Ludlum Measurements 18 User manual

LUDLUM MODEL 18
ANALYZER
March 2012
Serial Number 217996 and Succeeding
Serial Numbers

LUDLUM MODEL 18
ANALYZER
March 2012
Serial Number 217996 and Succeeding
Serial Numbers

STATEMENT OF WARRANTY
Ludlum Measurements, Inc. warrants the products covered in this manual to be free of
defects due to workmanship, material, and design for a period of twelve months from the
date of delivery. The calibration of a product is warranted to be within its specified
accuracy limits at the time of shipment. In the event of instrument failure, notify Ludlum
Measurements to determine if repair, recalibration, or replacement is required.
This warranty excludes the replacement of photomultiplier tubes, G-M and proportional
tubes, and scintillation crystals which are broken due to excessive physical abuse or used
for purposes other than intended.
There are no warranties, express or implied, including without limitation any implied
warranty of merchantability or fitness, which extend beyond the description of the face
there of. If the product does not perform as warranted herein, purchaser’s sole remedy
shall be repair or replacement, at the option of Ludlum Measurements. In no event will
Ludlum Measurements be liable for damages, lost revenue, lost wages, or any other
incidental or consequential damages, arising from the purchase, use, or inability to use
product.
RETURN OF GOODS TO MANUFACTURER
If equipment needs to be returned to Ludlum Measurements, Inc. for repair or calibration, please send to
the address below. All shipments should include documentation containing return shipping address,
customer name, telephone number, description of service requested, and all other necessary information.
Your cooperation will expedite the return of your equipment.
LUDLUM MEASUREMENTS, INC.
ATTN: REPAIR DEPARTMENT
501 OAK STREET
SWEETWATER, TX 79556
800-622-0828 325-235-5494
FAX [phone]

Ludlum Measurements, Inc. March 2012
Table of Contents
Introduction 1
Getting Started 2
Unpacking and Repacking 2-1
Battery Installation 2-1
Connecting a Detector to the Instrument 2-2
Battery Test 2-2
Instrument Test 2-2
Operational Check 2-3
Specifications 3
Identification of Controls and Functions 4
Safety Considerations 5
Environmental Conditions for Normal Use 5-1
Warning Markings and Symbols 5-1
Cleaning and Maintenance Precautions 5-2
Calibration and Maintenance 6
Establishing an Operating Point 6-1
Calibration 6-1
GM Detectors 6-2
Proportional Detectors 6-2
Scintillation Detectors 6-3
Window Calibration 6-3
HV Calibration 6-4
Ratemeter Calibration 6-5
Detector Overload (Option) Calibration 6-5
With Scintillation Detectors 6-5
With GM Detectors 6-5
Maintenance 6-6
Recalibration 6-7

Model 18 Analyzer Technical Manual
Ludlum Measurements, Inc. March 2012
Batteries 6-7
Troubleshooting 7
Troubleshooting Electronics which utilize a
GM, Scintillator, or Proportional Detector 7-1
Troubleshooting GM Detectors 7-3
Troubleshooting Scintillators 7-4
Troubleshooting Proportional Detectors 7-4
Recycling 8
Parts List 9
Model 18 Analyzer 9-1
Main Board, Drawing 363 × 509 9-1
Calibration Board, Drawing 363 × 513 9-3
Wiring Diagram, Drawing 363 × 515 9-4
Drawings and Diagrams 10

Model 18 Analyzer Technical Manual Section1
Ludlum Measurements, Inc. Page 1-1 March 2012
Introduction
he Ludlum Model 18 Analyzer supplies the complete electronic
requirements for scintillation, proportional or GM monitoring with
the added feature of a window amplifier for selective gamma
monitoring.
The analyzer has three high-voltage potentiometers with a three-position
selector switch to choose the high-voltage operating point. Each high-
voltage potentiometer may be preset for a specific energy or detector. Other
features include AUD ON/OFF and fast/slow (F/S) meter response switches,
meter RESET, and high-voltage (HV) test buttons. The instrument includes a
unimorph speaker and is complete with connector cable and batteries.
Three gamma thresholds may be detected by utilizing the three preset high-
voltage settings. For example, the gamma threshold can be set for above 10
keV, above 30 keV, and above 100 keV. In the presence of mixed radiation,
including plutonium, americium and uranium 235, a quantitative estimate of
the source contribution of each isotope can be made by measuring each
energy level.
The Model 18 also incorporates a window circuit allowing a narrow peak to
be monitored. For example, by setting the window at 1.5 times threshold,
settings of 12 keV through 18 keV for plutonium, 45 keV through 67 keV
for americium, and 130 keV through 195 keV for 235 U may be used for a
better estimate.
Section
1
T

