RS154 - OIP-D50C Telnet_RS-232 command set
OIP-D50C Telnet_RS-232 command set
No
Issue Date
Description
Apply Firmware
1
2021/07/26
First Version.
v0.36L
2
2021/09/03
Correct the commands.
*Notice:
1. The Telnet_RS-232 command list is for OIP-D50C
2. The yellow highlight means the latest update.
3. The blue highlight means the deleted item.

RS154 - OIP-D50C Telnet_RS-232 command set
Before attempting to use Telnet control, please ensure that both the unit and the PC are
connected to the same active networks.
To Access the Command Line Interface (CLI)
Windows 10
Windows 7
Click Start, type “cmd” in the search field, and press Enter.
Windows XP
Click Start > Run, type “cmd”, and press Enter.
Mac OS X
Click Go > Applications > Utilities > Terminal.
Once in the Command Line Interface (CLI) type “telnet” followed by the IP address of the unit
(and the port number if it is non-standard) and then hit “Enter”. This will connect us to the
unit we wish to control.
<Note 1> By default the unit will obtain the LAN 2 IP address via DHCP. If you are unsure of
the unit’s current LAN 2 IP address, please check the unit’s HDMI status display.
<Note 2> If the unit's IP address is changed then the IP address required for Telnet access will
also change accordingly.
<Note 3> Commands will not be executed unless followed by a carriage return. Commands
are not case-sensitive.

RS154 - OIP-D50C Telnet_RS-232 command set
Command
Command
Description and Parameters
help
Show the full command list.
Help N1
Show help details about command N1.
N1 = {Command}
?
Show the full command list.
? N1
Show help details about command N1.
N1 = {Command}
get fw ver
Show the unit’s current firmware version.
set factory default
Reset the unit to the factory defaults.
get command ver
Show the unit’s current command version.
get model name
Show the unit’s model name.
get model type
Show the unit’s product type.
get mac N1 addr
Show the MAC address of the specified LAN port.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
set factory ipconfig default
Reset the unit’s network settings to the factory defaults.
set system reboot
Reboot the unit.
set lan N1 ip mode N2
Set the IP address assignment mode of the specified LAN port.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
Available values for N2:
Static [Static IP mode]
DHCP [DHCP mode]
get lan N1 ip mode
Show the current IP address assignment mode of the specified LAN
port.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
get lan N1 ipconfig
Show the specified LAN port’s current IP configuration information.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
get lan N1 ipaddr
Show the specified LAN port’s current IP address.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
get lan N1 netmask
Show the specified LAN port’s current netmask.
Available values for N1:

RS154 - OIP-D50C Telnet_RS-232 command set
1 [OIP LAN]
2 [CTRL LAN]
get lan N1 gateway
Show the specified LAN port’s current gateway address.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
set lan N1 static ipaddr N2
Set the specified LAN port’s static IP address.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
N2 = X.X.X.X [X = 0~255, IP address]
get lan N1 static ipaddr
Show the specified LAN port’s current static IP address.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
set lan N1 static netmask N2
Set the specified LAN port’s static netmask.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
N2 = X.X.X.X [X = 0~255, netmask]
get lan N1 static netmask
Show the specified LAN port’s current static netmask.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
set lan N1 static gateway N2
Set the specified LAN port’s static gateway address.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
N2 = X.X.X.X [X = 0~255, gateway address]
get lan N1 static gateway
Show the specified LAN port’s current static gateway address.
Available values for N1:
1 [OIP LAN]
2 [CTRL LAN]
get uart list
List all available serial ports.
set uart N1 reset
Reset the specified serial port’s settings to the factory defaults.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
set uart N1 baudrate N2
Set the baud rate of the specified serial port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]

RS154 - OIP-D50C Telnet_RS-232 command set
Available values for N2:
2400 [2400 baud]
4800 [4800 baud]
9600 [9600 baud]
19200 [19200 baud]
38400 [38400 baud]
57600 [57600 baud]
115200 [115200 baud]
get uart N1 baudrate
Show the current baud rate of the specified serial port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
set uart N1 stop bit N2
Set the number of stop bits for the specified serial port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
Available values for N2:
1 [1 stop bit]
2 [2 stop bits]
get uart N1 stop bit
Show the current number of stop bits for the specified serial port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
set uart N1 data bit N2
Set the data bits used by the specified serial port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
Available values for N2:
7 [7 data bits]
8 [8 data bits]
get uart N1 data bit
Show the current number of data bits used by the specified serial
port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
set uart N1 parity N2
Set the parity of the specified serial port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
Available values for N2:
0 [None]
1 [Odd]
2 [Even]

