Stinger®MS+
DSL Access Concentrator
Combining intelligent IP and advanced ATM capabilities on every port,
the mid-sized Stinger®MS+ platform can deliver a wide range of voice,
video and data services over the existing copper infrastructure. This
high-performance access concentrator offers the management features
needed to accelerate service start up and cut costs, while supporting
the expansion of high-value service offerings with the latest multimedia
and video capabilities.
Features
•Intelligent IP and advanced ATM
switching – Deliver the speed,
high performance and reliability
required for high-value services
•Lucent Navis®iOperations
Management System – Speeds
service start-up, reduces
implementation costs and
streamlines integration with
any network
•QoS capabilities – Enable a broad
range of premium services,
backed by SLAs
•Medium capacity and port density –
Support 288 subscribers per
chassis, within a 4U (17.78cm)
system
•Intelligent IP services modules –
Increase efficiency and
performance by providing
intelligence at the network edge
Applications
• “Triple-Play” service packages
for residential customers,
including high-speed Internet,
video and voice services—all over
the copper loop
• Leading-edge video services,
including broadcast TV, Pay-Per-
View, streaming multimedia and
video on demand
• Multi-Dwelling Units, Multi-
Tenant Units, hospitality and
other in-building installations
Benefits
•Reduced Costs – Extend your
existing infrastructure cost-
effectively today; then migrate to
new capabilities with minimal
capital investment
•Competitive Edge – Gain the power
to offer today’s most advanced
broadband services – including
interactive video and broadcast TV
•Seamless Integration – Deploy the
Stinger®MS+ in your network for
multiple indoor applications
•Enhanced Profitability – Increase
revenues by extending your
complete spectrum of high-value
broadband services to smaller
markets

To learn more, contact your local Lucent
Technologies Representative, Authorized
Reseller, or Sales Agent.
Or, visit our Web site at www.lucent.com
Specifications subject to change
without notice.
This document is for planning purposes
only, and is not intended to create,
modify or supplement any Lucent
Technologies specifications or warranties
relating to these products or services.
Information and/or technical
specifications supplied within this
document do not waive (directly or
indirectly) any rights or licenses –
including but not limited to patents or
other protective rights – of Lucent
Technologies or others.
Stinger and Navis are registered
trademarks of Lucent Technologies.
Copyright © 2005
Lucent Technologies, Inc.
Printed in the U.S.A.
STMS v2.0305
Technical Specifications
Description Specifications
1.Electrical Specifications
Power Requirements: -48 VDC @ 770 Watts maximum
Inrush: All modules have inrush limiting circuits
Power Connectors: x2 M5 Studs per unit
Input Redundancy: Optional input available
Hot Swappable: Yes, both inputs can be Hot swapped
2.Physical Specifications
Height: 17.78 cm [7.0 in] [4U]
Width: 44.90 cm [17.7 in]
Depth: 39.00 cm [15.35 in]
Unit Weight: 30 kg [66 lbs] max – (Fully Configured)**
Rack Mount Options: Forced Air Cooled
Intake/ Exhaust
Fits 19-in, 23-in and ETSI racks with
the appropriate rack mounting ears
not to block airflow
Not to be blocked by more then 20%**
3.Card Slots
Front Access: 4 for line interface modules (LIMs)
1 for control module
Rear Access: 4 for line protection modules:
(LPMs), path selector modules
(PSMa), and/or Copper Loop Test
(CLT) modules
1 for trunk module (TM)
4.Line Interface 50 – pin RJ-21X
5.Trunk Interface
OC-3c/STM-1 optical Single mode
(standard or long-reach options)
Multimode
DS3/E3 electrical with pass through
OC-12/STM-4
10/100 Ethernet
Gigabit Ethernet
6.Operating Environment
Ambient operating temperature 32° to 131°F (0° to 55°C)
Relative humidity 10% – 95% (non-condensing)
Operating altitude Up to 4,000m (13,123 ft)
7.Regularity Compliance
Bellcore GR-63-CORE
Bellcore GR-1089-CORE
EN/IEC 60950 (CE)
EN 55022 Class A
EN 300386-2
8.Model Numbers
Stinger MS+Base unit with pre-installed:
19" Rack Mount Kit (STGRMSP19-UNIT-MODEL)
23" Rack Mount Kit (STGRMSP23-UNIT-MODEL)
ETSI Rack Mount Kit (STGRMSPETSI-UNIT-MODEL)
** Estimated