Model 18 Analyzer Technical Manual Section 2
Ludlum Measurements, Inc. Page 2-1 March 2012
Getting Started
Unpacking and Repacking
Remove the calibration certificate and place it in a secure location. Remove
the instrument and accessories (batteries, cable, etc.) and ensure that all of
the items listed on the packing list are in the carton. Check individual item
serial numbers and ensure calibration certificates match. The Model 18 serial
number is located on the front panel below the battery compartment. Most
Ludlum Measurements, Inc. detectors have a label on the base or body of
the detector for model and serial number identification.
Important!
If multiple shipments are received, ensure that the detectors
and instruments are not interchanged. Each instrument is
calibrated to specific detectors, and therefore not
interchangeable.
To return an instrument for repair or calibration, provide sufficient packing
material to prevent damage during shipment. Also provide appropriate
warning labels to ensure careful handling. Include detector(s) and related
cable(s) for calibration. Include brief information as to the reason for return,
as well as return shipping instructions:
- Return shipping address
- Customer name or contact
- Telephone number
- Description of service requested and all other necessary
information
Battery Installation
Ensure the Model 18 range selector switch is in the OFF position. Open the
battery lid by pushing down and turning the quarter-turn thumbscrew
Section
2

Model 18 Analyzer Technical Manual Section 2
Ludlum Measurements, Inc. Page 2-2 March 2012
counter-clockwise a quarter of a turn. Install two ˝D˝size batteries in the
compartment.
Note the (+) and (-) marks inside the battery door. Match the battery
polarity to these marks. Close the battery box lid, push down, and turn the
quarter-turn thumb screw clockwise a quarter of a turn.
Note:
The center post of a flashlight battery is positive. The batteries
are placed in the battery compartment in opposite directions.
Connecting a Detector to the Instrument
Caution!
The detector operating voltage (HV) is supplied to the detector
via the detector input connector. A mild electric shock may
occur if you make contact with the center pin of the input
connector. Switch the Model 18 range selector switch to the
OFF position before connecting or disconnecting the cable or
detector.
Connect one end of a detector cable to the detector by firmly pushing the
connectors together while twisting clockwise a quarter of a turn. Repeat the
process in the same manner with the other end of the cable and the
instrument.
BatteryTest
The batteries should be checked each time the instrument is turned on.
Move the range switch to the BAT position. Ensure that the meter needle
deflects to the battery check portion on the meter scale. If the meter does
not respond, check to see if the batteries have been correctly installed.
Replace the batteries if necessary.
Instrument Test
After checking the batteries, turn the instrument range switch to the ×1000
position. Place the AUD ON-OFF switch in the ON position and the WIN
IN/OUT switch to the OUT position. Expose the detector to a check source.

Model 18 Analyzer Technical Manual Section 2
Ludlum Measurements, Inc. Page 2-3 March 2012
The instrument speaker should emit ˝clicks˝ relative to the rate of counts
detected. The AUD ON/OFF switch will silence the audible clicks if in the OFF
position. It is recommended that the AUD ON/OFF switch be kept in the OFF
position when not needed in order to preserve battery life.
Rotate the range switch through the lower scales until a meter reading is
indicated. While observing the meter fluctuations, select between the fast
and slow response time (˝F/S˝) positions to observe variations in the display.
The ˝S˝position should respond approximately five times slower than the
˝F˝position.
Note:
The slow response position is normally used when the
instrument is displaying low numbers, which require a more
stable meter movement. The fast response position is used at
high rate levels.
Check the meter reset function by depressing the RES pushbutton and
ensuring the meter needle drops to ˝0.˝When the RES pushbutton is released
the meter needle recovers to the original reading.
Depress the HV pushbutton and note that the meter indicates the high-
voltage set point.
Note:
HV power supply has an output impedance of 10 megohms.
HV load should not exceed 25 microamperes. Calculate the
scintillation detector loading if an exact high voltage setting is
required.
See calibration procedures for details on the WIN IN/OUT operation.
Once this procedure has been completed, the instrument is ready for use.
Operational Check
To assure proper operation of the instrument between calibrations and
periods of nonuse, an instrument operational check including battery test
and instrument test (as described above) should be performed prior to use.

