Radiation Portal MONITOR
Installation manual
July 2023

LUDLUM MODELS
4530-4200
4530-7000
4530-6300
4530-10500
4530-8400
4530-14000
Radiation Portal MONITOR
Installation manual
July 2023

STATEMENT OF WARRANTY
Ludlum Measurements, Inc. warrants the portal monitor covered in this manual to be free of
defects due to workmanship, material, and design for a period of 24 months from the date of delivery.
The calibration of a product is warranted to be within its specified accuracy limits at the time of
shipment. Accessories such as computers, Universal Power Supplies (UPSs), cameras, network
equipment, etc., are warranted by the individual manufacturer, and are not covered by Ludlum
Measurements.
This warranty excludes the replacement of instruments, detectors, or parts that are broken due to
excessive physical abuse, acts of nature such as lightening, or used for purposes other than intended.
Warranty claims requiring an onsite technician will cover labor and parts only. All related travel expenses
such as airline costs, meals and incidentals, and lodging are to be paid for by the customer and are not
covered by the warranty.
There are no warranties, express or implied, including without limitation any warranty of
merchantability or fitness, which extend beyond the description of the face thereof. If the product does
not perform as warranted herein, the purchaser’s sole remedy shall be repair, recalibration, or
replacement, at the discretion of Ludlum Measurements. In no event will Ludlum Measurements be liable
for damages, lost revenue, lost wages, or any other incidental or consequential damages, arising from the
purchase, use, or inability to use product.
RETURN OF GOODS TO MANUFACTURER
If equipment needs to be returned to Ludlum Measurements, Inc. for repair or calibration, please
send to the address below. All shipments should include documentation containing return shipping
address, customer name, telephone number, description of service requested, and all other necessary
information. Your cooperation will expedite the return of your equipment.
LUDLUM MEASUREMENTS, INC.
ATTN: RADIATION SECURITY DIVISION
501 OAK STREET
SWEETWATER, TX 79556
800-622-0828 325-235-5494
FAX [phone]
GATE MONITOR TECH SUPPORT 800-717-9506 (24 hours)

Model4525RadiationPortalMonitor InstallationManual
Ludlum Measurements, Inc. July 2023
Table of Contents
Overview 1
Detector Stand Installation 2
Shipping Crates 2-1
Stand Location –Buffer Zone 2-5
Stand Orientation 2-5
Typical Stand Setup 2-6
Setting Up The Stands 2-6
Anchor Bolts and Pattern 2-6
Conduit Requirements 2-10
Control Box 2-11
Power Requirements 2-11
Control Box and Detector Wiring 2-12
Remote Display 2-13
Cat-5E LAN Cabling for Networking System 2-14
Miscellaneous Requirements 2-14
Drawings and Diagrams 3

Model4525RadiationPortalMonitor InstallationManual Section1
Ludlum Measurements, Inc. Page 1-1 July 2023
Overview
The Ludlum Model 4530 Radiation Portal Monitor or “gate monitor” is designed
to detect very low levels of radiation, typically in vehicle loads as they are driven
between the detectors. Usually, the radiation detectors are placed right before a
weigh scale. Some models are used in other applications as conveyor monitors or
charge buckets. This manual is intended to assist you in the installation of the
system.
Several different models and options are available. The 2100 size detector contains
approximately 34,691 cm3(2117 cubic inches) of plastic scintillator, and the 3500
size detector contains approximately 57,355 cm3(3500 cubic inches) of plastic
scintillator. In general, the full model number tells the number of detectors –the
Model 4530-4200 and 4530-7000 are two-detector systems, the Model 4530-6300
and 4530-10500 are three-detector systems, and the Model 4530-8400 and 4530-
14000 systems are four-detector systems.
The detectors are normally mounted to the side of the vehicle, and also sometimes
above the vehicle. The detectors are centered around the typical load; your situation
or location might require the detectors to be higher or lower than the dimensions
shown in the back of this manual.
Each system comes with a wall-mount computer display. This computer logs data
and displays the current status of the system. It is typically placed inside the scale
house, or in close proximity to the scale operator. A remote display, with status
lights and a reset button, is also available as an option. The remote can show the
status and allow someone to reset alarms whenever the main computer is
inaccessible. It is typically placed in the scale house, or sometimes under a weather-
protected porch.
Each system uses infrared sensors to detect the vehicle’s presence, and thus switch
from measuring the background radiation to checking for an alarm. Multiple sets of
sensors are used to measure the speed of the vehicle and to ensure that the vehicle
presence is sensed throughout the passage of the vehicle. The range of vehicle sizes,
from flatbed trailers to tall drop-off boxes, necessitates some care in positioning the
sensors. The drawings in the back of the manual suggest some mounting heights
that have worked at many locations.
Take a moment to review the block diagrams that are located at the back of this
manual (Drawings 517 x 638 and 517 x 638A). Compare those drawings with the
Section
1

