Boost fiber capacity using low-cost passive DWDM.
Readily integrates with existing environments
and is easy to maintain.
Benefits
• Delivers client signals cost-effectively
• Provides flexibility to support a wide range of applications
• Offers energy, space and operational savings
• Increases efficiency with scalable and flexible options
• Simplifies compatibility with bit-transparency
• Supports precise billing to match bandwidth changes
• Offers reliablity and affordability
Metropolis®Wavelength
Extension Solution

Delivers client signals cost-effectively
The Metropolis®Wavelength Extension Solution is an
innovative portfolio of products that helps you cost-
effectively meet increased demand and relieve fiber
exhaustion in metro access and metro core optical
networks. Plug and play setup with these seamless,
self-configuring products can help you provide service
to customers quickly and easily. They take advantage
of passive DWDM technology and are easy to deploy –
without the need for complex software downloads,
database backups, or provisioning. Together, they
provide transparent transport of signals including:
FICON, ESCON, Fibre Channel, Video, Gigabit
Ethernet (GbE), 155Mbps, 622Mbps, 2.5G, 10G, and
10G Ethernet on an ITU-T grid-compliant line.
Provides flexibility to support a
wide range of applications
The Metropolis®Wavelength Extension Solution
consists of:
• Metropolis®Multi-Wavelength Optical Amplifier (OA)
• Metropolis®Multi-Rate Transponder
• Metropolis®Passive OADM System
• Metropolis®Passive WDM System
These products can be configured to suit your specific
applications requirements. They help provide
operational efficiency and lower maintenance costs.
For example, the Metropolis®Multi-Rate Transponder
can be provisioned remotely from one data rate to
another using network management software. Your
customer receives a dedicated lambda that can be
provisioned to their bit rate without the need to
change any hardware or software.
The Metropolis®Passive WDM System can condense
up to 32 wavelengths onto a single fiber, offering an
excellent cost-effective answer for fiber exhaust in
your metro and access network. The Metropolis®
Passive OADM System helps provide optical add/drop
capability to your metro access network, and the
Metropolis®Multi-Wavelength OA can extend these
multi-wavelength spans up to 130km. This
combination of products offers a low-cost solution that
can save floor space, increase operational efficiency,
add network reliability and reduce maintenance costs.
Offers energy, space and
operational savings
For metro access, you need a solution that is highly
reliable and flexible – at a price that is cost-
competitive. This includes ongoing operations costs in
addition to your initial investment.
The Metropolis®Wavelength Extension Solution helps
you use energy and floor space more efficiently. A
single Metropolis®Multi-Rate Transponder can hold
12 transponders per shelf, and each one can support a
wide array of data/optical interfaces. Because a single
transponder can support multiple interfaces, it can
help reduce your spare parts inventory. The
Metropolis®Wavelength Extension Solution
components using passive technology help reduce
costs by simplifying operations and reducing energy.
Increases efficiency with scalable
and flexible options
The Metropolis®Wavelength Extension Solution
can be configured to suit many different applications
in the mobility, enterprise, access, and metro space.
This solution presents you with flexibility to select a
suitable configuration for your applications – allowing
you to turn up service and grow your system
according to ever-changing customer needs. Highly
scalable, it also offers:
• 8- or 16-channel unidirectional/bidirectional passive
DWDM systems
• 32-channel unidirectional passive DWDM systems
• One-, two- or four-channel OADM units
• Stand-alone multi-wavelength or single-wavelength
optical amplifiers
• Stand-alone transponders
The Metropolis®Wavelength Extension Solution is
designed with your network evolution in mind. Lucent
passive DWDM, OADM, and OAs support 2.5G and
10G, which are predominant in metro networks today.
2

Simplifies compatibility with
bit-transparency
This solution offers bit-transparent lambdas at a
fraction of metro-managed DWDM systems costs. The
ITU-T grid-compatible lambdas for DWDM and OADM
systems, and the SONET/DWDM standards-compliant
features, facilitates the ability of these products to
interwork with a variety of vendor’s equipment.
Supports precise billing to
match bandwidth changes
The Metropolis®Wavelength Extension Solution
allows you to alter bandwidth easily. You can remotely
change a customer’s bandwidth while in-service when
the provided bandwidth is exceeded, or at your
customer’s request. The network management system
tracks these changes so you can bill customers based
on their exact bandwidth usage.
Offers reliablity and affordability
This portfolio of products is field-proven – with
systems installed in a variety of configurations around
the world. The Metropolis®Wavelength Extension
Solution has demonstrated its high level of reliability.
Use this portfolio of innovative, modular products to
help you cost-effectively address metro access, fiber
exhaustion, and span extension applications in your
optical metro and metro core networks, and to
efficiently turn up services and grow your network as
your needs change.
Backbone Core
Central Office Hub Office
Enterprise Office
Enterprise Office
Enterprise Office
Metro Core Access
LambdaUnite®MultiService Switch (MSS)
Metropolis®DMX portfolio, Metropolis®ADM
MultiService Mux, WaveStar®ADM 16/1,
WaveStar®TDM 2.5G/10G
Metropolis®Multi-Rate Transponder
Metropolis®Passive OADM System
Metropolis®Multi-Wavelength OA
Optical regenerator
Metropolis®Passive DWM System
The Metropolis®Wavelength Extension Solution can address your metro, access and core network needs, including:
span extension in single and multi-wavelength applications, regeneration, wavelength service delivery to the
customer premise, and economic relief of bandwidth exhaust.
3

To learn more about our comprehensive portfolio, please
contact your Lucent Technologies Sales Representative or
call 1-888-426-2252.
Visit our web site at http://www.lucent.com.
This document is for planning purposes only, and is not
intended to modify or supplement any Lucent Technologies
specifications or warranties relating to these products or
services. The publication of information in this document does
not imply freedom from patent or other protective rights of
Lucent Technologies or others.
Metropolis and LambdaUnite are registered trademarks of
Lucent Technologies Inc.
Copyright 2003
Lucent Technologies Inc.
All rights reserved
ONG v1.0503
Metropolis®Wavelength
Extension Solution
The Lucent advantage…
With the Metropolis®Wavelength Extension Solution, you have the power
and flexibility to serve many different applications reliably and cost-effectively.
Its seamless, self-configuring design lets you scale your system using the latest
Lucent Technologies products. Plus, the Metropolis®Wavelength Extension
Solution gives you the added advantages of:
• Bit-transparency
• Energy and space savings
• Reduced maintenance and operational costs
• Low initial investment
• Equipment investment protection
• Standard-compliant design
• Cost-effective solution for metro fiber exhaust