Model 18 Analyzer Technical Manual Section 2
Ludlum Measurements, Inc. Page 2-4 March 2012
A reference reading with a check source should be obtained at the time of
initial calibration or as soon as possible for use in confirming proper
instrument operation. In each case, ensure a proper reading on each scale. If
the instrument fails to read within 20% of a proper reading, it should be sent
to a calibration facility for recalibration.

Model 18 Analyzer Technical Manual Section 3
Ludlum Measurements, Inc. Page 3-1 March 2012
Specifications
0
Compatible Detectors: GM, proportional, and scintillation
Multipliers: ×1, ×10, ×100, and ×1000 selected by a front-panel range
selector switch
High Voltage: three independent settings adjustable from 400 to 2500
volts; can be read on the meter face
Threshold: adjustable from -2 to -60 mV
Window: adjustable from 0-60 mV above threshold (can be turned ON
or OFF)
Overload (optional): senses detector saturation; indicated by red lamp
on meter face and/or full-scale meter deflection (adjustable, depending
on the detector selected)
Meter: 6.4 cm (2.5 in.) arc, 1 mA analog type
Meter Dial: 0-500 cpm, 0-2.5 kV, BAT TEST (others available)
Range: typically 0-500,000 counts/minute (CPM)
Linearity: reading within 10% of true value with detector connected
Battery Dependence: Instrument calibration change less than 15%
within battery check limits on the meter.
Calibration Controls: individual potentiometers for each range;
accessible from the front cover while in operational status
Section
3

Model 18 Analyzer Technical Manual Section 3
Ludlum Measurements, Inc. Page 3-2 March 2012
Audio: built-in unimorph speaker with ON-OFF switch (greater than
60 dB at 0.61 m {2 ft})
Response: toggle switch for 4 seconds in the fast (F) position or 22
seconds in the slow (S)position from 10% to 90% of final reading
Connector: Series ˝C˝(other available)
Reset: pushbutton to zero the meter
Operating Temperature: -20 to 50 °C (-4 to 122 °F)
Power: two ˝D˝cell batteries housed in a sealed externally accessible
compartment
Battery Life: typically 600 hours with alkaline batteries (battery
condition may be checked on the meter)
Size: 16.5 x 8.9 x 21.6 cm (6.5 x 3.5 x 8.5 in.) (H x W x L)
Weight: 1.6 kg (3.5 lb), including batteries
Construction: cast-and-drawn aluminum with beige powder coating and
silk-screened nomenclature

Model 18 Analyzer Technical Manual Section4
Ludlum Measurements, Inc. Page 4-1 March 2012
Identification of Controls and
Functions
Range Selector Switch: A six-position switch marked OFF, BAT,
×1000, ×100, ×10, and ×1. Turning the range selector switch from OFF
to BAT provides the operator with a battery check of the instrument. A
BAT check scale on the meter provides a visual means of checking the
battery-charge status. Moving the range selector switch to one of the
range multiplier positions (×1000, ×100, ×10, ×1) provides the operator
with an overall range of 0 to 500,000 cpm. Multiply the scale reading by
the multiplier to determine the actual scale reading.
Battery Compartment: Sealed compartment to house two ˝D˝cell
batteries.
RES Pushbutton: When depressed, this switch provides a rapid means
of driving the meter needle to zero.
AUD ON/OFF Toggle Switch: In the ON position, operates the
unimorph speaker, located on the left side of the instrument. The
frequency of the clicks is relative to the rate of the incoming pulses. The
higher the rate, the higher the audio frequency. The audio should be
turned OFF when not required to reduce battery drain.
HV Pushbutton: When depressed, displays the detector high voltage on
the meter.
F-S Toggle Switch: Provides meter response. Selecting the fast, ˝F˝
position, of the toggle switch provides 90% of full-scale meter deflection
in four seconds. In the slow, ˝S˝position, 90% of full-scale meter
deflection takes 22 seconds. In the ˝F˝position there is fast response and
large meter deviation. The ˝S˝position should be used for slow response
and damped meter deviation.
WIN IN/OUT: A toggle switch that disables the window circuit for gross
counting.
Section
4

