LUDLUM MODEL 2363
GAMMA-NEUTRON SURVEY METER
October 2015
Serial Number 220855 and Succeeding
Serial Numbers

LUDLUM MODEL 2363
GAMMA-NEUTRON SURVEY METER
October 2015
Serial Number 220855 and Succeeding
Serial Numbers

Ludlum Measurements, Inc. October 2015
Table of Contents
Introduction 1
Getting Started 2
Unpacking and Repacking 2-1
Battery Installation 2-1
Connecting a Detector to the Instrument 2-2
Battery Test 2-2
Operating the Instrument 2-3
Principle of Operation 2-3
Specifications 3
Description of Controls and Functions 4
Operator Controls 4-1
Internal Controls 4-2
Safety Considerations 5
Environmental Conditions for Normal Use 5-1
Cleaning Instructions and Precautions 5-1
Warning Markings and Symbols 5-2
Calibration and Maintenance 6
Calibration 6-1
Meter Calibration 6-1
Establishing an Operating Point 6-2
Maintenance 6-3
Recalibration 6-3
Batteries 6-4
RS-232 Interface 7
Communicating With the Model 2363 7-1
Commands 7-1
Read Commands 7-1
Set Commands 7-2
Command Descriptions 7-2

Model2363 TechnicalManual
Ludlum Measurements, Inc. October 2015
Model 2363 Interface Software 7-8
Functions 7-8
Main Screen 7-8
Auto Dump Data 7-10
Installation of the 2363 Interface Software 7-14
Removal of the Model 2363 Interface V2 7-14
Connecting to a Computer 7-14
Technical Theory of Operation 8
Troubleshooting 9
Recycling 10
Parts List 11
Model 2363 Gamma-Neutron Survey Meter 11-1
Main Board, Drawing 390 × 295 11-1
LED Board, Drawing 390 × 299 11-4
LCD Display Board, Drawing 390 × 170 11-4
Wiring Diagram, Drawing 390 × 290 11-4
Drawings and Diagrams 12

Model2363 TechnicalManual Section1
Ludlum Measurements, Inc. Page 1-1 October 2015
Introduction
he Ludlum Model 2363 Gamma/Neutron Survey Meter is an easy-
to-use survey instrument capable of measuring both neutron and
gamma radiation levels simultaneously, incorporating both analog
and digital displays for maximum versatility. This instrument logs up
to 1000 data points in non-volatile memory and consists of sample number,
date/time stamp, ratemeter measurements (both neutron and gamma),
integrated dose, and location identifier (10 characters).
The Model 2363 contains an internal energy-compensated GM (Geiger-
Mueller) detector for gamma measurements and is normally sold with an
external Model 42-41 PRESCILA detector for use in neutron
measurements.
This instrument incorporates a long arc-length analog meter face, which
normally displays exposure rates from 0 to 10 mrem/hr. The instrument’s
digital display is a full six-digit liquid crystal display (LCD) with an arrow
symbol for counting overflow. The display is direct-driven for optimal
viewing and wide temperature response.
The Model 2363 range selector switch allows for multiplication ranges of
×0.1, ×1, ×10, and ×100, and a front-panel three-position toggle switch is
used for selecting display of neutron, gamma, or neutron + gamma levels.
Neutron and gamma pulses are allotted different audible tones for ease of
user discrimination. A two-position, momentary-action switch allows either
an analog meter reset or display of the current integrated dose rate on the
LCD.
The following alarms may be set via the RS-232 port:
Neutron Rate meter (0-9999.99 mrem/hr)
Gamma Rate meter (0-9999.99 mrem/hr)
Section
1
T

Model2363 TechnicalManual Section1
Ludlum Measurements, Inc. Page 1-2 October 2015
Neutron + Gamma Rate (0-9999.99 mrem/hr)
Neutron + Gamma Integrated Dose (0-99999.9 mrem)
These alarm points, when exceeded, will light the appropriate LED on the
front panel and activate the audio alarm. The alarms will continue until the
RESET toggle switch is depressed, or until the INTEGRATED DOSE is zeroed.
The Model 2363 communicates through an RS-232 port located on the
instrument can. The computer interface software is supplied on CD and
includes the following functions:
Downloading of header and logged data into an ASCII file
Setting and reading of instrument parameters
Setting of the CALIBRATION DUE DATE
Setting of the internal real-time clock/calendar