Model4525RadiationPortalMonitor InstallationManual Section1
Ludlum Measurements, Inc. Page 1-2 July 2023
system that you have purchased or are about to purchase. The block diagram may
help you to understand the available options. You can also use the block diagram to
locate where at your location the different components will be situated.

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-1 July 2023
Detector Stand Installation
This procedure is intended to outline the stand installation of the Ludlum Model
4530-4200, 4530-7000, 4530-6300, 4530-10500, 4530-8400, and 4525-14000
Radiation Portal Monitors. It does not cover actual termination of cables, which is
normally performed by Ludlum Measurements, Inc. (LMI) field service
technicians. The stand installation covers the following items:
1) Shipping Crates
2) Stand Location –Buffer Zone
3) Stand Orientation
4) Typical Stand Setup
5) Setting Up the Stands
6) Conduit Requirements
7) Cable Requirements
8) Remote Display
9) CAT-5E LAN Cabling
10) Supervisor Computer
11) Monitor Computer (optional)
12) Miscellaneous Requirements
Note:
Drawings of the model numbers listed above are located in the back of this manual. Before
building and installing the stands, please review the drawings of the Model 4530 that you have
ordered to assist in the installation process.
Shipping Crates
Each system may be purchased with or without the steel stands that provide
protection to the radiation detectors. Purchase of the steel stands from Ludlum
Measurements, Inc. facilitates the installation process. The following lists the
contents of the shipping crates.
Section
2

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-2 July 2023
CRATE CONTENTS OF THE MODEL 4530-4200 OR 4530-7000 WITHOUT
STANDS
The system is shipped in one wooden crate containing:
Two large (approximately 208.28 x 63.5 x 16 cm {82 x 25 x 6.3 in})
white detector boxes labeled 1 and 2 One 304.8 m (1000 ft) roll of
CAT-5E cable for Ethernet connection (outdoor rated)
One white control box with embedded computer
Four infrared components with cables
Any other optional items will be packed in the crate with the detectors.
The total shipping weight of the 4530-4200 crate is approximately 521.63
kg (1150 lb).
Total shipping weight of the 4530-7000 crate is approximately 612.35 kg
(1350 lb).
CRATE CONTENTS OF THE MODEL 4530-6300OR 4530-10500 WITHOUT
STANDS
The system is shipped in one wooden crate containing
Three large (approximately 208.28 x 63.5 x 16 cm {82 x 25 x 6.3 in})
white detector boxes labeled 1, 2 and 3
One 304.8 m (1000 ft) roll of CAT-5E cable for Ethernet connection
(outdoor rated)
One white control box with embedded computer
Four infrared components with cables
Any other optional items will be packed in the crate with the detectors.
Total shipping weight of the 4530-6300 crate is approximately 703.07 kg
(1550 lb).
Total shipping weight of the 4530-10500 crate is approximately 839.15 kg
(1850 lb).
CRATE CONTENTS OF THE MODEL 4530-8400 OR 4530-14000 WITHOUT
STANDS
The system is shipped in two wooden crates containing:
Four large (approximately 208.28 x 63.5 x 16 cm {82 x 25 x 6.3 in}) white
detector boxes labeled 1, 2, and 4. Each crate contains two detector boxes.
One 304.8 m (1000 ft) roll of CAT-5E cable for Ethernet connection
(outdoor rated)

