Lucid 600 Series User manual

600 SERIES ADJUSTABLE BASE
[email protected]
888-975-8243
SERIAL NO.
OWNER’S MANUAL
600 SERIES ADJUSTABLE BASE

CONTENTS
Safety & Warranty Warnings
Overview & Parts List
Assembly
Remote Control & Pairing
Synchronizing Two Bases
Emergency Power Down
Connecting with Bluetooth
Troubleshooting
Warranty
04
06
08
12
15
16
16
17
18
600 SERIES ADJUSTABLE BASE

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 05 04
Safety & Warranty Warnings
PLEASE READ ALL INFORMATION CAREFULLY BEFORE
USING THIS PRODUCT. SAVE THESE INSTRUCTIONS.
IMPORTANT:
WARRANTY WARNINGS
Do not open or tamper with control box,
motors, or remote (with the exception of
battery compartments). The warranty will
be void if the internal workings of these
components are tampered with.
SAFETY WARNINGS
• Do not use bed outdoors.
• Using bed with oxygen administering
equipment other than the nasal masked
type creates a possible re hazard.
• When using nasal or masked type
administering equipment, route and
secure oxygen or air tubing properly to
ensure that tubing does not become
entangled or damaged during normal
operation of the bed.
• Keep moving parts free of obstruction
during bed operation (including sheets,
clothing, tubing, wiring, and products
using electric power cords).
WEIGHT LIMITS
• This product is not rated to support
weights in excess of:
Queen: 750 lbs. (340 kgs)
Twin XL: 500 lbs (226 kgs)
• This limit is inclusive of the mattress
and bedding. The bed will structurally
support this weight, provided it is evenly
distributed across the foundation. The
power foundation is not designed to
support or lift this amount in the head
or foot sections alone. Exceeding this
weight restriction could damage the
bed and/or cause injury and will void
the warranty.
HOSPITAL USE DISCLAIMER
This power foundation is designed for
residential use only. It is not approved for
hospital use and does not comply with
hospital standards.
PRODUCT RATING
The motors are not designed to operate
continuously for more than (2) minutes in
an (18) minute time period. Attempting
to exceed this rating will shorten the life
expectancy of the foundation and will void
the warranty.
SAFE OPERATION
• Use caution when having liquids in or
around the bed to ensure no spilling
occurs. In case of spillage, stand in a
dry, clean area of the oor and unplug
the bed immediately. Clean up spill and
allow the area around bed to dry
thoroughly before using the electric
controls again. Do not eat or drink hot
liquids while operating the bed.
• Do not allow children or individuals with
disabilities to operate the bed without
adult supervision.
• Do not allow any person or pet under
the bed at any time.
• During bed operation, make sure body
is positioned within the connes of the
bed. Do not place extremities over the
sides of the bed when operating bed
functions.
• After power foundation assembly is
completed, operate remote control to
ensure proper functions.
• Distribute body weight evenly over bed
surface. Do not place entire weight on
head or foot sections of the bed, during
reposition and entering or exiting bed.
FCC COMPLIANCE
• Operates on 2.4 GHz frequency
transmitter
• This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference,
and (2) this device must accept any
interference received, including
interference that may cause undesired
operation.
• To comply with FCC RF exposure
requirements, no change to the antenna
or the device is permitted. Any change
to the antenna or the device could
result in the device exceeding the RF
exposure requirement and void user's
right to operate the device.

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 07 06
Overview & Parts List
GET TO KNOW YOUR ADJUSTABLE BASE
Before beginning assembly of your adjustable base, please take
a moment to familiarize yourself with the parts and location of
components, as explained here.
If any parts or components are missing, or are different than
shown in the adjacent image, do not attempt to complete the
assembly process and contact customer support by calling
888-975-8243 or emailing [email protected].
REMOTE
POWER SUPPLY BOX & POWER CORD
CENTER CONNECTION BRACKETS (2)
LEGS
SECURITY STRAP
Twin XL Only
SYNC CABLE
Twin XL Only
HEAD MOTOR MASSAGE MOTORS
FOOT MOTOR
UNDERBED
LED LIGHTS
CONTROL BOX
USB PORTS
MATTRESS RETAINER BAR

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 09 08
Assembly
Open the carton in a at
position, bottom facing
up, to avoid damage.
Two people are
required to assemble
this adjustable base.
2.1.
NOTES
STEP 3
To install the six legs, thread the bolt of the
leg into the frame and tighten by hand.
Attach the center legs rst, which attach
on top of the center connection brackets
attached from step 2. Then fasten the
remaining corner legs.
STEP 2
Place the center connection brackets
over the pre-drilled leg holes located in
the middle of the base.
STEP 1
Remove folded bed base from the box and
carefully unfold the base. Set it mattress
side down on the oor.
STEP 4
Uncoil the input power cord (connected
to the control box on the underside of the
base) and plug it into the power supply box.
Take caution to avoid pinning ngers or
any underside wires along the hinge.
i
STEP 5
Uncoil the power cord (that has a wall
outlet connection) and attach it to the
power supply box opposite of the cord
attached in Step 4.

