Lumiax Epoch Series User manual

User Manual_Epoch series_ML
CE, Rohs, ISO9001:2015
Subject to change without notice!
User Manual
Epoch Series
Pure Sine Wave Inverter

Contents
1. ...............................................................................1
1.1 ...........................................................................................................................................1
1.2 Liability Exclusion.............................................................................................................................................1
1.3 Safety precautions...........................................................................................................................................1
2.Overview......................................................................................................................................2
3.Dimensions..................................................................................................................................3
4.Structure & Operations..............................................................................................................4
4.1 Structure & Characteristics...........................................................................................................................4
4.2 RS232...................................................................................................................................................................4
4.3 Mode Switch......................................................................................................................................................4
5.Desinations of Models...............................................................................................................4
6.Installation...................................................................................................................................5
6.1 Installation Notes.............................................................................................................................................5
6.2 Mounting Location Requirements.............................................................................................................6
6.3 Wiring Specifications......................................................................................................................................6
7.LED................................................................................................................................................7
8.Troubleshooting, Protections and maintenance....................................................................7
8.1 Protection...........................................................................................................................................................7
8.2 Troubleshooting...............................................................................................................................................8
8.3.Maintenance......................................................................................................................................................8
9. Technical Data............................................................................................................................9
Safety instructions and waiver of liability
Safety Instructions

1
1, Safety instructions and waiver of liability
Dear Clients,
Thank you for purchasing our Epoch Series inverter. Your support and trust in us are much appreciated. Please
take time to read this manual, this will help you make full use of the many advantages this inverter. This manual
presents important recommendations for installing and operating. Read it with special care in your own interest
and please pay attention to the safety recommendations herein indicated.
1.1Safety Instructions
Please reserve this manual for future review.
The following symbols are used throughout this manual to indicate potentially dangerous conditions or
mark important safety instructions. Please take care when meeting these symbols.
1.2 Liability Exclusion
The manufacturer shall not be liable for damages, especially on the battery, caused by use other than as
intended or as mentioned in this manual or if the recommendations of the battery manufacturer are
neglected. The manufacturer shall not be liable if there has been service or repair carried out by any
unauthorized person, unusual use, wrong installation, or bad system design.
1.3 Safety precautions
After receiving the inverter, please check the product condition first, if there is any damage occurred during
shipping, please contact the transportation company or us in time.。
WARNING: Indicates a potentially dangerous condition. Use extreme
caution when performing this task.
CAUTION:
1) There are no user serviceable parts inside the inverter. Do not
disassemble or attempt to repair the inverter.
2) Keep children away from batteries and the charge inverter.
CAUTION: Indicates a critical procedure for safe and proper operation of
the inverter.
CAUTION: Connect the inverter to the battery is highly recommended; the
minimum capacity (Ah) of the battery should be 5 times of the inverter rated
output power (P), which means Ah=5×(P/V).
CAUTION: The installation of the system must be done by professional
technicians.
CAUTION: Make sure there isn't any electrical arcing danger around the
operation area before installation.
WARNING: This off-grid inverter may be damaged if connected to the utility or
electrical source.
WARNING: Only a single inverter is allowed to operate at a time. Do not connect
multiple inverters in series or parallel. It may cause the inverter damaged.
WARNING: The AC output with high voltage during the inverter operation, do
not touch any connection point, it may cause danger.
WARNING HOT SURFACE: Do not touch the inverter when it's operating, the
inverter case of the inverter will generate a high value of heat, also keep
distance to the material or equipment affected by high temperature.
CAUTION: Do not open the inverter external case or try any operation when
the inverter is on.

