MAGMA Light Engine Manual 57-10019
1

Regulatory Models
Lumencor utilizes regulatory model names for all certified and CE marked products. The regulatory model names are
traceable to all regulatory documentation, third party reports and certifications.
“Regulatory Model: Magma” is used as a representative model for all certified and CE marked MAGMA products.
Emissions
This equipment has been tested and found to comply with the limits of EMC directive 2014/30/EU and FCC part 15 (CISPR
11:+A1:2016). These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Safety Certifications
TÜV SÜD America, CB Certification (IEC 61010-1:2010)
TÜV SÜD America, NRTLus Certification (UL 61010-1:2012/R:2016-04)
TÜV SÜD America, cNRTL Certification (CAN/CSA-C22.2 No. 61010-1:2012/U2:2016-04)!
TÜV SÜD America, EN Certification (EN 61010-1:2010)!
CE Marking
Low Voltage Directive (2014/35/EU)
EMC Directive (2014/30/EU)
RoHS Directive (2011/65/EU+2015/863/EU)
REACH Regulation (EC) No. (1907/2006/EC)
EU Declarations of Conformity can be found at https://lumencor.com/company/compliance
For EU customers discarding end-of-life Lumencor electrical and electronic equipment: Please submit an RMA request with
“Recycle product under WEEE” in the Description of Issues field.
For disposal in countries outside of the European Union: This symbol is only valid in the European Union (EU). If you wish to
discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.
Lumencor, Inc. |14940 NW Greenbrier Parkway | Beaverton, OR 97006 USA | 503.213.4269 | www.lumencor.com!
Revision C!
011822!
MAGMA Light Engine Manual 57-10019
2
Lumencor Light Engines as supplied, and as represented in this manual, meet safety and regulatory
requirements!For Research Use Only.!If the light engine is incorporated into an instrument or system for a
specific end-use application, it is the responsibility of the system integrator to verify that the light engine, and the
system into which it is incorporated, meet all safety and regulatory requirements of that end-use application.

Table of Contents!
1. Introduction
2. Precautions and Warnings
3. Installation and Operating Instructions
4. Light Output Characteristics
5. Operational Specifications
6. Routine Maintenance and Trouble Shooting
7. Customer Support
8. Warranty
MAGMA Light Engine Manual 57-10019
3

1. Introduction
The MAGMA Light Engine consists of 21 individually addressable solid-state light sources with
integrated electronic control systems. The constituent light sources may be LEDs or luminescent
light pipes. The outputs of the constituent light sources are refined by bandpass filters and merged
into a common optical train directed to the light output port on the front panel. The light output port
has a built-in adapter for connection to an optical fiber bundle. An onboard photodiode
continuously monitors the light output and generates a reference signal that can be applied to the
constituent sources in a feedback loop to maintain constant light output over time. The light sources
within the MAGMA Light Engine are controlled by an on-board microprocessor operating Lumencor
firmware accessed via one of two serial interfaces, USB/RS-232 or TCP. The user can
independently enable or disable each source by serial commands as well as change the intensity of
each source. The MAGMA Light Engine can either be controlled by a GUI resident on the on-board
microprocessor. Alternatively, the light sources may be turned on and offby TTL inputs from a
trigger device such as a camera or real-time controller. Optimal internal operating temperature is
maintained by negative pressure air cooling with the air intake at the front of the Light Engine and
the exhaust fan at the the rear.!
MAGMA Light Engine Manual 57-10019
4

2. Precautions and Warnings {Précautions et mises en garde}
A few simple practices will ensure trouble-free operation for the life of the light engine.!
Les quelques règles simples suivantes permettront d’assurer un fonctionnement fiable pendant toute
la durée de service de la source lumineuse.!
Safety Instructions:
Please read and follow all safety instructions provided BEFORE using the MAGMA light engine®.
Failure to comply with the safety instructions may result in fire, electrical shock, or personal injury
and may damage or impair protection provided by equipment. Please save all safety instructions.!
Instructions de sécurité:
Veiller à lire et à respecter toutes les instructions de sécurité fournies AVANT d’utiliser le MAGMA
light engine®afin d’écarter les risques d’incendie, de décharge électrique, de blessure corporelle et
de possibles dommages ou défaillance de la protection offerte par l’appareil. Conserver toutes les
instructions de sécurité.!
Safety Definitions {Définitions relatives à la sécurité}:
Warning: Statements identify conditions or practices that could result in personal injury.!
Avertissement: déclarations qui identifient des situations ou des pratiques susceptibles
d’entraîner des blessures corporelles. !
Caution: Statements identify conditions or practices that could result in damage to your equipment. !
Attention: déclarations qui identifient des situations ou des pratiques susceptibles d’endommager le
matériel.!
Safety Items {Mesures de sécurité}:
Warning: ONLY use the power supply provided by Lumencor. The Lumencor-supplied 24 VDC,
9.2 A external power supply is required for use with the MAGMA Light Engine. The light engine is
required to be supplied by an approved/certified DC power source meeting the minimum electrical
ratings of the product. The DC power supply must have the AC power cord connected to a
receptacle with a protective safety (earth) ground terminal.!
MAGMA Light Engine Manual 57-10019
5