Model 18 Analyzer Technical Manual Section4
Ludlum Measurements, Inc. Page 4-2 March 2012
HV selector switch: A three-position switch located below the WIN
IN/OUT switch, used for the selection of any one of the desired preset
high voltage settings.
HV Adjustments: Recessed potentiometers located under the calibration
cover, which provides a means of setting the high voltage from 400 to
2500 volts for each individual setting selected by the HV selector switch.
Range Calibration Adjustment: Recessed potentiometers located under
the calibration cover. These controls allow for individual calibration of
each range multiplier.
THR: Recessed potentiometer located under the calibration cover, which
allows the input sensitivity (threshold) to be adjusted from -2 to -60
millivolts. The threshold is normally set at the factory for -10 millivolts.
WIN: Recessed potentiometer located under the calibration cover, which
allows the window width to be adjusted from 0 to 2.0 times the
threshold setting (input sensitivity). The window is normally set for 1.5
times the threshold.
OL (optional): An internal potentiometer that allows for calibration of
the optional detector overload function.

Model 18 Analyzer Technical Manual Section 5
Ludlum Measurements, Inc. Page 5-1 March 2012
Safety Considerations
Environmental Conditions for Normal Use
Indoor or outdoor use
No maximum altitude
Temperature range of -20 to 50 °C (-4 to 122 °F); may be certified for
operation from -40 to 65 °C (-40 to 150 °F)
Maximum relative humidity of less then 95% (non-condensing)
Pollution Degree 3 (as defined by IEC 664) (Occurs when conductive
pollution or dry nonconductive pollution becomes conductive due to
condensation. This is typical of industrial or construction sites.)
Warning Markings and Symbols
Caution!
The operator or responsible body is cautioned that the
protection provided by the equipment may be impaired if the
equipment is used in a manner not specified by Ludlum
Measurements, Inc.
The Model 18 Analyzer is marked with the
following symbols:
CAUTION, RISK OF ELECTRIC SHOCK (per ISO 3864, No. B.3.6)
– designates a terminal (connector) that allows connection to a voltage
exceeding 1 kV. Contact with the subject connector while the instrument is
on or shortly after turning off may result in electric shock. This symbol
appears on the front panel.
Section
5

Model 18 Analyzer Technical Manual Section 5
Ludlum Measurements, Inc. Page 5-2 March 2012
CAUTION (per ISO 3864, No. B.3.1) – designates hazardous live voltage
and risk of electric shock. During normal use, internal components are
hazardous live. This instrument must be isolated or disconnected from the
hazardous live voltage before accessing the internal components. This
symbol appears on the front panel. Note the following precautions:
Warning!
The operator is strongly cautioned to take the following
precautions to avoid contact with internal hazardous live parts
that are accessible using a tool:
1. Turn the instrument power OFF and remove the batteries.
2. Allow the instrument to sit for one minute before accessing
internal components.
The “CE” mark is used to identify this instrument as being acceptable for
use within the European Union.
The “crossed-out wheelie bin” symbol notifies the consumer that the
product is not to be mixed with unsorted municipal waste when discarding;
each material must be separated. The symbol is placed on the battery
compartment lid. See section 8, “Recycling,” for further information.
Cleaning and Maintenance Precautions
The Model 18 may be cleaned externally with a damp cloth, using only water
as the wetting agent. Do not immerse the instrument in any liquid. Observe
the following precautions when cleaning or performing maintenance on the
instrument:
1. Turn the instrument OFF and remove the batteries.
2. Allow the instrument to sit for one minute before cleaning the
exterior or accessing any internal components for maintenance.