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 11 10
STEP 6
With two to four people, lift the bed by the
metal frame and turn it over so the mattress
side is facing up. Take caution not to lift
the bed with the fabric, or to use the legs
as pivot points. This pressure may cause
damage. Avoid dragging the base across
the oor.
STEP 7
Ensure two AAA batteries (included) are
installed correctly in the remote.
STEP 8
Slide the mattress retaining bar into the
anchors located at the foot of the bed.
STEP 9
Plug the power cord into the wall
outlet and refer to pages 12-15 to set
programmable positions, pair the remote,
and test functionality.
OPTIONAL: If using two separate Twin XL
or Split Cal King adjustable bases, wrap
a security strap around the front legs and
back legs. This will help prevent movement
and maintain stability.
Assembly, continued

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 13 12
PRESET BUTTONS
Zero Gravity (ZG): Elevate the
legs slightly higher than the
chest, allowing blood to ow
back to the heart to help reduce
stress and fatigue.
Anti-Snore: Raise the head to
allow for easier air intake.
TV: Raise the head to the ideal
position for watching TV, working,
or reading.
Lounge: Adjust to a chaise
lounge position to remove stress
and tension from the lower back.
PROGRAMMABLE BUTTONS
You can store new head and foot
positions by customizing the memory
(M) and preset (ZERO GRAVITY, ANTI-
SNORE, TV, and LOUNGE) positions.
1. Move the head and/or foot to your
desired position.
2. Press and hold the M or preset
button that you want to customize
for ve seconds until the remote
backlight ashes. The new bed
position is now stored, overriding the
factory default.
CHILD LOCK
Press and hold this button until
the backlight ashes to lock or
unlock the remote control keys.
MASSAGE BUTTONS
Press HEAD or FOOT to turn on and
change the intensity of the head or
foot massage.
Press ON/OFF to turn both head and
foot massage on or off.
Press MODE to select between three
different massage type or wave modes.
Press TIMER to turn the massage off
automatically after a set period of time.
Choose from 10-minute, 20-minute, and
30-minute durations.
FACTORY RESET
Press and hold ZG and FLAT buttons
simultaneously for ve seconds until the
backlight ashes. All customized settings
are now cleared or returned to factory
default settings.
Remote Control
FOOT DOWN
FOOT UP
HEAD MASSAGE
ALL MASSAGE ON/OFF
HEAD UP
HEAD DOWN
FLAT POSITION
TV MODEZERO-GRAVITY MODE
LOUNGE MODE
FOOT MASSAGE
MASSAGE TIMER
MASSAGE MODE
UNDERBED LIGHTS
ANTI-SNORE MODE
MEMORY POSITION
CHILD LOCK
FLASHLIGHT
PAIR (see page 14)
FLASHLIGHT
OVERVIEW
All of the functions of the bed, explained here, can be operated with the remote control.
This remote requires two AAA batteries (included) inserted in the back panel.

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 15 14
Remote Control Pairing
OVERVIEW
The original remote that comes in the box is already paired to
the base. No further action is required.
In the event that the remote is not paired with the base (as in the
case of a replacement remote), begin by checking the following:
STEP 2
On the control box (underside of base), press
the PAIR button twice. The LED light on the
control box turns blue.
STEP 3
On the remote control, press and hold the
PAIR button. The light on the remote ashes
and starts the pairing process.
If the pairing is successful, the LED light on
the control box turns to green. If pairing fails,
the LED light on the control box turns off.
Repeat the steps until pairing is successful.
Remote buttons highlighted
STEP 1
Ensure the remote batteries are functioning. Replace if necessary.
Conrm the power cord is connected to a powered source.
STEP 2
With the sync cable installed, use remote and test all functions of the
bed base. If remotes are not working, troubleshoot the problem by
following the instructions on page 17.
The two bases are now connected and ready for normal use.
Synchronizing Two Bases (Twin XL Only)
TO PAIR ONE REMOTE TO TWO BASES:
STEP 1
Place two Twin XL or split size adjustable bases
next to each other in desired location. Ensure
both bases are in the at position. Plug the sync
cable into the SYNC input (shown to the left) on
each base's control box.