Avertissement: utiliser uniquement l'alimentation fournie par Lumencor. Le Lumencor fourni 24
VDC/9.2 A alimentation externe est recommandé pour une utilisation avec le moteur de lumière
MAGMA . Le moteur léger doit être alimenté par une source d'alimentation CC approuvée/certifiée
répondant aux caractéristiques électriques minimales du produit. L'alimentation CC doit avoir le
cordon d'alimentation CA connecté à une prise avec une borne de terre de sécurité (terre).!
Warning: DO NOT look into the output of the light engine. The brightness of this light source is
higher than most commercial lighting fixtures and is intended to couple directly into a microscope or
other bioanalytjcal instrument.!
Avertissement: NE PAS regarde directement la sortie de la source lumineuse. L’intensité
lumineuse de cette source est supérieure à celle de la majorité des appareils d’éclairage disponibles
dans le commerce et est conçue pour un raccordement direct à un microscope ou autre appareil de
bioanalyse.!
Warning: DO NOT turn on the light without!the output end of the light guide
safely!directed!into an enclosed optical path. #DO NOT point the light output directly onto any
flammable or burn-susceptible material.#This includes all animal or vegetable tissues, plastics,
fabrics, paper and liquids.!
Avertissement: NE PAS allumer la lumière sans l'extrémité de sortie du guide de lumière
dirigée en toute sécurité dans un chemin optique fermé. NE PAS pointer la sortie de lumière
directement sur un matériau susceptible d'être inflammable ou susceptible de brûler. Cela comprend
tous les tissus, les plastiques, les tissus, le papier et les liquides animaux ou végétaux.!
RISK GROUP 3
Warning: Possibly hazardous optical radiation emitted from this product. Do not look at operating
lamp. Eye injury may result. !
Warning: Infrared (IR) emitted from this product. Do not look at operating lamp.!
MAGMA Light Engine Manual 57-10019
6

Warning: UV emitted from this product. Avoid eye and skin exposure to unshielded product.!
GROUPE DE RISQUE 3
Avertissement: Infrarouge (IR) émise par ce produit. Ne regardez pas la lampe d'exploitation.!
Avertissement: Rayonnement optique Peut-être dangereux émis par ce produit . Ne regardez pas
la lampe d'exploitation. Une blessure oculaire peut entraîner.!
Avertissement: UV émis par ce produit . Évitez les yeux et la peau exposition au produit non blindé.!
Caution: DO NOT open the unit. There are no serviceable parts inside and opening the light engine
enclosure will void the manufacturer’s warranty.!
Attention: NE PAS ouvrir l’appareil. Il ne contient aucune pièce réparable et l’ouverture de son
boîtier a pour effet d’annuler la garantie.!
Caution: DO NOT set liquids on the light engine. Spilled liquids may damage your light engine.!
Attention: NE PAS placer de liquide sur la source lumineuse. Les liquides renversés peuvent
endommager la source lumineuse.!
Caution: DO NOT drop the light engine. It contains glass optical components that could be
damaged or misaligned by the shock produced by a drop onto a hard surface.!
Attention: NE PAS laisser tomber la source lumineuse. Elle contient des composants optiques en
verre susceptibles d’être endommagés ou désalignés par le choc résultant d’une chute sur une
surface dure.!
DISCLAIMER: Lumencor shall not be liable for injury to the user or damage to the product
resulting from the MAGMA light engine®being used in a way for which it was not intended and
in complete disregard for any posted safety precautions and warnings.
AVIS DE NON-RESPONSABILITÉ: Lumencor décline toute responsabilité pour les blessures
corporelles ou les dommages au produit résultant d’une utilisation du MAGMA light engine
autre que celle prévue et du mépris total de les mesures de sécurité et mises en garde
affichées.
MAGMA Light Engine Manual 57-10019
7

