
bildskärm eller skrivas ut på följande, för allmänheten tillgängliga Internet-
ställe:
http://www.lucent.com/ins/doclibrary
EN 300 386-2 This equipment is a Class A digital device, intended for installation only
within telecommunication centers.
Japanese Regulatory Statements
VCCI This is a Class A product based on the standard of the Voluntary Control
Council for Interference by Information Technology Equipment (VCCI). If
this equipment is used in a domestic environment, radio disturbance may
occur, in which case, the user may be required to take corrective actions.
JATE This equipment complies with the Japan Approvals Institute for
Telecommunication Equipment (JATE) requirements when used in
conjunction with the I/O modules listed in the following table.
Table 1. JATE Approved Modules
Module
Model Num-
ber Module Description
Jate
Approval
Number
20N33 6-Port DS1 IMA (IMA DS1) D00-0807
20N36 6-Port Enhanced DS1/T1 Multiservice (DS1/T1
ENH) D00-0807

Copyright and Legal Notices
Regulatory Statements
xvi 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Class A Electromagnetic Compatibility (EMC) Regulatory Statement
CISPR 22, EN 55022,
AS/NZS-3548 This is a Class A product. In a domestic environment, this product may cause
radio interference, in which case the user may be required to take adequate
measures.
20N62 1-Port STM-1 Multimode with AQueMan
(STM-1 (MM AQ))L00-0198
20N63 1-Port STM-1 Single-Mode with AQueMan
(STM-1 (SM AQ))L00-0198
20N64 1-Port STM-1 Multimode with Traffic Shaping
(STM-1 (MM TS))L00-0198
20N65 1-Port STM-1 Single-Mode with Traffic Shaping
(STM-1 (SM TS))L00-0198
20N92 1-Port STM-1 1+1 MSP Multimode (STM-1 MM
MSP)L00-0230
20N93 1-Port STM-1 1+1 MSP Single-Mode (STM-1 SM
MSP)L00-0230
Table 1. JATE Approved Modules
Module
Model Num-
ber Module Description
Jate
Approval
Number

255-700-156 xvii
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Safety Information
Overview of This Section
When installing and operating the PSAX 4500 Multiservice Media Gateway,
follow the safety guidelines provided below to help prevent serious personal
injury and damage to the PSAX 4500 equipment. Please read all warnings
and instructions supplied before beginning installation or configuration of
the PSAX 4500 equipment. In addition to the general safety information
provided below, you should also refer to the text in the user and installation
guides for other important safety information and procedures.
Warnings
!
DANGER:
Read all installation instructions before connecting the system to a
power source.
!
DANGER:
Never push and/or place an object in or through any vent in the
PSAX 4500 chassis. Doing so may result in personal injury, equipment
damage, or both. Touching exposed electrical components may cause
injury.
!
DANGER:
Install only equipment identified in the installation guide for the
PSAX 4500 system. Using other equipment may result in improper
connection of circuitry, which may lead to equipment fire, personal
injury, or equipment damage.
!
DANGER:
Do not install or use the PSAX 4500 unit in wet locations. In the event
the unit becomes wet, turn it off, disconnect it from the facility power
source, and contact your NetworkCare Service Center. (See the Lucent
Technologies InterNetworking Systems Global Warranty that
accompanied your shipment for the appropriate telephone number.)
!
DANGER:
Ensure that the voltage and frequency of the facility power source match
the requirements of the PSAX 4500 Power Supply component. The