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 17 16
Emergency Power Down
Connecting with Bluetooth
PROBLEM POSSIBLE SOLUTION
No features of the base will activate. Ensure the remote is paired correctly with the
base (see page 14).
Unplug the power cord, wait 30 seconds and
plug back in to reset electric components.
The surge protection or the electrical outlet
may be defective. Test the outlet by plugging
in another working appliance.
Head or foot section will elevate, but will
not return to the at position.
Bed mechanism may be obstructed. Elevate
bed and check for obstruction. Remove
obstruction.
Head section may be too close to the wall.
Head and Foot lift function has minor
interference during operation.
Check batteries in wireless remote control.
Replace with two new AAA batteries if
necessary.
Make sure that you are following the duty
cycle of the motors (do not operate more
than two minutes over an 18 minute period.
Wireless remote may be experiencing
common radio frequency interference from
other radio transmitting devices. Wait several
seconds and try pressing appropriate button
again. See FCC Compliance Statement (page 5).
Base has lost power and will not lower. Press the blue pairing button located on the
control box cord for emergency lowering.
Troubleshooting
INSTALLING BATTERIES
Batteries act as a backup power source in
case of a power failure while the head and/
or foot sections are raised.
Locate and remove the cover on the 9V
battery compartment in the power supply
unit. Install two alkaline 9V batteries (not
included) and replace the cover.
If a power failure occurs, pressing the FLAT
button will return the base to a at position.
Enjoy the luxury of Bluetooth controls on your
mobile device using the Lucid Base App.
1. Download the Lucid Base App from
iTunes or the Google Play store.
2. Assemble your base and open the Lucid
Base App.
3. Select the ADD NEW button.
4. Select the L600.
5. Ensure your phone is connected by test-
ing the head-up position on the adjust-
able base.
6. Review the included list of programmed
shortcut positions.
7. *Enable "Hey Siri" Voice controls.
8. For more information on how to operate
your adjustable base, please visit
lucidmattress.com.
*iPhones only
Batteries are for single use only. After
lowering the adjustable bed once
during a power failure, replace with a
new set of batteries.
i

600 SERIES ADJUSTABLE BASE
OWNER'S MANUAL 19 18
Warranty Information Notes
DATE OF PURCHASE
PLACE OF PURCHASE
LOT # (found on ID Tag)
PO # (found on shipping box label)
SERIAL # (found on back cover of this manual)
ADDITIONAL NOTES
The foregoing warranty shall be exclusive and in lieu of any other warranty, express or implied, including warranties of merchant-
ability and tness for a particular purpose and all other warranties otherwise arising by operation of law, course of dealing, custom,
trade, or otherwise. LUCID® shall not be liable for any consequential damages or losses arising from the purchase, installation and/
or use of this product.
To assist with warranty claims, please keep your receipt and record the following:
WHAT IS COVERED
This warranty covers any defects in materials or
workmanship under the conditions and exceptions
stated below.
HOW LONG COVERAGE LASTS
This warranty runs for up to ten (10) years from the
date of purchase, according to the tiers set forth
below.
WHAT LUCID®WILL DO
Lucid® is the administrator of the warranty for the
adjustable base.
YEARS 1-3:
Warranty covers defects in the workmanship or
materials for a period of three (3) years from the
date of purchase. Lucid®will send replacement
parts for any defective part to the purchaser, and
Lucid® will pay all authorized labor and transpor-
tation costs associated with the repair or replace-
ment of any parts.
YEARS 4-10:
During the years four (4) through ten (10) from the
date of purchase, Lucid® will offer replacement
parts for any defective mechanical part. Purchaser
shall pay 1/7th of the replacement cost of the defec-
tive part multiplied by the number of years since
three (3) years after the warranty commencement
date and Lucid® shall bear the remainder of the
cost of the replacement part. The purchaser shall
bear all labor and shipping costs associated with
repair or replacement of the defective part(s). An
exception to this is the metal frame, which is cov-
ered in full for the duration of the 10-year warranty.
HOW TO GET SERVICE
E-mail “[email protected]” to submit
your warranty claim. Please keep your receipt so
that we may process your warranty request.
HOW STATE LAW APPLIES
This warranty gives you specic legal rights, and
you may also have other rights which vary from
state to state.
WARRANTY LIMITATIONS
This warranty excludes commercial use.
Purchaser must follow troubleshooting procedures
as set forth by the manufacturer or its agents
before warranty coverage may be granted.
At the sole discretion and direction of the manu-
facturer, parts demonstrated to be defective must
be returned. The manufacturer will arrange all
return shipping.
Warranty is void if purchased or transported
outside the USA.
10-YEAR LIMITED WARRANTY