Model2363 TechnicalManual Section2
Ludlum Measurements, Inc. Page 2-1 October 2015
Getting Started
Unpacking and Repacking
Remove the calibration certificate and place it in a secure location. Remove
the instrument and accessories (batteries, cable, etc.) and ensure that all of
the items listed on the packing list are in the carton. Check individual item
serial numbers and ensure calibration certificates match. The Model 2363
serial number is located on the front panel below the battery compartment.
Most Ludlum Measurements, Inc. detectors have a label on the base or body
of the detector for model and serial number identification.
Important!
If multiple shipments are received, ensure that the detectors
and instruments are not interchanged. Each instrument is
calibrated to specific detectors, and therefore not
interchangeable.
To return an instrument for repair or calibration, provide sufficient packing
material to prevent damage during shipment. Also provide appropriate
warning labels to ensure careful handling. Include detector(s) and related
cable(s) for calibration. Include brief information as to the reason for return,
as well as return shipping instructions:
- Return shipping address
- Customer name or contact
- Telephone number
- Description of service requested and all other necessary
information
Battery Installation
Ensure the Model 2363 range selector switch is in the ˝OFF˝position. Open
the battery lid by pushing down and turning the quarter-turn thumbscrew
Section
2

Model2363 TechnicalManual Section2
Ludlum Measurements, Inc. Page 2-2 October 2015
counterclockwise a quarter of a turn. Install two ˝D˝size batteries in the
compartment.
Note the (+) and (-) marks inside the battery door. Match the battery
polarity to these marks. Close the battery box lid and push down and turn
the quarter-turn thumb screw clockwise a quarter of a turn.
Note:
The center post of a flashlight battery is positive. The batteries
are placed in the battery compartment in opposite directions.
Connecting a Detector to the Instrument
Caution!
The detector operating voltage (HV) is supplied to the detector
via the detector input connector. A mild electric shock may
occur if you make contact with the center pin of the input
connector. Switch the Model 2363 to the OFF position before
connecting or disconnecting the cable or detector.
Connect oneend of a detector cable to the detector by firmly pushing the
connectors together while twisting clockwise a quarter of a turn. Repeat the
process in the same manner with the other end of the cable and in the
instrument.
Battery Test
The batteries should be checked each time the instrument is turned on.
Move the range selector switch to the BAT position. Verify that all three
alarm LEDs on the front panel turn on briefly. The LCD should go through
an initialization sequence displaying ˝88:8.8:8.8˝,then the current sample
number, and finally ˝0˝. Ensure that the meter needle deflects to the battery
check portion on the meter scale. If the meter does not respond, check to
see if the batteries have been correctly installed. Replace the batteries if
necessary.

Model2363 TechnicalManual Section2
Ludlum Measurements, Inc. Page 2-3 October 2015
Operating the Instrument
Connect a detector to the instrument if you have not already done so.
Obtain a meter reading from a check source or calibrated source, if available.
Verify that the reading falls within the expected range. Remove the source. If
a radiation source is available, increase the meter count to exceed the alarm
threshold. Both the appropriate alarm lamp and audio alarm signal should
activate.
Depress the RESET toggle switch. The meter needle should drive to zero,
and the alarm circuit should de-energize, shutting off both visual and audible
alarms.
Proceed with use.
Principle of Operation
The detected neutron count rate is displayed by selecting the ˝N˝position on
the three-position ˝N/N+G/G˝toggle switch. Similarly, the sum of the
neutron and gamma count rate or the gamma count rate only is displayed by
selecting the appropriate ˝N+G˝or ˝G˝position. The digital display will show
a direct reading in dose rate. Multiply the reading on the analog rate meter by
the range multiplier position.
The ˝RESET˝ toggle switch position resets the meter pointer to zero and
deactivates any current alarm. The current integrated dose is displayed on the
digital meter dial by selecting the ˝INTEGRATED DOSE (ID)˝ position.
Note:
The accumulated integrated dose may be reset by pressing the
ID toggle switch while turning the instrument ON.

Model2363 TechnicalManual Section3
Ludlum Measurements, Inc. Page 3-1 October 2015
Specifications
Ranges: four linear range multiples of ×0.1, ×1, ×10, and ×100; used in
combination with the 0-10 mrem/hr meter dial, providing an overall
range of 0-1000 mrem/hr
Gamma Energy Range: 60 keV to 3 MeV
Gamma Energy Response: ≤ 15%
Sensitivity: Gamma is approximately 1000 cpm/mR/hr (internal
detector. Neutron is approximately 350 cpm/mrem/hr (with Model 42-
41L).
Thresholds: Gamma threshold is fixed at 50 millivolts (mV). Neutron
threshold is adjustable from 5 to 100 mV.
Neutron High Voltage: internally adjustable from 500 to 1500 Vdc
Gamma High Voltage: fixed at 550 Vdc
Linearity: within 10% of true value for the analog rate meter; 2% for the
LCD
Response Time: ×0.1 range multiplier = 7 seconds, ×1 = 7 seconds,
×10 = 2 seconds, ×100 = 2 seconds; all response times measured from
10-90% of full scale
Audio: dual- or single-tone click-per-event through a built-in speaker with
an adjustable volume control located on the front panel; headset jack
located on the instrument can
Section
3