3. Installation and Operating Instructions
3.1 Contents
The MAGMA Light Engine ships with the following list of standard components:!
1. The MAGMA Light Engine, configured with 21 output channels (colors) and an output adapter
for an optical fiber bundle as documented on the certificate of conformance (Figure 1).!
2. A 24 V/9.2 A DC power supply (Lumencor part number 27-10019).!
3. A region-specific AC power cord for the power supply (see
adjacent table).!
4. RJ45 ethernet cable.!
5. Control key, external gate jumper and remote interlock jumper
(Figure 2).!
6. Quickstart Guide instruction document (85-10049)!
The model name, unique 4- or 5- digit serial number
MAGMA Light Engine Manual 57-10019
8
AC Power Cords
Region
Part Number
North America
29-10002
Europe
29-10005
United Kingdom
29-10004
Israel
29-10008
Australia/New Zealand
29-10024
Figure 2. Control key, remote interlock jumper and external
gate jumper. These items are packed in a plastic bag inside
the shipping box. Their functions are described in Section
3.3.1
EXAMPLE
Figure 1. Example certificate of conformance (C of C) for MAGMA
Light Engine. The C of C identifies the color channels installed in the
light engine and the bandpass filters associated with each channel.
Full (100%) power outputs measured at the terminus of the fiber
bundle are recorded in the third column.

and certification markings of the light engine are carried on a
label affixed to the rear panel . Performance specifications
for individual light engines are listed on the certificate of
conformance included with the shipping documents e-mailed
to the customer (Figure 1).!
3.2 Installation
NOTE: Any end-product/system incorporating or coupled to
a Lumencor Light Engine shall be fully evaluated to verify all
applicable safety and regulatory compliance requirements
prior to use.!
When setting the MAGMA Light Engine up for use, place the
unit on a hard surface and avoid blocking or restricting
airflow at the air inlets (front panel; Figure 3) or exhaust ports
(rear panel) on the enclosure. Restricting the airflow will
cause the unit to operate at elevated temperatures and will
result in decreased product life and/or premature failure.!
The MAGMA Light Engine must be operated in a non-
condensing environment (dew point <10ºC with controlled
ambient temperature <30º C). Thermal overload protection
is provided by the onboard microprocessor in conjunction
with an onboard temperature sensor. If the internal
temperature registered by the sensor exceeds 50°C or the
fan rotor is stopped, all light output channels automatically
turn OFF and are locked in this state until the internal
temperature is below 50°C and/or the fan restarts. The
current reading of the onboard temperature sensor is
displayed on the front panel status display (Figure 3) and in
the Control GUI (Section 3.3.3)!
Connect the DC power supply to a grounded AC wall
outlet using the power cord supplied with the light engine.
Connect the DC output to the 6-pin receptacle on the front
of the light engine (Figure 3). Turn the light engine on using
the master power switch. The embedded green indicator
will illuminate (if applicable, ensure that the liquid light
MAGMA Light Engine Manual 57-10019
9
Figure 4. MAGMA Light Engine rear panel.
Remote interlock
connector (with
jumper installed)
Figure 3. MAGMA Light Engine front panel
Output
coupler,
LLG