Model4525RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-3 July 2023
One white control box with embedded computer
Four infrared components with cables
Any other optional items will be packed in the crate with the detectors.
Total shipping weight of the 4530-8400 crates is approximately 997.90 kg
(2200 lb).
Total shipping weight of the 4530-14000 crates is approximately 1202.02
kg (2650 lb).
PALLET CONTENTS OF THE MODEL 4530-4200 OR 4530-7000 WITH STANDS
This system comes on two pallets. Each pallet contains a large yellow detector
stand with a large white detector box mounted inside the stand. The following
items are strapped onto the pallet with Stand # 1.
One 304.8 m (1000 ft) roll of CAT-5E cable for Ethernet connection
(outdoor rated)
One white control box with embedded computer
Four infrared components with cables
Any other optional items will be packed in the crate with the detectors.
The total shipping weight of the 4530-4200 two pallets is approximately
1533.14 kg (3380 lb) (includes stand).
The total shipping weight of the 4530-7000 two pallets is approximately
1632.93 kg (3600 lb) (includes stand).
PALLET CONTENTS OF THE MODEL 4530-6300 OR 4530-10500 WITH STANDS
The system comes in three pallets. The two smaller pallets contain a large yellow
detector stand with a large white detector box mounted inside the stand. The large
pallet contains a large yellow detector stand and white detector box attached to the
overhead mounting frame. Also strapped to the large pallet are the mounting legs
to suspend the overhead frame over the scale or lane. Pallet 1 holds Detector 1,
Pallet 2 holds Detector 2 and the overhead holds Detector 3. The following items
are strapped onto the pallet with Stand # 1:
One hardware mounting kit containing the following:
Qty 32 ¾ in. x 3-inch long hex bolts
Qty 32 ¾ in. hex nuts
Qty 32 ¾ in. lock washers
Qty 32 ¾ in. flat washers

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-4 July 2023
One 304.8 m (1000 ft) roll of CAT-5E cable for Ethernet connection
(outdoor rated)
One white control box with embedded computer
Four infrared components with cables
Any other optional items will be strapped on the pallet
The total shipping weight of the 4530-6300 three pallets is approximately
3491.66 kg (7700 lb) (includes stand).
The total shipping weight of the 4530-10500 three pallets is
approximately 3628.74 kg (8000 lb) (includes stand)
PALLET CONTENTS OF THE MODEL 4530-8400 OR 4530-14000 WITH
STANDS
The system comes in four pallets. Each pallet contains one large, yellow detector
stand with one large, white detector box mounted inside the stand. The crate
contains:
One hardware mounting kit containing the following:
Qty 8 ¾ x 3 in. long hex bolts
Qty 8 ¾ in. hex nuts
Qty 8 ¾ in. lock washers
Qty 16 ¾ in. flat washers
One 304.8 m (1000 ft) roll of CAT-5E cable for Ethernet connection
(outdoor rated)
One white control box with embedded computer
Four infrared components with cables
Any other optional items will be strapped on the pallet
The total shipping weight of the 4530-8400 four pallets is approximately
2789.59 kg (6150 lb) each (includes stands)
The total shipping weight of the 4530-14000 four pallets is approximately
2939.28 kg (6480 lb) each (includes stands)
UNPACKING SYSTEMS
1) Remove the cardboard and shrink wrap (if used).
2) Remove any peripherals inside and store in a safe dry location.
3) If packed in a crate, remove lid and all four sides. Safely lift each
detector one at a time from the base of the crate.

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-5 July 2023
Stand Location –Buffer Zone
For best operation, locate the stands in an area where a 3 m (10 ft) buffer zone can
be maintained around the detectors. Typically, the stands are mounted about 3 m
(10 ft) before the weigh scale. It is important that vehicles stay out of this buffer
zone except when they are moving slowly between the detectors. Placing a stop
sign at the entrance to this buffer zone is recommended, as well as painting a line
on the pavement. For Model 4530-4200, 4530-7000, 4530-8400, and 4530-14000
see drawing 517 x 550B in the back of this manual. For Model 4530-6300 and
4530-10500 see drawing 517 x 641B in the back of this manual. Failure to correctly
locate the system or failure to enforce the buffer zone will result in more frequent
false alarms. These false alarms are caused by the system having an incorrect
measurement of the true background radiation level.
Stand Orientation
MODELS 4530-4200 AND 4530-7000
MODEL 4530-6300 AND 4530-10500

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-6 July 2023
MODEL 4530-8400 AND 4530-14000
Typical Stand Setup
To see a typical installation of the gate monitors, see the following drawings:
Model 4530-4200 and 4530-7000:Drawings 517 x 550 through 517 x 550D
Model 4530-6300 and 4530-10500:Drawings 517 x 641 through 517 x 641B
Model 4530-8400 and 4530-14000 Vertical: Drawings 517 x 562 through 517 x
562C
Model 4530-8400 and 4530-14000 Horizontal: Drawings 517 x 655 through 517 x
655C
Setting up the Stands
ANCHOR BOLTS AND PATTERN
For anchor bolt specifications, see Drawing 511 x 836, which is the second to last
drawing in Section 4 Drawings & Diagrams at the end of this manual. Due to the
close tolerances of the anchor bolt holes, the anchor bolts must be placed
according to the dimensions specified on the Anchor Bolt Template drawings
(The anchor bolt drawings listed below are listed in an index at the beginning of
Section 4. An anchor bolt template is listed at the end of almost every system.):
MODELS 4530-4200,4530-7000,4530-8400, AND 4530-14000 =
DRAWING 511 ×461
MODELS 4530-6300 AND 4530-10500 =DRAWING 511 ×449
THE ANCHOR BOLTS SHOULD PROTRUDE FROM THE
CONCRETE FROM 10 TO 12.7 CM (4 TO 5IN.).