RS154 - OIP-D50C Telnet_RS-232 command set
get uart N1 parity
Show the current parity setting of the specified serial port.
Available values for N1:
1 [3-pin serial port]
2 [5-pin serial port]
set uart 2 mode N1
Set the operational mode of the Control Output (5-pin) serial port.
Available values for N1:
0 [Disabled]
1 [RS-232 mode]
2 [RS-422 mode]
3 [RS-485 mode]
get uart 2 mode
Show the current operational mode of the Control Output (5-pin)
serial port.
set uart 2 command [N1]
Transmit the specified command data via the Control Output
(5-pin) serial port.
N1 = {Command data} [ASCII text]
Note: To transmit hex data, each ASCII hex pair (octet) must be
preceded by “\x”. For example a carriage return would be “\x0D”.
set voip N1 audio out oN2 route
N3 n4
Route the specified Encoder's audio input to the specified
Decoder's audio output.
N1 = rx1~rx256 [Decoder device ID]
Available values for N2:
1 [HDMI audio output]
2 [Analog audio output]
N3 = tx1~tx128 [Encoder device ID]
Available values for N4:
1 [HDMI audio input]
2 [Analog audio input]
Note: The values for N2 and N4 must match.
set all voip audio out oN1 route
N2 N3
Route the specified Encoder's audio input to all Decoders’audio
outputs.
Available values for N1:
1 [HDMI audio output]
2 [Analog audio output]
N2 = tx1~tx128 [Encoder device ID]
Available values for N3:
1 [HDMI audio input]
2 [Analog audio input]
Note: The values for N1 and N3 must match.
set tx N1 uart 1 command [N2]
Transmit the specified command data via the serial port on the
specified Encoder.
N1 = 1~128 [Encoder device ID]
N2 = {Command data} [ASCII text]
Note: To transmit hex data, each ASCII hex pair (octet) must be

RS154 - OIP-D50C Telnet_RS-232 command set
preceded by “\x”. For example a carriage return would be “\x0D”.
set rx N1 uart 1 command [N2]
Transmit the specified command data via the serial port on the
specified Decoder.
N1 = 1~256 [Decoder device ID]
N2 = {Command data} [ASCII text]
Note: To transmit hex data, each ASCII hex pair (octet) must be
preceded by “\x”. For example a carriage return would be “\x0D”.
set all tx uart command [N1]
Transmit the specified command data via the serial port on all
Encoders.
N1 = {Command data} [ASCII text]
Note: To transmit hex data, each ASCII hex pair (octet) must be
preceded by “\x”. For example a carriage return would be “\x0D”.
set all rx uart command [N1]
Transmit the specified command data via the serial port on all
Decoders.
N1 = {Command data} [ASCII text]
Note: To transmit hex data, each ASCII hex pair (octet) must be
preceded by “\x”. For example a carriage return would be “\x0D”.
set voip N1 uart route N2
Route the specified Encoder or Decoder’s serial port Rx pin to the
serial port Tx pin on the specified Encoder or Decoder.
Available values for N1:
tx1~tx128 [Encoder device ID (Tx pin)]
rx1~rx256 [Decoder device ID (Tx pin)]
Available values for N2:
tx1~tx128 [Encoder device ID (Rx pin)]
rx1~rx256 [Decoder device ID (Rx pin)]
set all voip uart route N1
Route the specified Encoder or Decoder's serial port Rx pin to all
AVoIP devices’serial port Tx pins.
Available values for N1:
tx1~tx128 [Encoder device ID]
rx1~rx256 [Decoder device ID]
set tx N1 ir 1 command [N2]
Transmit the specified IR data via the IR output on the specified
Encoder.
N1 = 1~128 [Encoder device ID]
N2 = {IR ASCII hex data} [Pronto format IR data]
set rx N1 ir 1 command [N2]
Transmit the specified IR data via the IR output on the specified
Decoder.
N1 = 1~256 [Decoder device ID]
N2 = {IR ASCII hex data} [Pronto format IR data]
set all tx ir command [N1]
Transmit the specified IR data via the IR outputs on all Encoders.
N1 = {IR ASCII hex data} [Pronto format IR data]
set all rx ir command [N1]
Transmit the specified IR data via the IR outputs on all Decoders.
N1 = {IR ASCII hex data} [Pronto format IR data]

RS154 - OIP-D50C Telnet_RS-232 command set
set voip N1 ir route N2
Route the specified Encoder or Decoder’s IR input to the IR output
on the specified Encoder or Decoder.
Available values for N1:
tx1~tx128 [Encoder device ID (IR output)]
rx1~rx256 [Decoder device ID (IR output)]
Available values for N2:
tx1~tx128 [Encoder device ID (IR input)]
rx1~rx256 [Decoder device ID (IR input)]
set all voip ir route N1
Route the specified Encoder or Decoder’s IR input to all AVoIP
devices' IR outputs.
Available values for N1:
tx1~tx128 [Encoder device ID (IR input)]
rx1~rx256 [Decoder device ID (IR input)]
set voip N1 usb device o1 route
N2 1
Route the specified AVoIP device's USB device to the specified
AvoIP device's USB host.
Available values for N1:
tx1~tx128 [Encoder device ID (USB device)]
rx1~rx256 [Decoder device ID (USB device)]
Available values for N2:
tx1~tx128 [Encoder device ID (USB host)]
rx1~rx256 [Decoder device ID (USB host)]
set video wall preset N1
Execute the specific video wall configuration.
N1 = 1~128 [Video wall group ID]
set multiview preset N1
Execute the specific multiview preset.
N1 = 1~128 [Multiview preset ID]
set macro N1 run
Execute the specified macro immediately.
N1 = 1~16 [Macro ID]