guide is inserted and secured; see below).!
The MAGMA Light Engine may be configured for light delivery via a 3 mm liquid light guide or an
SMA-terminated optical fiber. The output couplers are built into the light engine front panel and are
not field-exchangeable (Figure 3). The 3 mm liquid light guide output coupler incorporates an
electrical power interlock switch in the back of the receptacle. The liquid light guide must be fully
inserted in the receptacle to activate the interlock. Electrical power supply to the light engine cannot
be turned on via front panel power switch until the interlock is activated. After fully inserting the
liquid light guide, lock it in position using the set screw on the side of the receptacle to prevent
inadvertent disconnection of the light guide during use.!
3.3 Operation
3.3.1 Controls and Interlocks
The Master Power Switch button on the front panel (Figure 3) turns the electrical power to the unit
on or off. A green power indicator embedded in the button is lit when the power supply is
connected to the light engine and the power button is in the on position. Initialization of the onboard
computer takes about 30 seconds after the master power switch is turned on. When initialization is
complete, the status indicator display (Figure 3) will activate.!
The Key Control (Figure 3) must be in the on position before light output can be turned on. The key
must be removed and stored in a secure location when the product is not in use. ONLY trained
individuals should use and have access to the key. The Master Power Switch button, Key control
and Remote interlock (Figures 3,4) can be used to shut offlight output.!
The Source Enabled indicator LED (below the status indicator display, Figure 3) provides a warning
indication that one or more light sources are active and emitting invisible and/or visible radiation.!
The Remote Interlock Connector: (Figure 4) is provided to allow for connection of a remote
interlock. When this interlock is open it will shut offlight output. After the interlock has been
opened, the Manual Reset button will need to be pushed to resume light output.!
WARNING:#The Remote Interlock relies on a passive continuity circuit for proper operation.#It does
not provide a voltage source for external circuitry, nor can external voltage sources be applied to it.
UNDER NO!CIRCUMSTANCES should a voltage or voltage source be applied to the Remote
Interlock circuit.##APPLYING A VOLTAGE OF EITHER POLARITY MAY RESULT IN ANOMALOUS
OPERATION AND/OR DAMAGE THE PRODUCT, AND COULD IMPACT SAFETY.
MAGMA Light Engine Manual 57-10019
10

Customers planning to connect multiple Light Engine remote interlocks together will need to contact
Lumencor prior to integration.#INTERCONNECTING LIGHT ENGINES OR USING THE REMOTE
INTERLOCK INCORRECTLY CAN RESULT IN ANOMALOUS BEHAVIOR AND/OR DAMAGE TO
THE PRODUCTS.!
AVERTISSEMENT!:#Le verrouillage à distance repose sur un circuit de continuité passif pour un
fonctionnement correct. Il ne fournit pas de source de tension pour les circuits externes, et aucune
source de tension externe ne peut lui être appliquée. EN AUCUN CAS, une tension ou une source
de tension ne doit être appliquée au circuit de verrouillage à distance. L'APPLICATION D'UNE
TENSION DE POLARITÉ OU DE POLARITÉ PEUT ENTRAÎNER UN FONCTIONNEMENT
ANOMAL ET/OU ENDOMMAGER LE PRODUIT, ET POURRAIT AVOIR UN IMPACT SUR LA
SÉCURITÉ.
Les clients prévoyant de connecter plusieurs verrouillages à distance Light Engine ensemble devront
contacter Lumencor avant l'intégration. L'INTERCONNEXION DE MOTEURS LÉGERS OU
L'UTILISATION INCORRECTE DU VERROUILLAGE À DISTANCE PEUT ENTRAÎNER UN
COMPORTEMENT ANOMAL ET/OU ENDOMMAGER LES PRODUITS.
WARNING: Prior to turning the light output on, be sure the output end of the liquid light guide or
optical fiber is safely directed into an enclosed optical path (e.g. a beam dump).!
AVERTISSEMENT!: avant d'activer la sortie de lumière, assurez-vous que l'extrémité de sortie du
guide de lumière liquide ou de la fibre optique est dirigée en toute sécurité dans un chemin optique
fermé (par exemple, une décharge de faisceau).!
Note: In the event of ANY normal or abnormal interlock fault condition (including high ESD/EMP/EFT
conditions ~2kV) you MUST clear the latch fault condition, either by depressing the manual reset
button or by cycling the power switch.!
the manual reset button.!
3.3.2 Start Up
1. Insert the light guide and secure it with the set screw .!
i
2. Insert the external gate jumper (Figure 2) in the labeled socket on the front panel (Figure 3). Insert
the interlock jumper in the labeled socket in the lower left corner of the rear panel (Figure 4).!
ii
3. Insert the control key, turn it to the ON position.!
4. Connect the isolated DC power supply to the light engine.!
5. Connect the AC power cord to the DC power supply.!
MAGMA Light Engine Manual 57-10019
11