Model4525RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-7 July 2023
Note:
LMI recommends the use of a template to be sure the anchor bolt
holes are placed in the correct locations. These can be supplied by
LMI. The part numbers are:
Models 4530-4200, 4530-7000, 4530-8400, and 4530-14000 template
part number 7511-461
Model 4530-6300 and 4530-10500 template part number 7511-449
The notch on the templates should be placed toward the center of the lane. The
anchor bolt holes are a tight tolerance fit for the ¾-inch anchor bolt; therefore,
care must be taken when the anchor bolts are placed in the concrete. Double-nut
the anchor bolt to the template before the concrete cures to ensure proper anchor-
bolt alignment.
LEVELING
1) Once the concrete is dry and all the bolts are straight, the mounting points
will need to be leveled. Shims may be used, but the following instructions assume
the use of leveling nuts.
2) Run a set of leveling nuts on the bolts as low as allowable (one nut per
bolt).
3) Place the flat template for the concrete holes on the leveling nuts.
4) Start leveling from the highest nut, using a 0.61 m (2 ft) (or larger) level in
the pattern described below. The stands should be level and plumb within 0.17 cm
(1/16 of an inch) over a 0.61 m (2 ft) distance.

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-8 July 2023
Models 4530-4200, 4530-7000, 4530-6300, 4530-10500, 4530-8400, and 4530-14000 Individual
Stand Leveling
LIFTING
Models 4530-4200 and 4530-7000
1) Attach the provided lifting lugs to the top of the stands. Use a lifting
harness rated for at least 1361 kg (3000 lb).
2) During lifting, the unit will lean towards the back. This will allow you
to engage two bolts first, and then the rest will align as the stand is
lowered (provided care was used in placing the bolts).
3) Before removing the lift harness (and lifting lugs) the four stand-
mounting nuts will need to be in place.
Model 4530-6300 and 4530-10500
1) Attach the provided lifting lugs and install them into the top of the
overhead stand legs. The top is the end with the gusset beams. Use a
lifting harness rated for at least 1361 kg (3000 lb).
2) Raise the legs and set them into place on the anchor bolts in the
concrete pad. Secure them into place. Remove lifting lugs. To lift the

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-9 July 2023
overhead frame, use TWO lifting harnesses, each rated for at
least 1361 kg (3000 lb). Wrap one harness around the beams and
against the end of the yellow box. Wrap the other the same way on
the other end of the yellow box. Hook into both straps to lift. Set the
overhead into position, attach all screws, and securely tighten.
3) Attach the lifting lugs used in Step 1 to the lower stands, the stands
will lean towards the back. This will allow you to engage two bolts
first, and then the rest will align as the stand is lowered (provided care
was used in placing the bolts).
4) Before removing the lift harness (and lifting lugs) the four stand mounting
nuts will need to be in place.
Model 4530-8400 and 4530-14000
1) Attach the provided lifting lugs to the top of the bottom stands. Use a
lifting harness rated for at least 1361 kg (3000 lb).
2) During lifting, the unit will lean towards the back. This will allow you
to engage two bolts first, and then the rest will align as the stand is
lowered (provided care was used in placing the bolts).
3) Before removing the lift harness (and lifting lugs) the four stand-
mounting nuts will need to be in place.
4) Remove the lifting lugs from the bottom stands and attach to the top
stands.
5) During lifting, the unit will lean towards the back. This will allow you
to engage two bolts first, and then the rest will align as the stand is
lowered (provided care was used in placing the bolts).
TORQUE SPECS FOR ¾-INCH BOLTS/NUTS (NOT SUPPLIED)
1) Grade 2 = 155 ft-lbs
2) Grade 3 (or 100,000 PSI Stainless Steel) = 234 ft-lbs.
3) Grade 5 = 257 ft-lbs
4) Grade 8 = 380 ft-lbs.