WARNING: Do not touch or open the external case!
The inverter is allowed to restart after removing the fault which affects the safety
performance of the inverter.
No maintenance parts are included in the inverter, please contact our customer
service department for required maintenance service.
2, Overview
Thanks for purchasing Epoch series inverters. The product is a pure sine wave inverter which can convert
12V/24Vdc to 220V/230Vac(or110V/120Vac) 50/60Hz based on full digital and intelligent design. It features high
reliability high efficiency, full protection functions, easy installation and operation. The inverter can be applied
in many fields, such as household appliances, electric tools and industrial devices etc, especially for solar
photovoltaic power system.
Complete isolation-type inverter technology.
Adoption of advanced SPWM technology, pure sine wave output.
Dynamic current loop control technology to ensure inverter reliable operation.
Wide DC input voltage range.
Low output harmonic distortion(THD≤2%)
LED indicators for input voltage range, normal output & failure state.
Extensive protections: short-circuit, overload, under/over input voltage, over-temperature, and
inverter's inner fault identification protections.
The output voltage and frequency can be switched.
Optional energy SAV mode(saving mode).
Wide working temperature range (industrial level).
Continuous operation at full power.
2
WARNING: The following operations may cause electric arc, fire or explosion.
When a fault occurs, please ask trained technicians to solve the issue. Any
incorrect operation would cause a serious accident.
Touch the wire end, which hasn't been insulation treated, may cause electric
shock.
Touch the wiring copper row, terminals or internal devices, which may cause
electric shock.
The power cable connection is loose.
Screw or other components inadvertently falls into the inverter.
Incorrect operation by untrained non-professional people.

73.20
123
77
190
173
189
3.50
8
327
383.50
3
3
Unit: mm
3, Dimensions

1000-1000W
1 2 31 2 3
120V 110V
123
4, Structure & Operations
5.Desinations of Models
④ Grounding terminal
⑤ n/Off SwitchO
⑥ LED
⑦ RS232 interface
⑧ ode SwitchM
⑨ C output teminalA
① Heat Sink
② DC input terminal ③ Ventilation fan
RJ11 interface
12 3 4 5 6
GND T×D T×D R×D R×D GND
4.2 RS232
The inverter is equipped with a RS232 port with RJ11 sockets, the RJ11 interface is defined as follows:
4.3 Mode Switch
of the inverter flexibly according to the demand
SAV/NOR: NOR is normal output mode, standby power<8W; SAV is power saving mode,
standby power<5W. When the switch is on "SAV" side, the inverter will enter into the
Saving Mode. It will shut off the output if the output power is less than 20W. Then
restart and detect the power of the load again after 10s. If the load is more than 20W,
the inverter will turn on the output. Otherwise it will shut off output again. It cycles like
this. So please don't use the saving mode if the load is smaller than 20W.
50/60Hz: Output frequency is adjustable.
220/230Vac(or110/120Vac): Output voltage is adjustable.
The output voltage, power and frequency can be modified .
!Ventilation fan: When the temperature of the radiator is greater than 40 ℃, the fan will be turned on;
otherwise, the fan will be turned off.
4.1 Characteristics Structure &
Pin No.
1
2
3
4
5
6
Definition
R×D
R×D
T×D
T×D
GND
GND
EP 1000-22X
Universal AC output socket
Rated output voltage：1-110/120Vac
2-220/230Vac
Rated input voltage： 1-12Vdc
2-24Vdc
4-48Vdc
Rated output power: 600-600W
Epoch Series
4

6, Installation
CAUTION: Please read the manual carefully to get familiar with the installation steps
before installation.
6.1 Installation Notes
③
②
①Be very careful when installing the batteries, especially flooded lead-acid batteries. Please wear eye
protection, and have fresh water available to rinse if any contact with battery acid.
Keep the battery away from any metal objects, which may cause a short circuit of the battery.
Loose connections and corroded wires may result in high heat that can melt wire insulation, burn
surrounding materials, or even cause a fire. Ensure tight connections and use cable clamps to secure cables
and prevent them from swaying in motion.
④Select the system connection cables according to the current density no higher than 3.5A/mm2.
⑤For outdoor installation, keep out of the direct sunshine and rain infiltration.
⑥Please do not install the inverter in humid, greasy, flammable, explosive, dust accumulative, or other
severe environments.
⑦AC output is a high voltage, and please do not touch the wiring connection.
⑧When the fan is working, and please do not touch it to avoid injury.
CAUTION: To avoid the danger of heat accumulation caused by the loose
connection, please ensure all the cable connections are tight.
WARNING: Make sure the inverter is clean and no electrical connection before
installation.
CAUTION: Please connect the inverter case to the ground and ensure the
sectional area of the connection cable is not less than 4mm²。
CAUTION: Follow the parameter setting requirements to set the DC input
voltage, higher or lower may cause the inverter down or even broken.
CAUTION: The cable between battery and inverter should be less than 3meters,
otherwise, please reduce the current density.
CAUTION: A fuse or breaker is recommended between battery and inverter,
also the rated current of the fuse or breaker should be 1.25*Rated current of battery.
CAUTION: Keep the inverter away from the flooded lead-acid battery because
the sparkle of the terminals may ignite the hydrogen released by the battery.
WARNING：Do not directly connect the battery charger or similar devices to
the input terminal of the inverter.
WARNING: Only the load is allowed to connect to the AC output terminal, do
not connect it to power supply or utility, which may cause the inverter
damaged, also please shut off the inverter before wiring.
5