6. As soon the DC power supply is energized, the master power button (top right) will automatically
light up.#The light engine automatically starts when the power is connected; there is no need to
push the master power button .!
iii
7. Wait 30–45 seconds for the initiation sequence (onboard microprocessor boot-up) to complete.#
Do not press any buttons or insert any plugs during this time.!
8. When the initiation sequence completes, “LUMENCOR” will flash on front display panel and then
be replaced by a display showing the current light engine IP address, the internal temperature
and the fan status.#At the same time, the fan will come on at HI for about 2 seconds and then
shut offautomatically. The light engine is now ready for use. Prior to turning the light output on,
verify the output end of the liquid light guide or optical fiber is safely directed into an enclosed
optical path (e.g. a beam dump).!
Notes:
1Ensure that the distal end of the light guide or optical fiber is safely directed into an enclosed
optical path (e.g. microscope epi-illuminator or a beam dump) before turning the light output on. If
the light engine is equipped with an output adapter for an SMA-terminated optical fiber, connect the
fiber to the output adapter using the integral threaded sleeve. !
2To enable light output of the MAGMA Light Engine the external gate jumper, control key, remote
interlock jumper, and Liquid light guide must be inserted. !
3For subsequent start ups, use the master power button to start or shut down the light engine.
Shut down can also be accomplished using the “Shut Down” button in the GUI (Figure 5, left).!
3.3.3 Ethernet Connection and Control GUI
The Web GUI provides a quick and easy way to control the light engine, providing the ability to turn
each source on/off, adjust the power of each source independently from offto full power (Figure 5).
The GUI also tracks the total on time and displays real-time power sensor readings. To set up the
Web GUI, follow the follow protocol below:!
1. Go to Start menu > Control Panel > Network & Internet and/ or Network & Sharing Center!
2. Click Change Adapter Settings!
3. Right-click on Local Area Connection!
4. Click on Properties (in pop-up)!
5. Select Internet Protocol Version 4 (TCP/IPv4)!
6. Click Properties button!
7. Use the following IP addresses:!
%IP Address: 192.168.201.201!
%Subnet Mask: 255.255.255.0!
%Default gate way and DNS Server are OK to leave blank!
MAGMA Light Engine Manual 57-10019
12

8. Connect the RJ45 cable (supplied with the light engine) between the LAN port on the light engine
and an ethernet port on the computer.!
9. Type the Light Engine IP address (Figure 3) into any web browser address bar to access the
resident Web GUI. The factory default IP address is 192.168.201.200!
Output power regulation allows users to eliminate variations in light output due to temperature
fluctuations and other environmental factors in photometric and quantitative imaging applications
where reproducibility and accuracy are essential. To use power regulation, a desired power reference
value in milliwatts is entered in the onboard control GUI. To activate power regulation, simply click
the padlock icon next to the reference power value. Gray shading of the padlock icon and the
reference power value shows that power regulation is active for the selected output channel. When
power regulation is active, the intensity setting for the channel is controlled by the onboard
microprocessor, based on feedback from the light engine’s reference photodiode array. The
microprocessor continuously adjusts the intensity setting so that the output power matches the
power reference value set by the user.!
3.3.4 Control via Serial Ports
MAGMA Light Engine have two serial ports, labeled USB and RS-232 (Figure 3), which can be set to
receive either LEGACY or STANDARD mode commands. Connection to the computer requires a
USB-A-to-USB B cable (29-10058) or USB-to-RS-232 cable (29-10011). LEGACY commands are
limited to controlling on/offswitching and intensity adjustment of individual color channels. Only one
of the two ports can be set to LEGACY mode at one time. The STANDARD mode command set
MAGMA Light Engine Manual 57-10019
13
Figure 6. MAGMA GUI, Settings Tab. The GUI is
accessed by typing the light engine IP address
(198.168.201.200 in this example) into a web browser.
Figure 5. MAGMA GUI, Control Tab. The GUI is
accessed by typing the light engine IP address
(198.168.201.200 in this example) into a web browser.