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-10 July 2023
SQUARING
The opposing front outside corners of the stands should be within a half-inch of
each other on the diagonal reading. Be sure to take the readings at the base of each
set of stands (see figures on the following page).
MODELS 4530-4200, 4530-7000, 4530-6300, 4530-10500, 4530-8400, AND
4530-14000 DIAGONAL SQUARING
Conduit Requirements
The bottom of each detector is pre-drilled for conduit connections. Refer to
Drawing 517 x 550C for Model 4530-4200 and 4530-7000, Drawing 517 x 641C
for Model 4530-6300 and 4530-10500, and Drawing 517 x 550C for Model
4530-8400 and 4530-14000 for conduit sizes and locations in the concrete pad.
OVER PULL AND LABELING FOR TERMINATION
All wires will be pulled, leaving a 0.61 m (24 in.) tail past the end of the conduit.
Each end of the cable must be labeled with its corresponding end on the
opposite side of the conduit. Numbers labels or colored tape are both
acceptable methods of labeling each end of the cable.
Note:
All additional conduit, from out of the concrete up to the enclosures
needs to be WATERTIGHT METALLIC. See Drawing 517 x 678 for
Conduit Template Guide for all vertical models.

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-11 July 2023
Control Box
The control box is required to be mounted indoors since it is not weathertight. It
is typically mounted inside the scale house or in close proximity to the scale
operator. Four each #8 screws should be used to mount it to the wall.
The Supervisor Computer is embedded in the control box. It allows the printing
of alarms, adjusting of set points, monitoring of multiple systems at one time, and
recording data seen from the systems for further analysis.
Caution:
Caution must be used when closing the electronics enclosures.
Excessive force could damage the electronic components.
Power Requirements
LMI recommends a dedicated 15 Amp circuit. LMI also recommends an
uninterrupted power supply (UPS) surge suppressor between the dedicated
breaker and the control box. This protects the system from improper
shutdowns and allows for continued operation during power outages.
AC power should be delivered to the control in accordance with code
requirements, which supersede these instructions. Such requirements, for
example, may include a disconnect device in clear sight of the control box.
Control Box and
Detector Wiring
Detector to Control Box Cable
Detector to Detector Cable
BOTH ENDS
PIN 1-GREEN/WHITE
PIN 2-GREEN
PIN 3-ORANGE/WHITE
PIN 4-ORANGE
PIN 5-BLUE/WHITE
PIN 6-BLUE
PIN 7-BROWN/WHITE
PIN 8-BROWN
See Drawings 517 x 646 through 517 x 646C for detector diagrams.

Model4530 RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-12 July 2023
IR Sensor Wiring
DETECTOR #1
Left and Right Receiver
Pin 1 = Brown
Pin 2 = White
Pin 3 = Blue
DETECTOR #2
Left and Right Transceiver
Pin 1 = Brown
Pin 2 = not used
Pin 3 = Blue
Remote Display
MOUNTING
Four holes have been provided to ensure proper mounting of the remote to the
wall. Sound judgment must be used to provide a secure platform for the
depression of the reset button. Refer to Drawing 517 × 637 (Model 4530
Remote)
The remote box comes ready to be mounted immediately above the control box
with an offset conduit elbow used to connect them. Refer to Drawing 517 X
637A. Additional CAT5E cable can be used to put the remote in any location
desired. Refer to Drawing 517 X 637B. Locations of the remote box will be
determined by the Location Supervisor (or equivalent) at each location.
CABLING
For the top mount option, the 30 in (0.76 m) of cable is provided by the
manufacturer already attached to the remote. Cabling will be run in the
conduit elbow down to the control box.
If mounting farther from the control box using the same CAT5E cable
provided with the system, route cabling from the control box to wherever
the remote display is mounted. Once indoors, conduit is not required, but
could be requested by the Location Supervisor.

Model4530RadiationPortalMonitor InstallationManual Section2
Ludlum Measurements, Inc. Page 2-13 July 2023
Cables outside of conduit will be secured every 0.30 m (1 ft) to prevent
entanglement and possible damage to the cable. The cable will be run into
the remote box leaving a 0.61 cm (2 ft) tail past the inside of the box.
Note:
When installing your system, LMI recommends a maximum
length from the control box to a detector of 61 m (200 ft).
BOTH ENDS
PIN 1-GREEN/WHITE
PIN 2-GREEN
PIN 3-ORANGE/WHITE
PIN 4-ORANGE
PIN 5-BLUE/WHITE
PIN 6-BLUE
PIN 7-BROWN/WHITE
PIN 8-BROWN