6.2 Mounting Location Requirements
Do not subject the inverter to direct sunlight or any other heat sources. Protect the inverter from any dust,
dirt and moisture. Mount it flat to a vertical wall. Must be a non-flammable material. Maintain a minimum
clearance of 15 cm below and around the inverter to ensure unhindered air circulation.
>15CM
>15CM
>15CM
Cool air
Hot air
6.3
Never touch uninsulated cables (ends), only use electric insulated tools, and make
sure that the wires are suitable.
Wiring Specifications
We strongly recommend connecting a fuse directly to the battery terminal to protect from any short circuit
in the battery circuit.
⑤
③
CAUTION: The inverter shall
be cooling through case if
installed in a closed box.
①
②④
CAUTION: 1.The switch of the inverter is OFF before wiring.
2.Do not close the circuit breaker or fuse and make sure that the leads of “+” and“-”
poles are correctly connected while wiring the inverter.
WARNING：The AC equipment shall be determined by the continuous output power of the
inverter, but the surge power must be lower than the instantaneous surge power of the inverter.
CAUTION: A fuse which current is 12.5*Select the maximum battery current, it must be installed
on the battery side with a distance from the battery not greater than 150mm.
6
Please confirm that the inverter is off before wiring.
Switch on the input breaker or the fuse between inverter and battery;
3) Turn on the power switch to start the inverter, Green indicator on solid, and the AC output is normal;
4) Turn on the load one by one, and check the operation status of both inverter and load;
5) If the fault indicator is red and the buzzer alarms when turn on the inverter, please switch off the loads
and inverter immediately. Refer to 8.2 Troubleshooting. After troubleshooting, please follow the above steps
and operate again.
1st step: Grounding: Connect the ground terminal of the inverter to the ground
2nd step: Loads: Connect the load to the inverter output (universal socket).
3rd step: Battery
Connect the battery cables observing the correct polarity to the input terminal of the Inverter(make sure
you identify the battery marking/symbol on the inverter casing!) . Pay greatest attention to polarity. Never,
ever invert the plus+ and minus- poles).
4th step: Power on the inverter
1) Tighten all cables connected to the inverter and remove all the remains around the inverter (leaving a
void of minimum 15 cm);
2)

12≤Vbat＜14.5V(@12V) ,
7, LED
Led Status Function
Battery LED
(Tri-color)
7
Inverter is about to be protected under heavy load
Over load, Short-circuit, No output in SAV mode
Flash(0.25s/0.25s)
On
Fault LED
(Red)
Red: On Vbat＜12(@12V), Vbat＜22V(@24V)
22≤Vbat 23V(@24V)
＜
14.5≤Vbat＜15.5(@12V), 23≤Vbat＜31V(@24V)
Green: On
Yellow: On
Over temperature protection(OTP)
Red: Flash()1s/1s
Low voltage protection(LVD)
Red: lash(0.25s/0.25s)F
Over voltage protection(OVP)
Red: Flash()3s/3s
LVD+OTP
Red: Flash()4s/4s
OVP+OTP
Red: Flash(6s/6s)
Working normally
Output LED
(Green) Working abnormally
Hardware Protection
On
Off
Ring
Buzzer
8, Troubleshooting, Protections and maintenance
Input reverse polarity protection
It is recommended that the battery be connected in series with fuse(60A) prevent the internal
components of inverter from being damaged.
Over voltage protection
When the input voltage exceeds 16/31V, the inverter will stop charging to protect the battery from
overcharging damage. When the voltage is reduced to 14.5/29V, it will resume normal operation.
Low voltage protection
When the input voltage is lower than 10.8/21V, the inverter will stop discharging to protect the battery from
over discharging damage. When the voltage rises above 12.5/25V, it resumes working.
Load Short circuit Protection
Once the load short circuit happens, the load short circuit protection will trigger automatically. (When
the overload protection happens, the AC output will recover automatically for 3 times(recover after 5s).
After then the AC output will not recover automatically after 3 times attempt until restarting the
inverter.)
Overload protection
Once the output power is higher than rated power, the over load protection will trigger automatically.
(When the overload protection happens, the AC output will recover automatically for 3 times(recover
after 5s). After then the AC output will not recover automatically after 3 times attempt until restarting
the inverter.)
Over Temperature Protection
The inverter detects the internal temperature through internal sensor, when the temperature exceeds
95℃, it will stop working and resume after temperature returns to 70℃.
8.1 Protection
!When the overload protection happens 4 times, the AC output do not have the recover
automatically function.