gives access to an extensive panel of operating status reports and configuration settings in addition
to the the basic control functions of the LEGACY command set. A complete listing of STANDARD
mode commands is provided in Lumencor Light Engine Command Reference (Document number
57-10018). Note that LEGACY and STANDARD mode communications use different serial protocols
(9600,8,N,1 and 115200,8,N,1 respectively). Changes to the command mode setting for a serial port
can be made via the Settings screen of Web GUI (Figure 6). Changes are applied instantaneously
and are retained between power cycles.!
In the Web GUI, select the serial port command mode setting that is compatible with the light engine
device driver in the control software. The COM port address assigned by the computer to the light
engine USB serial port must be correctly registered. These selections are typically found under the
“Devices” tab in the control software.!
3.3.6 TTL Control
The TTL Interface provides users with a faster method of switching color channel outputs on and off.
The TTL interface does not control source output intensity, which remains under serial (RS-232/USB/
TCP) control. Note that TTL and serial on/offcommands have a logical OR relationship. Therefore
source on/offcontrols on the light engine control pod, in the Web GUI or in third-party image
acquisition control software must be set in the “OFF” state when using TTL control. Individual TTL
inputs are provided for each color channel, as shown in the adjacent table. As a safeguard against
unintended light output when the inputs are initially connected, the
light engine TTL port is disabled and must be enabled by a serial
command. To enable the TTL input, click the Enabled button next to
“TTL inputs” in the GUI under the Settings tab (Figure 6) or send the
standard mode command SET TTLENABLE to the LAN port. Input
TTL signals can be conveniently addressed using an accessory BNC
breakout cable (Lumencor part no. 29-10240) connected to the front
panel TTL port. The breakout cable also provides a global shutter
input (labeled “shutter”). TTL signals input to the global shutter will
synchronously toggle all currently enabled source channels on and
off.!
4. Light Output Characteristics
MAGMA Light Engine may incorporate different types of solid state light sources. Constituent light
sources may include LEDs or luminescent light pipes. The light sources installed and the bandpass
filters associated with each are shown on the Certificate of Conformance included with the shipping
documents e-mailed by Lumencor to the customer. The certificate of conformance also shows full
(100%) power outputs for each source measured at the terminus of the optical fiber bundle (Figure
MAGMA Light Engine Manual 57-10019
14
TTL Connector Pin Definitions
OUTPUT
COLOR
Pin#
OUTPUT
COLOR
Pin#
RED
1
BLUE
12
GREEN
2
VIOLET
13
CYAN
3
nIR
14
TEAL
11
YELLOW
15
Gnd
6,7,8,10
Vihigh (min) = 2.0V, Vihigh (max) = 5.5V
Vilow (min) = 0.0V, Vilow (max) = 0.8V

1). Not all sources may be turned on simultaneously. To prevent exceeding the capacity of the DC
power supply, power consumption is tracked by the onboard microprocessor. If a set limit (see
Governor, Figure 5) is exceeded, either by increasing intensity settings for sources that are already
on, or by turning on additional sources, all light output is terminated and an error message will be
displayed on the control screen. To clear the error condition, click on the System tab in the GUI and
then click the Restart button under Governor.!
Light source outputs are refined by bandpass filters. The specifications of these bandpass filters are
recorded on the certificate of conformance as CWL/FWHM where CWL =center wavelength and
FWHM = full width at half-maximum transmission, both measure in nanometers (nm). In
fluorescence microscopy applications, it is usual to remove the exciter from the microscope filter
cube to facilitate fast electronic excitation switching. Compatibility of the bandpass filters with the
transmission characteristics of the dichroic beamsplitter and emission filter in the microscope cube
is required to maximize transmission of excitation light to the sample and to avoid excitation bleed-
through. Bandpass filters installed in the MAGMA are not user-exchangeable. Changes to the filter
configuration require return of the light engine to Lumencor’s factory for service (see Section 7).
Since changing bandpass filters will result in source output power changes, a new certificate of
conformance will be provided as part of this service.!
5. Operational Specifications
The MAGMA Light Engine must be operated and stored within the environmental conditions
specified in the table below. Performance specifications for individual light engines are listed on the
certificate of conformance included with the shipping documents e-mailed to the customer (see
example shown in Figure 1). It is important to retain the certificate of conformance for reference. In
the event that the light engine is sold, the certificate of conformance should be transferred to the
new owner. Certificates of conformance are also recorded in Lumencor’s database and copies can
be requested by e-mail to [e-mail]. The request message must include the 5-
digit serial number of the light engine.!
Specification
Detail
Temperature
Operating
32 to 95° F (0 to 35° C)
Non-operating
-4 to 158° F (-20 to 70° C)
Humidity
Operating and non-operating
0 to 80% relative humidity, non-condensing¹
Dew Point
Operating
32 to 59° F (0 to 15° C)
Altitude
Operating
0 to 10,000 feet (3,048 meters)
MAGMA Light Engine Manual 57-10019
15