Model2363 TechnicalManual Section3
Ludlum Measurements, Inc. Page 3-2 October 2015
Alarm points: four separate alarms set through the RS-232 port,
activating the alarm audio tone and lighting the appropriate LEDs;
marked GALARM, NALARM, or IDALARM. The four alarm points can be set
from 0 to 99999 for the following:
Neutron Rate meter
Gamma Rate meter
Neutron+Gamma Rate meter
Neutron+Gamma Integrated Dose
Meter: rugged 1 milliamp (mA), with pivot-and-jewel suspension and 6.4
cm (2.5 in.) arc
LCD: six-digit direct-driven with 6.4 mm characters and a counter
overflow arrow
Connector: series ˝C˝standard; others available
Power: two standard ˝D˝size batteries
Battery Life: 200 hours of operation with a fresh set of alkaline ˝D˝cell
batteries
Temperature Range:
Neutron: ±30% from 0 to 40°C (32 to 104 °F) (PRESCILA)
Gamma: ±10% from -20 to 50 °C (-4 to 122 °F) (internal GM)
Size (including connector protrusion):
Without PRESCILA With PRESCILA
Height: 19.6 cm (7.7 in.) 32.3 cm (12.7 in.)
Width: 8.9 cm (3.5 in.) 13.7 cm (5.4 in.)
Length: 21.1 cm (8.3 in.) 34.3 cm (13.5 in.)
Weight (including internal detector and batteries):
Without PRESCILA With PRESCILA
2.0 kg (4.5 lb) 4.2 kg (9.2 lb)
Finish: drawn-and-cast aluminum, with beige powder coating

Model2363 TechnicalManual Section4
Ludlum Measurements, Inc. Page 4-1 October 2015
Description of Controls and
Functions
Operator Controls
OFF/BAT/X100/X10/X1/X0.1 Switch (or Range Selector Switch): a six-
position rotary switch to select the analog meter range multipliers and
check the battery status. When switched to the ˝BAT˝position, the meter
pointer should deflect above the left vertical mark on the ˝BAT OK˝line.
Moving the range selector switch to one of the range multiplier positions
(×0.1, ×1, ×10, ×100) provides the operator with an overall range of 0-
1000 mrem/hr. Multiply the scale reading by the multiplier to
determining the actual reading.
During initial instrument turn-on, the meter will be driven full scale for
about two seconds and then return to 0. The LCD will show “88:8.8:8.8,”
display the current sample number, and then ˝0˝. If the count button is
pressed while the display is showing all 8s, then the following numbers
are shown: firmware number, date, time, neutron rate meter alarm,
gamma rate meter alarm, neutron + gamma rate meter alarm, integrated
dose alarm, current sample number, and then ˝0˝.
Liquid Crystal Display (LCD): six-digit display that displays the count rate
for the selected channel
VOL: Turning this control clockwise will increase the speaker volume and
counterclockwise will decrease the volume.
Note:
The volume should be turned down when not required, in
order to reduce battery drain.
N/N+G/G Switch: a three-position toggle switch used to select the sum of
neutron and gamma count channels (N+G), neutron count only (N), or
gamma count only (G), for display. This switch affects both the analog
Section
4

Model2363 TechnicalManual Section4
Ludlum Measurements, Inc. Page 4-2 October 2015
meter and digital display. The rate meter channels are active regardless of
the switch position and will continue to function when the channel is not
selected for display. This ability allows the operator to view each channel
separately or together by simply selecting the appropriate switch position.
Headphone Jack: 0.03 cm (one-eighth inch) phone jack for connection
of external headphones. Inserting a phone plug into the jack disconnects
the external unimorph speaker from the audio circuitry. Use 0.03 cm
(one-eighth inch) mating plug –LMI part # 21-9653.
RESET/INTEGRATED DOSE (ID): a dual-position momentary toggle
switch that provides readout of the integrated dose when the
“INTEGRATED DOSE (ID)”position is selected. When the RESET position
is selected, this switch provides a rapid means of driving the analog rate
meter to zero and resetting the meter after an alarm condition. The
integrated dose may be reset by holding this switch in the ID position
while turning the instrument on.
Log Pushbutton (located in the carrying handle): When pressed, the
instrument stores the current readings into non-volatile memory.
Internal Controls
Remove the instrument cover (can) to access the following dipswitches
on SW1.
Dipswitch1: This switch, when placed in the ON position, enables
calibration due date. The date is entered in Month/Day/Year format.
During power-up the Model 2363 checks to see if the current date is past
the calibration due date. If it is, then the Model 2363 displays ˝OUTCAL˝
and is disabled until this command is issued to set the calibration date
ahead of the current date. (See page 7-4, command SC, for more
information on calibration due date.)
Dipswitch 2: This switch is used to select tone discrimination between
neutron and gamma count channels. When in the DUAL mode, neutron
and gamma pulse tones will be audible in all selector switch positions (i.e.
if in the N-only position and gamma radiation is detected, the gamma
tones will be heard in addition to the neutron tones).
When the ˝SNGL˝tone position is selected, both neutron and gamma
pulse tones can be heard in the ˝N +G˝selection, but neutron pulses are