Model 18 Analyzer Technical Manual Section 6
Ludlum Measurements, Inc. Page 6-1 March 2012
Calibration and Maintenance
Establishing an Operating Point
The operating point for the instrument and probes is established by
setting the probe voltage and instrument sensitivity (HV and THR). The
proper selection of this point is the key to instrument performance.
Efficiency, background sensitivity, and noise are fixed by the physical
makeup of the given detector and rarely vary from unit to unit.
However, the selection of the operating point makes a marked
difference in the apparent contribution of these three sources of count.
In setting the operating point, the final result of the adjustment is to
establish the system gain so that the desirable signal pulses (including
background) are above the discrimination level and the unwanted pulses
from noise are below the discrimination level and are therefore not
counted.
Total system gain is controlled by adjusting either the instrument
threshold or high voltage. Voltage affects control in the probe; THR
(threshold) controls the amplifier gain.
The operating point for each detector is set at a compromise point of
sensitivity, stability, and background contribution. These operating
points are best for general monitoring. However, the factory set-point
may be adjusted for your specific operation.
In the special case of GM detectors, a minimum voltage must be applied
to establish the Geiger-Mueller characteristic. Further changes in gain
will not affect this type of probe.
Calibration
To access the calibration controls, remove the front-panel calibration
cover. In performing the following, use a Ludlum Model 500 Pulser or
equivalent for generation of pulse height, HV testing, and count rate
generation.
Section
6

Model 18 Analyzer Technical Manual Section 6
Ludlum Measurements, Inc. Page 6-2 March 2012
GM DETECTORS
Note:
The GM detector pulse is NOT proportional to Gamma
Energy. WINDOW operation has no function.
1. Check GM detector specifications for proper operating high
voltage. Select this voltage with the HV calibration control.
Press HV test and confirm proper high voltage reading.
2. Set THR control for 40 ±10 millivolts.
3. Set WIN IN/OUT to OUT.
4. Set F/Sand AUD ON/OFF as per local requirements
5. Connect GM detector and confirm proper operation with a
radiation source.
PROPORTIONAL DETECTORS
1. Set THR for 2 millivolts.
2. Set WIN IN/OUT to OUT.
3. Expose detector to a radiation source and the observe count
rate with and without the source as voltage is increased in 50
volt increments. Make a plot of Data vs High Voltage.
4. Select an operating high-voltage point with minimum
change in count-rate-vs-high-voltage (i.e. on the plateau).
5. Record this high voltage for future operational check.
Note:
Gas proportional detectors and some pure argon detectors
will develop a very rapid increase of background count.
This is called “voltage breakdown.” Operate at least 100
volts below this point.

Model 18 Analyzer Technical Manual Section 6
Ludlum Measurements, Inc. Page 6-3 March 2012
SCINTILLATION DETECTORS
1. Set THR for 10 millivolts.
2. Set WIN IN/OUT to OUT.
3. Expose detector to a radiation source and observe count
rate with and without source as voltage is increased in 50
volt increments. Plot this data-vs-high-voltage.
4. Select an operating high-voltage point with minimum
change in count-rate-vs-high-voltage (i.e. on the plateau).
5. Record this high voltage for future operational check.
WINDOW CALIBRATION
1. To find the peak energy of an isotope, the operating
characteristics of the detector must be determined. A
plateau graph of 50-volt increments should be taken with
the WIN IN/OUT switch in the OUT position and plotted for
both background and a reference source, such as 137Cs for
high energy or 241Am for low energy.
Window calibration will be valid only with the specific detector to be
used with the Model 18. A check source will be required. A Model 500
Pulser will be required if the WIN calibration is shifted to another energy.
Using the pulser, set THR on at 10 millivolts and WIN OFF
at 15 millivolts.
Example:
2. The peak energy of the source is located where the count
from the source "just starts" to appear above background.
Take note of the high voltage in this area. This will be the
region of the operating point for the reference source.
3. Place the WIN IN/OUT switch to IN, and set the WIN and
THR controls. Reduce the high voltage below the point
where the source count is not seen above background.