6. Routine Maintenance and Troubleshooting
No routine maintenance is required. There are no user-replaceable components or sub-assemblies
in the MAGMA Light Engine. Opening the light engine enclosure will void the manufacturer’s
warranty. If problems are encountered during installation or routine operation, review the
troubleshooting procedures described below. If the problem remains unresolved, please contact
Lumencor Technical Support for assistance, as directed in Section 7.!
Non-operating
0 to 45,000 feet (13,176 meters)
Dimensions
Size (W x L x H)
145 mm x 340 mm x 203 mm (5.7 in x 13.4 in x 8.0 in)
Weight
8.7 kg /19.1 lbs
Lifetime
Time for light engine output to decrease to 70% of the values recorded on
the original certificate of conformance𝟤
Power supply
24VDC / 9.2A
Warm-up Period
1 s
Protection
Thermal overload (Section 3.2). Power overdraw (Section 4)
Sound Level
Sound level at 1 meter < 65db(A)
Control Interfaces
USB, RS-232, TCP, TTL
Warranty
24 months parts and labor
¹The MAGMA light engine must be operated in a non-condensing environment.
𝟤The corresponding number of days/months/years may vary considerably depending on the duty cycle
implemented by the user and the prevailing environmental conditions during operation.
Specification
Detail
Troubleshooting Procedures
Problem
Check the following
No response to serial (USB or
RS-232) commands
Check that the LEGACY or STANDARD command mode selection (GUI
Settings; Figure 5) is compatible with the software driver.
No response to TTL trigger
commands
Check that TTL inputs are ENABLED (GUI Settings; Figure 6) and that
the TTL polarity setting is consistent with the trigger inputs. Also check
that all serial ON/OFF controls are in the OFF state.
No light output in response to
source ON command (serial or
TTL).
There are 4 interlocks that need to be closed, check all of these:!
1. Liquid light guide must be inserted in light output receptacle¹.!
2. Remote interlock jumper must be inserted in rear panel¹.!
3. External gate jumper must be inserted in front panel (Figure 3).!
4. Control key must be inserted in front panel and turned to “on”
position¹.
Unusually weak fluorescence
signals across all detection
channels
Weak fluorescence in all detection channels (DAPI, FITC, TRITC, Cy5 etc)
is likely to be due to poor light transmission by the liquid light guide, the
collimating adaptor or another distal component of the microscope
optical path and not to abnormally low light output from the light engine.
MAGMA Light Engine Manual 57-10019
16

7. Customer Support
For technical support of the MAGMA Light Engine, please contact Lumencor by phone at
503-213-4269 or through e-mail at [e-mail]. Please be prepared to provide the
5-digit serial number of the light engine. Any light engine returned to Lumencor for repairs or
upgrades requires a pre-issued return material authorization (RMA) number. To request an RMA
number, fill out and submit the online request form. It is the customer’s responsibility to properly
package and safely ship products to Lumencor. Instructions for shipping will be provided in the e-
mail giving notification of the RMA number.!
8. Warranty
MAGMA Light Engine come with an 24 month warranty, starting on the original date of shipment
from Lumencor. Light Engines qualifying for warranty service must be verifiably delivering
performance that is substantially at variance with the levels documented in the certificate of
conformance. The light engine must also have been used and maintained under operating
conditions consistent with the specifications given in Section 5, and observing all the Precautions
and Warnings notified in Section 2. This warranty does not extend to light engines that have been
subject to misuse, accident, tampering or improper installation. Accessories including (but not
limited to) liquid light guides, optical fibers, collimators, cables and control consoles are not covered
by the warranties attached to light engines. Please fill out and submit the online warranty
registration form . This will facilitate provision of warranty service should it be required.!
Unusually weak fluorescence
signals in a single detection
channel (e.g. DAPI)
1. Check that the light engine power output reading in the Web GUI
(Figure 5) is normal.!
2. Check that the dichroic beamsplitter and emission bandpass filter in
the microscope are compatible with light engine excitation filter
specifications shown on the certificate of conformance (Figure 1)².
High, spatially uniform
fluorescence background
Check that the dichroic beamsplitter and emission bandpass filter in the
microscope are compatible with light engine excitation filter
specifications shown on the certificate of conformance (Figure 1)².
¹If a safety interlock is open, the condition will be indicated by a red status indicator in the lower right corner
of the GUI control screen (Figure 5).!
²Excitation filters are installed in the light engine. Excitation filters installed in the microscope cube are
generally redundant and it is recommended that they are removed.
MAGMA Light Engine Manual 57-10019
17