Model2363 TechnicalManual Section4
Ludlum Measurements, Inc. Page 4-3 October 2015
the only audible tones in the ˝N˝channel selection, and gamma pulse
tones are the only audible tones in the ˝G˝channel selection.
SWITCH 2 TONE MODE
ON DUAL
OFF SINGLE
Dipswitch 3: This switch, when placed in the ON position, disables auto-
dump to the RS-232 port. (See page 7-6, command SM, for more
information on auto-dump.)
Remove the instrument cover to access the following calibration
potentiometers.
MTR: a multi-turn potentiometer used to calibrate the meter to the cpm
reading
NHV: a multi-turn potentiometer used to adjust the neutron high voltage
from 500 to 1000 Vdc
NTHR: a multi-turn potentiometer used to adjust the neutron pulse
threshold from 5 to 100 mV

Model2363 TechnicalManual Section5
Ludlum Measurements, Inc. Page 5-1 October 2015
Safety Considerations
Environmental Conditions for Normal Use
Indoor or outdoor use
No maximum altitude
Temperature range of ±30% from 0 to 40°C (32 to 104 °F) for Neutron
(PRESCILA probe) and ±10% from -20 to 50 °C (-4 to 122 °F) for
Gamma (internal GM)
Maximum relative humidity of less than 95% (non-condensing)
Maximum transient voltage of 1500 Vdc
Pollution Degree 3 (as defined by IEC 664) Occurs when conductive
pollution or dry nonconductive pollution becomes conductive due to
condensation. This is typical of industrial or construction sites.)
Cleaning Instructions and Precautions
The Model 2363 Gamma-Neutron Survey Meter may be cleaned externally
with a damp cloth, using only water as the wetting agent. Do not immerse
the instrument in any liquid. Observe the following precautions when
cleaning:
1. Turn the instrument range selector switch to the OFF position.
2. Allow the instrument to sit for one minute before cleaning.
Section
5

Model2363 TechnicalManual Section5
Ludlum Measurements, Inc. Page 5-2 October 2015
Warning Markings and Symbols
Caution!
The operator or responsible body is cautioned that the
protection provided by the equipment may be impaired if the
equipment is used in a manner not specified by Ludlum
Measurements, Inc.
The Model 2363 Gamma-Neutron Survey Meter is marked with the
following symbols:
CAUTION (per ISO 3864, No. B.3.1): designates hazardous live voltage
and risk of electric shock. During normal use, internal components are
hazardous live. This instrument must be isolated or disconnected from the
hazardous live voltage before accessing the internal components. This
symbol appears on the front panel. Note the following precautions:
Warning!
The operator is strongly cautioned to take the following
precautions to avoid contact with internal hazardous live parts
that are accessible using a tool:
1. Turn the instrument power OFF and disconnect the power
cord.
2. Allow the instrument to sit for one minute before accessing
internal components.
CAUTION, RISK OF ELECTRIC SHOCK (per ISO 3864, No. B.3.6):
designates a terminal (connector) that allows connection to a voltage
exceeding 1 kV. Contact with the subject connector while the instrument is
on or shortly after turning off may result in electric shock. This symbol
appears on the front panel.
The crossed-out wheelie bin symbol notifies the consumer that the
product is not to be mixed with unsorted municipal waste when discarding;
each material must be separated. The symbol is placed near the AC
receptacle. See Section 10, “Recycling,” for further information.