WARNING: Do not try to repair or maintain the inverter by own, and it may
cause danger.
Battery LED is red, and
flash(0.25S/0.25S)
Battery LED is red, and
flash(3S/3S)
Battery LED is red, and
flash(1S/1S)
Fault LED flash
(0.25S/0.25S)
Fault LED is on
Faults
Low DC
input voltage
High DC
input voltage
Over temperature
Inverter is about to
be protected under
heavy load
Short circuit and
over current in
loading
Reason
Measure the DC input voltage if the voltage is lower than
10.8/21V. Adjust the input voltage to recover normally.
Measure the DC input voltage if the voltage is lower than
16/31V. Adjust the input voltage to recover normally.
Improve ventilation quality, do not block the vent, reduce
the temperature around the power supply, restart the
device after the temperature reaches 70℃, if still not
working, please derate the power for use.
Check if the load exceeds the rated output power of the
inverter.
Check that if the output is overloaded, if the output line is
shorted, or if the dial switch is SAV mode. Clear the fault
and restart the inverter to resume normal operation.
Troubleshooting
8.2 Troubleshooting
8.3 Maintenance
Output LED is off Inverter is abnormal Check input and output
8
For best system performance, the following inspections and maintenance tasks are recommended to be
carried out for at least two times a year.
Make sure no block on air-flow around the inverter. Clear up any dirt and fragments on radiator.
Check all the naked wires to make sure insulation is not damaged. Repair or replace some wires if
necessary.
Check and confirm that LED is consistent with required. Pay attention to any troubleshooting or error
indication. Take corrective action if necessary.
Make sure all system components are effectively and tightly connected to ground.
Check all terminals for any corrosion signs, damaged insulation, increased temperature or
carbonization/discolored signs.
Check for any dirt and any corrosion signs. Implement corrections actions as early as possible.
WARNING：Risk of electric shock!
Make sure that all the power has been turned off and standing still for 20
minutes before above operations, and then follow the corresponding inspections
and operations.

≤0.9A@12Vdc
EP600-12X
12V
10.8~15.5Vdc
600W
750~900W
＞1200W
＜1350W
＞92.5%
≥93%
2.9Kg
Nothing
9
Item
Electrical Parameters
Input rated voltage
Input voltage range
No load current
Output voltage
Continuous power
Power 60sec
Power 1.5sec
Surge Power
Output Mode
Output wave
Frequency
Diatortion THD
*1
Efficiency at full load
*2
Max. efficiency
SAV mode
DC current
Shutdown status
Fuse
Environment Parameters
Dimension
Hole Size
Weight
Working temperature
Storage temperature
Humidity
Altitude
Other Parameters
Insulation
Dielectric strenth
Application
EP1000-21X
24V
21~30.5Vdc
≤0.5A@24Vdc
110/120Vac 220/230Vac
1000W
1100~1300W
>1300W
<2000W
Single-phase electricity
Pure sine wave
50/60Hz
THD≤2%(Resisitive load)
>92%
≥93% ≥94%
0.2A; The load is detected every 10sec, if the output
power is greaterthan 20W, it will output continuously
50A
＜1mA
90A
383*189*73mm
φ7mm
3.1Kg
-20℃~+50℃
-35℃~+70℃
＜95%(N.C.)
＜5000m（Derating to operate accoding to IEC62040 at a height
exceeding 1000m）
Between AC output/DC input terminals and metal case: ≥550MΩ
Between AC output/DC input terminals and metal case:
Test voltage AC1500V, 1min
Household appliances, cars, solar system and so on
EP1000-22X
9, Technical Data
*1.Ressistive at full load is continuous output power when the DC input is the rated voltage(@25℃);
*2.The efficiency is referred to the max. power when connected with different load under the rated DC input
voltage.
*3.Select appropriate inverters according to voltage standards of different countries
Power 10sec 900~1200W
/
