OmniCure
®
Series 1500 Quick Start Guide SIDE 1
WARNING: Never look into the light emitting end of the light guide! The light could severely damage the cornea and retina of the eye if the light is Printed in Canada
observed directly. Eye shielding must be used at all times as well as clothing to protect exposed skin. Refer to OmniCure 1500 User’s Guide, Section 3 035-00365R Rev. 1
Start-Up
1. Install the lamp module and ensure the lamp housing panel is securely
fastened (see side 2).
2. Install the light guide, remove protective end caps from the light guide
and insert the light guide into the light guide port on the front panel until it
seats with a positive click. When the power is turned on and the light
guide is properly installed the light guide LED will turn green.
3. Plug the unit into a properly grounded AC outlet.
4. Turn on the Power switch at the front of the unit. As soon as the LED
display turns on it will display the version of software currently
programmed in the S1500 (i.e. R – X). Once the software version level
has been indicated, the display will reset after several seconds to the
next display mode
5. The lamp will automatically turn on within 45 seconds and the lamp
indicator will illuminate. The display will flash during the warm up period
for approximately 4 minutes. The display will stop flashing when the
warm up period has completed. Wait until the warm up period has
completed before using the S1500 to perform an exposure
6. Allow the lamp to warm up (approximately 4 minutes). During the warm
up period the LED display and indicators will flash.
Setting the Display Mode
The OmniCure®S1500 will display 3 modes: Timer Mode, Level Mode and
Lamp Hour Mode. Press the front panel MODE button to cycle through the
display modes.
1. When the display is in Timer Mode, the number shown will indicate the
exposure time in seconds and tenth of seconds (XXX.X)
2. The OmniCure®Series 1500 system operates in the Relative output
intensity Level Mode.
Relative Mode: refers to the condition when S1500 has not been
calibrated. The display (XXX) will show the percentage of maximum
iris position.
3. When the display is in Lamp Hour Mode, this shows the accumulated
number of hours the lamp has been on. (XXXX.)
Setting the Exposure Time
1. Set the system to Timer Mode (XXX.X) by pressing the Mode button.
2. Press the UP or DOWN button to increase or decrease the exposure time by 1/10s
3. For coarse adjustments, press and hold the UP or DOWN button to rapidly
increase or decrease the exposure time.
Setting the Intensity Level
1. Set your OmniCure®S1500 to Level Mode (XXX) by pressing the Mode button.
2. Press the START /STOP button to open the shutter. The OPEN indicator will
illuminate. Warning: UV light and high levels of visible light will be emitted
from the end of the light guide!
3. Press the UP or DOWN button to increase or decrease the light output.
4. In Relative Mode, the % iris opening displayed will increase or decrease by 1 for
each time the UP or DOWN button is pressed.
5. For coarse adjustments, press and hold the UP or DOWN button to rapidly
increase or decrease the light output.
6. Press the START /STOP button to close the shutter. The OPEN indicator will turn off.
Running a Timed Exposure:
1. Set the system to Timer Mode (XXX.X).
2. Press the START /STOP button. The shutter will open and the exposure time will
begin to count down. When the exposure time has elapsed to zero, the shutter
will close.
Running an Exposure with No Timer:
1. Set the system to Intensity Mode (XXX).
2. Press the START /STOP button. The shutter will open. The shutter will remain open
until the START /STOP is pressed again.
Using the Foot pedal / Remote Device (Rear Panel: 3.5mm Jack)
1. Depressing the foot pedal, or providing a momentary contact closure, provides
the same function as pressing the START/STOP button. The shutter opens as per
the current mode (Intensity or Timer) of the unit.

OmniCure
®
Series 1500
Quick Start Guide SIDE 2
Caution eye damage may result from directly viewing ultraviolet light – protective eye shielding and clothing must be used at all times
Lumen Dynamics Group Inc. Tel: [phone]
2260 Argentia Rd. Toll Free: 1-800-668-8752
Mississauga, Ont. L5N 6H7 Fax: [phone]
www.ldgi-uv.com
Installing the Lamp Module
The OmniCure®S1500 curing system is available configured in two different
versions. One version is for standard curing and one version is for surface
curing. The appropriate type of lamp must be installed depending on which
configuration your S1500 is set.
1. Be sure the AC power cord is disconnected from the unit.
2. Remove the screw from the lamp access side panel using the tool
provided and remove the panel from the unit cover.
3. Carefully remove the lamp module from its container, holding only the
ceramic component and glass rim
4. As illustrated below, position the lamp facing towards the front of the unit
with the power leads facing towards you.
Caution: Do not touch the bulb’s glass envelope or the inside surface of
the reflector. Skin oils can cause the lamp module to fail prematurely.
5. Make sure the middle of the lamp is in position to fit into the spring
clamp. Slide the lamp until it snaps into the spring clamp. The leading
edge of the reflector should fit snugly into the lamp holder recess.
6. Locate the 4-pin Intelli-Lamp sensor connector at the rear of the lamp module
and connect it to its mate located on the top of the lamp-housing wall.
Tip: the Intelli-lamp connector will only attach in the correct orientation. If you
are having difficulty attaching the connector, try rotating it by 180º.
7. Locate the Power connector with two leads and connect it to its mate located
on the bottom of the lamp-housing wall.
Tip: the Lamp Power connector will only attach in the correct orientation. If
you are having difficulty inserting the connector, try rotating it by 180º.
8. It is very important to ensure that the lamp anode cooling fin (bar) and
lamp power lead, at the front of the lamp are centered within the lamp
holder cutout. Rotate the lamp as required.
9. Replace the lamp housing side panel and tighten the fastening screw.
Note 1: if the lamp housing panel is not secured completely, the lamp will not
strike and the “bulb” message will display when power is turned on to the unit.
Note 2: if the wrong type of lamp has been installed in your unit, the message
“E1” will appear on the LED display.
R IM
*C ENTER
LAMP POWER
LEAD AS
SHOWN*