Model2363 TechnicalManual Section6
Ludlum Measurements, Inc. Page 6-1 October 2015
Calibration and Maintenance
Calibration
Note:
Local procedures may supersede the following.
Meter Calibration
A Ludlum Model 500 Pulser or equivalent is required. If the pulser does not
have high-voltage readout, use a-high impedance voltmeter with at least
1000 megohm input resistance to measure the detector voltage.
Ensure that the meter movement has proper mechanical zero. The
adjustment is on the front of the meter bezel. It must be adjusted to ˝0˝with
the ON/OFF selector switch in the OFF position.
Connect the Model 500 Pulser to the Model 2363 with the appropriate
cable. Rotate the Model 2363 range selector switch to the ×100 position.
Select the ˝N˝channel position.
Adjust the pulser for 400 cpm and the pulse amplitude to -20 mV. Connect
the instrument to a computer using a straight-thru 9-pin cable. Using the
Ludlum Model 2363 interface software, adjust ˝SE10001˝ for 1 cpm per
mrem/hr.
Remove the instrument cover and adjust the MTR potentiometer until the
meter reads 400 cpm. Adjust the pulser to 100 cpm and ensure the rate
meter reads 100 10%. Decade the pulser and the Model 2363 range
selector switch to check meter linearity on the ×10, ×1, and ×0.1 positions.
Linearity should be within 10% of each reading.
Adjust the NHV and NTHR controls for the appropriate set points as
described in the following subsection, “Establishing an Operating Point.”
Section
6

Model2363 TechnicalManual Section6
Ludlum Measurements, Inc. Page 6-2 October 2015
Replace 2363 cover and proceed with use.
Establishing an Operating Point
The Model 2363 contains an internal energy-compensated GM (Geiger-
Mueller) detector for gamma measurements. The operating point for this
detector is fixed, with a high-voltage requirement of 550 Vdc, and a
threshold of -50mV.
The Model 2363 is normally sold with an external PRESCILA neutron
detector (Model 42-41). The PRESCILA detector operating parameters are
established by adjusting the detector operating voltage (HV) and neutron
threshold to find an optimum efficiency for the neutron scintillator with a
known level of gamma cross-talk. The following is an outline of this
procedure.
1. Using the Ludlum Model 500 pulser or equivalent, adjust the
neutron threshold (NTHR) of the Model 2363 to -10 mV and
set the HV (NHV) to 635 Vdc.
2. Connect the Model 42-41 PRESCILA to the Model 2363 with a
0.99 m (39 in.) cable. Using the front face of the detector as the
detector reference point (not the center of the detector), point
the detector at the source. Ensure that all internal dipswitches
are set to the ON position.
3. Connect the Model 2363 to a computer using a straight-thru 9
pin cable. Use the Ludlum Model 2363 Software interface to
ensure that the following parameters are set:
SE10350 Neutron calibration constant of
350 cpm/mrem/hr
SE21050 Gamma calibration constant of
1000 cpm/mR/hr
RP100 Gamma dead time correction
of 100 µsec
SI00 Automatic time constant
ST Set the current time
SD Set the current date
SC Set the calibration due date
(one year, unless specified)

Model2363 TechnicalManual Section6
Ludlum Measurements, Inc. Page 6-3 October 2015
4. Move the PRESCILA to a 100 mR/hr 137Cs field, set the
selector switch to “N” (neutron only), and adjust the neutron
threshold until a meter reading of 1.2 mrem/hr ±5%
(corresponding to 450 cpm) is achieved. Do not adjust the
threshold below -5 mV. If necessary, switch to increasing the
HV in 5-volt steps. Record this reading.
5. Take the PRESCILA to an AmBe neutron field of 20 mrem/hr.
Adjust the calibration constant to calibrate the reading of the
meter to 20 mrem/hr. A typical conversion rate (as determined
by LANL) is 350 cpm per mrem/hr ±25%. Record and verify
that the following readings are within 10%: 2 and 5 mrem/hr,
20 and 50 mrem/hr, and 200 and 500 mrem/hr.
6. Take the Model 2363 to a 137Cs range and change the selector
switch to “G” (gamma only). Adjust the gamma calibration
constant and dead time correction to calibrate the meter within
10% at the following fields: 2 and 5 mR/hr, 20 and 50 mR/hr,
and 200 and 500 mR/hr.
Maintenance
Instrument maintenance consists of keeping the instrument clean and
periodically checking the batteries and the calibration. The Model 2363
instrument may be cleaned with a damp cloth (using only water as the
wetting agent). Do not immerse instrument in any liquid. Observe the
following precautions when cleaning:
1. Turn the instrument OFF and remove the batteries.
2. Allow the instrument to sit for one minute before accessing
internal components.
Recalibration
Recalibration should be accomplished after maintenance or adjustments
have been performed on the instrument. Recalibration is not normally
required following instrument cleaning, battery replacement, or cable
replacement.
