OmniCure® Series Quick Start Guide SIDE 1
WARNING: Never look into the light emitting end of the light guide! The light could severely damage the cornea and retina of the eye if the light is
Printed in Canada
observed directly. Eye shielding must be used at all times as well as clothing to protect exposed skin. Refer to OmniCure 2000 User’s Guide, Section 5
035-00309R Rev. 3
Start Up
1. Install the lamp module (see side 2).
2. Plug the unit into a properly grounded AC outlet.
3. Turn on the Power switch at the front of the unit.
4. The lamp will automatically strike when power is turned on to the unit.
The LAMP indicator will be illuminated.
5. Allow the lamp to warm up (Lumen Dynamics recommends 20 Minutes
of proper warm-up to ensure stable optical output). During the warm
up period the LED display and indicators will flash. THE LAMP MUST
BE ALLOWED TO WARM-UP UNINTERRUPTED.
Installing the Light Guide
1. Remove the protective end caps from the light guide
2. Insert the light guide into the light guide port on the front panel until it
seats with a positive click.
Note: When the power is turned on and the light guide is properly installed,
the light guide LED will be green.
Setting the Display Mode
The OmniCure®Series 2000 will display 3 modes: Timer Mode, Level Mode
and Lamp Hour Mode.
1. When the display is in Timer Mode, the front panel “TIMER” LED is
illuminated. The number shown will indicate the exposure time in
seconds and tenth of seconds (XXX.X)
2. When the display is in Level Mode, the front panel “LEVEL” LED is
illuminated.
The OmniCure®Series 2000 system can operate in two different
output intensity modes: Absolute or Relative.
Absolute Mode: refers to the condition when the Series 2000 has
been calibrated. The display (XX.XX) will show an absolute value
of irradiance in W/cm2and the “CAL” LED is ON.
Relative Mode: refers to the condition when Series 2000 has not
been calibrated. The display (XXX) will show the percentage of
maximum iris position and the “CAL” LED is OFF.
3. When the display is in Lamp Hour Mode, the front panel “L.HRS” LED
is illuminated. This shows the accumulated number of hours the lamp
has been on. (XXXX.)
4. Press the front panel MODE button to cycle through the display modes.
Setting the Exposure Time
1. Set the system to Timer Mode (XXX.X) by pressing the Mode button.
2. Press the UP or DOWN button to increase or decrease the exposure time by
1/10s
3. For coarse adjustments, press and hold the UP or DOWN button to rapidly
increase or decrease the exposure time.
Setting the Intensity Level
1. Set your OmniCure®Series 2000 to Level Mode (XXX)by pressing the Mode
button.
2. Press the START /STOP button to open the shutter. The OPEN indicator will
illuminate. Warning: UV light and high levels of visible light will be
emitted from the end of the light guide!
3. Press the UP or DOWN button to increase or decrease the light output.
4. In Relative Mode, the % iris opening displayed will increase or decrease by 1
for each time the UP or DOWN button is pressed.
5. In Absolute Mode, the irradiance level displayed will increase or decrease by
10mW/cm2for each time the UP or DOWN button is pressed.
Note: The Series 2000 must be calibrated to operate in Absolute Mode.
6. For coarse adjustments, press and hold the UP or DOWN button to rapidly
increase or decrease the light output.
7. Press the START /STOP button to close the shutter. The OPEN indicator will turn
off.
Running a Timed Exposure:
1. Set the system to Timer Mode (XXX.X).
2. Press the START /STOP button. The shutter will open and the exposure time will
begin to count down. When the exposure time has elapsed to zero, the shutter
will close.
Running an Exposure with No Timer:
1. Set the system to Intensity Mode (XXX).
2. Press the START /STOP button. The shutter will open. The shutter will remain
open until the START /STOP is pressed again.
Using the Footpedal / Remote Device (Rear Panel: 3.5mm Jack)
1. Depressing the footpedal, or providing a momentary contact closure, provides
the same function as pressing the START/STOP button. The shutter opens as
per the current mode (Intensity or Timer) of the unit.

OmniCure® Series 2000 Lumen Dynamics
Quick Start Guide SIDE 2
Lumen Dynamics
Tel: [phone]
2260 Argentia Rd.
Toll Free: 1-800-668-8752
Mississauga, Ont. L5N 6H7
Fax: [phone]
www.ldgi-uv.com
Installing the Lamp Module
The OmniCure®Series 2000 curing system is available configured in two
different versions. One version is for standard curing and one version is for
surface curing. The appropriate type of lamp must be installed depending on
which configuration your Series 2000 is set.
1. Be sure the AC power cord is disconnected from the unit.
2. Remove the screw from the lamp access side panel using the tool
provided and remove the panel from the unit cover.
3. Carefully remove the lamp module from its container, holding only the
ceramic component and glass rim
4. As illustrated below, position the lamp facing towards the front of the
unit with the power leads facing towards you.
Caution: Do not touch the bulb’s glass envelope or the inside surface
of the reflector. Skin oils can cause the lamp module to fail
prematurely.
5. Make sure the middle of the lamp is in position to fit into the spring
clamp. Slide the lamp until it snaps into the spring clamp. The leading
edge of the reflector should fit snugly into the lamp holder recess.
6. Locate the 4-pin Intelli-Lamp sensor connector at the rear of the lamp module
and connect it to its mate located on the top of the lamp-housing wall.
Tip: the Intelli-lamp connector will only attach in the correct orientation. If
you are having difficulty attaching the connector, try rotating it by 180º.
7. Locate the Power connector with two leads and connect it to its mate located
on the bottom of the lamp-housing wall.
Tip: the Lamp Power connector will only attach in the correct orientation. If
you are having difficulty inserting the connector, try rotating it by 180º.
8. It is very important to ensure that the lamp anode cooling fin (bar)
and lamp power lead, at the front of the lamp are centered within the
lamp holder cutout. Rotate the lamp as required.
9. Replace the lamp housing side panel and tighten the fastening screw.
Note 1: if the lamp housing panel is not secured completely, the lamp will
not strike and the “bulb” message will display when power is turned on to
the unit.
Note 2: if the wrong type of lamp has been installed in your unit, the
message “E1” will appear on the LED display.
Exposure to Mercury represents a health hazard to humans. When unpacking or
installing the lamp, always wear protective clothing and a face mask.
Rim
*Center
lamp
power
lead as
shown*
