Lumantek ez-DSK UB4 Installation guide

UB4
Quick Manual
Live CG Generator, ez-DSK UB4
Features
1. Fail Safe 2. Zero Delay 3. Re-clocking 4. Distributor and Converter
Introduction
ez-DSK is a computer graphics (CG) generator which can add user created CG’s to the
outgoing broadcast video with ease. CG’s include images, videos, sequences, texts, and
widgets, and these are overlaid to your outgoing video allowing not to waste extra video
ports.
ez-DSK has ‘Zero Delay’ transmission with ‘Fail Safe’ mechanism. In case that the device is
not working properly, CG insertion may stop, but original video will still be broadcasted.
ez-DSK comes with 1 SDI (loop) output, 4 SDI and 1 HDMI output ports, so it is a distributor
and a SDI-HDMI converter as well. All outgoing ports re-clock the videos for further reach
for better quality video broadcasting.

1. Power : Green light lit when power is inserted.
2. Alarm : Signals trouble. Blinks red light when USB3.0 is not connected or when
incoming video resolution does not match to ez-DSK resolution.
3. Lock : Green light lit when incoming video is detected.
4. USB : Green light lit when USB3.0 is connected with a computer.
System Information
[ Front ]
[ Rear ]
1
ez-DSK
1. Power switch : DC power on/off switch
2. DC power : DC power insert port (DC+7V to +18V)
3. SDI in : Incoming video port
4. Loop out : Outgoing video port (clean output)
5. SDI out : Outgoing CG video port Fail Safe
6. SDI out : Outgoing CG video port
7. HDMI out : Outgoing CG video port
8. USB3.0 : CG insert port
3
2
4 5
7
6
8

TV / Monitor
Video Switcher SDI Monitors
PC
Connection Map

Computor system requirements (minimum)
1. OS : Windows7 , Windows8 or Windows10
2. CPU : Intel i5
3. RAM : 8GB
4. VGA : GeForce GTX 1050
5. Resolution : 1920 x 1080
6. Others : USB3.0 Port
* No hardware connection required for installation. However, you need hardware connection to
use the CG software.
PC 권장사양
1. Resolution light is GREEN when system
and input resolution match (are same).
PC 권장사양
2. Resolution light is RED when the system
and input resolution do not match.
PC 권장사양
3. Resolution light is GRAY when no input
is available.
Resolution Configuration
System Res.
1080p30
1080p29.97
1080p25
1080p24
1080p23
1080i60
1080i59
1080i50
720p60
720p59
720p50
Input Display Resolution
1080p30, 1080p29.97
1080p30, 1080p29.97
1080p25
1080p24, 1080p23
1080p24, 1080p23
1080i60, 1080i59
1080i60, 1080i59
1080i50
720p60, 720p59
720p60, 720p59
720p50
System Resolution
System Resolution
System Resolution

Software Interface Configuration
파일 목록
예배 파일.hcg
새 파일
Logo CG 자막 취소
대기 화면
송출화면
추가 복사 삭제
P
예배 파일.hcg
열기 저장 새로저장 닫기
로고(오버레이) 콘텐츠 배경 홈
CUT
MIX
DOWN
UP
RIGHT
LEFTRIGHTUPDOWNMIXCUT
3.53.02.52.01.51.0
자막 송출
Connected
맨앞으로 앞으로 뒤로 맨뒤로
채우기 수직맞춤
모두 선택
수평맞춤 원래크기로
복사 삭제
편집
위젯 템플릿 편집 PIP 환경설정
12:30
이미지 동영상 시퀀스 텍스트파일 성경 찬송가
T
교독문 문자
A a
File management
파일 목록
예배 파일.hcg
새 파일
Logo CG 자막 취소
대기 화면
송출화면
추가 복사 삭제
P
예배 파일.hcg
열기 저장 새로저장 닫기
로고(오버레이) 콘텐츠 배경 홈
CUT
MIX
DOWN
UP
RIGHT
LEFTRIGHTUPDOWNMIXCUT
3.53.02.52.01.51.0
자막 송출
Connected
맨앞으로 앞으로 뒤로 맨뒤로
채우기 수직맞춤
모두 선택
수평맞춤 원래크기로
복사 삭제
편집
위젯 템플릿 편집 PIP 환경설정
12:30
이미지 동영상 시퀀스 텍스트파일 성경 찬송가
T
교독문 문자
A a
Layer page control Editing tools Editing area
Editing menu Broadcasting
control

Software Icon
- Supports images file formats. i.e. jpeg, pgn, bmp, gif.
- Supports transparent value (alpha channel) in 32 bit bmp, png, gif, and tga
formats.
- Editing area allows you to move, rotate, and change sizes while editing tools
allow you to cut or edit transparency ratio.
- Can play and stop the broadcast and control volume of the video.
- Only 1 video content per layer allowed.
- Editing area allows you to move, rotate, and change sizes while editing tools
allow you to cut or edit transparency ratio.
- Sequence files follow image file formats.
- The order of the sequences follow the order of the file names.
- Open saved text files into a page.
- There are 9 different version of the bible.
- Use ‘search’ function to find the verse you need.
T
Videos
Sequences
Text File
Bible

12:30 - Use Widgets to display current time.
- Templates become active on the lowest layer of the editing screen.
- Templates can be added or moved between layers with hot keys.
- You can use custom made templates and save them to use as needed.
- Draw lines, straight lines, squares, circles.
- After selection, color, size, shadows can be edited.
- Configure language settings, system resolution, editing area.
Ez-DSK manual is available for download on the website.
Please refer to the manual for details.
Widget
Template
Edit
Settings
