Lucent Technologies INDeX 20DS Turret User manual

Performance figures and data quoted in this document are typical, and must be
specifically confirmed in writing by Lucent Technologies before they become applicable
to any particular order or contract. The company reserves the right to make alterations or
amendments to the detailed specifications at its discretion. The publication of information
in this document does not imply freedom from patent or other protective rights of Lucent
Technologies, or others.
All trademarks acknowledged. SDX and INDeX are registered trademarks of Lucent
Technologies.
©Lucent Technologies 1999.
Sterling Court
15 - 21 Mundells
Welwyn Garden City
Hertfordshire AL7 1LZ
England
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: http://www.sdxplc.com
38DHB0002UKDN - Issue 1 (12/99)




INDeX 20DS 38DHB0002UKDN – ISSUE 1 (12/99)
INDeX 20DS Quick Guide
Introduction
= Replace handset or press
ANSWER RELEASE
.
= Pickup the handset orcontinue handsfree.
<value> = Entervalue required (e.g. phone number).
(note) = Note, {option} = Optional step
X...Y = Enter value in range X to Y.
Associating 20DS to a Terminal
Power supply: Only
use the PSU's supplied by Lucent Technologies.
–
United Kingdom:
38YPW00001SBC.
–
Rest of Europe:
38YPW00001EBC.
Connect a PSU to each 20DS unit and switch on
.
WARNING:
Youmustensure that the PSU's ventilationslots are not obstructed and
that there is clear space all around the PSU. Do not fit the PSU adjacent
to other PSU's as excessive heat may be generated.
Line cord:
Plug into both 20DS's and an INDeX phone socket.
Associating Terminal:
On each 20DS unit, use keys with solid green lampsto dial extension number of
associated terminal.Solid green lamp keysmimic keypad layout. All lampson 20DS unit are extinguished if
number entered correctly. 20DS unit is ready to program.
Solid Green
Number Pad
Keys
Flashing
Keys
Red Clear Key
Associating to Another Terminal:
Switch off 20DS powersupply.Hold down any two DSS keys (different
columns) and reconnect powersupply.Use keyswith solid green lamps to dial extension numberof new
associated terminal.Solid green lamp keysmimic keypad layout. All lampson 20DS unit are extinguished if
number entered correctly. 20DS unit is ready to program.
Miss-Dialling:
CLEAR to delete entry
38DHB0002UKDN – ISSUE 1 (12/99) INDeX 20DS
Programming the 20DS
•
To program a DSS key with extension, groupor line directory number:
PROGRAM, DSS key, <passcode of terminal>, <extension, line or group number>,
DONE and PROGRAM to finish.
•
To program a DSS key with a SPEED DIAL number:
PROGRAM, DSS key, <passcode of terminal>, SPEED DIAL, <number>, DONE and PROGRAM to finish.
•
To clear a programmed DSS key:
PROGRAM, DSS key, <passcode of terminal>, CANCEL, DONE and PROGRAM to finish.
BLF Lamp Status
•
Slow Red Flash:
A call on a line set underthe key has been parked. To unpark the call press the DSS key.
•
Fast Red Flash:
Shows thatthe extension set underthe keyis ringing. To pickup the call press the DSS key.
•
Solid Red:
The extension, line or group set under the key isbusy or notavailable (e.g.set to no calls with no divert
number set). Groups only show busy ifall members are busy.
•
Slow Green Flash:
Shows a callparked byyour phone. To unpark the call,press the DSS key.
•
Fast Green Flash:
Shows an external call ringing on a line.To answerthe call, pressthe DSS key.
•
Solid Green:
Shows a callconnected to your phone (or held byit).
•
Alternating Green/Red Lamp Signals:
Indicates a call to a Pilot number set underthe DSS key.
Making Calls
•
To make an external call:
Press DSS key, <external number>,
•
To make an internal call:
Press DSS key,
•
To make a speed dial call:
Press DSS key,
•
To end calls:
(All types)
Answering Calls
•
To answer calls:
Press DSS key next to fast flashing Green (external)or Red (extension)lamp
•
To pickup calls:
Press DSS key next to:
Fastflashing red lamp – extension orgroup
Fastflashing green lamp – incoming call on line
Parking, Holding & Transferring Calls
•
To Park a call:
PARK
•
To Hold a call:
HOLD
•
To make an unannounced transfer:
Press DSS keyof required extn/group,ANSWER RELEASE
•
To make an announced transfer:
Press DSS key of required extn,/group
Accepted call: ANSWER RELEASE
Unaccepted call: Press HOLD to return to caller.
•
To retrieve a parked/held call:
Press HOLD or the DSS keybeside slowgreen flashing lamp.