Safety Information
xviii 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
PSAX 4500 system should be operated only from the power source type
indicated on the marking label.
!
DANGER:
Shock hazard! This equipment does not contain any user serviceable
parts. Maintenance is to be performed only by qualified service
personnel.
!
DANGER:
The OC-3c, STM-1, and OC-12c/STM-4c single-mode modules contain a
Class-1 laser-generating device. Unterminated optical connectors may
emit laser radiation. Do not view with optical instruments.
!
DANGER:
Interface lines connected to the Voice 2-Wire Office module (model
number 20N32) that exit the building premises must be connected to any
nationally recognized testing laboratory (NRTL)-listed
telecommunications protection device that provides primary and
secondary protection. These protection devices provide overvoltage
protection to the Voice 2-Wire Office module interface lines.
!
DANGER:
A readily accessible disconnect device must be provided in the fixed
wiring for a direct-current Power Supply. It must be suitable for the rated
voltage and current specified in the PSAX 4500 installation guide.
!
DANGER:
When installing the unit, the ground connection must always be
connected first. When uninstalling the unit, the ground connection must
always be disconnected last.
!
DANGER:
This equipment is to be properly grounded prior to operation. Ensure the
PSAX 4500 chassis is properly grounded during normal use.
WARNING:
!
Be sure to use the ejector handles during installation and removal of I/O
and server modules.
WARNING:
!
Electrostatic discharge (ESD) can damage module and chassis
components. All personnel should be grounded and follow proper ESD

255-700-156 xix
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Safety Information
procedures before installing, removing, or handling hardware
components.
WARNING:
!
Interface lines connected to the Voice 2-Wire Station module must be
connected only to telephone sets. Do not connect these station port
interface lines to Public Switched Telephone Network (PSTN) type
interfaces.
!CAUTION:
Ultimate disposal of this product should be handled according to all laws
and regulations in your specific geographic region.
!CAUTION:
Do not make electrical or mechanical modifications to any of the
components in the PSAX system. Lucent Technologies is not responsible
for the safety or the performance of a modified Lucent product. Do not
attempt to repair any failed Power Supply module, Stratum 3–4 module,
CPU module, I/O, or server module.
!CAUTION:
When inserting modules into the chassis, slide them gently, not
forcefully. Excessive force may cause the modules to be seated
improperly in the chassis, and result in possible damage to the module or
the chassis. Install or remove modules one at a time. Doing this aids in
preventing the PSAX 4500 system from indicating any erroneous failure
messages, and allows the PSAX 4500 system to reinitialize and display
the accurate configuration of the module that is inserted.
Electrostatic Discharge (ESD) Precautions
The room in which the PSAX 4500 system will be located must have built-in
precautions to provide protection from ESD damage to electronic
components. To protect your PSAX 4500 system, observe the precautions
provided in this section.
Grounding Wrist Straps
Using a grounding wrist strap (see Figure 0-2) is recommended when
installing and operating the PSAX 4500 system. A wrist strap grounding
point is provided on the upper left corner of the PSAX 4500 chassis front
panel.

Safety Information
xx 255-700-156
PacketStar®PSAX 4500 Multiservice Media Gateway User Guide,Issue1 Release7.0
Follow these guidelines for grounding wrist straps:
•Attach at least one wrist strap to a common ground for each
unit/electronic rack to be handled.
•Wrist straps or wrist strap cords should have built-in 1 megohm
(minimum) resistors for operator protection.
•Wrist straps and wrist strap cords should be UL listed.
•Ensure that the cord for the wrist strap is long enough so that you can
wear it while working at the cabinet front or back.
Place the wrist strap so you can touch it first and discharge through it instead
of discharging on the cabinet.
Floor Covering
Be sure that the room has antistatic flooring (conductive mat, carpeting, or
tiles) to minimize static buildup as you walk across the room. Follow these
guidelines for installing and maintaining proper flooring:
•The use of grounding foot straps is recommended while walking in rooms
providing antistatic flooring. Foot straps provide additional protection
against electrostatic discharge. Foot straps should have built-in 1 mega
ohm (minimum) resistors for your protection.
•Wool carpeting is not an acceptable flooring.
Other types of carpeting (when used) require daily spraying with a topical
antistatic chemical before any work in the system room is performed. This
constant attention to carpeting maintenance is acceptable, but time-
consuming.
Humidity
Maintaining the proper humidity in the room where the PSAX 4500 system
will be located helps control many static problems. This is especially
Figure 0-2. Grounding Wrist Strap
